Multi Format Switcher System
MVS-6520 System
MVS-6530 System
MVS-3000A System
MVS-3000 System
(With ICP-series Control Panel)
MVS-6520 MVS-6530 MVS-3000A MVS-3000
ICP-6520 ICP-6530 ICP-3000 ICP-3016
ICP-6511 MKS-6550 MKS-6570
Startup Guide [English]
Software Version 1.10 and Later
1st Edition (Revised 1)

NOTICE TO USERS
© 2012, 2013 Sony Corporation. All rights reserved.
This manual or the software described herein, in
wholeorin part, maynot bereproduced, translatedor
reduced to any machine readable form without prior
written approval from Sony Corporation.
SONY CORPORATION PROVIDES NO
WARRANTY WITH REGARD TO THIS MANUAL,
THE SOFTWARE OR OTHER INFORMATION
CONTAINED HEREIN AND HEREBY EXPRESSLY
DISCLAIMS ANY IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR ANY
PARTICULAR PURPOSE WITH REGARD TO THIS
MANUAL, THE SOFTWARE OR SUCH OTHER
INFORMATION. IN NO EVENT SHALL SONY
CORPORATION BE LIABLE FOR ANY
INCIDENTAL, CONSEQUENTIAL OR SPECIAL
DAMAGES, WHETHER BASED ON TORT,
CONTRACT, OR OTHERWISE, ARISING OUT OF
OR IN CONNECTION WITH THIS MANUAL, THE
SOFTWARE OR OTHER INFORMATION
CONTAINED HEREIN OR THE USE THEREOF.
Sony Corporation reserves the right to make any
modification to this manual or the information
contained herein at any time without notice.
Thesoftwaredescribedhereinmayalsobegoverned
by the terms of a separate user license agreement.

Table of Contents 3
Table of Contents
Overview
Introduction.................................................4
Names of Parts............................................5
MVS-6520/6530/3000A/3000
Multi Format Switcher Processor........5
ICP-6520/6530/3000/3016 Control Panel.....8
ICP-6511 Menu Panel...................................9
Connection
System Configuration...............................10
Video Input/Output Systems.......................10
Device Control Systems..............................11
Connecting Devices..................................12
MVS System Connection............................ 12
Peripheral Device Connection ....................13
Preparation
Preparation Procedure .............................15
Turning Power On/Off...............................16
Opening Menus...........................................18
Configuring the Network..........................19
Setting the Control Panel Type................20
Setting Signal Formats.............................21
Setting the Signal Format............................21
Setting the Screen Aspect Ratio..................22
Assigning Signals to
Cross-Point Buttons ..........................22
Setting the Signal Name..............................22
Assigning Pair Signals to
Cross-Point Buttons...........................23
Assigning M/E Reentry Input Signals to
Cross-Point Buttons...........................24
Assigning Output Signals........................24
Setting Monitor Outputs ............................. 24
Using Multi Viewer....................................25
Setting Multi Viewer Output.......................25
Configuring Multi Viewer ..........................26
Assigning Signals to Subscreens.................26
Setting Multi Viewer Tally Output.............27
Setting Tally...............................................28
Setting Parallel Tally...................................28
Setting Serial Tally......................................28
Assigning 8-Keyer Buttons
(MVS-6530 only) .................................37
Assigning Key 5 to Key 8 to
1st Row Buttons.................................37
Assigning Key Selection Functions to
Next Transition Selection Buttons.....38
Enabling Background DME Wipes
(MVS-3000/3000A only)......................39
Setting the Startup State..........................39
Selecting the Startup Mode at Power On....39
Customizing the User Default Settings.......40
Saving Data to Removable Disk..............41
Setting Up a Removable Disk for Use........41
Saving/Recalling User Settings
on Removable Disks..........................42
Setting Simple Connection of
AUX Bus Remote Panel.....................43
Basic Image Creation Operations
Video Switching (Transitions) .................45
Types of Transitions
(Mix/NAM/Wipe/DME Wipe)..........45
Names of Parts in the Control Panel...........46
Video Transitions using Cuts......................47
Video Transitions using Wipes or Mixes....48
Saving DME Wipe Settings
in a DME Wipe Snapshot...................50
Setting Picture-in-Picture (DME Wipe)......50
Saving/Recalling a DME Wipe Snapshot...52
Inserting Titles (Keys) ..............................53
What is a Key?............................................53
Entering Titles using Luminance Keys.......53
Composing Images using
Chroma Keys......................................56

