Sony MHC-NXM1 User manual

©2004 Sony Corporation
2-022-183-11(2)
Mini Hi-Fi
Component
System
Operating Instructions ________________________
Инструкция по эксплуатации _________________
GB
RU
MHC-NXM1
MHC-NXM3

2GB
To prevent fire or shock hazard, do not
expose the unit to rain or moisture.
To prevent fire, do not cover the ventilation of the
apparatus with news papers, table-cloths, curtains, etc.
And don’t place lighted candles on the apparatus.
To prevent fire or shock hazard, do not place objects
filled with liquids, such as vases, on the apparatus.
This appliance is
classified as a CLASS 1
LASER product. This
markingislocatedonthe
rear exterior.
Don’t throw away the battery with
general house waste, dispose of it
correctly as chemical waste.
WARNING
Do not install the appliance in a confined space,
such as a bookcase or built-in cabinet.

3GB
How to use this manual...........................4
Playable discs..........................................4
Getting Started
Hooking up the system............................6
Setting the clock......................................8
CD/MP3 – Play
Loading a disc.........................................9
Playing a disc..........................................9
— Normal Play/Shuffle Play
Playing repeatedly.................................11
— Repeat Play
Creating your own program..................11
— Program Play
Tuner
Presetting radio stations........................12
Listening to the radio............................14
— Preset Tuning
— Manual Tuning
Using the Radio Data System (RDS)....15
(European model only)
Tape – Play
Loading a tape.......................................16
Playing a tape........................................16
Tape – Recording
Recording your favorite CD tracks on a
tape..................................................17
— CD-TAPE Synchro Recording
Recording on a tape manually...............18
— Manual Recording
Sound Adjustment
Adjusting the sound ..............................19
Timer
Falling asleep to music......................... 20
— Sleep Timer
Waking up to music.............................. 21
— Play Timer
Timer recording radio programs........... 22
— Rec Timer
Display
Turning off the display ......................... 23
— Power Saving Mode
Adjusting the brightness of the display
back light........................................ 23
Viewing information about the disc in the
display ............................................ 24
Optional Components
Hooking up optional components.........25
Listening to audio from a connected
component...................................... 26
Recording on a connected
component...................................... 26
Troubleshooting
Problems and remedies......................... 27
Messages............................................... 30
Additional Information
Precautions............................................ 31
Specifications........................................ 32
List of button locations and reference
pages............................................... 35
Table of Contents
GB

4GB
This manual mainly explains operations using
the remote, but the same operations can also be
performed using the buttons on the unit having
the same or similar names.
You can play back the following discs on this
system. Other discs cannot be played back.
List of playable discs
Discs that this system cannot
play
•CD-ROMs
• CD-Rs/CD-RWs otherthan those recorded in
the following formats:
– music CD format
– MP3 format that conforms to ISO96601)
Level 1/Level 2, Joliet or Multi Session2)
• A disc that has a non-standard shape (e.g.,
card, heart).
• A disc with paper or stickers on it.
• A disc that has the adhesive, cellophane tape,
or a sticker still left on it.
• Data part of CD-Extras3)
• Data track of Mixed CDs4)
1) ISO9660 Format
The most common international standard for the
logical format of files and folders on a CD-ROM.
There are several specification levels. In Level 1,
file names must be in the 8.3 format (no more than
eight characters in the name, no more than three
characters in the extension “.MP3”) and in capital
letters. Folder names can be no longer than eight
characters. There can be no more than eight nested
folder levels. Level 2 specifications allow file
names and folder names up to 31 characters long.
Each folder can have up to 8 trees.
For Joliet in the expansion format (file and folder
names can have up to 64 characters) make sure of
the contents of the writing software, etc.
2) Multi Session
This is a recording method that enables adding of
data using the Track-At-Once method.
Conventional CDs begin at a CD control area called
the Lead-in and end at an area called Lead-out. A
Multi Session CD is a CD having multiple sessions,
with each segment from Lead-in to Lead-out
regarded as a single session.
3) CD-Extra: This format records audio (audio CD
data) on the tracks in session 1 and data on the tracks
in session 2.
4) Mixed CD: This format records data on the first
track and audio (audio CD data) on the second and
subsequent tracks of a session.
How to use this manual
Playable discs
Format of discs Disc logo
Audio CDs
CD-R/CD-RW
(audio data/MP3 files)

