13
SECTION 4
TEST MODE
[LED All Lit, Key Check Mode]
Procedure:
1. Press the ?/1button to turn the power ON.
2. Press three buttons of s(DECK B), A(DISC 1), and
[DISC 5] simultaneously.
3. LEDs are all turned on.
Press the G(CD) button, and the key check mode is activated.
LEDs are all OFF.
4. When a button is pressed, the LED near the pressed button
blinks or lights up.
Also, if all buttons are pressed, all LEDs light up (not blink).
5. To release from this mode, press three buttons in the same
manner as step 2, or remove the power cord.
[CD Delivery Mode]
• This mode moves the optical pick-up to the position durable to
vibration. Use this mode when returning the set to the customer
after repair.
Procedure:
1. Press the ?/1button to turn the power ON.
2. Press the s(DECK B) and [DISC 1] buttons simultaneously.
3. A message “LOCK” is displayed on the liquid crystal display
of the STR-NX1/NX3, and the CD delivery mode is set.
[Tape Deck Test Mode]
(In case of connected to the STR-NX1/NX3)
• If connected to the STR-NX1/NX3, the mode also acts as the
STR-NX1/NX3 amplifer test mode.
Procedure:
1. Press the ?/1button to turn the power ON.
2. Pressthreebuttonsof s(DECKB), A(DISC1),and S(CD)
simultaneously.
3. On liquid crystal display of the STR-NX1/NX3, the disc cal-
endar blinks, and “ALC OFF” is displayed, then the function
which was set before the test mode became active is displayed.
4. The automatic level control of the tape deck is in OFF status,
but while the s(CD) and [REC PAUSE/START] buttons are
pressed during recording, automatic level control goes in ON
status.
[Tape Deck Test Mode]
(In case of connected to the power feed jig)
Procedure:
1. Turn on the Power switch on the power feed jig.
2. Press three buttons of s(DECK B), A(DISC 1),
and s(CD) simultaneously.
3. The G(CD) and S(CD) LEDs blink, and then pressing G
(CD), G/g(DECK A), or G/g(DECK B) button can
make each play possible.
4. Also, the other functions are enabled by pressing two buttons
simultaneously.
A combination of respective functions and buttons is as fol-
lows.
function button
CD AMS – s(DECK A), S(CD)
AMS + s(DECK A), s(CD)
FR s(DECK B), S(CD)
FF s(DECK B), s(CD)
Deck-A REW/AMS – s(CD), g(DECK A)
FF/AMS + s(CD), G(DECK A)
Deck-B REW/AMS – s(CD), g(DECK B)
FF/AMS + s(CD), G(DECK B)
Note: Check that CD/TC signal change switch of relay connector jig is
set to the TC position.

14
SECTION 5
MECHANICAL ADJUSTMENTS SECTION 6 ELECTRICAL ADJUSTMENTS
Precaution
1. Clean the following parts with a denatured alcohol-moistened
swab:
record/playback heads pinch rollers
erase head rubber belts
capstan idlers
2. Demagnetize the record/playback head with a head demagne-
tizer.
3. Do not use a magnetized screwdriver for the adjustments.
4. After the adjustments, apply suitable locking compound to the
parts adjusted.
5. The adjustments should be performed with the rated power sup-
ply voltage unless otherwise noted.
Torque Measurement
31 to 71 g • cm
(0.43 – 0.98 oz • inch)
2 to 6 g • cm
(0.03 – 0.08 oz • inch)
31 to 71 g • cm
(0.43 – 0.98 oz • inch)
2 to 6 g • cm
(0.03 – 0.08 oz • inch)
71 to 143 g • cm
(0.99 – 1.99 oz • inch)
100 g or more
(3.53 oz or more)
100 g or more
(3.53 oz or more)
Mode
FWD
Torque meter
CQ-102C
Meter reading
FWD
back tension
REV
REV
back tension
FF/REW
FWD tension
REV tension
CQ-102C
CQ-102RC
CQ-102RC
CQ-201B
CQ-403A
CQ-403R
1. Demagnetize the record/playback head with a head demagne-
tizer.
2. Do not use a magnetized screwdriver for the adjustments.
3. After the adjustments, apply suitable locking compound to the
parts adjust.
4. The adjustments should be performed with the rated power
supply voltage unless otherwise noted.
5. The adjustments should be performed in the order given in
this service manual. (As a general rule, playback circuit ad-
justment should be completed before performing recording
circuit adjustment.)
6. The adjustments should be performed for both L-CH and R-
CH.
7. Switches and controls should be set as follows unless other-
wise specified.
8. Set to the DOLBY NR OFF.
9. Set to the test mode. (See page 13)
• Test Tape
Record/Playback Head Azimuth Adjustment
Note: Perform this adjustments for both decks
Procedure:
1. Mode: Playback
Tape Signal Used for
P-4-A100 10 kHz, –10 dB Azimuth Adjustment
WS-48B 3 kHz, 0 dB Tape Speed Adjustment
P-4-L300 315 Hz, 0 dB Level Adjustment
0 dB=0.775 V
TAPE DECK SECTION
DECK A DECK B
AUDIO OUT jac
k
+
–
level meter
test tape
P-4-A100
(10 kHz, –10 dB)
PFJ-1
or
STR-NX1/
NX3
set

