Sony VSR-2000A User manual

MULTI ACCESS VIDEO AND AUDIO SERVER
VSR-2000A
SDI MPEG ENCODER BOARD
ANALOG MPEG DECODER BOARD
BKSR-2031
BKSR-2020
INSTALLATION MANUAL
1st Edition
UPGRADE KIT
BKSR-U2000

VSR-2000A
!WARNING
This manual is intended for qualified service personnel only.
To reduce the risk of electric shock, fire or injury, do not perform any servicing other than that
contained in the operating instructions unless you are qualified to do so. Refer all servicing to
qualified service personnel.
!WARNUNG
Die Anleitung ist nur für qualifiziertes Fachpersonal bestimmt.
Alle Wartungsarbeiten dürfen nur von qualifiziertem Fachpersonal ausgeführt werden. Um die
Gefahr eines elektrischen Schlages, Feuergefahr und Verletzungen zu vermeiden, sind bei
Wartungsarbeiten strikt die Angaben in der Anleitung zu befolgen. Andere als die angegeben
Wartungsarbeiten dürfen nur von Personen ausgeführt werden, die eine spezielle Befähigung
dazu besitzen.
!AVERTISSEMENT
Ce manual est destiné uniquement aux personnes compétentes en charge de l’entretien. Afin
de réduire les risques de décharge électrique, d’incendie ou de blessure n’effectuer que les
réparations indiquées dans le mode d’emploi à moins d’être qualifié pour en effectuer d’autres.
Pour toute réparation faire appel à une personne compétente uniquement.
VSR-2000A (SY) Serial No.10001 and Higher
BKSR-2020 (SY) Serial No.10001 and Higher
BKSR-2031 (SY) Serial No.10001 and Higher
BKSR-U2000 (SY) Serial No.10001 and Higher
Attention-when the product is installed in Rack:
1. Prevention against overloading of branch circuit
When this product is installed in a rack and is
supplied power from an outlet on the rack, please
make sure that the rack does not overload the
supply circuit.
2. Providing protective earth
When this product is installed in a rack and is
supplied power from an outlet on the rack, please
confirm that the outlet is provided with a suitable
protective earth connection.
3. Internal air ambient temperature of the rack
When this product is installed in a rack, please
make sure that the internal air ambient temperature
of the rack is within the specified limit of this
product.
4. Prevention against achieving hazardous
condition due to uneven mechanical loading
When this product is installed in a rack, please
make sure that the rack does not achieve
hazardous condition due to uneven mechanical
loading.
5. Install the equipment while taking the operating
temperature of the equipment into
consideration
For the operating temperature of the equipment,
refer to the specifications of the Operation Manual.
6. When performing the installation, keep the rear
of the unit 10 cm (4 inches) or more away from
walls in order to obtain proper exhaust and
radiation of heat.
When using a LAN cable:
For safety, do not connect to the connector for
peripheral device wiring that might have excessive
voltage.

