Sony SA-WP5000 User manual
SERVICE MANUAL
Sony Corporation
Audio Business Group
Published by Sony Techno Create Corporation
SPECIFICATIONS
SA-WP5000
ACTIVE SUBWOOFER
SS-CNP5000/MSP5000/SRP5000
SPEAKER SYSTEM
9-889-038-02
2008E05-1
© 2008.05
E Model
Australian Model
• SA-WP5000 is the active subwoofer in HT-DDW5000/DDW7000.
• SS-CNP5000 is the center speaker in HT-DDW5000/DDW7000.
• SS-MSP5000 is the front speaker in HT-DDW5000/DDW7000.
• SS-SRP5000 is the surround/surround back speaker in HT-DDW5000/
DDW7000.
• SS-CRP5000/CRP7001 are composed of SS-CNP5000, SS-MSP5000
and SS-SRP5000.
SA-WP5000/SS-CNP5000/CRP5000/
CRP7001/MSP5000/SRP5000
Photo: SA-WP5000 Photo: SS-CNP5000 Photo: SS-MSP5000 Photo: SS-SRP5000
SS-CRP5000/CRP7001 COMPONENT MODEL NAME
SS-CRP5000/CRP7001
Front speaker SS-MSP5000
Center speaker SS-CNP5000
Surround/Surround back speaker SS-SRP5000
Speaker section
• Front speaker (SS-MSP5000)
Speaker system 2-way, 3-driver, Bass
reflex, Magnetically
shielded
Speaker unit
Woofer: 160 mm, cone type × 2
Tweeter: 25 mm, horn type
Rated Impedance 4 ohm
Dimensions (width/height/depth) (Approx.)
305 × 1,000 × 325 mm
(with foot)
Mass (Approx.) 13.5 kg
• Center speaker (SS-CNP5000)
Speaker system 2-way, 3-driver, Bass
reflex, Magnetically
shielded
Speaker unit
Woofer: 100 mm, cone type × 2
Tweeter: 25 mm, horn type
Rated Impedance 4 ohm
Dimensions (width/height/depth) (Approx.)
515 × 175 × 225 mm
(with foot)
Mass (Approx.) 4.8 kg
• Surround/Surround back speaker
(SS-SRP5000)
Speaker system Full range, Bass reflex
Speaker unit
Woofer: 100 mm, cone type
Rated Impedance 4 ohm
Dimensions (width/height/depth) (Approx.)
174 × 220 × 166 mm
(with foot)
Mass (Approx.) 1.4 kg
• Subwoofer (SA-WP5000)
Speaker system Active subwoofer, Bass
reflex, Magnetically
shielded
Speaker unit 250 mm, cone type
RMS output 200 W5)
175 W6)
Input LINE IN (input pin jacks)
5)Measured under the following conditions:
6)Measured under the following conditions:
Area code Power requirements
E51, SP, MY, AUS 240 V AC, 50 Hz
MX 127 V AC, 60 Hz
AR, TH 230 V AC, 50 Hz
Area code Power requirements
AR, TH 220 V AC, 50 Hz
Power requirements
Power consumption 80 W
Dimensions (width/height/depth) (Approx.)
335 × 420 × 430 mm
(with foot)
Mass (Approx.) 11 kg
Design and specifications are subject to
change without notice.
Area code Power requirements
SP, MY 230 – 240 V AC, 50/60 Hz
MX 127VAC,60Hz
E51 120/220/240 V AC,
50/60 Hz
AUS 240 V AC, 50 Hz
AR, TH 220 – 230 V AC, 50/60 Hz
Ver. 1.1 2008.05
• Abbreviation
AR : Argentina model
AUS : Australian model
E51 : Chilean and Peruvian models
MX : Mexican model
MY : Malaysia model
SP : Singapore model
TH : Thai model
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
SA-WP5000/SS-CNP5000/CRP5000/CRP7001/MSP5000/SRP5000
2
UNLEADED SOLDER
Boards requiring use of unleaded solder are printed with the lead-
free mark (LF) indicating the solder contains no lead.
(Caution: Some printed circuit boards may not come printed with
the lead free mark due to their particular size)
: LEAD FREE MARK
Unleaded solder has the following characteristics.
• Unleaded solder melts at a temperature about 40 °C higher
than ordinary solder.
Ordinary soldering irons can be used but the iron tip has to be
applied to the solder joint for a slightly longer time.
Soldering irons using a temperature regulator should be set to
about 350 °C.
Caution: The printed pattern (copper foil) may peel away if the
heated tip is applied for too long, so be careful!
• Strong viscosity
Unleaded solder is more viscous (sticky, less prone to flow)
than ordinary solder so use caution not to let solder bridges
occur such as on IC pins, etc.
• Usable with ordinary solder
It is best to use only unleaded solder but unleaded solder may
also be added to ordinary solder.
Notes on chip component replacement
• Never reuse a disconnected chip component.
• Notice that the minus side of a tantalum capacitor may be dam-
aged by heat.
SAFETY-RELATED COMPONET WARNING!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINE
WITH MARK 0ON THE SCHEMATIC DIAGRAMS AND IN
THE PARTS LIST ARE CRITICAL TO SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY PARTS
WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS
MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY.
