Sony SRS-Z510 User manual

SRS-Z510
US Model
Canadian Model
AEP Model
UK Model
E Model
Australian Model
Tourist Model
SERVICE MANUAL
ACTIVE SPEAKER SYSTEM
SPECIFICATIONS
Ver 1.1 2003. 03
Sony Corporation
Personal Audio Company
Published by Sony Engineering Corporation
9-877-078-02
2003C1600-1
© 2003.03
Speaker section
Enclosure type Full range, Bass reflex,
magnetically shielded
Speaker system 57 mm (diameter)
Impedance 8Ω
Rated input power 3 W
Amplifier section (Left Speaker)
Rated output 3.5 W + 3.5 W
(10 % T.H.D., 1 kHz, 6Ω)
Bass boost MEGA BASS
Input Input cord a stereo-mini
plug (2 m) ×1
Stereo mini jack ×1
Input impedance 4.7 kΩ(at 1 kHz)
Output Stereo mini jack ×1
(PHONES)
General
Power DC 9V (supplied AC power
adaptor)
Dimensions (w/h/d) approx. 84 ×176 ×130 mm
(3
3
/ 8 ×7 ×5
1
/ 8 inch)
Mass (Left) 610 g (1 lb. 6 oz.),
(Right) 560 g (1 lb. 4 oz.)
Supplied accessories
AC power adaptor (1)
Operating Instructions (1)
Design and specifications are subject to change
without notice.
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

2
SRS-Z510
TABLE OF CONTENTS
Notes on chip component replacement
•Never reuse a disconnected chip component.
•Notice that the minus side of a tantalum capacitor may be dam-
aged by heat.
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINEWITH
MARK 0ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS
LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE
COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS
APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS
PUBLISHED BY SONY.
1. GENERAL ·········································································· 3
2. DIAGRAMS ········································································ 4
2-1. Printed Wiring Board ······················································ 5
2-2. Schematic Diagram ························································· 6
2-3. IC Block Diagram ··························································· 7
3. EXPLODED VIEWS
3-1. Left Speaker Section ······················································· 8
3-2. Right Speaker Section ····················································· 9
4. ELECTRICAL PARTS LIST ······································· 10
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!
LES COMPOSANTS IDENTIFÉS PAR UNE MARQUE 0SUR LES
DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT
CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE
REMPLACER CES COMPOSANTS QUE PAR DES PIÈSES SONY
DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU
DANS LES SUPPÉMENTS PUBLIÉS PAR SONY.
Ver 1.1 2003.03
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

3
SRS-Z510
SECTION 1
GENERAL This section is extracted from
instruction manual.
Left speaker (rear)
Enceinte gauche (arrière)
Linker Lautsprecher (hinten)
Altavoz izquierdo (trasero)
Linker luidspreker (achterkant)
to DC IN 9 V jack
Vers la prise DC IN 9 V
an Buchse DC IN 9 V
a la toma DC IN 9 V
naar de DC IN 9V
AC power adaptor (supplied)
Adaptateur secteur (fourni)
Netzteil (mitgeliefert)
Adaptador de alimentación de ca (suministrado)
Netspanningsadapter (meegeleverd)
to wall outlet
Vers la prise murale
an eine Netzsteckdose
a la toma de pared
naar stopcontact
Right speaker (rear)
Enceinte droite (arrière)
Rechter Lautsprecher (hinten)
Altavoz derecho (posterior)
Rechter luidspreker (achterkant)
Left speaker (rear)
Enceinte gauche (arrière)
Linker Lautsprecher (hinten)
Altavoz izquierdo (posterior)
Linker luidspreker (achterkant)
to R OUT jack
Vers la prise R OUT
an Buchse R OUT
a la toma R OUT
naar R OUT
aansluiting
To LINE OUT or to headphones jack
(stereo mini jack)
Vers LINE OUT ou vers la prise de
casque (mini-prise stéréo)
an LINE OUT oder an
Kopfhörerbuchse (Stereominibuchse)
a la toma LINE OUT o a la toma de
auriculares (minitoma estéreo)
Naar LINE OUT of hoofdtelefoon-
aansluiting (stereo mini-aansluiting)
CD/MD Walkman*, etc
Walkman* CD et MD
ou un autre appareil
CD/MD-Walkman usw.
Walkman de CD/MD*,
etc.
CD/MD Walkman,
enzovoort
Left speaker (front)
Enceinte gauche (avant)
Linker Lautsprecher (vorne)
Altavoz izquierdo (frontal)
Linker luidspreker
(voorkant)
Right speaker (front)
Enceinte droite (avant)
Rechter Lautsprecher (vorne)
Altavoz derecho (frontal)
Rechter luidspreker
(voorkant)
to INPUT2 jack
Vers la prise INPUT2
an Buchse INPUT2
a la toma INPUT2
naar INPUT2 aansluiting
RK-G136 connecting cord (optional)
Câble de raccordement RK-G136 (en option)
Verbindungskabel RK-G136 (gesondert erhältlich)
Cable de conexión RK-G136 (opcional)
RK-G136 aansluitsnoer (niet meegeleverd)
PC, etc.
Ordinateur ou un
autre appareil
PC usw.
PC, etc.
PC, enzovoort
*“WALKMAN” is a registered trademark of Sony Corporation to
represent Headphone Stereo products.
« WALKMAN » est une marque déposée par Sony Corporation pour
représenter les produits stéréo dotés d’écouteurs.
“WALKMAN” es una marca registrada de Sony Corporation que
representa los productos audífonos estéreo.
POWER VOLUME
PHONES
CD/MD Walkman, etc
Walkman CD et MD
ou un autre appareil
CD/MD-Walkman
usw.
Walkman de CD/MD,
etc.
CD/MD Walkman,
enzovoort