1 (E)
VSR-2000A
Table of Contents
Manual Structure
Purpose of this manual ........................................................................................ 3 (E)
Related manuals................................................................................................... 3 (E)
Contents ............................................................................................................... 3 (E)
Trademarks .......................................................................................................... 3 (E)
1. Installation
1-1. Cautions before Installation .................................................................. 1-1 (E)
1-2. Installation Procedure ............................................................................ 1-2 (E)
1-3. Operating Conditions and Installation Space ........................................ 1-2 (E)
1-3-1. Operating Conditions ........................................................... 1-2 (E)
1-3-2. Installation Space ................................................................. 1-3 (E)
1-4. Power Supply ........................................................................................ 1-4 (E)
1-4-1. Information for Power Supply .............................................1-4 (E)
1-4-2. Power Cord ........................................................................... 1-4 (E)
1-5. Installing Optional Boards .................................................................... 1-5 (E)
1-5-1. Installing BKSR-2020 .......................................................... 1-6 (E)
1-5-2. Installing BKSR-2031 .......................................................... 1-7 (E)
1-6. Rack Mounting ...................................................................................... 1-8 (E)
1-7. Front Panel Assembly Installation/Removal ....................................... 1-10 (E)
1-8. HDD Unit Installation .........................................................................1-11 (E)
1-9. Signal Input and Output ...................................................................... 1-12 (E)
1-10. Connecting Connectors and Cable ...................................................... 1-14 (E)
1-11. Example of System Connection .......................................................... 1-15 (E)
1-11-1. SD System Connection ...................................................... 1-15 (E)
1-11-2. HD (1080/59.94i) System Connection ............................... 1-16 (E)
1-12. Switch Setting of the Connector Panel................................................ 1-17 (E)
1-13. HDD Physical Format and Logical Format ........................................1-17 (E)
1-14. Video System Adjustment................................................................... 1-18 (E)
1-14-1. 525/60 (NTSC) System ......................................................1-19 (E)
1-14-2. 625/50 (PAL) System ......................................................... 1-22 (E)
1-14-3. System Phase Adjustment ..................................................1-24 (E)
1-14-4. Subcarrier Phase Adjustment ............................................. 1-25 (E)

2 (E) VSR-2000A
2. Service Overview
2-1. Circuit Protection Device ......................................................................2-1 (E)
2-2. Filter Cleaning ....................................................................................... 2-1 (E)
2-3. Fan Motor Replacement ........................................................................2-2 (E)
2-4. Replacing the Power Supply Unit .........................................................2-3 (E)
2-5. Replacing the HDD Unit .......................................................................2-4 (E)
2-6. Function of Switches/LEDs on Board ................................................... 2-6 (E)
2-6-1. CCM-38A Board .................................................................. 2-6 (E)
2-6-2. DEC-117 Board (BKSR-2031) ............................................ 2-9 (E)
2-6-3. ENC-58 Board (BKSR-2020) ............................................ 2-10 (E)
2-6-4. LE-224 Board ..................................................................... 2-11 (E)
2-6-5. LE-225 Board ..................................................................... 2-12 (E)
2-6-6. SPG-15 Board ....................................................................2-13 (E)
2-6-7. SY-302 Board ..................................................................... 2-14 (E)
2-6-8. PU-122 Board ..................................................................... 2-16 (E)
3. Upgrading

3 (E)
VSR-2000A
Manual Structure
Purpose of this manual
This manual is the installation manual of the VSR-2000A Multi Access Video and
Audio Server and Optional Board.
This manual is intended for use by trained system and service engineers, and
describes the information regarding installation. It also describes the information
regarding the following optional boards, and so on.
.SDI MPEG Encoder BKSR-2020
.Analog MPEG Decoder Board BKSR-2031
.Upgrade Kit BKSR-U2000
Related manuals
Besides this Installation Manual, the following manuals are available for the VSR-
2000A.
.VSR-2000A Operation Manual (Supplied with VSR-2000A)
This manual describes the precautions of VSR-2000 and description of each block.
.VSR-2000/2000A/BKSR-2020/2021/2025/2030/2031/2035/2070/2090/U2000
Service Manual (Available on request)
This manual describes the information that premise the service based on parts
replacement (Version upgrading, diagnostics function, parts replacement, electri-
cal adjustment, circuit outline, parts list, block diagrams).
If this manual is required, please contact your local Sony Sales Office/Service
Center.
Contents
The following is a summary of all the section for understanding the contents of this
manual.
Section 1 Installation
This section describes the procedure for rack mounting, and the connector and cable
information for peripheral equipment connections, how to format the HDD, the
electrical alignment, etc.
Section 2 Service Overview
This section describes the replacement of HDD unit and fan motor unit, function of
the switches and LEDs on the board.
Section 3 Upgrading
This section describes the upgrading procedure from VSR-2000 to VSR-2000A
using the upgrade kit BKSR-U2000.
Trademarks
Trademarks and registered trademarks used in this manual are follows.
.Ethernet is a registered trademark of Xerox Corporation.
.Windows/WindowsXP is a registered trademark of Microsoft Corporation.
.IBM is a registered trademark of International Business Machines Corporation.
.Pentium is a registered trademark of Intel Corporation.