15
Tape Speed Adjustment DECK B
• Execute only if connected to the STR-NX1/NX3
Mode: Playback
1. Insert the WS-48B into the deck B.
2. Press the G(DECK B) button.
3. Press the [HI-DUB] button in playback mode.
Then at HIGH speed mode.
4. Adjust RV1001 on the LEAF SW board do that frequency
counter reads 6,000 ± 180 Hz.
5. Press the [HI-DUB] button.
Then back to NORMAL speed mode.
6. Adjust RV1002 on the LEAF SW board so that frequency
counter reads 3,000 ± 90 Hz.
Adjustment Location: LEAF SW board
Sample value of Wow and Flutter: 0.3% or less W.RMS (JIS)
(WS-48B)
Playback level Adjustment DECK A DECK B
Procedure:
Mode: Playback
Deck A is RV311 (L-CH) and RV411 (R-CH), Deck B is RV301
(L-CH) and RV401 (R-CH) so that adjustment within specified
value as follows.
Specified Value:
AUDIO OUT jack PB level: 301.5 to 338.3 mV (–8.2 to –7.2
dB) level
difference between the channels: within ± 0.5 dB
Adjustment Location: AUDIO board
2. Turn the adjustment screw and check output peaks. If the peaks
do not match for L-CH and R-CH, turn the adjustment screw
so that outputs match within 1dB of peak.
3. Mode: Playback
4. Repeat step 1 to 3 in playback (REV) mode.
5. After the adjustments, apply suitable locking compound to the
pats adjusted.
Adjustment Location:Playback Head (Deck A).
Record/Playback/Earth Head (Deck B).
Screw
position
L-CH
peak
within
1dB
Output
level
L-CH
peak R-CH
peak
within
1dB
Screw
position
R-CH
peak
test tape
P-4-A100
(10 kHz, –10 dB) oscilloscope
AUDIO OUT (R) jack
L-CH
R-CH
VH
waveform of oscilloscope
in phase 45 ° 90 ° 135 ° 180 °
good wrong
AUDIO OUT (L) jack
L-CH
R-CH
PFJ-1
or
STR-NX1/
NX3
set
forward
reverse
Open the cassette holder
and unhock six claws of
the sub panel (TC2)
with tweezers or something,
then remove the sub panel (TC2).
+
–
AUDIO OUT jack
test tape
WS-48B
(3 kHz, 0 dB) frequency counter
set STR-NX1/
NX3
+
–
test tape
P-4-L300
(315 Hz, 0 dB) level meter
AUDIO OUT jack
PFJ-1
or
STR-NX1/
NX3
set

16
REC Bias Adjustment DECK B
Procedure:
1. Mode: Record
2. Mode: Playback
3. Confirm playback the signal recorded in step 1 become speci-
fied value as follows.
If these values are out of specified value, adjust the RV341 (L-
CH) and RV441 (R-CH) on the AUDIO board to repeat steps
1and 2.
Specified value: Playback output of 315 Hz to playback
output of 10 kHz: ± 0.5 dB
Adjustment Location: AUDIO board
REC Level Adjustment DECK B
Procedure:
1. Mode: Record
2. Mode: Playback
3. Confirm playback the signal recorded in step 1 become speci-
fied value as follows.
If these values are out of specified value, adjust the RV301 (L-
CH) and RV351 (R-CH) on the MAIN board to repeat steps 1
and 2.
Specified value:
AUDIO OUT jack PB level: 47.2 to 53.0 mV (–24.3 to –23.3 dB)
Adjustment Location: MAIN board
– MAIN BOARD (Conductor Side) –
– AUDIO BOARD (Component Side) –
– LEAF SW BOARD (Component Side) –
RV401
RV301 RV341 RV311 RV411
IC602 CN601
LRRL
     
