Sony MHC-EC79I User manual

MHC-EC79i
Mini Hi - Fi Shelf System
Made for iPod? : charge, play and control your compatible iPod
2
Single disc CD player with CD-R/RW and PM3 playback capability
that accommodates not only factory -pressed CD-Audio discs, but
also consumer- recorded CD -R and CD-RW discs.
1
Audio -in for experiencing simple plug-and- play integration with
digital music players, PC's and more.
380 W (RMS) Total Output Power -(190W x 2) .
3
AM/FM tuner with 30 station presets which provides accurate, drift-
free tuning of AM and FM stations and allows you to preset 10 of your
favorite AM and 20 FM stations.
Remote control with full iPod menu control which allows you to control
most functions of your iPod.

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 04/13/2009
MHC-EC79i
Mini Hi - Fi Shelf System
Please visit the Dealer Network for current information at
www.sony.com/dn
Features
Made for iPod ® Charge, play, and control your compatible
iPod.
2
Single Disc CD Player With CD, CD - R/RW and MP3 Playback.
Accommodates not only factory - pressed CD - Audio discs, but
also consumer - recorded CD - R and CD - RW discs .
1
Audio - in Experience simple plug - and - play integration with
digital music players, PC's and more.
3 - way 3 - driver, Bass Reflex Speaker System Woofer: 130 mm,
cone type
Tweeter: 40 mm, horn type
AM/FM Tuner with 30 Station Presets Provides accurate, drift -
free tuning of AM/FM stations and allows you to preset up to 30
of your favorite stations: 10 AM and 20 FM.
380W (RMS) Total Power Output (190W x 2) .
3
Remote Control with Full iPod ® Menu Control Allows you to
control your iPod from across the room.
Specifications
Audio
Digital - to - AnalogConverter: 44.1kHz/24bit
Format(s)Supported: CD,CD - R,CD - RW,MP3
AntennaSystem: Simple Type
Impedance: 8 ohms
CD Play Mode(s): Normal,Shuffle,Program,Repeat
StationPreset(s): FM 20/AM 10
Equalizer: Preset EQ: 7
Audio Power Output: Channel - wise Amp Measurement: 190W x 2
SpeakerType: 3way
Band: FM/AM
Convenience Features
TimerEvents: Play/Sleep
Power Save Mode: Yes
Power
OutputPower: 380W Total
BatteryType: Remote Battery Size/Type:AA/Manganese
Video
PlayMode: Normal/Shuffle/Program/Repeat
Inputs and Outputs
HeadphoneInput(s): 1 (3.5mm)
HeadphoneJack: Yes (3.5mm)
PC Audio Input(s): Yes
Analog Audio Input(s) (Total): Audio Line: 3.5mm
Dimensions
Weight: Main Unit: 6.0Kg; Front Speaker: 3.5Kg: Front Speaker:
3.5Kg
Measurements: Main Unit: 200 x 306 x 415 (WHD); Front Speaker:
220 x 350 x 220 (WHD); Front Speaker:220 x 350 x 220 (WHD)
Supplied Accessories
RM - AMU009 Remote Control
TDM - iP10 Digital Media Port
UPC Code: 027242752252
1.NotallWMAandMP3filesmayplaybackduetofilevariations.Playbackdependsonrecordingconditions.
2.CompatiblewithiPodtouch,iPodnano3rdgeneration,iPodclassic,iPodnano2ndgeneration,iPod5th
generation, iPod nano 1st generation, iPod 4th generation, iPod mini.
3.Unitaudiooutputtestedat8ohmsin frequency range 120 Hz to10kHz with a Total Harmonic Distortionof
0.07percent.
©2009 Sony ElectronicsInc. All rightsreserved.Reproduction in wholeor in partwithout written permissionis
prohibited.Sony ® isatrademark of Sony. iPod ®is a trademarkof AppleComputers, Inc. Allother trademarks
aretrademarks of their respective owners. Features and specificationsare subject to change without notice.
Non - metricweightsand measures are approximate.