1-1 (E)
VSR-2000A
1-1. Cautions before Installation
The Hard Disk Drives (HDD) are installed in this unit. The HDD is a precision part. The causes such as
shock, vibration and static electricity to the unit, and the conditions of temperature and humidity may
damage HDD or its data.
Before installation, read fully the following cautions, and perform the installation with extra care.
Cautions about Shock and Vibration
When transporting and moving;
.Pack the unit using the packaging materials specified by the manufacturer.
(When transporting the unit, pack the HDDs separately.)
.Use a proper cart.
.Put a cushion* on the cart.
.Avoid rough routes, and manage the cart gently.
When placing on a floor or table;
.Put a cushion* on stable and horizontal place, and put the unit on it gently.
.Do not place the unit near vibrating equipments.
For the unit;
.Never hit the unit by tool, and drop the tool on the unit.
Take extra care;
.Never give vibration or shock to the unit while the power is turned on, or within about 30 seconds after
turning off the power.
.Be extremely careful when removing and/or installing the HDD unit, fan motor unit or power supply
unit while the unit is in live state.
*Cushion : Polyethylene foam (density: 38 kg/m3, surface intrinsic resistance : 1011 to 1012 Z, thickness: 50 mm) or equivalent.
Cautions about Rack Mounting the Unit
. Mount the unit into the rack with the HDD removed from the unit, because do not give shock to the HDD.
.Be sure to turn off the power of the rack mounted unit which has a live HDD.
Caution about Static Electricity
. Keep static-producing items such as plastics (air cap, packing material, etc.) away from the working area.
Cautions about Temperature and Humidity
.Temperature and humidity of storage and operating condition must be kept within the correct specified
range.
.Never turn on the power with the cabinet is removed in consideration of the air-cooling effect.
Cautions when an Error Appears in a HDD
.Treat this unit conform to the above cautions, even when an error appeared.
.Keep the unit in the condition in which the error appeared, and record the details of the error.
Section 1
Installation

1-2 (E) VSR-2000A
1-2. Installation Procedure
n
Keep the packing materials such as carton, cushion, etc.
after unpacking.
When transporting the unit, pack the unit using the materi-
als provided. Pack the HDDs separately.
1-3. Operating Conditions and
Installation Space
1-3-1. Operating Conditions
1. Set the operating temperature and humidity
within the following conditions.
Operating Temperature : +5 dC to +40 dC
Operating humidity : 10 % to 90 %
(Condensation not allowed)
Storage temperature : _20 dC to +60 dC
2. Do not install this unit in the following
locations.
.Areas where the unit will be exposed to direct
sunlight or any other strong lights.
.Dusty areas or areas where the unit will be subject to
vibration.
.Areas with strong electric or magnetic fields.
.Areas near heat sources.
.Areas where the unit will be subjected to electrical
noise.
.Areas where the unit will be subjected to static
electricity noise.
.Unstable and unbalanced places.
3. To prevent the internal temperature from
rising, ensure air ventilation of the place
where the unit is installed.
The ventilating slots should be 20 cm away from the
walls for proper ventilation.
c
Do not block the ventilation slots.
If the ventilation slots are blocked, overheating inside the
unit may cause fire.
1-2. Installation Procedure
1-3. Operating Conditions and Installation Space
Start
Determination of
installtion place
Option boards
installtion
Rack mounting
HDD unit installtion
Connection
System connection
Formatting HDD
Adjustment
End
1-3. Operating Conditions
and Installation Space
1-4. Power Supply
1-5. Installation
Optional Boards
1-6. Rack Mounting
1-8. HDD Unit
Installation
1-9. Signal Input and Output
1-10. Connecting Connectors
and Cable
1-11. System Connection
1-12. Switch Setting of the
Connector Panel
1-13. HDD Physical Format
and Logical Format
1-14. Video System
Adjustment

