Sony BKMA-U55 User manual

HARD DISC DRIVE UPGRADE KIT FOR MAV-555
BKMA-U55
INSTALLATION MANUAL
1st Edition
Serial No. 10001 and Higher

!WARNING
This manual is intended for qualified service personnel only.
To reduce the risk of electric shock, fire or injury, do not perform any servicing other than that
contained in the operating instructions unless you are qualified to do so.Refer all servicing to
qualified service personnel.
!WARNUNG
Die Anleitung ist nur für qualifiziertes Fachpersonal bestimmt.
Alle Wartungsarbeiten dürfen nur von qualifiziertem Fachpersonal ausgeführt werden. Um die
Gefahr eines elektrischen Schlages, Feuergefahr und Verletzungen zu vermeiden, sind bei
Wartungsarbeiten strikt die Angaben in der Anleitung zu befolgen. Andere als die angegeben
Wartungsarbeiten dürfen nur von Personen ausgeführt werden, die eine spezielle Befähigung
dazu besitzen.
!AVERTISSEMENT
Ce manual est destiné uniquement aux personnes compétentes en charge de l’entretien.Afin
de réduire les risques de décharge électrique, d’incendie ou de blessure n’effectuer que les
réparations indiquées dans le mode d’emploi à moins d’être qualifié pour en effectuer d’autres.
Pour toute réparation faire appel à une personne compétente uniquement.
BKMA-U55

1 (E)
BKMA-U55
Table of Contents
Manual Structure
Purpose of this manual ........................................................................................ 3 (E)
Related manuals................................................................................................... 3 (E)
Contents ............................................................................................................... 3 (E)
Trademarks .......................................................................................................... 3 (E)
1. Installation
1-1. Operating Precautions When Replacing Hard Disk Drive....................1-1 (E)
1-2. Installation Conditions, Installation Space and
Power Source Specifications.................................................................1-3 (E)
2. Replacement of the Hard Disk Drive
2-1. Replacement Procedure.........................................................................2-1 (E)
2-2. Confirming Versions of MAV-555 and
BKMA-505/510/520/530/560 ...............................................................2-1 (E)
2-3. Replacing HDD of MAV-555 ...............................................................2-4 (E)
2-4. Setting Switches on the PU-109 Board .................................................2-6 (E)
2-5. Erasing All Materials after Installation of HDD (Logical Format).......2-7 (E)
2-5-1. Erasing All Materials in the HDD........................................2-7 (E)
2-6. Confirming Operation ...........................................................................2-8 (E)
3. Service Overview
3-1. HDD Unit ..............................................................................................3-1 (E)

3 (E)
BKMA-U55
Manual Structure
Purpose of this manual This manual is the installation manual of the BKMA-U55 Hard Disk Upgrade Kit
for the Multi-access Video Disk Recorder MAV-555.
This manual is intended for use by trained system and service engineers, and
describes the information regarding installation.
Related manuals Besides this Installation Manual, the following manuals are available for the
BKMA-U55.
..
..
.MAV-555, BKMA-505/510/511/512/570 Series
Maintenance Manual Volume 1 (Available on request)
This manual describes the information that premise the service based on parts
replacement (diagnostics, parts replacement, electrical alignment, and circuit
descriptions, etc.).
If this manual is required, please contact your local Sony Sales Office/Service
Center.
..
..
.MAV-555, BKMA-505/510/511/512/570 Series
Maintenance Manual Volume 2 (Available on request)
This manual describes the information that premise the service based on parts
replacement (parts list, block diagrams, schematic diagrams, board layouts, etc.).
If this manual is required, please contact your local Sony Sales Office/Service
Center.
Contents The following is a summary of all the section for understanding the contents of this
manual.
Section 1 Installation
Explains the operating precautions when replacing hard disk drive, the installation
environment, the power source specifications, etc.
Section 2 Replacement of the Hard Disk Drive
Explains the procedures to replace the hard disk drive.
Section 3 Service Overview
Explains the hard disk drive unit.
Trademarks Registered trademarks used in this manual are follows.
.Ethernet is a registered trademark of Xerox Corporation.
.Windows and Windows NT are the registered trademarks of Microsoft Corporation.