4Introduction
Overview
Overview
Introduction
The Startup Guide (this document) describes the basic
settings and operations to begin using the MVS-6520/
6530/3000A/3000 system.
For details about settings and operations, refer to the
User’s Guide.
System name and nomenclature
An MVS system using the MVS-6520, MVS-6530, or
MVS-3000A Multi Format Switcher Processor is referred
to as the “MVS-6520/6530/3000A system,” and an MVS
system using the MVS-3000 Multi Format Switcher
Processor is referred to as the “MVS-3000 system.”
In this document, the MVS-6520/6530/3000A system and
MVS-3000 system are collectively referred to as the
“MVS system.”
Also, the ICP-6520, ICP-6530, ICP-3000, and ICP-3016
control panels are collectively referred to as the “ICP-
series control panel.”
Illustrations and screenshots
The illustrations and screenshots used in this document to
describe functions and procedures may vary depending on
the system configuration.

5
Names of Parts
Overview
Names of Parts
MVS-6520/6530/3000A/3000 Multi Format Switcher Processor
Rear panel: MVS-6520, MVS-3000A, and MVS-3000
1
IN
2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
1
IN
2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
1
OUT
2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
1
16
17
32
33
48
1
2
3
4
5
1
16
17
32
6
7
8
SERIALTALLY REMOTE 4 REMOTE 3 REMOTE 2 REMOTE 1
TALLY/GPI IN13-18 OUT33-48 TALLY/GPI IN7-12 OUT17-32 TALLY/GPI IN1-6 OUT1-16 UTIL(FM)FM DEVICE
REF IN UTIL(SW)MVS REMOTE S2 REMOTE S1 UTIL(SCU)S-BUS
Slots 6 to 8
Slots 1 to 5
Slots 1 to 5
Slots 6 to 8
a-AC IN A and B connectors
bU terminal
gREMOTE 1 to 4 connectors iFM DEVICE connector
jS-BUS connector
hUTIL (FM) connector
dOUTPUTS 1 to 16 connectors
oREF INPUT connectors
nUTIL (SW) connector
mMVS connector lREMOTE S1 and S2
connectors kUTIL (SCU) connector
cPRIMARY INPUTS 1 to 32 connectors
fSERIAL TALLY connector
eTALLY/GPI IN 1 to 18 and TALLY/
GPI OUT 1 to 48 connectors

6Names of Parts
Overview
Rear panel: MVS-6530
a-AC IN (AC power input) A and B connectors
(3-pin)
Connect to 100 V to 240 V AC power supply with the
optional AC power cords.
The unit is equipped with two power supplies. When A or
B power supply is connected, unit operation can proceed.
bU(signal ground) terminal
Connect to the system ground.
cPRIMARY INPUTS
1 to 32 connectors (BNC-type)1): MVS-6520/
3000A/3000
1 to 48 connectors (BNC-type)1): MVS-6530
These connectors allow you to input up to 32 or up to 48
serial digital video signals to the MVS-6520/3000A/3000
or MVS-6530, respectively.
1
IN
2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
1
IN
2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
1
IN
2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
1
OUT
2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
1
OUT
2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
1
16
17
32
33
48
1
2
3
4
5
1
16
17
32
6
7
8
SERIALTALLY REMOTE 4 REMOTE 3 REMOTE 2 REMOTE 1
TALLY/GPI IN13-18 OUT33-48 TALLY/GPI IN7-12 OUT17-32 TALLY/GPI IN1-6 OUT1-16 UTIL(FM)FM DEVICE
REF IN UTIL(SW)MVS REMOTE S2 REMOTE S1 UTIL(SCU)S-BUS
Slots 6 to 8
Slots 1 to 5
Slots 1 to 5
Slots 6 to 8
a-AC IN A and B connectors
bU terminal
gREMOTE 1 to 4 connectors iFM DEVICE connector
jS-BUS connector
hUTIL (FM) connector
dOUTPUTS 1 to 32 connectors
oREF INPUT connectors
nUTIL (SW) connector
mMVS connector lREMOTE S1 and S2
connectors kUTIL (SCU) connector
cPRIMARY INPUTS 1 to 48 connectors
fSERIAL TALLY connector
eTALLY/GPI IN 1 to 18 and TALLY/
GPI OUT 1 to 48 connectors