RV441
PB LEVEL
– DECK B –
REC BIAS
LR
  
PB LEVEL
– DECK A –
TAPE SPEED
RV1002 RV1001
(NORMAL) (HIGH)
CN1001
         
attenuator
1) 315 Hz
2) 10 kHz 50 mV (–23.8 dB)
PFJ-1
or
STR-NX1/
NX3
AUDIO IN jack



600 Ω
blank tape
CN-123
AF OSC
set
+
–
recorded
portion level meter
AUDIO OUT jack
PFJ-1
or
STR-NX1/
NX3
set
attenuator
315 Hz, 50 mV (–23.8 dB)
AUDIO IN jack
600
Ω
blank tape
CN-123
AF OSC
PFJ-1
or
STR-NX1/
NX3 set
+
–
recorded
portion level meter
AUDIO OUT jack
PFJ-1
or
STR-NX1/
NX3
set
RV351
(R-CH)
RV301
(L-CH)
IC301
REC
LEVEL









CN3011
3

17
Note:
1. CD Block is basically designed to operate without adjustment. There-
fore, check each item in order given.
2. Use YEDS-18 disc (3-702-101-01) unless otherwise indicated.
3. Use an oscilloscope with more than 10 MΩimpedance.
4. Clean the object lens by an applicator with neutral detergent when the
signal level is low than specified value with the following checks.
5. Use the following extension cables and relay connector.
• Extension cable (19P) (Part No. J-2501-011-B)
Relay connector (Part No. J-2501-167-A)
(BD board CN101 to MAIN board CN111)
• Extension cable (17P) (with connector) (Part No. J-2501-167-A)
(CONNECTOR board CN701 to MAIN board CN301)
1. S-CURVE CHECK
Procedure:
1. Connect oscilloscope to TP (FEO).
2. Connect between TP (FEO) and TP (VC) by lead wire.
3. Connect between TP (AGCCON) and TP (GND) by lead wire.
4. Turn the power ON.
5. Load a disc (YEDS-18) and turn the power ON again and ac-
tuate the focus search. (Actuate the focus search when disc
tray is moving in and out)
6. Check the oscilloscope waveform (S-curve) is symmetrical
between A and B. And confirm peak to peak level within
2.4±0.7 Vp-p.
S-curve waveform
7. After check, remove the lead wire connected in step 2.
Note: • Try to measure several times to make sure than the ratio ofA : B
or B : A is more than 10 : 7.
• Take sweep time as long as possible and light up the brightness
to obtain best waveform.
CD SECTION
A
B
symmetry
within 2.4
± 0.7 Vp-p
+
–
BD board
TP (RF)
TP (VC)
oscilloscope
VOLT/DIV: 200 m
V
TIME/DIV: 500 ns
level:
1.2
± 0.2 Vp-p
+
–
BD board
TP (FEO)
TP (VC)
oscilloscope
2. RF LEVEL CHECK
Procedure:
1. Connect oscilloscope to TP (RF).
As TP (RF) and TP (VC) are located at the edge of board, clip
them together with the board using alligator clips.
2. Turn the power ON.
3. Load a disc (YEDS-18) and playback.
4. Confirm that oscilloscope waveform is clear and check RF sig-
nal level is correct or not.
Note: Clear RF signal waveform means that the shape “ ” can be clearly
distinguished at the center of the waveform.
RF signal waveform

2121
HTC-NX1
7-3. SCHEMATIC DIAGRAM – BD Board – • See page 32 for Waveforms. •See page 32 for IC Block Diagrams.
The components identified by mark 0or dotted
line with mark 0are critical for safety.
Replaceonly with partnumber specified.
Lescomposantsidentifiésparunemarque0sont
critiques pour la sécurité. Ne les remplacer que
par une pièce portant le numéro spécifié.
• Voltages and waveforms are dc with respect to ground
under no-signal conditions.
no mark : CD PLAY
(Page 29)