• JIG
When disassembling the set, use the following jig (for speaker
removal).
Part No.: J-2501-238-A
JIG FOR SPEAKER REMOVAL
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
SA-WP5000/SS-CNP5000/CRP5000/CRP7001/MSP5000/SRP5000
3
SECTION 1
DISASSEMBLY
Note: Follow the disassembly procedure in the numerical order given.
1-1. FRONT PANEL ASSY (SA-WP5000)
1-2. FRONT PANEL ASSY (SS-CNP5000)
Insert the jig (J-2501-238-A) into a space
and raise the front panel assy gradually.
Note: When using a jig, please work so as not
to injure front panel and speaker cabinet.
Insert the jig (J-2501-238-A) into a space
and raise the front panel assy gradually.
Note: When using a jig, please work so as not
to injure front panel and speaker cabinet.
eight bosses
front panel assy
Insert a flat-tip screwdriver into a recess
in the bottom of the set
to raise the front panel assy a little.
Insert the jig (J-2501-238-A) into a space
and raise the front panel assy gradually.
Note 1: When using a jig, please work so as not
to injure front panel and speaker cabinet.
Note 2: Please insert jig from a gap on the front
panel assy underside and expand the
surrounding gap in turn.
nine bosses
front panel assy
Insert a flat-tip screwdriver
into a recess in the bottom of the set
to raise the front panel assy a little.
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
SA-WP5000/SS-CNP5000/CRP5000/CRP7001/MSP5000/SRP5000
4
Insert the jig (J-2501-238-A) into a space
and raise the front panel assy gradually.
Note: When using a jig, please work so as not to injure
front panel and speaker cabinet.
Insert the jig (J-2501-238-A) into a space
and raise the duct panel assy gradually.
Note: When using a jig, please work
so as not to injure duct panel assy
and speaker cabinet.
Insert the jig (J-2501-238-A) into a space
and raise the duct panel assy gradually.
Note: When using a jig, please work
so as not to injure duct panel assy
and speaker cabinet.
ten bosses
twelve bosses
front panel assy
duct panel assy
1-3. FRONT PANEL ASSY, DUCT PANEL ASSY (SS-MPS5000)
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
SA-WP5000/SS-CNP5000/CRP5000/CRP7001/MSP5000/SRP5000
SA-WP5000/SS-CNP5000/CRP5000/CRP7001/MSP5000/SRP5000
55
SECTION 2
DIAGRAMS
For Schematic Diagrams.
Note:
• All capacitors are in μF unless otherwise noted. (p: pF) 50
WV or less are not indicated except for electrolytics and
tantalums.
• All resistors are in Ωand 1/4 W or less unless otherwise
specified.
• 2: nonflammable resistor.
• 5: fusible resistor.
• C: panel designation.
THIS NOTE IS COMMON FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS.
(In addition to this, the necessary note is printed in each block.)
• A: B+ Line.
• B: B– Line.
• Voltages and waveforms are dc with respect to ground
under no-signal conditions.
no mark
: Power on
• Voltages are taken with VOM (Input impedance 10 MΩ).
Voltage variations may be noted due to normal production
tolerances.
• Signal path.
F: AUDIO
• Abbreviation
AR :
Argentina model
AUS : Australian model
E51 : Chilean and Peruvian models
MX : Mexican model
MY : Malaysia model
SP : Singapore model
TH : Thai model
For Printed Wiring Boards.
Note:
• X: Parts extracted from the component side.
• Y: parts extracted from the conductor side.
• : Pattern from the side which enables seeing.
(The other layers' patterns are not indicated.)
• Indication of transistor.
CEB
These are omitted.
B
These are omitted.
CE
Q
Note: The components identified by mark 0or dotted
line with mark 0are critical for safety.
Replace only with part number specified.
INPUT CONTROL board
SWITCH board
LED board
MAIN board
POWER TRANS board
• Circuit Boards Location
– SA-WP5000 –
• IC Block Diagram
– MAIN Board (SA-WP5000) –
IC500 μPC1237C-A
SWITCH FOR
LATCH/AUTOMATIC
RESET
OUTPUT
OFFSET
DETECTOR
OVERLOAD
DETECTOR
AC-OFF
DETECTOR
FLIP-FLOP
OUTPUT
OFFSET
DETECTOR
OUTPUT
OFFSET
DETECTOR
1LOADOVER
2DETECT DC
3RESET
4OFF AC
6
DRIVER
RELAY
5
GND
7
OFF AC
8
VCC
Ver. 1.1
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
SA-WP5000/SS-CNP5000/CRP5000/CRP7001/MSP5000/SRP5000
SA-WP5000/SS-CNP5000/CRP5000/CRP7001/MSP5000/SRP5000
66
• : Uses unleaded solder.
• See page 5 for Circuit Boards Location.