1-3 (E)
VSR-2000A
1-3-2. Installation Space
m
.The rear side of this unit should be 50 cm away from the walls considering serviceability such as option
board replacement.
.If the power is turned on with the cabinet is removed, the air-cooling effect of the fan will be greatly
reduced, damaging the HDD or its data. Avoid operating the unit with the cabinet is removed.
655
647
633
22
604
620
34
175
316
477.7
583
100.2120.8
419 126
107.2
221 (5U)
424
465
482
37.537.5 146
Unit : mm
1-3. Operating Conditions and Installation Space

1-4 (E) VSR-2000A
1-4. Power Supply
1-4-1. Information for Power Supply
A switching regulator is used for the power supply of this
unit. Voltage within the range of 100 V to 240 V can be
used without changing the supply voltage.
Power supply voltage : AC 100 to 240 V
Power supply frequency : 50/60 Hz
Power consumption : 350 W (continuous rating)
Inrush current : 35 A
1-4-2. Power Cord
w
.Use the specified power cord only
.Otherwise, fire or electric shock may occur.
w
.Do not damage the power cord.
.Otherwise, fire or electric shock may occur.
c
.Ground the unit safety.
.Otherwise, electric shock may occur.
Recommended parts
For customers in U.S.A. and Canada.
1Power cord : !1-557-377-11
2Plug holder (C) : 3-613-640-01 (Supplied)
For customers in the United Kingdom.
1Power cord : !1-782-929-11
2Plug holder (C) : 3-613-640-01 (Supplied)
12AC inlet
(MAV)
12
AC inlet
(MAV)
Safety earth (Green/Yellow)
Live (Brown)
Neutral (Blue)
1-4. Power Supply

1-5 (E)
VSR-2000A
1-5. Installing Optional Boards
1. The following options can be installed to this system.
.BKSH-236G (36GB HDD Unit)
.BKSH-272G (73GB HDD Unit)
.BKSR-2020 (SDI MPEG Encoder Board)
.BKSR-2021 (Analog MPEG Encoder Board)
.BKSR-2030 (SDI MPEG Decoder Board)
.BKSR-2031 (Analog MPEG Decoder Board)
.BKSR-2090 (DVB-ASI Board)
.BKSR-2025 (MPEG HD Encoder Board)
.BKSR-2035 (MPEG HD Decoder Board)
2. To install the encoder boards (BKSR-2020/2021/2025), install the encoder boards starting from slot
No. 1 in order.
.A maximum of three units of the BKSR-2020/2021 can be installed.
.A maximum of one BKSR-2025 can be installed.
3. After installing the encoder boards (BKSR-2020/2021/2025), install the decoder boards (BKSR-
2030/2031/2035) starting from the top slot.
4. Inclusive of the encoder boards (BKSR-2020/2021) and the decoder boards ( BKSR-2030/2031/2035) ,
a maximum of five boards can be installed. (Slot No. 6 cannot be used.)
n
If you have installed the BKSR-2025 already, a maximum of four boards can be installed. (The
BKSR-2025 occupies space of two slots.)
5. If any slot is left un-used, be sure to install the blank panel supplied to the un-used slot. (If blank
panel is not installed, cooling capacity of the fan decreases and the system may not work properly.)
6. For installation of the BKSR-2021/2025/2035/2090, refer to the Installation Manual supplied with
each optional board.
The unit is designed to memorize the configuration of the optional boards when the power is turned on for
the first time after shipment.
To change the configuration of the optional boards, change the setting using the supplied BZSR-2000
Trial version.
(For details, refer to the Operation Manual supplied with the CD-ROM of the BZSR-2000 Trial version.)
n
Before installing each option board, the default setting sometimes needs to be changed depending on the
operating conditions of the system. Change the setting according to the operating conditions while
referring to “2-6. Function of Switches/LEDs on Board” in this manual and “2-1. Description of Internal
Switches and Indicator” in the Installation Manual supplied with each option board.
BKSR-2020
BKSR-2031
Blank panel
Blank panel
Blank panel
Blank panel
1-5. Installing Optional Boards

