Sony MHC-EC70 - Mini Hi-fi Component System User manual

MHC -EC70
MiniHi -FiComponentSystem
NEW
320WattsTotal:160Watts perChannelx 2(RMS10% THD,120-10kHz)
3-WayMain Speakerswithhuge 63/10"Woofers forMaximumBass
PC/AudioIn forDigitalMusic PlayersorPC Input
3Disc CDChangerwith PlayExchange
CD-R/CD-RWwith MP3PlaybackCapability
1
PianoKey CassetteControls
Tunerwith 20FM/10AM StationPresets
4Preset EQsettings
BassReflex SpeakerSystem
SynchronizedCD/Cassette Dubbing
TwoTimer Functions
DSGXBass BoostFunction

LastUpdated:07/03/2007
MHC -EC70
MiniHi -FiComponentSystem
PleasevisittheDealerNetworkforcurrentinformationatwww.sony.com/dn
Features
320 Watts Total Power 160 per channel x 2(RMS 10% THD, 120-10
kHz)
3 Way Main Speakers with huge 6 3/10" Woofers for Maximum
Bass A two driver design helps ensure audio accuracy by providing
a greater frequency range. The speaker's crossover splits the
frequency band into three ranges: bass frequencies to the woofer,
treble frequencies go to the tweeter and the middle frequencies
are sent to a third drive commonly referred to as the midrange.
3 Disc CD Changer with Play Exchange A feature that allows 2 discs
to be changed while the third continues to play.
CD-R/CD-RW with MP3 Playback Capability Plays back MP3 files
recorded onto CD-R/RW discs.
1
Piano Key Single Cassette Often referred to as a "soft-touch" design,
a full-logic transport's controls require less effort to use than older
style mechanical transports.
Tuner with 20 FM/10 AM Station Presets Provides easy access to
the most listened to radio stations.
4 Preset EQ settings Creates enhanced sound modes for differnt
types of music, such as rock and pop.
PC/Audio In for Digital Music Players or PC Input An exciting new
feature that takes music playback beyond tape and CD. It allows
simple plug-and-play integration with a digital music device or PC
via a 2.5 mm jack.
Bass Reflex Speaker System A type of speaker enclosure that
includes a "tuned" port to increase and extend bass response (by
releasing some of the energy created by the inward movement of
the woofer cone).
Synchronized CD/Cassette Dubbing Starts cassette recording when
compact disc playback begins
Two Timer Modes Provides a Sleep and Wake timers for ease of use.
Specifications
General
Type of Use: Shelf System
Tray Type: Tray Loading 3 Disc CD Changer with Play Exchange
(Semiconductor Laser 780nm)
Disc Capacity: 3
Audio
Digital -to-Analog Converter: 1 Bit
Frequency Response: CD: 20-20000Hz ( ± 0.5dB); Cassette: 50-13000Hz
( ± 0.3db)
Format(s) Supported: CD-DA, CD-R/RW, CD's WITH MP3 Playback
Capability
Tuning: Auto Scan Radio
Antenna System: AM: Loop Antenna, FM: Lead Antenna
Tape System: 4 Track, 2 Channel Stereo Cassette, CD Synchronized
Recording
Frequency Range: AM: 530-1710kHz; FM: 87.5-108.0MHz
CD Play Mode(s): Program, Shuffle, Repeat
Station Preset(s): 30 (10 AM, 20 FM)
Sound Enhancer: Groove Bass Boost Function, Virtual Surround
Sound Mode
Equalizer: 9 Presets (Rock, Pop, Jazz, Dance, Soul, Oriental, Reggae,
Salsa, Samba), 3 Personal File Settings
Tape Operation: Full Logic Dual Cassette Deck
Tuner Type: FM/AM Superheterodyne Tuner
Convenience Features
Timer Events: Record/Play/Sleep (Wake-up or Fall Asleep To Music-
Select from 10 Timed Shut Offs)
Power Save Mode: Yes
Hardware
Display: LCD
Remote Control: Yes (Remote Commander®Remote Control)
Power
Power Requirements: AC 120V, 60Hz
Output Power: 300W Total (150 W +150 W (6 ohms at 1 kHz, 10% THD))
Power Consumption: 205W
Manual: 210W
Battery Type: Remote: "AA" x 2
Power Handling Capacity: With 6 ohms loads, both channels driven
from 120-10000 Hz; rated 150 W per channel-minimum RMS power,
with no more than 10% total harmonic distortion from 250
milliwatts to rated output.
Speaker
Speaker System: 3 Way, 3 Unit, Bass Reflex Type
Speaker Dimensions: 2" (5cm)
Woofer Size(s): 5.1" (13cm); 5.1" (13cm) (Subwoofer)
Inputs and Outputs
Analog Audio Input(s): 1 (Rear, Stereo Mini)
Headphone Input(s): 1 (Front, Stereo Mini)
Antenna Terminal(s): 2 (Rear)
PC Audio Input(s): Yes
Dimensions
Weight: Speaker: 8 lbs 6 oz (3.8 Kg) (each x 2); Main Unit: 22 lbs 1 oz (10
Kg)
Measurements: Speaker: 9 1/16 x 13 7/12 x 9 1/4" (230 x 345 x 235mm)
(each x 2); Main Unit: 11 x 12 4/5 x 16 13/14" (280 x 325 x 430mm)
Supplied Accessories
Instruction Manual
Remote Commander®Remote Control (RM-SC50)
AM Roop Antenna
FM Lead Antenna
UPC Code: 027242683624
1.CD - R/RWmedia/formatsarenotuniversallycompatible.
©2006SonyElectronicsInc.
Reproductioninwholeorinpartwithoutwrittenpermissionisprohibited.Allrightsreserved.Sony,Remote
Commander,andlike.no.otheraretrademarksofSony.Allothertrademarksarepropertyoftheirrespective
owners.
Featuresandspecificationsaresubjecttochangewithoutnotice.Non - metricweightsandmeasuresare
approximate.