1-1 (E)
BKMA-U55
1-1. Operating Precautions When Replacing Hard Disk Drive
The Hard Disk Drives (HDD) are installed in the MAV-555.
The HDD is a precision part. The causes such as shock, vibration and static electricity to the unit, and the
conditions of temperature and humidity may damage HDD or its data.
Before installation, read fully the following cautions, and perform the installation with extra care.
Cautions about shock and vibration
When transporting and moving;
.Pack the unit using the packaging materials specified by the manufacturer.
.Use a proper cart.
.Put a cushion*on the cart.
.Avoid rough routes, and manage the cart gently.
When placing on a floor or table;
.Put a cushion*on stable and horizontal place, and put the unit on it gently.
.Do not place the unit near vibrating equipments.
For the unit;
.Never hit the unit by tool, and drop the tool on the unit.
Take extra care;
.Never give vibration or shock to the unit while the power is turned on, or within about 30 seconds after
turning off the power.
*Cushion: Polyethylene foam (density: 38 kg/m3, surface intrinsic resistance : 1011 to 1012 Z, thickness: 50 mm) or equivalent.
Cautions about rack mounting the unit
.Be careful not to give shock to the HDD.
Caution about static electricity
.Keep static-producing items such as plastics away from the working area.
Cautions about temperature and humidity
.Temperature and humidity of storage and operating condition must be kept within the correct specified
range.
.Never turn on the power with the cabinet is removed in consideration of the air-cooling effect.
Cautions when an error appears in a HDD
.Treat this unit conform to the above cautions, even when an error appeared.
.Keep the unit in the condition in which the error appeared, and record the details of the error.
Section 1
Installation

1-2 (E) BKMA-U55
H
D
D
Prolonging Life of Hard Disk Drive
The life of the hard disk drive (HDD) is shortened by vibration, shock,
temperature, humidity and static electricity.
To prolong the life of the hard disk drive, observe the following precautions. Read these
precautions before
using the hard disk
drive!
Static Electricity
Static electricity can reach up to several kilo volts and instantaneously
damage the HDD board.
.Be sure to touch the metal rack or similar earthed part
before touching the HDD in order to discharge the static
electricity of your body. We recommend wearing an earthed
wrist-band.
Vibration, Shock
Excessive vibration and shock to the HDD can damage the internal
heads and media.
In some cases, it may take several months for the heads and media to
become damaged after the vibration or shock is applied.
.Take great care not to drop the product or HDD assembly, and to
avoid collision when handling the product and HDD.
.The HDD is at greatest risk of damage when the power is
turned on, and for thirty seconds after the power is
turned off. Never move, transport or tap the product
during these times.
.Be sure to pack the product and the HDD assembly in the
packaging materials specified by the manufacturer or in a
carrying case that protects the HDD from shock and vibration
when transporting the HDD assembly or the product.
Temperature, Humidity
Use of the HDD in an environmental temperature exceeding the product
specification will accelerate wear of the parts and components of the HDD.
A sharp change of environmental temperature and humidity can cause
troubles inside the HDD such as condensation, even if the environ-
mental temperature and humidity are within the product specifica-
tions.
.The HDD starts up automatically when the main power of the
product is turned on. Always operate the HDD under the
specified environmental temperature and humidity once
the main power is turned on.
.When the HDD is moved into a warm indoor room from the cold
outdoors, the HDD assembly should be left for three hours
or more without removal from the packaging materials or
carrying case.
1-1. Operating Precautions When Replacing Hard Disk Drive

1-3 (E)
BKMA-U55
1-2. Installation Conditions, Installation Space and Power Source
Specifications
Installation conditions, installation space and power source specifications are the same as those of the
MAV-555.
Refer to the MAV-555 Installation Manual.
1-2. Installation Conditions, Installation Space and Power Source Specifications