5GB
Notes on CD-R and CD-RW
• Some CD-Rs or CD-RWs cannot be played
on this system depending upon the recording
quality or physical condition of the disc, or
the characteristics of the recording device.
Furthermore,the discwill notplayif it hasnot
been correctly finalized. For more
information, see the operating instructionsfor
the recording device.
• Discs recorded on CD-R/CD-RW drives may
not be played back because of scratches, dirt,
recording condition or the driver’s
characteristics.
• CD-R and CD-RW discs recorded in multi-
session that have not ended by “closing the
session” are not supported.
• The system may be unable to play MP3
format files that do not have the “.MP3”
extension.
• Attempting to play non-MP3 format files that
havethe“.MP3”extensionmayresultinnoise
or malfunction.
• With formats other than ISO9660 level 1 and
2, folder names or file names may not be
displayed correctly.
• The following discs take a longer time to start
playback.
– a disc recorded with complicated tree
structure.
– a disc recorded in Multi Session.
– a disc to which data can be added (non-
finalized disc).
Music discs encoded with
copyright protection
technologies
This product is designed to playback discs that
conform to the Compact Disc (CD) standard.
Recently, various music discs encoded with
copyright protection technologies are marketed
by some record companies. Please be aware that
among those discs, there are some that do not
conform to the CD standard and may not be
playable by this product.
Cautions when playing a disc
that is recorded in Multi
Session
• If the disc begins with a CD-DA session, it is
recognized as a CD-DA (audio) disc, and
playback continues until an MP3 session is
encountered.
• If the disc begins with an MP3 session, it is
recognized as an MP3 disc, and playback
continues until a CD-DA (audio) session is
encountered.
• The playback range of an MP3 disc is
determined by the tree structure of files
produced by analyzing of the disc.
• A disc with a mixed CD format will be
recognized as a CD-DA (audio) disc.

6GB
Perform the following procedures 1to 4to hook up your system using the supplied cords and
accessories. MHC-NXM3 is used for illustration purpose.
1Connect the speakers.
Connect the right and left speaker cords to
the SPEAKER terminals on the unit and to
theterminalsonthespeakers(MHC-NXM3
only) as shown below.
Main Unit
Speakers (MHC-NXM3 only)
2Connect the FM and AM antennas.
Set up the AM loop antenna, then connect
it.
Getting Started
Hooking up the system
AM loop antenna
Right speaker Left speaker
FM lead antenna
RL
SPEAKER
Black (#)

Getting Started
7GB
Note
Keep the antennas away from the speaker cords.
3For models with a voltage selector, set
VOLTAGE SELECTOR to the local
power line voltage.
Refer to the print on your system’s
VOLTAGE SELECTOR for available
settings.
* Saudi Arabian model: 120 – 127 V
4Connect the power cord to a wall
outlet.
The demonstration appears in the display.
When you press ?/1, the system turns on
and the demonstration automatically ends.
If the plug does not fit the wall socket,
detach the supplied plug adaptor (only for
models equipped with an adaptor).
Inserting two R6 (size AA)
batteries into the remote
Note
If you do not use the remote for a long period of time,
remove the batteries to avoid possible damage from
battery leakage and corrosion.
Tip
With normal use, the batteries should last for about six
months. When the remote no longer operates the
system, replace both batteries with new ones.
Attaching the speaker pads
Attach the supplied speaker pads to the bottom
of the speakers to stabilize the speakers and
prevent them from slipping.
AM
FM 75
Ω
COAXIAL
Extend the FM lead antenna horizontally
AM loop antenna
When carrying this system
Perform the following procedure to protect
the CD mechanism.
Use buttons on the unit for the operation.
1Make sure that all discs are removed
from the system.
2Press CD.
3Hold down xand then press CD until
“LOCK” appears.
4Unplug the power cord.

