Sony CCP-8000 Series User manual

SYSTEM SETUP MANUAL
1st Edition
MULTI FORMAT SWITCHER SYSTEM
MVS-8000 System
MVS-8400/8300/8200
SWITCHER PROCESSOR PACK
MVE-8000
DME PROCESSOR PACK
DCU-8000
DEVICE CONTROL UNIT PACK
CCP-8000
CENTER CONTROL PANEL PACK

MVS-8000 System
SYSTEM SETUP
!WARNING
This manual is intended for qualified service personnel only.
To reduce the risk of electric shock, fire or injury, do not perform any servicing other than that
contained in the operating instructions unless you are qualified to do so. Refer all servicing to
qualified service personnel.
!WARNUNG
Die Anleitung ist nur für qualifiziertes Fachpersonal bestimmt.
Alle Wartungsarbeiten dürfen nur von qualifiziertem Fachpersonal ausgeführt werden. Um die
Gefahr eines elektrischen Schlages, Feuergefahr und Verletzungen zu vermeiden, sind bei
Wartungsarbeiten strikt die Angaben in der Anleitung zu befolgen. Andere als die angegeben
Wartungsarbeiten dürfen nur von Personen ausgeführt werden, die eine spezielle Befähigung
dazu besitzen.
!AVERTISSEMENT
Ce manual est destiné uniquement aux personnes compétentes en charge de l'entretien. Afin de
réduire les risques de décharge électrique, d'incendie ou de blessure n'effectuer que les
réparations indiquées dans le mode d'emploi à moins d'être qualifié pour en effectuer d'autres.
Pour toute réparation faire appel à une personne compétente uniquement.

1
MVS-8000 System
SYSTEM SETUP
Table of Contents
1. System Overview
1-1. Introduction .................................................................................................1-1
1-2. Features .......................................................................................................1-1
1-3. System Description .....................................................................................1-2
1-3-1. MVS-8000..................................................................................1-3
1-3-2. MVE-8000..................................................................................1-9
1-3-3. CCP-8000 .................................................................................1-13
1-3-4. DCU-8000 ................................................................................1-21
1-4. MVS-8000 System Example.....................................................................1-24
1-5. Functional Overview .................................................................................1-25
1-5-1. Video Signal Flow....................................................................1-25
2. Installation
2-1. Installation Tasks ........................................................................................2-1
2-2. MVS-8000 Installation................................................................................2-2
2-2-1. Rack Mounting ...........................................................................2-2
2-3. MVE-8000 Installation................................................................................2-4
2-3-1. Rack Mounting ...........................................................................2-4
2-4. CCP-8000 Installation .................................................................................2-6
2-4-1. Installation Space .......................................................................2-6
2-4-2. Installing the Main Panel ...........................................................2-8
2-4-3. Installing the AUX Panel ...........................................................2-9
2-4-4. Installing the Menu Panel...........................................................2-9
2-4-5. Rack Mounting .........................................................................2-10
2-5. DCU-8000 Installation ..............................................................................2-13
2-5-1. Rack Mounting .........................................................................2-13
2-6. MVS-8000 System Video Cabling............................................................2-15
2-7. MVS-8000 System Control Cabling .........................................................2-16
2-7-1. Cabling .....................................................................................2-16
2-7-2. LAN Requirements ..................................................................2-18
2-8. CCP-8000 Panel Cabling ..........................................................................2-19
2-8-1. Connecting the MKS-8075/MKS-8076 ...................................2-22