2-1. PRINTED WIRING BOARDS - MAIN Section (SA-WP5000) -
IC500
IC202
IC203
MAIN BOARD
1-869-085-
(POWER)
(11)
11
LED BOARD
61
1
12
12
1
15
15
2
8
45
18
45
18
45
EE
E
E
E
E
E
E
E
BCE BCE
E
E
E
E
INPUT CONTROL
BOARD
INPUT
LEVEL
SP1
1-869-082- (11)
11
1-869-084- (11)
11
1
A
B
C
D
E
F
G
H
I
J
K
2 3 4 5 6 7 8 9 10 11 12 13
POWER TRANS BOARD
CNP401
A
JW100
C302
C308
C310
C128
C127
C121
Q103
Q102
R123
R216
C204
C206
G1
R209
R207
R205
R202
R210
R212
R206
R315
C201
D101
R124
C301
R304
R330
R324
C307
Q305
Q304
JW108
JW114
JW115
JW116
R509
JW112
JW111
JW113
R318
R328
R319
R314
JW109
JW110
R329
C313
C309
R301
R308
Q301
D307
D304
D303
D306
C303
R306
D308
D309
R309
JW102
JW101
R310
R323 R322
R321
R320
R507
RY301
R305
C305
C304
R331
R332
R307
JW103
Q303
Q302
C120
D102
R214
R211
C207
R213
C208
JW105
JW104
C210
C212
C211
R217
CN201
(CHASSIS)
C209
C321
(AUS)
CN301 CN601
C203
C322
R208
Q306
Q311
R325
C306
R327
Q309
JW131
JW130
R316
Q310
Q307
R326
C320
JW117
C318 D503
R317
JW107
C319
Q308
C731
JW129
R732
Q731
R731
C403
JW127
JW126
JW133
C404
C407
C408
JW123
JW122
JW121
JW118
JW120
JW119
R311
D305
D506
C507
D505
R508
R601
JW124
R515
R510
C506 C509 R500
JW125
R511
Q505
R501
C504
D801
D804
D802 D803
C409
C510
R513
R512
R404
C410
R403
C508
D504
CN402
C402 C401
D402
JW132
JW134
CNP801
C801
RV801
C601
CN901
D901
J101
Ref. No. Location
• Semiconductor
Location
D101 D-4
D102 D-4
D303 C-5
D304 C-5
D305 F-8
D306 C-4
D307 C-4
D308 B-4
D309 B-4
D402 G-12
D504 G-10
D505 F-8
D506 G-8
D801 F-9
D802 F-9
D803 F-10
D804 F-10
D901 J-7
IC202 F-4
IC203 E-3
IC500 G-8
Q102 E-3
Q103 E-5
Q301 C-5
Q302 C-5
Q303 B-5
Q304 B-6
Q305 B-5
Q306 B-6
Q307 A-9
Q308 A-10
Q309 B-9
Q310 A-9
Q311 C-6
Q505 F-9
Q731 C-10
Ver. 1.1
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
SA-WP5000/SS-CNP5000/CRP5000/CRP7001/MSP5000/SRP5000
SA-WP5000/SS-CNP5000/CRP5000/CRP7001/MSP5000/SRP5000
77
2-2. SCHEMATIC DIAGRAM - MAIN Section (SA-WP5000) - • See page 5 for IC Block Diagram.
C407
C408
C302
R301
R304
C209
C201
R327
C309
C304
R202
R205
R216
R217
R213
R329
R318
R319
R308
R323
R322
R310
R307
R123
R124
D402
R309
R324
R328
RY301
C206
C801
C211
R316
R500
R510
R731
C320
IC202(1/2)
IC202(2/2)
IC203(1/2)
IC203(2/2)
R330
R305
R212
R206
R207
R211
R210
R214
C303
C310
C305
R511
R515
R501
R332
R331
R508
C203
C207
C208
C409
C410
C127
C128
C318
C505
C506
C507
C508
C204
C212
R317
R320
R326
R325
R321
D801D804
D803 D802
D504
D101
D102
C308
R601
R311
C301
C322
R732
C731
R209
C601
C504 C307
R208
CNP801 CN201
C402
C401
CN402
CN301
CN601 CN901
C120
C121
Q103
Q102
G1
D306
D307
D309
D308
D506
D505
R512
R513
C509
R507
IC500
Q505
Q301
D303
D304
Q302
Q303
R306
Q305
Q306
Q304
Q311
C313
R314
Q309
Q310
D305
Q307
5W
Q308
Q731
R503
R509
C403
R403
R404
D901
C510
J101
RV801
C210
C306
C319
220
35V
100
35V
10
50V
1k
47k
220p
10
50V
0.22 x2
47
35V220p
1k
47k
1k
100k
8.2k
2.2k
560
47k
330
10k
22k
180
330
10k
10k
D5SBA204101
180 180
180
10
50V
220p
220p
180
22k
100k
4.7k
100P 500V
NJM4565D
NJM4565D
NJM4565D
NJM4565D
33
1.2k
8.2k
68k
10k
8.2k
47k
150k
100
10V
22
100V
2200p
R315
C321
(AUS)
4.7
2200p
10k
10k
10k
1k
1k
22k
0.22
0.022 0.68
0.1
0.1
47
25V
47
25V
0.022
0.022
100
10V
0.022
4.7
50V
0.22
0.1
10
10
10
47
150
10EDB40-TA2B510EDB40-TA2B5
10EDB40-TA2B5 10EDB40-TA2B5
10EDB40-TA2B5
MTZJ-T-72-15A
MTZJ-T-72-15A
10p
2.2k
1W
220
2W
220p
220p
15k
220p
10k
10
50V
22
50V 22
100V
4.7k
5P 5P
0.1
100V
0.1
100V
6P
2P
2P 2P
100
16V
100
16V
2SA1175-FEK
2SC2785TP-E
1SS133T-72
1SS133T-72
1SS133T-72
1SS133T-72
1SS133T-72
1SS133T-72
68k
15k
47
50V
150k
2SA988TP
-PAFAEA
2SA988TP
-PAFAEA
1SS133T-72
1SS133T-72
2SA988TP
-PAFAEA
2SC2785TP-E
2SC2785TP-E
2SC2705-O
2SA988TP
-PAFAEA
2SA1145-O
47p
47k
2SA1175-FEK
2SC3623ATP-LK
1SS133T-72
MP1620-OPY-MK
MN2488
-OPY-MK
2SC1841
-TP-PAFAEA
1
1
LNH301MPU0A1
(POWER)
47
50V
INPUT
20k
LEVEL
0.1
100p
100P 500V
∗
3300 71V
(MX, SP, MY, AR, TH, AUS)
3300 80V(E51)
∗C403, 404
C404
∗
SP1
Ver. 1.1
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
SA-WP5000/SS-CNP5000/CRP5000/CRP7001/MSP5000/SRP5000
SA-WP5000/SS-CNP5000/CRP5000/CRP7001/MSP5000/SRP5000
88
2-3. PRINTED WIRING BOARDS - POWER Section (SA-WP5000) -
• : Uses unleaded solder.