8GB
Use buttons on the remote for the operation.
1Press ?/1 to turn on the unit.
2Press CLOCK/TIMER SET.
3Press .or >repeatedly to set the
hour.
4Press ENTER.
5Press .or >repeatedly to set the
minute.
6Press ENTER.
The clock starts working.
To adjust the clock
1Press CLOCK/TIMER SET.
2Press .or >repeatedly to select
“CLOCK SET?”, then press ENTER.
3Do the same procedures as step 3 to 6
above.
Note
The clock is not displayed in Power Saving Mode.
Setting the clock

CD/MP3 – Play
9GB
Use buttons on the unit for the operation.
1Press DISC 1 – 5 to select the disc tray.
When no disc is in the disc tray you
selected, “No Disc” appears. Perform step 2
while “DISC-1” (eg., 2 – 5) flashes.
2Press CD Z.
3Place a disc with the label side up on
the disc tray.
4Press CD Zagain to close the disc
tray.
Notes
• Do notuse a disc with tape, seals orpaste on itas this
may cause malfunction.
• Do not forcibly press the disc tray closed with your
finger, as this may cause malfunction.
This system lets you play audio CDs and discs
with MP3 audio tracks.
Example: When a disc is loaded
1Press CD (or FUNCTION repeatedly) to
switch the function to CD.
2Press PLAY MODE repeatedly in stop
mode until the mode you want appears
in the display.
CD/MP3 – Play
Loading a disc
Whenyouplay
a 8 cm disc,
place it on the
inner circle of
the tray.
Playing a disc
— Normal Play/Shuffle Play
Select To play
ALL DISCS
(Normal Play) All discs in the disc tray continuously.
1DISC
(Normal Play) The tracks on the disc you have selected in original
order.
ALBM
(Normal Play) All MP3 audio tracks in the album on the disc you have
selected in original order.
When playing a non-MP3
disc, Album Play performs
the same operationas 1DISC
Play.
ALL DISCS
SHUF (Shuffle
Play)
The tracks on all discs in
random order.
1DISC SHUF
(Shuffle Play) The tracks on the disc you have selected in random
order.
ALBM SHUF
(Shuffle Play) The MP3 audio tracks in the album on the disc you have
selected in random order.
When playing a non-MP3
disc, Album Shuffle Play
performs the same operation
as 1DISC SHUF Play.
PGM
(Program Play) The tracks on the disc in the order you want them to be
played (see “Creating your
own program” on page 11).
DISC
1 2 3 4 5 A B
Track number
Disc tray
number
Playing time
Disc presence indicator
continued

10GB
3Press N(or nN on the unit).
Other operations
* You may not be able to search between multiple files.
Also, the time may not be displayed correctly for
some files.
Notes
• You cannot change the play mode during playback.
• Some time may be needed to start playback of discs
recorded in complex configurations such as many
layers.
• When the disc is inserted, the player reads all the
tracks on that disc. If there are many albums or non-
MP3 audio tracks on the disc, it may take a long time
for play to begin or for the next MP3 audio track to
start play.
• Do not save unnecessary albums or tracks other than
MP3 ones in the disc to be used for MP3 listening.
We recommend that you do not save other types of
tracks or unnecessary albums on a disc that has MP3
audio tracks.
• An album that does not include an MP3 audio track
is skipped.
• Maximum album number: 150 (including root
folder)
• The maximum number of MP3 audio tracks and
albums that can be contained on a single disc is 300.
• Playback is possible up to 8 levels.
• MP3 audio tracks are played back in the order that
they are recorded on the disc.
• Depending on the encoding/writing software,
recording device, or the recording media used at the
time an MP3 audio track is recorded, you may
encounter such problems as disabled playback,
sound interruptions, and noise.
Tip
When disc access takes a long time, set “CD POWER
ON” by CD power manage function (page 13).
To Do this
Stop play Press x.
Pause Press X. Press again to resume
play.
Select a track Press .or >repeatedly.
Select an album
of MP3* Press ALBUM – or + repeatedly after step 2.
Find a point in a
track Keep pressing mor Mduring playback and release it at the
desired point.
Select a disc in
stop mode Press DISC SKIP (or DISC 1 – 5 on the unit).
Switch to CD
function from
another source
Press DISC 1 – 5 on the unit
(Automatic Source Selection).
Remove a disc Press DISC 1 – 5 on the unit, then
press CD Zon the unit.