1-6 (E) VSR-2000A
1-5-1. Installing BKSR-2020
General Information for Installation
.The BKSR-2020 can be attached into slot No. 1, No. 2
and No. 3 of the VSR-2000A.
.To prevent from wrong insertion when the board is
replaced, stick the slot label (supplied with BKSR-2020)
after inserting the board.
.To maintain the cooling effect of the VSR-2000A, do not
leave the slots open.
Be sure to attach the blank panel on the empty slot.
.Adjustments after installation/replacement of board are
not necessary.
Installation Procedure
1. Turn off the main power switch of the VSR-2000A.
2. Remove the two screws of the desired slot, and remove
the blank panel.
n
Keep the removed blank panel.
3. Insert the BKSR-2020 to the slot. Push the handle of
the board in the direction of installing, and insert it in
the mother board completely.
4. Fix the BKSR-2020 with the two screws that are used
to fix the blank panel.
5. Stick the slot label (supplied with the BKSR-2020) of
the inserted slot number.
n
To remove a board, hold the handle of the board and pull it
in the direction of removing and remove the board to the
front.
VSR-2000A (rear side)
No.1 slot
VSR-2000A
BVTT3 x6
BVTT
3 x6
Blank panel
BKSR-2020
Installing
Removing
Handles
BKSR-2020
BVTT
3 x6
Slot label
1-5. Installing Optional Boards

1-7 (E)
VSR-2000A
1-5-2. Installing BKSR-2031
General Information for Installation
.The BKSR-2031 can be attached on the desired slot
except of the No. 6 slot of the VSR-2000A.
.To prevent from wrong insertion when the board is
replaced, stick the slot label (supplied with BKSR-2031)
after inserting the board.
.To maintain the cooling effect of the VSR-2000A, do not
leave the slots open.
Be sure to attach the blank panel on the empty slot.
.Adjustments after installation/replacement of board are
not necessary.
Installation Procedure
1. Turn off the main power switch of the VSR-2000A.
2. Remove the two screws of the desired slot, and remove
the blank panel.
n
Keep the removed blank panel.
VSR-2000A (rear side)
No. 6 slot
VSR-2000A
BVTT3 x6
BVTT
3 x6
Blank panel
3. Insert the BKSR-2031 to the slot. Push the handle of
the board in the direction of installing, and insert it in
the mother board completely.
4. Fix the BKSR-2031 with the two screws that have
been used to fix the blank panel.
5. Stick the slot label (supplied with the BKSR-2031) of
the inserted slot number.
n
To remove a board, hold the handle of the board and pull it
in the direction of removing and remove the board to the
front.
BKSR-2031
BVTT
3 x6
Slot label
1-5. Installing Optional Boards
BKSR-2031
Installing
Removing
Handles

1-8 (E) VSR-2000A
1-6. Rack Mounting
c
Install the unit in a stable location.
If the unit is mounted on a unstable table or slant bench,
the unit can fall and result in physical injury.
c
Use the specified support angle.
If the parts other than the specified one are used, the unit
can fall and results in physical injury.
This unit can be mounted in a 19-inch standard rack of EIA
standard. To mount the unit in the rack use the specified
rack mount kits and parts.
n
Mount the unit in the rack with the HDD removed from the
unit.
Specified rack mount kit : RMM-2000 (option)
Constituent parts
.Outer Support Assembly 2 pcs
Outer Support 2 pcs
Bracket 4 pcs
Screw (B4 x 8) 8 pcs
Inner Support 2 pcs
.Plate Nut 4 pcs
.Screw (B4 x 12) 8 pcs
.Screw (B4 x 8) 10 pcs
The following parts are supplied for rack mounting.
.Rack mounting screw (RK5 x14) 4 pcs
.Rack mounting ornamental washer 4 pcs
n
Standard Tightening Torque
Screw Size Standard Tightening Torque
M3.0 0.7 to 1.0 N.m (7 to 10 kgf.cm)
M4.0 1.2 to 1.6 N.m (12 to 16 kgf.cm)
1. Turn off the power of the rack mounted unit incorpo-
rating the HDD.
2. Remove the four screws at the both sides of the unit,
and remove the four foot-holder assemblies while
lifting up the unit.
3. Attach the two inner supports to the side panels of the
unit.
4. Loosen the four screws of the outer support assembly
to slide the brackets.
B4 x6
Foot-holder
assembly
B4 x8
B4 x8
Inner support
Outer support assembly
Bracket
Bracket B4 x 8
B4 x 8
1-6. Rack Mounting

