Sony TMS Installation guide

Integrator Training
Digital Cinema Deployment
TMS Hardware Integrator Installation
Training Manual (CHIPS)
October 15

Integrator Training, UK
Confidential Digital Cinema Deployment 2 of 49
October 15
CHIPS Stand-Alone Integrator Installation Training (CHIPS)
Document History
The following table details the revision history for this document.
Date Description of Changes Author Issue /
Version
06/12/2010 Original Chris Mullins 1.0
24/10/2011 Revised Chris Mullins 2.0
07/02/2012 Revised Chris Mullins 4.0
10/02/2012 Revised Chris Mullins 5.0
05/04/2012 Revised – Drawings / Section 11.1 / minor changes Chris Mullins 6.0
13/07/2012 Revised – For new Server Image Andrew Buckland 7.0
23/07/2012 Revision Andrew Buckland 8.0
28/01/2013 Updated and edited Andrew Buckland 8.2
01/09/2015 Updated and edited Chris Mullins 8.4
Confidentiality
This document and any attachments have been prepared by Sony Professional Solutions Europe for the sole use
of integrator being trained. The contents are confidential and must not be communicated in whole or part to any
other party without the prior written approval of Sony.
© 2010 Sony Professional Solutions Europe. All rights reserved.

Integrator Training, UK
Confidential Digital Cinema Deployment 3 of 49
October 15
CHIPS Stand-Alone Integrator Installation Training (CHIPS)
Contents
TMS HARDWARE INTEGRATOR INSTALLATION TRAINING (CHIPS) 1
1SCHEMATICS 5
1.1CHIPS Rack Layout Description 5
1.1.1Rear connections of TMS Server 6
1.2Rack Layout Schematic 7
1.3Network Schematic 8
1.4Power and Control Schematic 9
2CHIPS POWER UP PROCEDURE 10
2.1IPMI Settings 11
3CHIPS POWER DOWN PROCEDURE 13
4USERNAMES AND PASSWORDS 14
5STANDARD IP ADDRESS SCHEMA 15
6CHIPS INITIAL CONFIGURATION 16
6.1TMS Server Configuration 16
6.1.1Basic OS Options 16
6.1.2Windows Activation 16
6.1.3Administrator Account Password 17
6.1.4TMS Server Network Settings 18
6.2Switch Configuration 21
6.3UPS Configuration 27
6.4Setting up the Library 28
6.5TMS Licensing 28
7TMS SOFTWARE CONFIGURATION 30
7.1Start/Restart TMS Service (if required) 30
7.1.1View TMS GUI on Web browser 30
7.2Log in Details 30
7.3Create an Auditorium 31
7.3.1Specific Settings for Doremi Servers 31
7.4Edit Cue Template Settings 32
8OTHER USEFUL TMS SETTINGS 34
8.1Configuration – Library Settings 34
8.1.1Ingest Settings 34
8.1.2Library Path 35
8.1.3External Device Path 36
8.2Configuration - SPL/Pack Settings 36
8.2.1Add Additional Pack Types 36
8.3Configuration - Schedule Settings 36
8.3.1Schedule Import 36

Integrator Training, UK
Confidential Digital Cinema Deployment 4 of 49
October 15
CHIPS Stand-Alone Integrator Installation Training (CHIPS)
8.4CineWatch Device Monitor Site Name Settings 37
8.5TMS Server Desktop Shortcuts 38
8.6Paragon ExtFS driver 39
8.6.1All NTP addresses 39
9PLEASE SET THE WINDOWS TIME SERVICE IS SET TO AUTOMATIC (DELAYED START).FINAL
TMS SERVER CONFIGURATION 39
9.1TMS Server Windows Login 40
9.2TMS Service is Running 40
9.3Windows Time Service is Running 40
9.4Firewall Settings 40
10SONY PROJECTOR PREPARATION FOR TMS 41
10.1Screen to Screen (S2S) Network Setup 41
10.2Screen to Screen Source Setup 41
10.3NTP Setup 41
10.4Network Setup 42
10.5SMSManager_custom.ini file change 42
11SMS-C CONFIGURATION 43
11.1Initial Login configuration 43
11.2SMS-C Folder setting on SMS-C 45
11.2.1SMS-C ‘Export’ Folder Settings 45
12TMS CLIENT WORKSTATION CONFIGURATION 46
12.1Hardware Setup 46
12.2General Setup 46
12.2.1Initial Windows Configuration 46
12.2.2Firewall Settings 46
12.2.3Software Prerequisites 47
12.3Network Setup 47
12.4NTP Client Setup 47
12.5SMSC Installation 47
12.5.1Initial Login configuration 47
12.6Create Shortcuts 48
13HARDWARE TEST PROCEDURES 48