CD/MP3 – Play
11GB
You can play all the tracks or a single track on a
disc repeatedly.
Press REPEAT repeatedly during playback
until “REP” or “REP1” appears.
REP: For all the tracks on a disc, or all the MP3
audio tracks in an album up to five times.
REP1: For a single track only.
To cancel Repeat Play
Press REPEAT repeatedly until both “REP” and
“REP1” disappear.
Notes
• You cannot select “REP” and “ALL DISCS SHUF”
at the same time.
• When you select “REP1”, that track is repeated
endlessly until “REP1” is canceled.
You can make a program of up to 25 steps from
all the discs in the order you want to play them.
You can synchro record the programmed tracks
onto a cassette tape (page 17).
1Press CD (or FUNCTION repeatedly) to
switch the function to CD.
2Press PLAY MODE in stop mode
repeatedly until “PGM” appears.
3Press DISC SKIP (or DISC 1 – 5 on the
unit) to select a disc.
To program all the tracks on a disc at once,
proceed to step 5 with “AL” displayed.
4Press .or >repeatedly until the
desired track number appears.
When programming the MP3 audio tracks,
press ALBUM – or + to select album, then
press .or >repeatedly until the
desired track number appears.
5Press ENTER.
The track is programmed.
The program step number appears,
followed by the total playing time.
6Program additional discs or tracks.
7Press N(or nN on the unit).
Program Play starts.
Playing repeatedly
— Repeat Play
Creating your own
program
—ProgramPlay
To program Repeat steps
Other discs 3 and 5
Othertracksonthe
same disc 4 and 5
Other tracks on
other discs 3 to 5
DISC
PGM
1 2 3 4 5 A B
Selected track
number Total playing time (including selected track)
Disc tray number
continued

12GB
Other operations
Tips
• The program you made remains after Program Play
finishes. To play the same program again, press CD
(or FUNCTION repeatedly) to switch the function to
CD, then press N(ornN on the unit). However,
the program is cleared when you open the disc tray.
• “– –.– –” appears when the total CD program time
exceeds 100 minutes, or when you select a CD track
whose number is 21 or over, or when you select an
MP3 audio track.
You can preset up to 20 FM stations and 10 AM
stations. You can then tune in any of those
stations simply by selecting the corresponding
preset number.
Automatic tuning preset
You can automatically tune in all of the stations
that can be received in your area and then store
the radio frequency of the desired stations.
1Press TUNER BAND (or FUNCTION
repeatedly) to switch the function to
tuner.
2Press TUNER BAND repeatedly to
select “FM” or “AM”.
3Press TUNING MODE repeatedly until
“AUTO” appears in the display.
4Press – or + (or TUNING – or + on the
unit).
The frequency changes as the system scans
for a station. Scanning stops automatically
when a station is tuned in. At that time,
“TUNED” and “ST” (for stereo program
only) appear.
If “TUNED” does not appear and the
scanning does not stop
Set the frequency of the desired radio
station as described in “Manual tuning
preset” (page 13).
5Press TUNER MEMORY.
The preset number flashes. Perform steps 6
and 7 while the preset number flashes.
To Do this
Cancel Program Play Press PLAY MODE
repeatedly in stop mode
until “PGM” disappears.
Clear a track from
the end Press CLEAR in stop mode.
Tuner
Presetting radio stations
ST TUNED
MHz
1 2 3 4 5 A B
Preset number