2323
HTC-NX1
7-5. SCHEMATIC DIAGRAM – CD MOTOR/SENSOR Section – • See page 33 for IC Block Diagram.
• Voltages are dc with respect to ground under no-signal
conditions.
no mark : CD PLAY
(Page 29)
(Page 29)

2525
HTC-NX1
7-7. SCHEMATIC DIAGRAM – AUDIO Board – • See page 33 for IC Block Diagram.
• Voltages are dc with respect to ground under no-signal
conditions.
no mark :TAPE PLAYBACK
( ) : RECORD
PB LEVEL (L)
(DECK A)
PB LEVEL (R)
(DECK A)
PB LEVEL (L)
(DECK B)
PB LEVEL (R)
(DECK B)
PB EQ AMP
(DECK A)
PB EQ AMP
(DECK B)
SWITCHING
REC BIAS (L)
(DECK B)
REC BIAS (R)
(DECK B)
BIAS OSC
REC BIAS
-6.8
(PLAYBACK)
D
NC
A +7.5V
APB–LCH
APB–RCH
AGND
BPB–LCH
BPB–RCH
A –7.5V
–VBIAS (–7.5V)
+VBIAS (+7.5V)
B–REC–RCH
B–REC–LCH
TC–HEAD–GND
The components identified by mark 0or dotted
line with mark 0are critical for safety.
Replaceonly with partnumber specified.
Lescomposantsidentifiésparunemarque0sont
critiques pour la sécurité. Ne les remplacer que
par une pièce portant le numéro spécifié.
(Page 28)

2626
HTC-NX1
7-8. PRINTED WIRING BOARD – LEAF SW Board – • See page 19 for Circuit Boards Location.
7-9. SCHEMATIC DIAGRAM – LEAF SW Board –
• Voltages are dc with respect to ground under no-signal
conditions.
no mark :TAPE PLAYBACK
( ) : RECORD
∗: Impossible to measure
05
DECK A
PLUNGER
DECK B
PLUNGER
(DECK A PLAY)
(DECK A HALF) (DECK A 120/70) (DECK A REC)
(DECK B HALF)
(DECK B PLAY)
(DECK B 120/70)
(DECK B REC)
21
21
L
4
12
34
12
3
()
DECK B
PLUNGER
DECK A
PLUNGER
(CAPSTAN)
(DECK A 120/70)
(DECK A HALF)
(DECK A REC)
(DECK B HALF)
(DECK B REC)
(DECK B 120/70)
ROTATION DETECT SENSOR
(DECK A)
ROTATION DETECT
SENSOR (DECK B)
(DECK A PLAY) (DECK B PLAY)
E
CONTROL SWITCH
CAPM–
CAPM+
CAPM–H/L
A–TRGM
TRGM–GND
B–TRGM
A–SHUT
DGND
A–HALF
+5V
A–120/70
B–SHUT
A PLAY
B–HALF / REC–A / REC–B
B–120/70
B PALY
NC
(Page 27)
(Page 28)

2828
HTC-NX1
7-11. SCHEMATIC DIAGRAM – MAIN Board (1/2) –
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replaceonly with partnumber specified.
Lescomposantsidentifiésparunemarque0sont
critiques pour la sécurité. Ne les remplacer que
par une pièce portant le numéro spécifié.
• Voltages are dc with respect to ground under no-signal
conditions.
no mark : CD PLAY
( ) :TAPE PLAYBACK (DECK A)
[ ] :TAPE PLAYBACK (DECK B)
〈〈 〉〉 : RECORD
(Page 25)
(Page 26)
(Page 29)

2929
HTC-NX1
7-12. SCHEMATIC DIAGRAM – MAIN Board (2/2) – • See page 32 forWaveform.
[ ] :TAPE PLAYBACK (DECK B)
〈〈 〉〉 : RECORD
∗: Impossible to measure
• Voltages and waveforms are dc with respect to ground
under no-signal conditions.
no mark : CD PLAY
( ) :TAPE PLAYBACK (DECK A)
(Page 23)
(Page 23)
(Page 21)
(Page 28)
(Page 31)
(Page 31)
(Page 31)

3131
HTC-NX1
7-14. SCHEMATIC DIAGRAM – PANEL Section –
• Voltages are dc with respect to ground under no-signal
conditions.
no mark : CD PLAY
(Page 29)
(Page 29)
(Page 29)