1-9 (E)
VSR-2000A
5. Secure the outer support assemblies to the rack tempo-
rarily.
6. Tighten all the screws loosened in step 4 and tempo-
rarily secured in step 5.
7. Mount the unit into the rack so that the inner support
angles are on the outer support angles.
c
Be sure to mount the unit with more than the two
persons to avoid back injuries and prevent the unit
from falling.
8. After the unit is mounted in the rack, fix the rack
angles onto the rack with ornamental washers and
screws supplied with the unit.
c
Secure the rack angles to the rack with the screws.
Otherwise the unit may slide and fall off, resulting in
injury.
Bracket
Inner support
Outer support
Rack side Body
RK5 x 14
RK5 x 14
Ornamental
washers
Unit : mm
1-6. Rack Mounting
B4 x12
Plate nut
12.7
The protruded side
must be positioned
on the top.
Bracket
Outer support
Rack side

1-10 (E) VSR-2000A
1-7. Front Panel Assembly Installation/
Removal
n
To remove or to install the front panel assembly while the
main power is turned on, be sure to put on the earth-band
to ground the unit against electrostatic shock.
Removing/installing the front unit without earth-band
could cause wrong operation.
1. Loosen the four screws (with drop-safe) of the front
panel assembly.
2. While pressing the two panel brackets between the
ornamental panel and the front panel (B), remove the
front panel assembly.
3. Install the front panel assembly by reversing the
disassembling procedure.
RK
4 x20
RK4 x20
Ornamental panel
Front
panel (B)
Panel bracket
Panel
bracket
Front panel assembly
1-7. Front Panel Assembly Installation/Removal

1-11 (E)
VSR-2000A
1-8. HDD Unit Installation
m
.While installing the HDD unit, be sure to put on the
earth-band to ground the unit against electrostatic shock.
.Be sure to place the removed HDD unit on the cushion
gently.
.Place the HDD unit on the cushion with the CAUTION
label side down.
Procedure
1. Remove the front panel assembly (Refer to Section 1-7).
2. Insert the replaced HDD unit into the slot gently, and
push the levers in the direction of the arrows to lock
the HDD unit.
n
Install the HDD with its CAUTION label facing up.
3. Stick the label with the HDD No. corresponding to the
slot on the front.
n
Format the HDDs after the HDD unit has been in-
stalled (Refer to Section 1-13).
Levers
HDD No. label
HDD unit
CAUTION
label
HDD unit
Cushion
Label side down
1-8. HDD Unit Installation

1-12 (E) VSR-2000A
1-9. Signal Input and Output
REF VIDEO INPUT : (BNC)
1.0 V p-p, 75 Z(VBS or VS)
TIME CODE INPUT : (XLR 3-pin, Female)
0.5 to 18.0 V p-p, 10 kZ, Balanced
SERIAL V/A INPUT : (BNC)
270 Mbps, 75 Z
VIDEO OUTPUT 1, 2 : (BNC)
1.0 Vp-p, 75 Z, sync negative
VIDEO OUTPUT Y/G, R-Y/R, B-Y/B :
(BNC)
1.0 Vp-p, 75 Z, sync negative
AUDIO OUPUT 1, 2 : (XLR 3-pin, Male)
Max. +24 dBm/600 Z
(standard +4 dBm/600 Z)
REMOTE : RS-422A (D-sub 9-pin, Female)
VTR CONTROL
< External View >
Pin No. Signal
1 GND
2 TX (_)
3 RX (+)
4 GND
5NC
6 GND
7 TX (+)
8 RX (_)
9 GND
REMOTE : RS-232C (D-sub 9-pin, Female)
< External View >
Pin No. Signal
1NC
2RX
3TX
4 DTR
5SG
6 DSR
7 RTS
8 CTS
9NC
ETHERNET : 100BASE-T (8-pin modular jack)
< External View >
Pin No. Signal
1 TX +
2 TX _
3 RX +
4NC
5NC
6 RX _
7NC
8NC
51
6
9
51
6
9
1
8
1-9. Signal Input and Output