• See page 5 for Circuit Boards Location.
POWER TRANS BOARD
SWITCH BOARD
1-869-083- (11)
11
F901
T1
POWER
TRANSFORMER
12
12
12
POWER
(AC IN)
A
MAIN BOARD
CN402
1-869-086- (11)
11
12 6
F900
S2
F902
1
A
B
C
D
E
F
G
H
I
234567
CN3
CN20
C901
S901
CN1
JW901
JW1
JW902
FH903
FH904
VOLTAGE
SELECTOR
(EXCEPT E51)
(E51)
(E51)
CNP401
FH902 FH901
FH906 FH905
240V
220V
120V
5
5
CN3
CN1
CN20
(AC IN)
FH905 FH906
CNP401
T1
F902
S901
C901
2P
2P
2P
6P
POWER
TRANSFORMER
POWER
0.0047 250V
T1AL/250V
FH903 FH904
F901
3.15A/125V (E51)
T1AL/250V
(SP, MY, AR, TH, AUS)
T2.5AL/250V (MX)
FH901 FH902
F900
T1AL/250V
JW1
(EXCEPT E51)
(E51)
(E51)
S2
VOLTAGE
SELECTOR
JW901 240V
3
220V
S
120V
2-4. SCHEMATIC DIAGRAM - POWER Section (SA-WP5000) -
Ver. 1.1
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
9
SA-WP5000/SS-CNP5000/CRP5000/CRP7001/MSP5000/SRP5000
SECTION 3
EXPLODED VIEWS
1 A-1441-087-A FRONT PANEL ASSY (for BLACK)
(E51, SP, MY, TH, AUS)
1 A-1543-260-A FRONT PANEL ASSY (for SILVER) (E51, MX, AR)
2 4-999-482-91 KNOB (VOL)
03 1-777-071-23 CORD, POWER (E51, SP, MY)
03 1-783-941-12 CORD, POWER (AR)
03 1-829-627-11 POWER-SUPPLY CORD (MX)
03 1-833-566-21 POWER-SUPPLY CORD (AUS)
03 1-834-288-21 POWER-SUPPLY CORD (TH)
4 A-1439-168-A MAIN BOARD, COMPLETE (E51)
4 A-1439-204-A MAIN BOARD, COMPLETE (SP, MY, TH)
4 A-1439-205-A MAIN BOARD, COMPLETE (AUS)
4 A-1439-206-A MAIN BOARD, COMPLETE (AR)
4 A-1439-208-A MAIN BOARD, COMPLETE (MX)
5 3-905-609-31 SCREW (TRANSISTOR)
6 4-229-966-02 SCREW (4X16), +BV TAPPING
7 3-703-244-00 CORD BUSH (2104) (EXCEPT TH)
7 4-916-783-01 BUSHING, CORD (TH)
8 4-244-832-51 KNOB POWER
9 4-986-971-02 SCREW (3.5)
11 4-874-614-12 SCREW (1) (3.5X14), TAPPING
12 4-874-614-71 SCREW
0F900 1-532-463-33 FUSE (T1AL/250V) (E51)
0F901 1-532-463-33 FUSE (T1AL/250V) (SP, MY, AR, TH, AUS)
0F901 1-532-464-33 FUSE (T2.5AL/250V) (MX)
0F901 1-533-690-12 FUSE, GLASS CYLINDRICAL (DIA.5) (3.15A/125V)
(E51)
0F902 1-532-463-33 FUSE (T1AL/250V) (E51)
Q307 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q308 6-702-390-01 TRANSISTOR MN2488-OPY-MK
RV801 1-227-511-11 RES, VAR, CARBON 20K (LEVEL)
SP1 1-826-607-21 LOUDSPEAKER (25 cm)
0T1 1-443-886-21 TRANSFORMER, POWER (SP, MY, AR, TH, AUS)
0T1 1-445-016-11 TRANSFORMER, POWER (MX)
0T1 1-445-478-11 POWER SOURCE TRANSFORMER (E51)
#1 7-685-881-09 SCREW +BVTT 4X8 (S)
#2 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Note:
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice.