39
(3) CD MECHANISM DECK SECTION-1
(CDM53D-K1BD33)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
151
151
151
151
165
164
151
176
153
151 175
151
151
156
157
158
155 154
159
151161
162
160
151
151
151
177
169
167
151
166
151
171
172
170
173
168
151
171
170
174
151
152
M702
#3 #3
#3
151 4-218-253-01 SCREW (M2.6), +BVTP
*152 1-671-508-21 LOAD MOTOR BOARD
153 4-220-261-01 GEAR (EJECT)
*154 1-671-502-21 INT/COUNT SW BOARD
*155 1-671-504-21 SENSOR BOARD
156 4-212-676-03 SPRING (LID), TORSION
157 4-220-285-01 LID (DISC)
158 4-985-672-01 SCREW (+PTPWH M2.6), FLOATING
159 A-4672-622-F BASE (GUIDE) ASSY, FITTING
*160 1-671-503-21 OUT SW BOARD
*161 1-671-789-21 SENSOR 2 BOARD
162 4-220-274-01 HOLDER (SENSOR)
*164 1-671-505-21 IN SW BOARD
165 A-4680-437-A MAGNET ASSY
166 4-214-129-01 COVER
167 4-211-235-01 BELT (COMMUNICATION)
168 4-211-236-01 BELT (LOADING)
169 4-220-278-01 PULLEY (MODE)
170 4-220-276-01 PULLEY (LD)
171 4-220-267-01 GEAR (LD DECELERATION)
172 4-220-272-01 LEVER (GOOSENECK)
173 4-220-271-01 GEAR (TRAY)
*174 1-671-506-21 CONNECTOR BOARD
175 3-341-549-21 SCREW (2.6X12) (DIA. 7.5), +PTP WH
176 4-213-488-04 CHASSIS (MOLD B)
177 4-213-579-01 BRACKET (CHASSIS)
M702 X-4950-342-1 MOTOR (LOADING) ASSY

40
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
210 213
215
214
217
220
218
219
221
222
201
223
224
227
229 230
231
232
225
226
228
219
216
210
202
202
201
219
BU-K1BD33
201 236
219
237
235
233
234
201
204
204
205
204
202
202
209
212
211
#3
M701
#3
#3
#3
not supplied
not
supplied not
supplied
not supplied
not supplied
#3 S707
B
B
A
A
201 4-985-672-01 SCREW (+PTPWH M2.6), FLOATING
202 4-220-933-01 INSULATOR
204 4-213-487-53 TRAY (SUB)
205 4-213-482-02 CHASSIS (MOLD A)
209 X-4950-322-3 HOLDER (BU) ASSY
210 4-211-244-01 SCREW, STEP
211 4-211-223-04 SLIDER (U/D)
212 4-933-134-01 SCREW (M2.6), +PTPWH
213 4-211-224-03 BASE (STOCKER), FITTING
214 4-211-211-02 STOCKER (R)
215 4-211-210-03 STOCKER (L)
216 4-220-261-01 GEAR (EJECT)
217 4-220-266-01 GEAR (MODE DECELERATION)
218 4-220-276-01 PULLEY (LD)
219 4-218-253-01 SCREW (M2.6), +BVTP
220 4-211-237-01 BELT (MODE)
221 4-220-283-01 SLIDER (SHUTTER)
222 4-212-678-01 SPRING (SHUTTER), TENSION
223 4-220-284-01 SLIDER (SELECTION)
224 4-220-275-01 GEAR (CHUCKING)
225 4-211-245-01 SPRING, COMPRESSION
*226 1-671-507-21 CLAMP MOTOR BOARD
227 4-220-265-01 GEAR (LD MOVABLE)
228 4-220-269-01 GEAR (SELECTION)
229 4-211-242-01 SHAFT (SELECTION GEAR)
230 4-220-268-01 GEAR (LD DECELERATION B)
231 4-220-262-01 GEAR (RELAY)
232 4-220-273-01 LEVER (SELECTION)
233 4-216-879-01 SPRING (GEAR), COIL
234 3-701-446-21 WASHER
235 4-220-270-01 GEAR (GEAR A)
236 4-220-264-01 GEAR (U/D SLIDER)
237 4-220-263-01 GEAR (GEAR B)
M701 X-4950-341-1 MOTOR (CLAMP) ASSY
(ELEVATOR UP/DOWN)
S707 1-418-045-01 ENCODER, ROTARY
(DISC TRAY ADDRESS DETECT)
(4) CD MECHANISM DECK SECTION-2
(CDM53D-K1BD33)