Tuner
13GB
6Press – or + (or TUNING – or + on the
unit) repeatedly to select the desired
preset number.
7Press ENTER.
8Repeat steps 2 through 7 to store other
stations.
Tip
Press TUNING MODE to stop scanning.
Manual tuning preset
You can manually tune in and store the radio
frequency of the desired stations.
1Press TUNER BAND (or FUNCTION
repeatedly) to switch the function to
tuner.
2Press TUNER BAND repeatedly to
select “FM” or “AM”.
3Press TUNING MODE repeatedly until
“AUTO”and “PRESET”disappearfrom
the display.
4Press – or + (or TUNING – or + on the
unit) repeatedly to tune in the desired
station.
5Press TUNER MEMORY.
6Press – or + (or TUNING – or + on the
unit) repeatedly to select the desired
preset number.
7Press ENTER.
8Repeat steps 2 through 7 to store other
stations.
Other operations
To improve tuner reception
When tuner reception is poor, set CD player
power off by CD power manage function.
CDpowerisfactorysettoon.Usebuttonson the
unit for the operation.
1Press CD.
2Press ?/1 to turn off the system.
3Press ?/1 while holding x.
“CD POWER OFF” appears.
To set CD power on
Repeat the procedure above and “CD POWER
ON” appears.
Notes
• When “CD POWER OFF” is selected, disc access
time is increased.
• You cannot change the setting in Power Saving
Mode (page 23).
To change the AM tuning interval
(except for European, Russian
and Saudi Arabian models)
The AM tuning interval is factory-preset to
9 kHz(or10 kHzfor someareas).Tochangethe
AM tuning interval, tune in any AM stationfirst,
then turn off the system. While holding x, press
?/1 on the unit. When you change the interval,
all the AM preset stations are erased. To reset
the interval, repeat the same procedure.
Note
You cannot change the AM tuning interval in Power
Saving Mode (page 23).
Tips
• The preset stations are retained for about half a day
even if you disconnect the power cord or if a power
failure occurs.
• To improve broadcast reception, adjust the supplied
antennas, or connect a commercially available
external antenna.
To Do this
Tune in a station
with a weak signal Follow the procedure described in “Manual tuning preset”
(page 13).
Set another station
to the existing
preset number
After step 5, press – or + (or
TUNING – or + on the unit)
repeatedly to select the preset
number you want to store the
station.

14GB
You can listen to a radio station either by
selecting a preset station, or by manually tuning
in the station.
Listening to a preset station
— Preset Tuning
Preset radio stations in the tuner’s memory first
(see “Presetting radio stations” on page 12).
1Press TUNER BAND (or FUNCTION
repeatedly) to switch the function to
tuner.
2Press TUNER BAND repeatedly to
select “FM” or “AM”.
3Press TUNING MODE repeatedly until
“PRESET” appears in the display.
4Press – or + (or TUNING – or + on the
unit) repeatedly to select the desired
preset station.
Listening to non-preset radio
station
— Manual Tuning
1Press TUNER BAND (or FUNCTION
repeatedly) to switch the function to
tuner.
2Press TUNER BAND repeatedly to
select “FM” or “AM”.
3Press TUNING MODE repeatedly until
“AUTO”and“PRESET”disappearfrom
the display.
4Press – or + (or TUNING – or + on the
unit) repeatedly to tune in the desired
station.
Note
When switching to CD function from tuner, a longer
time may be required to access the disc. In this case, set
“CD POWER ON” by CD power manage function
(page 13).
Tips
• To improve broadcast reception, adjust the supplied
antennas, or connect a commercially available
external antenna.
• When an FM stereo program has static noise, press
FM MODE repeatedly until “MONO” appears.
There will be no stereo effect, but the reception will
improve.
• Press TUNING MODE repeatedly until “AUTO”
appears in step 3 above, then press – or + (or
TUNING – or + on the unit). The frequency
indication changes and scanning stops when the
system tunes in a station (Automatic Tuning).
• To record the radio programs, use manual recording
(page 18).
Listening to the radio