Integrator Training, UK
Confidential Digital Cinema Deployment 5 of 49
October 15
CHIPS Stand-Alone Integrator Installation Training (CHIPS)
1 Schematics
Populate the pre-wired CHIPS rack using the following schematics.
1.1 CHIPS Rack Layout Description
UPS - Uninterruptable Power Supply that will power the CHIPS system in the event of
a power cut. The UPS will do a clean shutdown of the system when the battery level
goes below a determined level.
TMS SERVER - The TMS server is where the Theatre Management System (TMS)
software is installed. All ingests of DCPs go through the TMS server either through
USB, eSATA or network interfaces. The CineWatch application is also installed which
provides a system monitoring service over SNMP. It also provides an increased level
of support as Sony can monitor and access the system remotely (if VPN link is
available). Upgrades of the projector firmware/software can be done remotely using
CineWatch

Integrator Training, UK
Confidential Digital Cinema Deployment 6 of 49
October 15
CHIPS Stand-Alone Integrator Installation Training (CHIPS)
LIBRARY STORAGE - This is included in on board the TMS Server. The Library
Storage contains 8 x 2TB disks formatted to NTFS in a raid 6 configuration leaving
12TB useable space on the disk. Assuming a DCP feature size of 250GB this will
give storage for approximately 60 feature films (200GB DCP).
DCP HDD POWER AND USB DISTRIBUTION - A mains distribution panel is
provided so that a DCP HDD can be powered at the front of the rack. 4x USB ports
are available on the front of the TMS Application Server. Also KDM’s can be ingested
by USB memory stick.
CRU DATAPORT (High Speed Ingest) - The CRU Dataport provides increased
ingest speed through an eSATA interface to the Application Server. 2 x CRU DCP
HDD can be inserted, powered automatically and then ingested using the TMS Client.
KVM MONITOR/KEYBOARD DRAWER - The KVM monitor and keyboard is used for
configuration and maintenance of the system and can access both the Application
Server and the CineWatch Server. The KVM monitor is usually kept closed and not
used for daily use.
48 PORT Gb NETWORK SWITCH - The Gigabit switch is configured with a 4 x 1Gb
trunk to the Application Server for throughput and a single Gb link to each projector,
TMS Client and customer network.
TMS WORKSTATION - The TMS client PC is a standard PC which is not required to
be high performance. From this PC the TMS graphical user interface is accessed
through Windows Internet Explorer (or FireFox). The TMS Client is usually located in
the projection box and is the main point of interaction with the system. Scheduling,
Content Management, Status Monitoring and Show Management can be performed
at this terminal. A system can have multiple TMS Clients.
1.1.1 Rear connections of TMS Server
Figure 1 - Rear connections of TMS Server
Please note that the 4 network cables that form the 4Gb TMS trunk to the network
switch are all connected to the Network PCI card not the on board nics.

Integrator Training, UK
Confidential Digital Cinema Deployment 7 of 49
October 15
CHIPS Stand-Alone Integrator Installation Training (CHIPS)
1.2 Rack Layout Schematic

Integrator Training, UK
Confidential Digital Cinema Deployment 8 of 49
October 15
CHIPS Stand-Alone Integrator Installation Training (CHIPS)
1.3 Network Schematic

Integrator Training, UK
Confidential Digital Cinema Deployment 9 of 49
October 15
CHIPS Stand-Alone Integrator Installation Training (CHIPS)
1.4 Power and Control Schematic