7
Names of Parts
Overview
dOUTPUTS
1 to 16 connectors (BNC-type)1): MVS-6520/
3000A/3000
1 to 32 connectors (BNC-type)1): MVS-6530
These connectors output serial digital signals. You can
assign them as program output, preview output, AUX
output, and so on.
Make output assignments on the MVS system control
panel.
The configurable connectors foreach signal type aregiven
below.
For details about output signals and settings, refer to the
User’s Guide.
eTALLY/GPI IN (tally/general purpose interface
input) 1 to 18 and TALLY/GPI OUT (tally/general
purposeinterfaceoutput)1 to48connectors(D-sub
25-pin)
Outputtally datacreatedwiththecontrolpaneloftheMVS
system (opencollector). These connectors can also beused
as GPI output ports.
You can also input trigger signals as GPI inputs.
Input and output settings are made on the control panel of
the MVS system.
fSERIAL TALLY connector (D-sub 9-pin,
RS-422A)
Outputtally datacreatedwiththecontrolpaneloftheMVS
system.
gREMOTE 1 to 4 connectors (D-sub 9-pin, RS-
422A)
Connect devices supporting Sony 9-pin VTR, VDCP
(Video Disk Communications Protocol), or P-Bus
(Peripheral II Protocol) protocols.
hUTIL (FM) (utility (frame memory data))
connector (RJ-45 compliant)
Intended for future expansion.
iFM (frame memory) DEVICE connector (USB 2.0
compliant)
This connector is for attaching an external HDD for frame
memory.2)
jS-BUS connector (BNC-type)1)
Connect this connector with a BNC cable to an S-Bus data
link via a T bridge.
Connecting devices such as IXS series routing switchers
andMKS-8080/8082AUXbusremotepanelsvia an S-Bus
data link enables the following kinds of control.
• Returning to the S-Bus, tally data created by this unit on
the basis of data received from other devices
• Switchingthecross-pointsof aroutingswitcherfrom the
control panel
• Switching the cross-points of a switcher from the remote
panel
• Displaying on the control panel source names set on a
routing switcher
kUTIL (SCU) (utility (SCU)) connector (RJ-45
compliant)
Intended for future expansion.
lREMOTE S1 and S2 connectors (D-sub 9-pin, RS-
422A compliant)
These connectors are used to operate the MVS system
from external devices.
Define the types of the connected devices on the control
panel.
mMVS (multi format video switcher) connector
(RJ-45 compliant)
Connect to an ICP-series control panel.
For details about connecting a DCU and MVE-8000A/
9000 multi format DME processor, refer to the User’s
Guide.
nUTIL (SW) (utility (SW)) connector (RJ-45
compliant)
Intended for future expansion.
oREF INPUT (reference video input) connectors
(BNC-type)1)
Ifyou wishtosynchronizethisunittoanexternalreference
signal, input the reference signal. For an HDTV system,
input an HD tri-level sync signal, black burst signal, or
analog sync signal. For an SDTV system, input a black
burst signal or analog sync signal.
The two connectors have a loop-through configuration.
Signal input to one connector can be output from the other
connector. If you will not be using the loop-through
output, be sure to terminate the unused connector with the
supplied 75 ohm terminator.
1) Attach the cable connected to the BNC-type connectors to the rack or other
support so there is no load on the connector. There is a risk of damage to
the BNC-type connectors and cable.
2) For information about devices that can be connected, contact your Sony
representative.
Switcher
processor Type of output signal
Re-Entry
Source Aux Bus Output/MV/FC/ DME
MVS-6520/
3000A OUTPUTS 1 to 16 OUTPUTS 1 to 16 OUTPUTS 1 to 16 (FC: 15, 16
combination only)
MVS-6530 OUTPUTS
1 to 24 OUTPUTS 1 to 24 OUTPUTS 1 to 32 (FC: 15,16 and 31,
32 combinations
only)
MVS-3000 OUTPUTS
1 to 12 OUTPUTS 1 to 12 OUTPUTS 1 to 16 (FC: 15, 16
combination only)