41
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
not supplied
not supplied
not supplied
M102
252
251
253 258
257
254
255 256
M101
251 4-996-243-01 SCREW (M2), +PSW
252 A-4724-330-A BD BOARD, COPLETE
0253 8-820-026-03 OPTICAL PICK-UP KSM-213BFN/C2NP
254 3-713-786-51 SCREW +P 2X3
255 2-626-908-01 SHAFT, SLED
256 2-627-003-02 GEAR (B) (RP)
257 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
258 4-216-878-11 COLLAR
M101 X-2646-110-3 MOTOR ASSY, SPINDLE
M102 X-2625-769-1 MOTOR ASSY, SLED
The components identified by
mark 0or dotted line with
mark 0are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
(5) CD BASE UNIT SECTION
(BU-K1BD33)

42
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
401
402
402
403
403
404
404
405
405
406
406
407
408
408
407
HRPE101
HP101
409
401 3-376-464-11 SCREW (+PTT 2.6X6), GROUND POINT
402 3-036-914-01 RIVET
403 3-016-574-11 SPRING (HEAD), TENSION
404 X-3374-156-4 PINCH LEVER (REV) ASSY
405 X-3374-155-4 PINCH LEVER (FWD) ASSY
406 3-016-564-01 BASE (PINCH LEVER FWD)
407 3-016-565-01 BASE (PINCH LEVER REV)
408 3-026-892-01 SPRING (CASSETTE), LEAF
*409 A-2007-731-A AUDIO BOARD, COMPLETE
HP101 A-2056-681-A DECK (A) ASSY, HEAD (PLAYBACK)
HRPE101A-2056-682-A DECK (B) ASSY, HEAD (REC/PB/ERASE)
(6) TAPE MECHANISM DECK SECTION-1
(TCM-230AWR2)

43
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
451
452
452
453
454
455
455
456
456
457
458
458
459
464
464
464
464
459
460
460
461
462
463
M1
#6
#5
#4
465
*451 X-3374-214-4 CHASSIS ASSY, MAIN
452 3-016-570-01 BELT (CAPSTAN)
453 3-016-569-01 BELT (TENSION)
454 3-017-360-01 BRACKET (MOTOR)
455 X-3376-497-3 FLYWHEEL (FWD) ASSY
456 X-3374-235-1 FLYWHEEL (REV) ASSY
457 X-3374-238-1 PULLEY ASSY, TENSION
458 3-024-405-01 BELT (FR2)
459 A-2004-629-A MECHANICAL BLOCK ASSY
460 3-016-566-01 SLIDER, REVERSE
*461 A-2007-732-A LEAF SW BOARD, COMPLETE
462 3-016-575-11 SPRING, TORSION
463 3-019-208-01 WASHER, STOPPER
464 3-030-823-01 SCREW (+BVTT) (2X3.5)
465 3-027-453-01 SPRING (GROUND), TENSION
M1 A-2004-628-A MOTOR ASSY, CAPSTAN
(7) TAPE MECHANISM DECK SECTION-2
(TCM-230AWR2)