Some delay should be anticipated when
ordering these items.
• The mechanical parts with no reference
number in the exploded views are not sup-
plied.
• Color Indication of Appearance Parts Ex-
ample:
KNOB, BALANCE (WHITE) . . . (RED)
RR
Parts Color Cabinet’s Color
The components identified by mark 0
or dotted line with mark 0are critical for
safety.
Replace only with part number specified.
3-1. SA-WP5000
1
6
SP1
including
RV801
Q307 Q308
not supplied
not supplied
not supplied
not supplied
not
supplied
not supplied
not
supplied
not
supplied
not supplied
not
supplied
not supplied
not supplied
not
supplied
11 2
7
8
9
9
3
#2
#2
#1
4
11 5
RV801
912
a
b
ab
F901
F900
F902 T1
#1
not supplied
(LED board)
not supplied
(INPUT
CONTROL board)
not supplied
(SWITCH board)
not supplied
(POWER TRANS board)
(E51)
(E51)
• Abbreviation
AR : Argentina model
AUS : Australian model
E51 : Chilean and Peruvian models
MX : Mexican model
MY : Malaysia model
SP : Singapore model
TH : Thai model
Ver. 1.1
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
10
SA-WP5000/SS-CNP5000/CRP5000/CRP7001/MSP5000/SRP5000
51 A-1441-039-A FRONT PANEL ASSY (for BLACK)
(E51, SP, MY, TH, AUS)
51 A-1543-242-A FRONT PANEL ASSY (for SILVER) (E51, MX, AR)
52 4-874-614-12 SCREW (1) (3.5X14), TAPPING
53 A-1441-037-A SPEAKER CABINET ASSY
SP51 A-1441-038-A HORN ASSY (including tweeter) (for BLACK)
(E51, SP, MY, TH, AUS)
SP51 A-1543-245-A HORN ASSY (including tweeter) (for SILVER)
(E51, MX, AR)
SP52 1-826-601-21 LOUDSPEAKER (10 cm) (Lch)
SP53 1-826-601-21 LOUDSPEAKER (10 cm) (Rch)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
3-2. SS-CNP5000
51
52
52
53
not supplied
not supplied
not supplied
SP51
SP52
SP53
Ver. 1.1
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
11
SA-WP5000/SS-CNP5000/CRP5000/CRP7001/MSP5000/SRP5000
101 A-1441-017-A FRONT PANEL ASSY (for BLACK)
(E51, SP, MY, TH, AUS)
101 A-1543-241-A FRONT PANEL ASSY (for SILVER) (E51, MX, AR)
102 4-238-407-12 SCREW (1) (4X20), +BV TAPPING
104 A-1441-014-A SPEAKER CABINET ASSY
105 3-293-482-01 FOOT3
106 2-655-031-01 FOOT (4 pieces, 1set)
107 4-874-614-12 SCREW (1) (3.5X14), TAPPING
108 3-293-480-01 FOOT1
SP101 1-826-593-21 SPEAKER (16 cm) (Woofer: Upper)
SP102 1-826-593-21 SPEAKER (16 cm) (Woofer: Lower)
SP103 A-1441-016-A HORN ASSY (including tweeter) (for BLACK)
(E51, SP, MY, TH, AUS)
SP103 A-1543-244-A HORN ASSY (including tweeter) (for SIVLER)
(E51, MX, AR)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
3-3. SS-MPS5000
107
107
107
107
104
not supplied
not supplied
not
supplied
not supplied
not supplied
not supplied
not
supplied
not
supplied
not supplied
101
106
108
102
102 102
102
108
105
105
SP103
SP101
SP102
Ver. 1.1
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
12
SA-WP5000/SS-CNP5000/CRP5000/CRP7001/MSP5000/SRP5000
151 A-1439-443-A OVERALL ASSY (BLACK) (E51, SP, MY, TH, AUS) 151 A-1543-248-A OVERALL ASSY (SILVER) (E51, MX, AR)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
3-4. SS-SRP5000
151
Ver. 1.1
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
13
SA-WP5000/SS-CNP5000/CRP5000/CRP7001/MSP5000/SRP5000
SECTION 4
ELECTRICAL PARTS LIST
INPUT CONTROL BOARD (SA-WP5000)
********************
< CAPACITOR >
C801 1-128-813-11 CERAMIC 220PF 5% 50V