8Names of Parts
Overview
ICP-6520/6530/3000/3016 Control Panel
Rear panel
aUTIL (utility) connector (RJ-45 compliant)
Intended for future expansion.
bMVS (multi format video switcher) connector (RJ-
45 compliant)
Connect tothe MVS-6520/6530/3000A/3000 multi format
switcher processor.
For details about connecting a DCU and MVE-8000A/
9000 multi format DME processor, refer to the User’s
Guide.
cDEVICE 1 to 4 connectors (USB 2.0 compliant,
USB Type-A)
Connect to an ICP-6511 menu panel or USB device.1)
dDVI-D connector
Connect to an ICP-6511 menu panel orexternal monitor.1)
eU(signal ground) terminal
Connect to the system ground.
f- AC IN (AC power input) A and B connectors
(3-pin)
Connect to 100 V to 240 V AC power supply with the
optional AC power cords.
The unit is equipped with two power supplies. When A or
B power supply is connected, unit operation can proceed.
1) For information about devices that can be connected, contact your Sony
representative.
UTIL MVS DVI-D OUTDEVICE
4321
bMVS connector
aUTIL connector
dDVI-D connector
f-AC IN A and B connectors
cDEVICE 1 to 4 connectors
eUterminal
ICP-6520 diagram shown.

9
Names of Parts
Overview
ICP-6511 Menu Panel
The menu panel is optional.
Bottom panel
aDEVICE connector (USB 2.0, USB Type-B)
Connect to the DEVICE 1 connector of the ICP-series
control panel.
bDVI-D connector
Connect to the DVI-D output of the ICP-series control
panel.
cDC IN connector
Connect to the 12V DC connector of the supplied AC
adaptor.
Side panel
DEVICE connector (USB 2.0, USB Type-A)
In general, connect to a USB memory device, and input
and output files.
DEVICE DVI-D
IN 12V
!
aDEVICE connector
bDVI-D connector
cDC IN connector
DEVICE connector

10 System Configuration
Connection
Connection
System Configuration
Video Input/Output Systems
P ONES
V R
O
A K1
ENU
AGE D SP AY
SUB
CLP
2
S I T
IP
M NU S E CE A K
S T
T UMB
AL RES T O TN
A K2
SHU T E
EY HI
EX A D
CH P ER
R FW
P EV N XTLAY TOP
S
R C
EJ CT
H CH CH 3 CH 4
N T O K
L AL
E
A C S
E EL
E
A A
P E
P
Camera Playback VTR
Program monitor Monitor for multi viewer
MVS-6520/6530/3000A/
3000 Multi Format
Switcher Processor
Recording VTR
Character generator
Removable
disk
ICP-6511
Menu Panel a)
ICP-6520/6530/3000/3016 Control Panel b)
Video signal inputs
Video signal outputs
In addition to these devices, a DCU (MKS-8700/2700) or
DME processor (MVE-8000A/9000) can be used to extend
the system. For more information, refer to the User’s Guide.
Preview monitor
a) Menu can also be operated by connecting an external
monitor in place of the menu panel.
b) ICP-6520 diagram shown.