Tuner
15GB
What is the Radio Data
System?
Radio Data System (RDS) is a broadcasting
service that allows radio stations to send
additional information along with the regular
program signal. RDS is available only on FM
stations.*
Note
RDS may not work properly if the station you are tuned
in is not transmitting the RDS signal properly or if the
signal is weak.
* Not allFM stations provide RDS service, nor do they
provide the same types of services. If you are not
familiar with the RDS system, check with your local
radio stations for details on RDS services in your
area.
Receiving RDS broadcasts
Simply select a station from the FM band.
When you tune in a station that provides RDS
services, the station name appears in the display.
To check the RDS information
Each time you press DISPLAY, the display
changes cyclically as follows:
Station name* tFrequency tProgram type*
tClock display tBass level tTreble level
* If the RDS broadcast is not properly received, the
station name or the program type may not appear in
the display.
Using the Radio Data
System (RDS)
(European model only)

16GB
1Press A TAPE Zor TAPE ZB on the
unit.
2Load a recorded/recordable tape into
the cassette holder.
You can use TYPE I (normal) tape.
1Load a tape.
2Press TAPE (or FUNCTION repeatedly)
or TAPE A/B on the unit to switch the
function to TAPE.
3Press TAPE (or TAPE A/B on the unit)
repeatedly to select deck A or B.
4Press PLAY MODE repeatedly to select
“g” to play one side. Select “j”*to
playboth sides.Select “RELAY” (Relay
Play)*to play both decks in
succession.
5Press N(or nN on the unit).
The tape starts playing. Press the button
again to play the reverse side.
* Relay play always follow this cyclic sequence:
Deck A (front side) tDeck A (reverse side)
tDeck B (front side) tDeck B (reverse
side)
For MHC-NXM1, deck A does not play the
reverse side.
Other operations
* For MHC-NXM1, deck A does not play the reverse
side.
Tape – Play
Loading a tape
With the side you
want to play/record
facing towards you.
Playing a tape
To Do this
Play the reverse
side* Press N(or nN on the unit) again during play.
Stop play Press x.
Pause Press X. Press again to resume
play.
Fast-forward or
rewind Press mor M in stop mode.
Remove a tape Press A TAPE Z or TAPE ZB
on the unit.
RELAY
1 2 3 4 5 A B
Playing direction

Tape – Play/Tape – Recording
17GB
Searching for the beginning of
the current or the previous or the
next track (AMS)*
To go forward
Press >during play.
Each time you press the button, the search
direction, + (forward), and number of tracks
being skipped (1 to 9) appear.
To go back
Press .during playback.
Each time you press the button, the search
direction, – (back), and number of tracks being
skipped (1 to 9) appear.
* AMS (Automatic Music Sensor)
Note
The AMS function may not operate correctly under the
following circumstances:
– When the unrecorded space between songs is less
than 4 seconds long.
– When the system is placed near a television.
Tips
• If you select “j” or “RELAY”*, the deck stops
automatically after repeating the sequence five times.
• When a tape is inserted, corresponding forward
(N)/reverse (n) indicators light.
* For MHC-NXM1, deck A does not play the reverse
side.
You can record a whole CD on a tape.
You can use TYPE I (normal) tape. The
recording level is adjusted automatically.
Use buttons on the unit for the operation.
1Load a recordable tape into deck B.
2Press TAPE A/B to select deck B, then
press nN repeatedly to select
recording side. And press xto stop
playback.
3Press PLAY MODE on the remote
repeatedly to select “g” to record on
one side. Select “j” (or “RELAY”) to
record on both sides.
4Press CD and load a disc you want to
record.
When you want to record an album from an
MP3 disc, be sure to press ALBUM – or +
to select the desired album before
proceeding.
5Press CD SYNC.
Deck B stands by for recording.
“REC” flashes.
6Press zSTART.
Recording starts.
To stop recording
Press x.
To record a disc by specifying
track order
You can record only your favorite CD tracks
using Program Play. Between steps 4 and 5,
perform steps 2 to 6 of “Creating your own
program” (page 11).
Tape – Recording
Recording your favorite
CD tracks on a tape
— CD-TAPE Synchro Recording
continued