< JACK >
J101 1-815-025-11 JACK, PIN 1P (INPUT)
< VARIABLE RESISTOR >
RV801 1-227-511-11 RES, VAR, CARBON 20K (LEVEL)
*************************************************************
LED BOARD (SA-WP5000)
**********
< CAPACITOR >
C601 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
*CNP901 1-564-517-11 PLUG, CONNECTOR 2P
< LED >
D901 6-501-077-01 LED LNH301MPU0A1 (POWER)
*************************************************************
A-1439-168-A MAIN BOARD, COMPLETE (E51) (SA-WP5000)
A-1439-204-A MAIN BOARD, COMPLETE (SP, MY, TH)
(SA-WP5000)
A-1439-205-A MAIN BOARD, COMPLETE (AUS) (SA-WP5000)
A-1439-206-A MAIN BOARD, COMPLETE (AR) (SA-WP5000)
A-1439-208-A MAIN BOARD, COMPLETE (MX) (SA-WP5000)
********************
< CAPACITOR >
C120 1-126-933-11 ELECT 100uF 20% 16V
C121 1-126-933-11 ELECT 100uF 20% 16V
C127 1-126-947-11 ELECT 47uF 20% 35V
C128 1-126-947-11 ELECT 47uF 20% 35V
C201 1-126-964-11 ELECT 10uF 20% 50V
C203 1-137-190-91 FILM 0.22uF 5% 50V
C204 1-137-190-91 FILM 0.22uF 5% 50V
C206 1-126-964-11 ELECT 10uF 20% 50V
C207 1-136-157-00 FILM 0.022uF 5% 50V
C208 1-136-175-00 FILM 0.68uF 5% 50V
C209 1-128-813-11 CERAMIC 220PF 5% 50V
C210 1-127-888-11 CERAMIC 0.1uF 10% 50V
C211 1-128-813-11 CERAMIC 220PF 5% 50V
C212 1-127-888-11 CERAMIC 0.1uF 10% 50V
C301 1-128-813-11 CERAMIC 220PF 5% 50V
C302 1-126-964-11 ELECT 10uF 20% 50V
C303 1-104-658-91 ELECT 100uF 20% 10V
C304 1-128-813-11 CERAMIC 220PF 5% 50V
C305 1-128-825-11 CERAMIC 2200PF 5% 50V
C306 1-102-973-00 CERAMIC 100PF 5% 50V
C307 1-128-560-11 ELECT 22uF 20% 100V
C308 1-102-947-00 CERAMIC 10PF 0.5PF 50V
C309 1-126-947-11 ELECT 47uF 20% 35V
C310 1-128-560-11 ELECT 22uF 20% 100V
C313 1-101-880-00 CERAMIC 47PF 5% 50V
C318 1-127-880-11 CERAMIC 0.022uF 10% 50V
C319 1-101-810-00 CERAMIC 100PF 5% 500V
C320 1-101-810-00 CERAMIC 100PF 5% 500V
C321 1-128-825-11 CERAMIC 2200PF 5% 50V (AUS)
C322 1-128-813-11 CERAMIC 220PF 5% 50V
C401 1-130-777-00 MYLAR 0.1uF 5% 100V
C402 1-130-777-00 MYLAR 0.1uF 5% 100V
C403 1-100-304-11 ELECT 3300uF 20% 71V
(MX, SP, MY, AR, TH, AUS)
C403 1-127-814-11 ELECT (BLOCK) 3300uF 20% 80V
(E51)
C404 1-100-304-11 ELECT 3300uF 20% 71V
(MX, SP, MY, AR, TH, AUS)
C404 1-127-814-11 ELECT (BLOCK) 3300uF 20% 80V
(E51)
C407 1-126-949-11 ELECT 220uF 20% 35V
C408 1-126-948-11 ELECT 100uF 20% 35V
C409 1-127-888-11 CERAMIC 0.1uF 10% 50V
C410 1-127-888-11 CERAMIC 0.1uF 10% 50V
C504 1-126-965-91 ELECT 22uF 20% 50V
C505 1-127-880-11 CERAMIC 0.022uF 10% 50V
C506 1-104-658-91 ELECT 100uF 20% 10V
C507 1-127-880-11 CERAMIC 0.022uF 10% 50V
C508 1-126-963-11 ELECT 4.7uF 20% 50V
C509 1-126-967-11 ELECT 47uF 20% 50V
C510 1-126-967-11 ELECT 47uF 20% 50V
C731 1-128-813-11 CERAMIC 220PF 5% 50V
< CONNECTOR >
CN201 1-784-931-11 PIN, CONNECTOR 5P
CN301 1-564-320-00 PIN, CONNECTOR (3.96mm PITCH) 2P
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice.
Some delay should be anticipated when
ordering these items.
• CAPACITORS
uF: μF
• COILS
uH: μH
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviation
AR : Argentina model
AUS : Australian model
E51 : Chilean and Peruvian models
MX : Mexican model
MY : Malaysia model
The components identified by mark 0
or dotted line with mark 0are critical for
safety.
Replace only with part number specified.