44
SECTION 9
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AUDIO
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
Les composants identifiés par une
marque 0sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark 0or dotted line with mark
0are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
• Abbreviation
AUS : Australian model
CND: Canadian model
JE : Tourist model
KR : Korean model
MY : Malaysia model
SP : Singapore model
TH : Thai model
*A-2007-731-A AUDIO BOARD, COMPLETE
**********************
< CAPACITOR >
C301 1-162-289-31 CERAMIC 390PF 10% 50V
C302 1-126-968-11 ELECT 100uF 20% 6.3V
C303 1-162-282-31 CERAMIC 100PF 10% 50V
C304 1-130-483-00 MYLAR 0.01uF 5% 50V
C305 1-107-715-11 ELECT 22uF 20% 16V
C311 1-162-289-31 CERAMIC 390PF 10% 50V
C313 1-162-282-31 CERAMIC 100PF 10% 50V
C314 1-130-487-00 MYLAR 0.022uF 5% 50V
C315 1-126-233-11 ELECT 22uF 20% 50V
C331 1-137-427-11 FILM 120PF 5% 50V
C332 1-162-288-31 CERAMIC 330PF 10% 50V
C333 1-162-209-31 CERAMIC 27PF 5% 50V
C401 1-162-289-31 CERAMIC 390PF 10% 50V
C402 1-126-968-11 ELECT 100uF 20% 6.3V
C403 1-162-282-31 CERAMIC 100PF 10% 50V
C404 1-130-483-00 MYLAR 0.01uF 5% 50V
C405 1-107-715-11 ELECT 22uF 20% 16V
C411 1-162-289-31 CERAMIC 390PF 10% 50V
C413 1-162-282-31 CERAMIC 100PF 10% 50V
C414 1-130-487-00 MYLAR 0.022uF 5% 50V
C415 1-126-233-11 ELECT 22uF 20% 50V
C431 1-137-427-11 FILM 120PF 5% 50V
C432 1-162-288-31 CERAMIC 330PF 10% 50V
C433 1-162-209-31 CERAMIC 27PF 5% 50V
C601 1-104-396-11 ELECT 10uF 20% 16V
C602 1-104-396-11 ELECT 10uF 20% 16V
C611 1-104-396-11 ELECT 10uF 20% 16V
C612 1-104-396-11 ELECT 10uF 20% 16V
C621 1-137-150-11 FILM 0.01uF 5% 100V
C622 1-126-961-11 ELECT 2.2uF 20% 50V
C623 1-136-155-00 FILM 0.015uF 5% 50V
C624 1-130-481-00 MYLAR 0.0068uF 5% 50V
C625 1-130-481-00 MYLAR 0.0068uF 5% 50V
C627 1-124-903-11 ELECT 1uF 20% 50V
C628 1-136-153-00 FILM 0.01uF 5% 50V
C642 1-104-664-11 ELECT 47uF 20% 16V
< CONNECTOR >
CN601 1-563-834-21 SOCKET, CONNECTOR 15P
< IC >
IC601 8-759-111-44 IC uPC4570C-1
IC602 8-759-143-54 IC uPC1330HA
IC611 8-759-111-44 IC uPC4570C-1
< COIL >
L331 1-410-780-11 INDUCTOR 27mH
L431 1-410-780-11 INDUCTOR 27mH
L601 1-414-193-41 INDUCTOR 220uH
L602 1-414-193-41 INDUCTOR 220uH
< TRANSISTOR >
Q621 8-729-142-46 TRANSISTOR 2SC2001TP-LK
Q622 8-729-142-46 TRANSISTOR 2SC2001TP-LK
Q623 8-729-801-93 TRANSISTOR 2SD1387-34-TP
< RESISTOR >
R301 1-247-881-00 CARBON 120K 5% 1/4W
R302 1-249-409-11 CARBON 220 5% 1/4W
R303 1-249-433-11 CARBON 22K 5% 1/4W
R304 1-247-889-00 CARBON 270K 5% 1/4W
R305 1-247-858-11 CARBON 13K 5% 1/4W
R311 1-247-881-00 CARBON 120K 5% 1/4W
R312 1-247-807-31 CARBON 100 5% 1/4W
R314 1-247-882-11 CARBON 130K 5% 1/4W
R315 1-247-850-11 CARBON 6.2K 5% 1/4W
R331 1-249-430-11 CARBON 12K 5% 1/4W
R401 1-247-881-00 CARBON 120K 5% 1/4W
R402 1-249-409-11 CARBON 220 5% 1/4W
R403 1-249-433-11 CARBON 22K 5% 1/4W
R404 1-247-889-00 CARBON 270K 5% 1/4W
R405 1-247-858-11 CARBON 13K 5% 1/4W
R411 1-247-881-00 CARBON 120K 5% 1/4W
R412 1-247-807-31 CARBON 100 5% 1/4W
R414 1-247-882-11 CARBON 130K 5% 1/4W
R415 1-247-850-11 CARBON 6.2K 5% 1/4W
R431 1-249-430-11 CARBON 12K 5% 1/4W
R601 1-249-409-11 CARBON 220 5% 1/4W
R602 1-249-409-11 CARBON 220 5% 1/4W
R608 1-249-409-11 CARBON 220 5% 1/4W
R609 1-249-433-11 CARBON 22K 5% 1/4W
R611 1-249-409-11 CARBON 220 5% 1/4W