11
System Configuration
Connection
Device Control Systems
P ONES
OG
A K1
MENU
AGE D SP AY
SUB
CLP
3
S T
P
M NU S E A K
S T
T UMB
AL RES T T
A K2
SHU T E
T P
E HI
EX A D
CH P ER
F R V FW ND
P EV N XTPLAY TOP
ST NDB
R C
C C 3 C 4
N T O K
L AL
R E
A C S
E EL
E
P E T
P
1 2 3 4 5 6 7 8 9 10111213141516
ASGN D ST EVE R R
SELECTOR
K Y XPT
H LD LOC CHO C EAR
AUX BUS REMOTE PANEL MKS-8082
12345678910111213141516
17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
M/E
1M/E 2M/E 3P/P
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
ASS GN
23 24 25 26 27 28 29 30 31 32
KEY X-HO D DEST M/E 1 M E 2 M/E 3 /P
AUX BUS REMOTE PANEL MKS 8080
VTRs and DDRs
Control devices connected using Sony 9-pin VTR, VDCP, or
P-Bus protocols
(RS-422A)
MVS-6520/6530/3000A/
3000 Multi Format
Switcher Processor
ICP-6511 Menu Panel
ICP-6520/6530/3000/3016 Control Panel a)
MKS-8080 AUX Bus Remote Panel b)
MKS-8082 AUX Bus Remote Panel b)
Removable
disk
Other devices on S-Bus data link a) ICP-6520 diagram shown.
b) The MKS-8080/8082 can also be connected directly to a
switcher, without using the primary station of the S-Bus
data link.
AUX bus control devices and editors
(RS-422A)
REMOTE S1 and S2
MVSS-BUS
REMOTE 1 to 4

12 Connecting Devices
Connection
Connecting Devices
This section describes the connection procedure for the
following system configuration as an example.
• MVS-6520 or MVS-3000A Switcher Processor
(with MKS-6550 Format Converter Board and MKS-
6570 Digital Multi Effect Board installed)
• ICP-6520 Control Panel
• ICP-6511 Menu Panel
• Cameras for recording (4)
• VTRs for playback (2)
• Character generator (1)
• Video monitors (2)
• Monitor for multi viewer (1)
The MVS-3000 does not support the MKS-6570 DME
board.
MVS System Connection
1 Connect the power supply.
Switcher processor
aConnect the Uterminal to the system ground.
bConnect the ~AC IN A and B connectors to the 100
V to 240 V AC power supplies using power cords
(not supplied).
Control panel
aConnect the Uterminal to the system ground.
bConnect the ~AC IN A and B connectors to the 100
V to 240 V AC power supplies using power cords
(not supplied).
Menu panel
aConnect the supplied AC adaptor to the DC IN
connector, then connect the AC adaptor using a
power cord (not supplied).
Notes
MVS
DEVICE 1
DEVICE
DVI-D
DVI-D
MVS
U
U
MVS-6520/3000A Switcher Processor ICP-6511 Menu Panel
ICP-6520 Control Panel
AC power supplies
AC adaptor
AC power
supplies
LAN cable (straight type)
DVI cable
USB cable

13
Connecting Devices
Connection
2 Connect the switcher processor and control panel.
aConnect the MVS connector of the switcher
processor and the MVS connector of the control
panel using a LAN cable.
3 Connect the control panel and menu panel.
aConnect the DVI-D connector of the control panel
and the DVI-D connector of the menu panel using
the DVI cable supplied with the menu panel.
bConnect the DEVICE 1 connector of the control
panel and the DEVICE connector on the bottom of
the menu panel using the USB cable supplied with
the menu panel.
Peripheral Device Connection
O S
G
ME U
P GE D PL Y
UB
P
3
HFT
E U E M RK
T
H MB
LT
L
K Y N I
E A D
C A ER
E W
PR V N XTL Y S OP REC
H 1 H H CH
L AL
C E
LVL
R
P S
HO ES
OG
ME U
P E D Y
UB
LP
HFT
P
E U E M RK
ET
H MB
N IL E ET
H T L
O
K I
E A D
C A ER
F E F W D
PR V N XTL Y S OP
S AN B
REC
E E T
1 C
L AL
C E
LVL
R
P S
PRIMARY INPUTS 1 2 3 4 5 6 7 8
OUTPUTS 1
2
REF INPUT REF INPUT OUTPUTS 9
Character generator
Referencesignal
generator
75 ohm terminator
Video signal
Key signal