SP : Singapore model
TH : Thai model
LEDINPUT CONTROL
Ver. 1.1
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
SA-WP5000/SS-CNP5000/CRP5000/CRP7001/MSP5000/SRP5000
14
CN402 1-785-104-11 PIN, CONNECTOR (3.96mm PITCH) 6P
*CN601 1-506-944-11 PIN, CONNECTOR 2P
< DIODE >
D101 8-719-947-60 DIODE MTZJ-T-72-15A
D102 8-719-947-60 DIODE MTZJ-T-72-15A
D303 8-719-991-33 DIODE 1SS133T-77
D304 8-719-991-33 DIODE 1SS133T-77
D305 8-719-991-33 DIODE 1SS133T-77
D306 8-719-991-33 DIODE 1SS133T-77
D307 8-719-991-33 DIODE 1SS133T-77
D308 8-719-991-33 DIODE 1SS133T-77
D309 8-719-991-33 DIODE 1SS133T-77
D402 8-719-510-68 DIODE D5SBA204101
D504 6-500-522-11 DIODE 10EDB40-TA2B5
D505 8-719-991-33 DIODE 1SS133T-77
D506 8-719-991-33 DIODE 1SS133T-77
D801 6-500-522-11 DIODE 10EDB40-TA2B5
D802 6-500-522-11 DIODE 10EDB40-TA2B5
D803 6-500-522-11 DIODE 10EDB40-TA2B5
D804 6-500-522-11 DIODE 10EDB40-TA2B5
< GROUND TERMINAL >
G1 1-537-738-21 TERMINAL, GROUND
< IC >
IC202 8-759-167-88 IC NJM4565D
IC203 8-759-167-88 IC NJM4565D
IC500 6-708-609-01 IC uPC1237C-A
< TRANSISTOR >
Q102 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q103 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q301 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q302 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q303 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q304 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q305 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q306 8-729-270-51 TRANSISTOR 2SC2705-O
Q309 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q310 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q311 8-729-214-51 TRANSISTOR 2SA1145-O
Q505 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q731 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
< RESISTOR >
R123 1-249-429-11 CARBON 10K 5% 1/4W
R124 1-249-429-11 CARBON 10K 5% 1/4W
R202 1-247-831-91 CARBON 1K 5% 1/4W
R205 1-247-871-91 CARBON 47K 5% 1/4W
R206 1-249-439-11 CARBON 68K 5% 1/4W
R207 1-249-429-11 CARBON 10K 5% 1/4W
R208 1-247-847-91 CARBON 4.7K 5% 1/4W
R209 1-249-429-11 CARBON 10K 5% 1/4W
R210 1-247-871-91 CARBON 47K 5% 1/4W
R211 1-249-428-11 CARBON 8.2K 5% 1/4W
R212 1-249-428-11 CARBON 8.2K 5% 1/4W
R213 1-249-428-11 CARBON 8.2K 5% 1/4W
R214 1-247-883-00 CARBON 150K 5% 1/4W
R216 1-247-831-91 CARBON 1K 5% 1/4W
MAIN
R217 1-247-879-91 CARBON 100K 5% 1/4W
R301 1-247-831-91 CARBON 1K 5% 1/4W
R304 1-247-871-91 CARBON 47K 5% 1/4W
R305 1-249-418-11 CARBON 1.2K 5% 1/4W
R307 1-249-411-11 CARBON 330 5% 1/4W
R308 1-249-411-11 CARBON 330 5% 1/4W
R309 1-249-408-11 CARBON 180 5% 1/4W
R310 1-249-408-11 CARBON 180 5% 1/4W
0R311 1-215-888-51 METAL OXIDE 220 5% 2W F
R314 1-247-871-91 CARBON 47K 5% 1/4W
R315 1-249-389-11 CARBON 4.7 5% 1/4W
(AUS)
R316 1-249-408-11 CARBON 180 5% 1/4W
R317 1-249-393-11 CARBON 10 5% 1/4W
R318 1-249-414-11 CARBON 560 5% 1/4W
R319 1-247-871-91 CARBON 47K 5% 1/4W
R320 1-249-393-11 CARBON 10 5% 1/4W
R321 1-249-407-11 CARBON 150 5% 1/4W
R322 1-247-863-91 CARBON 22K 5% 1/4W
R323 1-249-429-11 CARBON 10K 5% 1/4W
R324 1-249-408-11 CARBON 180 5% 1/4W
R325 1-249-401-11 CARBON 47 5% 1/4W
R326 1-249-393-11 CARBON 10 5% 1/4W
0R327 1-234-572-11 ENCAPSULATED COMPONENT 0.22 5W F
R328 1-249-408-11 CARBON 180 5% 1/4W
R329 1-249-421-11 CARBON 2.2K 5% 1/4W
R330 1-249-399-11 CARBON 33 5% 1/4W
R331 1-247-831-91 CARBON 1K 5% 1/4W
R332 1-247-831-91 CARBON 1K 5% 1/4W
0R403 1-217-637-91 FUSIBLE 1 5% 1/4W F
0R404 1-217-637-91 FUSIBLE 1 5% 1/4W F
R500 1-247-863-91 CARBON 22K 5% 1/4W
R501 1-249-429-11 CARBON 10K 5% 1/4W
R507 1-247-883-00 CARBON 150K 5% 1/4W
R508 1-247-863-91 CARBON 22K 5% 1/4W
R510 1-247-879-91 CARBON 100K 5% 1/4W
R511 1-249-429-11 CARBON 10K 5% 1/4W