Integrator Training, UK
Confidential Digital Cinema Deployment 10 of 49
October 15
CHIPS Stand-Alone Integrator Installation Training (CHIPS)
2 CHIPS Power Up Procedure
Before performing the power up procedure please confirm that all wiring is cabled as
per the network and control schematics
Connect power cable from the UPS to the mains power supply
The UPS cable has two connectors, a C19 16A rectangle connector that connects to
the UPS, and a European plug adapter that connects to the house power supply.
Since the rack only has two servers the standard house power supply will be
sufficient to power the equipment.
Turn on the UPS
Hold the ‘ON’ button on the UPS for 3 seconds to protect the load
Turn on the Supermicro TMS Server
Press the power switch on the front of the server.
UPS Cable
esc
ON Button
FRONT
UPS
House
Power
Supply
ON Button

Integrator Training, UK
Confidential Digital Cinema Deployment 11 of 49
October 15
CHIPS Stand-Alone Integrator Installation Training (CHIPS)
2.1 IPMI Settings
Make sure IPMI network cable is connected prior powering on the Server
Press “DEL” to enter the BIOS SETUP.
In this menu, Navigate to Advanced and IPMI

Integrator Training, UK
Confidential Digital Cinema Deployment 12 of 49
October 15
CHIPS Stand-Alone Integrator Installation Training (CHIPS)
Use the IP schema for IPMI LAN IP address details
Enter the Subnet MASK as 255.255.255.0
Enter the Gateway as the Site Gateway in the IP Schema (10.XX.13.4)
Save and exit
Server will restart
Log on the TMS Server
Please see Usernames and Passwords section

Integrator Training, UK
Confidential Digital Cinema Deployment 13 of 49
October 15
CHIPS Stand-Alone Integrator Installation Training (CHIPS)
3 CHIPS Power Down Procedure
Shutdown the TMS Server using the OS
Using the KVM Drawer shut down the TMS Server.
Turn off the UPS
Hold the ‘ON’ button on the UPS for 3 seconds to unprotect the load
Disconnect the power cables from the mains supply
Remove the UPS power cable from the wall socket (if required).
Press
Shutdown
esc
ON Button
FRONT

Integrator Training, UK
Confidential Digital Cinema Deployment 14 of 49
October 15
CHIPS Stand-Alone Integrator Installation Training (CHIPS)
4 Usernames and Passwords
The following usernames and passwords are the typical ones implemented in a
CHIPS rack build. Please confirm on a project by project basis.
CHIPS Server Windows Login Credentials
USERNAME PASSWORD NOTES USED BY
Administrator S0nytms01 Administrator Rights Sony/Dealer/Exhibitor
TMS Software Login Credentials
USERNAME PASSWORD NOTES USED BY
tmsadmin cinemasystem
Administrator Rights
(Changed in v1.63.1) Sony/Dealer
CineWatch Software (Device Monitor) Login Credentials
USERNAME PASSWORD NOTES USED BY
admin admin Administrator Rights Sony/Dealer
TMS Client Workstation Windows Login Credentials
USERNAME PASSWORD NOTES USED BY
Administrator S0nytms01 Administrator Rights Sony
tmsuser Password01 Standard User Rights Sony and
Customer

Integrator Training, UK
Confidential Digital Cinema Deployment 15 of 49
October 15
CHIPS Stand-Alone Integrator Installation Training (CHIPS)
5 Standard IP Address Schema
Please see the document, Local IP Schema supplied with this Integrator Installation
Training manual.
CHIPS System IP Addresses Default
Network Interface 192.168.101.0/24
CHIPS Switch Management 192.168.101.1
Default Gateway 192.168.101.254
TMS Server 192.168.101.5
TMS Client PC 192.168.101.8
UPS 192.168.101.9
Satellite Receiver (Optional) 192.168.101.10
Projector TMS 1 (Ctrl IN Port) 192.168.101.11
Projector TMS 2 (Ctrl IN Port) 192.168.101.12
Projector TMS 3 (Ctrl IN Port) 192.168.101.13
Projector TMS 4 (Ctrl IN Port) 192.168.101.14
Projector TMS 5 (Ctrl IN Port) 192.168.101.15
Projector TMS 6 (Ctrl IN Port) 192.168.101.16
Projector TMS 7 (Ctrl IN Port) 192.168.101.17
Projector TMS 8 (Ctrl IN Port) 192.168.101.18
Projector TMS 9 (Ctrl IN Port) 192.168.101.19
Projector TMS 10 (Ctrl IN Port) 192.168.101.20
Projector S2S 1 (Data IN Port) 192.168.101.51
Projector S2S 2 (Data IN Port) 192.168.101.52
Projector S2S 3 (Data IN Port) 192.168.101.53
Projector S2S 4 (Data IN Port) 192.168.101.54
Projector S2S 5 (Data IN Port) 192.168.101.55
Projector S2S 6 (Data IN Port) 192.168.101.56
Projector S2S 7 (Data IN Port) 192.168.101.57
Projector S2S 8 (Data IN Port) 192.168.101.58
Projector S2S 9 (Data IN Port) 192.168.101.59
Projector S2S 10 (Data IN Port) 192.168.101.60
TMS IMPI PORT 192.168.101.222