2-1 (E)
BKMA-U55
Section 2
Replacement of the Hard Disk Drive
Before starting to increase the capacity of the HDD by installing the BKMA-U55, confirm that the MAV-
555 and the related optional units are version 2.00 or higher. For upgrading the system to the newest
version, upgrade it by referring to the CD that is supplied with the BKMA-U55.
m
.When capacity of the HDD is increased by installing the BKMA-U55, the “ALL ERASE” menu needs
to be executed after replacement of the hard disk. Because the pre-recorded materials will be all erased,
copy of all the necessary materials to VTR and others for backup purpose.
.Be sure to implement the “ALL ERASE” menu from the application software when it is connected to
an application.
.All of the work procedures to increase the capacity of the HDD by installing the BKMA-U55 must be
executed while the system power is kept turned off.
2-1. Replacement Procedure
To replace the HDD, perform the following steps starting from the top in this order. For details, refer to
each item.
Confirming versions of MAV-555 and
BKMA-505/510/520/530/560
Upgrading versions of MAV-555 and
BKMA-505/510/520/530/560
(Only when it is necessary)
Replacing HDD of MAV-555
Setting Switch of PU-109 Board
Erasing All Materials after Installation of HDD
(Logical format)
Confirming Operation
Refer to Section 2-2.
Refer to Section 2-3.
Refer to Section 2-4.
Refer to Section 2-5.
Refer to Section 2-6.
2-2. Confirming Versions of MAV-555 and BKMA-505/510/520/530/560
Required tools
.PC (System requirement: Any of Windows 95/98/2000/NT4.0)
.Ethernet card
.Ethernet cross cable
.Version check software: GCD Loader V0.21 (This is stored in the supplied CD.)
Connection
Connect the Ethernet terminal of the rear panel to a personal computer using an Ethernet cross cable.

2-2 (E) BKMA-U55
Microsoft(R) Windows 95
(C)Copyright Microsoft Corp 1981-1995.
C:\>ping\192.168.0.1"
C:\>ping\192.168.0.1"
Pinging 192.168.0.1 with 32 bytes of data:
Reply from 192.168.0.1: bytes=32 time=2ms TTL=254
Reply from 192.168.0.1: bytes=32 time=1ms TTL=254
Reply from 192.168.0.1: bytes=32 time<10ms TTL=254
Reply from 192.168.0.1: bytes=32 time=1ms TTL=254
C:\>
C:\>ping\192.168.0.1"
Pinging 192.168.0.1 with 32 bytes of data:
Request timed out
Request timed out
Request timed out
Request timed out
C:\>
Preparation
1. Set the IP address and the sub-net mask of the MAV-555 to the factory settings.
m
.The IP address and sub-net mask can be confirmed in set-up menu No. 220.
.The factory settings are as follows:
IP address : 192.168.0.1
Sub-net mask : 255.255.255.0
2. Set the IP address and the sub-net mask of the personal computer as follows:
IP address : 192.168.0.2
Sub-net mask : 255.255.255.0
3. Start up the personal computer.
4. Wait for the MS-DOS prompt (or command prompt) to appear.
5. Input [ping 192.168.0.1].
6. Confirm that the reply is returned normally.
Message example (normally)
Message example (abnormally)
7. If the reply is not returned normally, input [arp -d 192.168.0.1] and perform from step 5 again.
(There can be a case that the APR table information is left remained when two or more MAV-555s
are connected continuously.)
2-2. Confirming Versions of MAV-555 and BKMA-505/510/520/530/560

2-3 (E)
BKMA-U55
Checking the versions
1. Start up the GCD loader.
2. Input the Target Address.
3. Select [Information] _[Target Version] from the top menu.
4. Click the Version button of each board and confirm the current version.
5. Press the Close button.
2-2. Confirming Versions of MAV-555 and BKMA-505/510/520/530/560

2-4 (E) BKMA-U55
Checking the version of BKMA-505
When the option BKMA-505 (Disk Recorder Control
Panel) is installed in the MAV-555, check the version of
the BKMA-505 as well in the following steps
1. Press the L3 while pressing the MODE button of the
BKMA-505. (CP Setup)
2. Press the L4 (Software version).
3. Check each version of the Main and Sub that is
displayed on the LCD panel of the BKMA-505.
Example of display
CP Setup
BKMA-505 Software Version
Main CPU Software : x.xx
Sub CPU Software : x.xx
2-3. Replacing HDD of MAV-555
Removal
n
After turning off the main power, wait for the 30 seconds
or longer before starting the removal.
1. Remove the top plate (B). (Refer to Section 3-2-2 of
the MAV-555 Maintenance Manual Volume.1.)
10K
36
Screws (with drop-safe)
Hole
Top plate B
Seal
2-2. Confirming Versions of MAV-555 and BKMA-505/510/520/530/560
2-3. Replacing HDD of MAV-555

