Sony SS-DX5 User manual

SS-DX5/DX5B/DX5J/DX8/DX8B/
VX55/VX55B/VX55J/VX88/VX88B
E Model
SS-DX5/DX5B/DX5J/DX8/DX8B/
VX55/VX55B/VX55J/VX88/VX88B
Australian Model
SS-DX5/DX8
Tourist Model
SS-VX55J
SERVICE MANUAL
SPEAKER SYSTEM
SPECIFICATIONS
Photo: SS-DX5
• This set is the speaker system in
MHC-DX5/DX5J/DX8/VX55/VX55J/VX88.
Speaker system 3-way, 3-unit,
bass-reflex type
Speaker units
Super Woofer: 15 cm, cone type
Woofer: 15 cm, cone type (DX5/DX5B/DX5J/DX8/DX8B)
15 cm, hop type (VX55/VX55B/VX55J/VX88/VX88B)
Tweeter: 5 cm, cone type
Nominal impedance 6 Ω
Dimensions (w/h/d) Approx. 250 ×360 ×360
mm (9 7 /8 ×14 1 /4 ×14 1 /4 in.)
Mass Approx. 6.2 kg net per (DX5/DX5B/DX5J/DX8/DX8B)
Approx. 7.1 kg net per (VX55/VX55B/VX55J/VX88/VX88B)
Design and specifications are subject to change without notice
Ver 1.0 2000.2

2
Sony Corporation
Home Audio Division Company
9-929-081-11 2000B1626-1D
Printed in Japan ©2000.2
Published by Quality Assurance Dept.
EXPLODED VIEW AND PARTS LIST
S
2
3
45
6
7
9
8
2
1
2
not supplied
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
1 A-4412-045-A FRONT PANEL ASSY (DX5:EA)
1 A-4412-047-A FRONT PANEL ASSY
(DX5:E,TH,AUS/DX5J/DX8/VX55:TH/VX55J/VX88)
1 A-4412-252-A FRONT PANEL ASSY (VX55:EA)
1 A-4412-243-A FRONT PANEL ASSY (VX55:E)
1 A-4412-045-A FRONT PANELASSY
(DX5B/DX8B/VX55B/VX88B)
2 4-874-614-21 SCREW(4) (3.5X14), TAPPING
3 1-529-571-11 SPEAKER (15cm)(DX5/DX5B/DX5J/DX8/DX8B)
3 1-529-690-11 SPEAKER (15cm)(VX88/VX88B)
3 1-529-693-11 SPEAKER (15cm)(VX55/VX55B/VX55J)
4 1-529-573-11 SPEAKER (5cm)(DX5/DX5B/DX5J/DX8:TH)
4 1-529-692-11 SPEAKER (5cm)
(DX8:E,EA,MX,AUS/DX8B/VX88/VX88B)
4 1-529-695-11 SPEAKER (5cm)(VX55/VX55J)
5 4-986-971-01 SCREW(3.5)
6 1-529-572-11 SPEAKER (15cm)(DX5/DX5B/DX5J/DX8/DX8B)
6 1-529-691-11 SPEAKER (15cm)(VX88/VX88B)
6 1-529-694-11 SPEAKER (15cm)(VX55/VX55B/VX55J)
7 A-4411-948-A SPEAKER CABINET ASSY
(DX5:E,EA,AUS/DX8:E,EA,MX,AUS/VX88:E,EA)
7 A-4412-253-A SPEAKER CABINET ASSY (VX55:EA)
7 A-4412-241-A SPEAKER CABINET ASSY
(DX5:TH/DX8:TH/VX55:TH/VX88:TH)
7 A-4412-242-A SPEAKER CABINET ASSY (VX55:E)
7 A-4412-244-A SPEAKER CABINET ASSY (DX5J,VX55J)
7 A-4411-948-A SPEAKER CABINET ASSY
(DX5B/DX8B/VX55B/VX88B)
8 1-694-650-11 TERMINAL
9 1-775-512-21 CORD,SPEAKER CONNECTION
• Abbreviation
EA : Saudi Arabia model.
MX : Mexican model.
TH : Thai model.
AUS : Australian model.