1-13 (E)
VSR-2000A
14
1
13
25
GPI : GPI (D-sub 25-pin, Female)
< External View >
Electric specifications
I/O (1-pin to 24-pin)
Output : Open collector output (74ALS05 or equivalent),
sync current Max. 8 mA, active low
Input : TTL input (74ABT16244 or equivalent),
pull-up 10 kZ5V, active low
Pin No. Signal Function
1 Slot1-IN Command in
2 Slot1-OUT1 Status 1 out
3 Slot1-OUT2 Status 2 out
4 Slot1-R Reserved
5 Slot2-IN Command in
6 Slot2-OUT1 Status 1 out
7 Slot2-OUT2 Status 2 out
8 Slot2-R Reserved
9 Slot3-IN Command in
10 Slot3-OUT1 Status 1 out
11 Slot3-OUT2 Status 2 out
12 Slot3-R Reserved
13 Slot4-IN Command in
14 Slot4-OUT1 Status 1 out
15 Slot4-OUT2 Status 2 out
16 Slot4-R Reserved
17 Slot5-IN Command in
18 Slot5-OUT1 Status 1 out
19 Slot5-OUT2 Status 2 out
20 Slot5-R Reserved
21 Reserved
22 Reserved
23 Reserved
24 Reserved
25 GND
1-9. Signal Input and Output

1-14 (E) VSR-2000A
1-10. Connecting Connectors and Cable
When connecting cables to various connectors on the connector panel, connect the following connectors/
cable or their equivalent.
VSR-2000A Matching Connector/Cable
Panel Indication Connector Connector Sony Part No.
REF VIDEO BNC, 75 ZBNC, 75 Z1-569-370-12
5C-2V cable*1
TIME CODE IN XLR 3-pin, Female XLR 3-pin, Male 1-508-084-00*2
REMOTE D-sub 9-pin, Female D-sub 9-pin, Male 1-560-651-00 (Connector)
VTR CONTROL 1-561-749-00 (Shell)
GPI D-sub 25-pin, Female D-sub 25-pin, Male 1-560-904-00 (Connector)
1-563-377-11 (Shell)
ETHERNET RJ-45 modular jack*3–––––– ––––––
*1 : Use of the coaxial cable 5C-2V of Fujikura America Inc./Fujikura Europe Ltd. (FEL) or equivalent is recommended.
*2 : ITT Cannon XLR-3-12C or the equivalent.
*3 : Conforms to the IEEE 802.3 Ethernet 100BASE-T standard.
BKSR-2031 Matching Connector/Cable
Panel Indication Connector Connector Sony Part No.
VIDEO OUTPUT 1, 2 BNC, 75 Z, Female BNC, 75 Z, Male 1-569-370-12
Y/G, R-Y/R, B-Y/B
AUDIO OUTPUT 1, 2 XLR 3-pin, Male XLR 3-pin, Female 1-508-083-11*1
*1 : ITT Cannon XLR-3-11C or the equivalent.
BKSR-2020 Matching Connector/Cable
Panel Indication Connector Connector Sony Part No.
SERIAL V/A INPUT BNC, 75 Z, Female BNC, 75 Z, Male 1-569-370-12
1-10. Connecting Connectors and Cable