2-5 (E)
BKMA-U55
2. Open the lock lever in the direction of the arrow and
remove the HDD unit from the slot gently.
n
When placing the removed HDD unit, place it on a
cushion gently with the WARRANTY label side
facing down.
FRONT
Lock levers
WARRANTY label
(yellow)
Installation
1. Insert a new HDD unit into the slot gently with the
lock levers opened.
2. Close the lock lever in the direction of the arrow to fix
it.
3. Attach the HDD number labels to the respective HDD
units that are newly installed, in accordance with the
respective slot numbers.
4. Attach the HDD identification label.
m
.Attach the HDD unit with the WARRANTY label side
on the right.
.Avoid excessive shock.
Lock lever
Locked
Released
Lock lever
HDD unit
HDD unit
2-3. Replacing HDD of MAV-555

2-6 (E) BKMA-U55
2-4. Setting Switches on the PU-109 Board
ABC DEFG
HJKL
1
2
3
4
5
6
7
8
9
S400
S1101
A side (Component side)
Set the switches S400 and S1101 as follows.
Switch Pin-1 Pin-2 Set the HD capacity
S400 OFF ON Set for 36 GB.
S1101 OFF ON Set for 36 GB.
2-4. Setting Switches on the PU-109 Board

2-7 (E)
BKMA-U55
R1 00 : 00 : 00 : 00 P1 00 : 00 : 00 : 00
R2 00 : 00 : 00 : 00 P2 00 : 00 : 00 : 00
2-5. Erasing All Materials after
Installation of HDD (Logical Format)
n
Refer to the Operation Manual for details of how to use the
setup menu.
2-5-1. Erasing All Materials in the HDD
1. Open the “099-ALL ERASE”display from the setup
menu.
2. Press the VIDEO/MENU knob once and open the
SubMenu.
3. Press the VIDEO/MENU knob once.
4. Turn the VIDEO/MENU knob, and select “YES”.
5. Press the SET button to erase all materials in the
HDDs.
099-ALL ERASE
Execute
099-ALL ERASE
NO?Execute
099-ALL ERASE
[SET]YESExecute
099-ALL ERASE
SubMenu
The ITEM indicator flashes.
2-5. Erasing All Materials after Installation of HDD (Logical Format)

2-8 (E) BKMA-U55
CONTROL PANEL PANEL SELECT CHARACTER
REAR FRONT 1 2 3
NONE OFF ONBOTH
SETUP
SELECT
METER
PANEL CONTROL PANEL
\
COMPOSITE SDI
VIDEO
INPUT
REMOTE
R1
PORT SELECT
R2/
P3
P1
P2
INPUT SDI
AES/EBU
ANALOG
CH1
CH1
PRESET
AUDIO INPUT / MONITOR SELECT
CH2 CH3 CH4
MONITOR L
R
METER
PANEL
525
REMOTE
MENU
LOCAL
CONTROL
PANEL
625 SETUP BANK
TOTAL /
REMAIN
PROCESS
CONTROL VIDEO
CHROMA
SET UP/BLACK
CHROMA/PHASE
PHONES
123
SYSTEM HDD
HELP
FULL /
TIME
TC/UB TIMER SEL
MENU
10
SET
0
CH2
PRESET
CH3
PRESET
CH4
PRESET
VIDEO/MENU
PRESET
TOTAL/REMAIN button :Displays remain time.
Press the TOTAL/REMAIN button on the MAV-555 front panel, and check the REMAIN time to be
displayed.
.Reference display value (immediately after ALL ERASE)
Video 30 Mbps, Audio16 bit : 19h24m
Video 50 Mbps, Audio16 bit : 11h56m
Video 30 Mbps, Audio20 bit : 16h21m
Video 50 Mbps, Audio20 bit : S11h56m
2-6. Confirming Operation
Perform recording and playback to confirm that there is no abnormality.
2-5. Erasing All Materials after Installation of HDD (Logical Format)
2-6. Confirming Operation
Setting switch

3-1 (E)
BKMA-U55
3-1. HDD Unit
Part name : HDD (10K-36C-RP) assembly
Part No. : A-8328-370-A
Section 3
Service Overview