14 Connecting Devices
Connection
1 Connect devices to the PRIMARY INPUTS of the
switcher processor.
aConnect the cameras for recording.
In this example, connect four cameras to
PRIMARY INPUTS 1 to 4.
bConnect the playback VTRs.
In this example, connect two VTRs to PRIMARY
INPUTS 5 and 6.
cConnect the character generator.
In this example, connect to PRIMARY INPUTS 7
and 8.
2 Connect devices to the OUTPUTS of the switcher
processor.
aConnect the video monitors.
In this example, connect two monitors to
OUTPUTS 1 and 2.
bConnect the monitor for multi viewer.
In this example, connect to OUTPUTS 9.
3 Connect reference signals to the REF INPUT
connectors of the switcher processor.
aConnect one REF INPUT connector to a reference
signal generator.
bTerminate the other REF INPUT connector using
the supplied 75 ohm terminator.
To use the tally
Set the tally output, using either the SERIAL TALLY
connector or the TALLY connector (parallel tally) of the
switcher processor
To use an external monitor for menu
operations
Instead of the dedicated MVS system ICP-6511 menu
panel, you can connect an external monitor and operate the
menus from a touch panel or by mouse control.
External monitor connection
Connect the DVI-D connector of the control panel and the
DVI-D connector of the external monitor using a DVI
cable.
If using a touch panel, connect the DEVICE connector of
the control panel and the USB connector of the external
monitor using a USB cable.
If using a mouse, connect the mouse to the DEVICE
connector of the control panel using a USB cable.
For details about connecting monitors, contact your Sony
representative.
TALLY connector (GPI IN/OUT connector)
SERIAL TALLY connector
DVI-D connector
DEVICE connector

15
Preparation Procedure
Preparation
Preparation
Preparation Procedure
This section describes the setup required before operation
in the MVS system.
Turn on the power (1p. 16)
m
System settings
Configure the network (1p. 19)
m
Set the type of control panel (1p. 20)
m
Set the signal format (1p. 21)
m
Signal settings
Assign input signals (1p. 22)
m
Assign output signals (1p. 24)
m
Other settings
Make the following system configuration and other
settings, as required.
• Configure multi viewer (1p. 25)
•Settally(1p. 28)
• Assign buttons required for 8-keyer operation
(MVS-6530 only) (1p. 37)
• Enable background DME wipe (MVS-3000/
3000A only) (1p. 39)
• Set startup mode (1p. 39)
• Save data to removable disk (1p. 41)
• SetsimpleconnectionofAUX busremotepanel
(1p. 43)

16 Turning Power On/Off
Preparation
Turning Power On/Off
After connecting the system, turn on the power using the
following procedure.
1 Set the POWER A and B switches of the switcher
processor to ON (“?” side).
When the switcher processor is turned on, the status
indicators for supplies A and B light green.
2 Check that the status indicators on the control panel
are lit green, then press the POWER switch.
The POWER switch mark “1” lights green.
The control panel boots in approximately one minute,
and the top menu list appears on the menu panel
screen.
MVS-6520/6530/3000A/3000
Switcher Processor
1
2
3
3
ICP-6520/6530 Control Panel
ICP-3000/3016 Control Panel
ICP-6520 diagram shown.
ICP-3000 diagram shown.

17
Turning Power On/Off
Preparation
3 Pull the fader lever down from top to bottom.
When “Non Sync” or “Sync” appears at the top and
bottom stops of the fader lever (non-sync state), the
fader lever movement and transitions do not match.
Pull the fader level from top to bottom to release non-
sync state.
4 Turn on the power of other devices in the system.
Screen saver and panel sleep mode
If no operation is performed for a given time, the menu
display screensaver starts. The brightness of all indicators
and displays on the control panel also dims.
For details about settings, refer to the User’s Guide.
To turn the power off
1 On the menu screen, check that the local disk is not
being accessed.
A“localdisk”referstotheinternalflashmemorydrive
in a control panel.
While the system is accessing the local disk or frame
memoryexternal HDD,theindicatoronthemenupage
number button lights red.
Check to make sure the indicator is not lit before
turning off the power.
Remove all USB flash memory and other removable
disks before turning off the power.
2 Shut down the control panel.
Pressthemenu page numberbuttonanddisplaythetop
menu window, then press the [Shutdown] button.
MVS-6520/3000A/3000 screen shown.
On the MVS-6530, the [M/E2] button is also displayed.
Fader lever
Notes
Indicator on the menu page
number button
Menu page
number button Shutdown button
MVS-6520/3000A/3000 screen shown.
On the MVS-6530, the [M/E2] button is also displayed.