R512 1-249-439-11 CARBON 68K 5% 1/4W
R513 1-249-431-11 CARBON 15K 5% 1/4W
R515 1-249-429-11 CARBON 10K 5% 1/4W
0R601 1-215-871-51 METAL OXIDE 2.2K 5% 1W F
R731 1-247-847-91 CARBON 4.7K 5% 1/4W
R732 1-249-431-11 CARBON 15K 5% 1/4W
< RELAY >
RY301 1-755-170-11 RELAY (12V)
*************************************************************
POWER TRANS BOARD (SA-WP5000)
*******************
< CONNECTOR >
*CN1 1-695-044-11 PIN, CONNECTOR (3.96mm PITCH) 2P
< FUSE HOLDER >
FH901 1-533-217-31 FUSE HOLDER (E51)
FH902 1-533-217-31 FUSE HOLDER (E51)
FH903 1-533-217-31 FUSE HOLDER
FH904 1-533-217-31 FUSE HOLDER
FH905 1-533-217-31 FUSE HOLDER (E51)
POWER TRANS
Ver. 1.1
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
SA-WP5000/SS-CNP5000/CRP5000/CRP7001/MSP5000/SRP5000
1515
SWITCH
FH906 1-533-217-31 FUSE HOLDER (E51)
< SWITCH >
S2 1-771-291-31 SWITCH, POWER (VOLTAGE SELECTOR) (E51)
*************************************************************
SWITCH BOARD (SA-WP5000)
*************
< CAPACITOR >
0C901 1-112-872-51 CERAMIC 0.0047uF 20% 250V
< CONNECTOR >
*CN3 1-695-044-11 PIN, CONNECTOR (3.96mm PITCH) 2P
*CN20 1-695-044-11 PIN, CONNECTOR (3.96mm PITCH) 2P
< SWITCH >
0S901 1-572-267-51 SWITCH, PUSH (AC POWER) (1 KEY) (POWER)
*************************************************************
MISCELLANEOUS
**************
03 1-777-071-23 CORD, POWER (SA-WP5000: E51, SP, MY)
03 1-783-941-12 CORD, POWER (SA-WP5000: AR)
03 1-829-627-11 POWER-SUPPLY CORD (SA-WP5000: MX)
03 1-833-566-21 POWER-SUPPLY CORD (SA-WP5000: AUS)
03 1-834-288-21 POWER-SUPPLY CORD (SA-WP5000: TH)
151 A-1439-443-A OVERALL ASSY (BLACK)
(SS-SRP5000: E51, SP, MY, TH, AUS)
151 A-1543-248-A OVERALL ASSY (SILVER)
(SS-SRP5000: E51, MX, AR)
0F900 1-532-463-33 FUSE (T1AL/250V) (SA-WP5000: E51)
0F901 1-532-463-33 FUSE (T1AL/250V)
(SA-WP5000: SP, MY, AR, TH, AUS)
0F901 1-532-464-33 FUSE (T2.5AL/250V) (SA-WP5000: MX)
0F901 1-533-690-12 FUSE, GLASS CYLINDRICAL(DIA.5) (3.15A/125V)
(SA-WP5000: E51)
0F902 1-532-463-33 FUSE (T1AL/250V) (SA-WP5000: E51)
Q307 6-702-391-01 TRANSISTOR MP1620-OPY-MK (SA-WP5000)
Q308 6-702-390-01 TRANSISTOR MN2488-OPY-MK (SA-WP5000)
SP1 1-826-607-21 LOUDSPEAKER (25 cm) (SA-WP5000)
SP51 A-1441-038-A HORN ASSY (including tweeter) (for BLACK)
(E51, SP, MY, TH, AUS) (SS-CNP5000)
SP51 A-1543-245-A HORN ASSY (including tweeter) (for SILVER)
(E51, MX, AR) (SS-CNP5000)
SP52 1-826-601-21 LOUDSPEAKER (10 cm) (Lch) (SS-CNP5000)
SP53 1-826-601-21 LOUDSPEAKER (10 cm) (Rch) (SS-CNP5000)
SP101 1-826-593-21 SPEAKER (16 cm) (Woofer: Upper) (SS-MSP5000)
SP102 1-826-593-21 SPEAKER (16 cm) (Woofer: Lower) (SS-MSP5000)
SP103 A-1441-016-A HORN ASSY (including tweeter) (for BLACK)
(E51, SP, MY, TH, AUS) (SS-MSP5000)
SP103 A-1543-244-A HORN ASSY (including tweeter) (for SIVLER)
(E51, MX, AR) (SS-MSP5000)
0T1 1-443-886-21 TRANSFORMER, POWER
(SA-WP5000: SP, MY, AR, TH, AUS)
0T1 1-445-016-11 TRANSFORMER, POWER (SA-WP5000: MX)
0T1 1-445-478-11 POWER SOURCE TRANSFORMER
(SA-WP5000: E51)
*************************************************************
POWER TRANS
Ver. 1.1
ACCESSORY
**********
01-569-008-22 ADAPTOR, CONVERSION 2P (for SA-WP5000)
(E51)
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
SA-WP5000/SS-CNP5000/CRP5000/CRP7001/MSP5000/SRP5000
REVISION HISTORY
Checking the version allows you to jump to the revised page.
Also, clicking the version at the top of the revised page allows you to jump to the next revised page.
Ver. Date Description of Revision
1.0 2008.03 New
1.1 2008.05 Addition of SS-CRP7001 (for Package speaker name of HT-DDW7000)
Addition of Thai model (for HT-DDW5000)
Addition of Australian model (for HT-DDW7000)
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