Integrator Training, UK
Confidential Digital Cinema Deployment 16 of 49
October 15
CHIPS Stand-Alone Integrator Installation Training (CHIPS)
6 CHIPS Initial Configuration
The CHIPS system needs to be configured before you proceed. The TMS server has
a standard Sony TMS image on it which covers the core software installation however
there a number of tasks that need to be completed to make the system operational.
Please make sure all cabling is completed before following the next steps.
6.1 TMS Server Configuration
6.1.1 Basic OS Options
When the TMS server is powered on for the first time you will be greeted with the
standard Windows options for configuring the Operating system.
Enter Region Select your local region
Enter time/currency Select your local time/currency
Keyboard Select UK
The Keyboard should be selected as UK because the KVM keyboard is UK. The
keyboard setting for your region can be selected once in Windows.
6.1.2 Windows Activation
Windows will ask for the activation key for TMS Server. Please use the telephone
option during activation to obtain the License key as the internet will not be connected
during the installation.
Enter the Virtual Key (Bottom Key) and then select Telephone system
Product key format: AAAAA-BBBBB-CCCCC-DDDDD-EEEEEE

Integrator Training, UK
Confidential Digital Cinema Deployment 17 of 49
October 15
CHIPS Stand-Alone Integrator Installation Training (CHIPS)
6.1.3 Administrator Account Password
Once the server has restarted there should be the following users available.
Administrator - Administrator and Support Account
DCP Delivery - FTP account used for DCP Delivery
POSUSER - Point of Sale User (May not be required)
PRESHOW - Preshow User (May not be required)
Click on Administrator and when prompted for a password enter the following
password:
Administrator PW: S0nytms01
This password must be used otherwise the TMS service that provides the TMS GUI
will not start!
Number 0

Integrator Training, UK
Confidential Digital Cinema Deployment 18 of 49
October 15
CHIPS Stand-Alone Integrator Installation Training (CHIPS)
6.1.4 TMS Server Network Settings
The next steps show how to configure the four network ports to form and TMS team.
Remove the current network settings on the onboard NICs
Go to Start Menu > Control Panel > Network and Sharing Centre
Click on Change Adapter Settings to see the NICs on the TMS server
Right Click on Local Area Connection 7 > Properties
Click on Configure > Settings
Remove Team
Yes, Ok
To configure the TMS Network Team
Right Click on Local Area Connection 8 > Properties
Click on Configure > Teaming Tab
Click on “Team this adapter...” then click on “New Team”

Integrator Training, UK
Confidential Digital Cinema Deployment 19 of 49
October 15
CHIPS Stand-Alone Integrator Installation Training (CHIPS)
Name the team: TMS Team
Click Next, then Select Network Connections 7, 8, 9, 10
Click Next, then Select IEEE 802.3ad Dynamic Link Aggregation
Click Next, Finish, Ok.
Configure the TMS Team IP Address
On the Adapter Settings page select Local Area Connection 7 (TMS Team)
Right Click > Properties > Select Internet Protocol Version 4 > Properties

Integrator Training, UK
Confidential Digital Cinema Deployment 20 of 49
October 15
CHIPS Stand-Alone Integrator Installation Training (CHIPS)
Use the following IP information from the Local IP Schema document
supplied:
oIP Address (CHIPS TMS Server IP) – 192.168.101.5
o(Subnet Mask) 255.255.255.0
oDefault Gateway (SITE Gateway IP) – 192.168.101.254
Where XX = Site Code/IP
TMS Network Configuration Complete
10.XX.13.202
10.XX.13.4