18 Turning Power On/Off
Preparation
A shutdown confirmation message appears.
Press [Yes] to commence shutdown. The process is
completed when the menu screen goes completely
black.
Check that the POWER switch indicator “1” on the
control panel has gone out.
You can forcibly turn off the power to the control
panel without following the normal shutdown
procedure by pressing and holding thePOWER switch
for five seconds or longer. If you force shutdown,
settings data may not be saved.
3 Set the POWER A and B switches of the switcher
processor to OFF (“a” side).
Opening Menus
In the MVS system, basic operations and system setupcan
be done using the menu.
This section describes how to open the “M/E-1 >Key1
>Type menu (1111)” as an example. Other menus can be
opened using the same procedure.
For details about menu operations, refer to the User’s
Guide.
1 Recall the top menu (top level in menu hierarchy).
aPress the menu page number button.
The top menu window appears.
bPress a top menu selection button.
In this example, press the [M/E1] button.
You can also open the top menus using the top menu
selection buttons in the menu panel.
2 Select a menu.
aSelect a submenu (level 2 in the menu hierarchy)
using VF buttons on the left edge.
In this example, select [Key1].
bSelect a submenu (level 3 in the menu hierarchy)
using HF buttons on the bottom edge.
In this example, select [Type].
The M/E-1 >Key1 >Type menu appears.
You can also open the menu by entering the page
number “1111” in the top menu window.
Notes
Menu page number button
Top menu selection buttons
Top menu window
Memo
Memo
Top menu selection buttons
MVS-6520/3000A/3000 diagram shown.
On the MVS-6530, the [M/E2] button is also displayed.
VF buttons
HF buttons

19
Configuring the Network
Preparation
Configuring the Network
When power is turned on, all devices connected to the
MVS system LAN are detected and corresponding settings
are registered.
1 Display the menu.
aOpen the Engineering Setup >System >Network
Config menu (7311).
2 Set the group ID.
Network Config menu
aCheck the group ID.
In this example, check that the group ID is set to
“1”.
If the group ID is not set to “1”, press [Group ID]
and change the setting.
For details about settings, refer to the User’s
Guide.
3 Detect the connected devices.
aPress [Auto Config].
bCheck the message, then press [Yes].
A list of detected devices appears.
4 Register the list of detected devices.
aPress [Define].
bCheck the message, then press [Yes].
The list is registered as the network settings when
power is turned on.
Group ID
Auto Config Define
MVS-6520/6530/3000A screen shown.
On the MVS-3000, [DME1] is not displayed.
DME
Control panel
Switcher processor

20 Setting the Control Panel Type
Preparation
Setting the Control Panel
Type
You can set the type of the ICP-series control panel
connected to the MVS system.
1 Display the menu.
aOpen the Engineering Setup >System >Install/Unit
Config menu (7316).
2 Select the control panel.
Install/Unit Config menu
aSelect “PNL1” (control panel) in the [Device]
column.
bPress [Unit Config].
The Unit Config menu (7316.8) appears.
3 Set the type of the control panel.
Unit Config menu
aIn the <ICP Type> group, select the control panel
type.
In this example, select [ICP-6520].
Select the type matching the connected control
panel.
bPress [Execute].
cCheck the message, then press [Yes].
The system reboots with the applied settings.
Device
Unit Config
(Example screen, which may vary from the actual screen
display.)
MVS-6520/6530/3000A screen shown.
On the MVS-3000, [DME1] is not displayed.
ICP Type Execute