18GB
Tips
• When you record on both sides, be sure to start from
the front side. If you start from the reverse side,
recording stops at the end of the reverse side.
• If you select both sides recording and the tape
reaches the end of the front side part-way through a
track, the entire track is recorded again from the
beginning of the reverse side. You can record just the portions you like from a
CD, tape or radio program on a tape.
You can also record from connected
components (see “Hooking up optional
components” on page 25).
Use buttons on the unit for the operation.
1Load a recordable tape into deck B.
2Press TAPE A/B to select deck B, then
press nN repeatedly to select
recording side. And press xto stop
playback.
3Press PLAY MODE on the remote
repeatedly to select “g” to record on
one side. Select “j” (or “RELAY”) to
record on both sides.
4Press one of the following buttons to
select the desired source to record.
• CD: To record from this system’s CD
player.
• TAPE A/B: Torecord from this system’s
tape deck A.
• TUNER/BAND: To record from this
system’s tuner.
• VIDEO/MD: To record from the optional
component connected to the VIDEO/MD
IN jacks.
5Press zSTART.
Deck B stands by for recording.
“REC” flashes.
6Press zSTART, then start playing the
desired source to record.
Recording starts.
Other operations
Recording on a tape
manually
— Manual Recording
To Do this
Stop recording Press x.
Pause recording Press zSTART on the unit.

Sound Adjustment
19GB
Notes
• You cannot listen to other sources while recording.
• If TAPE B is selected in step 4, silence is recorded.
Tips
• For recording from the tuner:
If noise is heard while recording from the tuner,
move the respective antenna to reduce the noise.
• When you record on both sides, be sure to start from
the front side. If you start from the reverse side,
recording stops at the end of the reverse side.
Generating a more dynamic
sound (Dynamic Sound
Generator X-tra)
Press DSGX on the unit.
Each time you press the button, the display
changes as follows:
DSGX ON yDSGX OFF
Generating a more attractive
sound (MP3 BOOSTER)
You can enjoy a more attractive sound when
playing MP3 audio tracks.
1Press CD (or FUNCTION repeatedly) to
switch the function to CD.
2Hold DSGX on the unit for 2 seconds.
Each time you hold the button for 2
seconds, the display changes as follows:
BOOSTER ON yBOOSTER OFF
Adjusting the bass and treble
You can adjust the bass and treble to enjoy more
powerful sound.
1Press EQ repeatedly to select “BASS”
or “TREBLE”.
Each time you press the button, the display
changes as follows:
BASS yTREBLE
2Press .or >repeatedly to adjust
the level while “BASS” or “TREBLE”
appears.
To adjust the bass on the unit
Turn BASS control.
To adjust the treble on the unit
Turn TREBLE control.
Sound Adjustment
Adjusting the sound
continued

20GB
To exit the bass and treble
settings
If you do not perform any operations for
4 seconds, the display automatically returns to
the original display.
You can set the system to turn off after a certain
time, so that you can fall asleep to music.
Press SLEEP.
Each time you press the button, the minute
display (the turn-off time) changes cyclically as
follows:
AUTO* t90min t80min t… t10min
tOFF
* The system automatically turns off in 100 minutes or
after the current disc or tape finishes playing.
Other operations
* You cannot check the remaining time if you select
“AUTO”.
Tip
You can use the Sleep Timer, even if you have not set
the clock.
Timer
Falling asleep to music
— Sleep Timer
To Press
Check the
remaining time* SLEEP once.
Change the time
to turn off SLEEP repeatedly to select the time you want.
Cancel the Sleep
Timer Function SLEEP repeatedly until “OFF” appears.