2MVS-8000 System
SYSTEM SETUP
3. Configuration
3-1. Introduction .................................................................................................3-1
3-2. Basic Configuration Steps...........................................................................3-1
3-3. IP Address ...................................................................................................3-2
3-3-1. Default IP Address .....................................................................3-3
3-3-2. Changing IP Address..................................................................3-4
3-4. Ethernet Switch Settings .............................................................................3-5
3-5. Software Installation ...................................................................................3-9
3-6. Engineering Setups......................................................................................3-9
3-7. Tally Setup ................................................................................................3-10
3-7-1. Setting Router...........................................................................3-12
3-7-2. Setting Group Tally ..................................................................3-24
3-7-3. Setting Wiring ..........................................................................3-26
3-7-4. Setting Tally Enable .................................................................3-29
3-7-5. Setting Tally Copy ...................................................................3-32
3-7-6. Setting Parallel Tally ................................................................3-35
3-7-7. Setting Serial Tally...................................................................3-37
3-8. Pin Output .................................................................................................3-41
3-8-1. MVS-8000................................................................................3-41
3-8-2. MVE-8000................................................................................3-43
3-8-3. CCP-8000 ................................................................................. 3-44
3-8-4. DCU-8000 ................................................................................3-46
4. Specifications
4-1. MVS-8000...................................................................................................4-1
4-2. MVE-8000...................................................................................................4-9
4-3. DCU-8000 .................................................................................................4-11
4-4. CCP-8000 ..................................................................................................4-13

1-1
MVS-8000 System
SYSTEM SETUP
Section 1
System Overview
1-1. Introduction
The MVS-8000 system has integrated a wide variety of new features including SDTV and HDTV televi-
sion signal capability, advanced networking and layout-free control panels.
The MVS-8000 system includes SD/HD simulcast, multiple frame rates and resolutions, multi-channel
casting and even broadcast equipment sharing, to name just a few.
The MVS-8000 system is completely ready for smooth integration into current systems, offering the
added quality, reliability and features, needed for the live/post production environment.
The MVS series can be flexibly expanded as a user’s needs grow simply installing the appropriate options
to the basic system.
1-2. Features
Flexible configurations
Item Expandable number Expansion basis
M/E configuration 2 M/E Per M/E
3 M/E
4 M/E
Inputs SD: up to 80 inputs Per 17 inputs
HD: up to 68 inputs
Outputs 56 assignable outputs Per 8 outputs
(including 8 monitor outputs)
DME Channel 1 to 8 CH Per 1 CH
(4 CH in one chassis)
SD/HD capability
High definition Standard definition
1080i/60/59.94/50 480i/59.94
1080PsF/30/29.97/25/24/23.976 576i/50
720p/59.94 (future)

1-2 MVS-8000 System
SYSTEM SETUP
1-3. System Description
The MVS-8000 System consists of Switcher Processor Pack (MVS-8400/8300/8200), DME Processor
Pack (MVE-8000), Center Control Panel Pack (CCP-8000) and Device Control Unit Pack (DCU-8000).
1-3. System Description
MVE-8000
DCU-8000
MVS-8400/8300/8200
AUX PANEL
MENU PANEL
MIAN PANEL
POWERA
SYSTEM CONTROL UNIT MKS-8010
MKS-8010
CCP-8000

1-3
MVS-8000 System
SYSTEM SETUP
1-3-1. MVS-8000
The MVS-8000 is a 16 rack unit chassis which can be mounted in the standard 483 mm (19 inch) rack.
External dimensions of MVS-8000
577.9
400.1
177.8
65.1
375
708(16U)
465
482
440
35 27
61 380
520
1-3. System Description
Unit : mm

1-4 MVS-8000 System
SYSTEM SETUP
n
The MVS-8000 has a built-in cooling system consisting of eighteen fans in total fan mounted on the rear
and both sides of the frame, and an air filter on the rear of the front panel. Cooling air is drawn in at the
front side of the frame, through the filter, boards, and modules, and then expelled out the rear and both
sides of the frame at the fan unit.
If dust is accumulated at the intake of the fan or the cables doesn't keep off over 10 cm from the fans, air
is prevented from flowing smoothly that result in rise of temperature inside the machine. It may result in
adverse effects on performance and life of the machine.
Fans Fans
Fans
Fans
Fans
Fans
1-3. System Description
MVS-8000
Multi Format Switcher Processor
<Rear Side>

1-5
MVS-8000 System
SYSTEM SETUP
The MVS-8000 has the slots for plug-in boards in its front and rear. It contains of 32 slots in total for
standard/option boards.
n
The MVS-8000 is shown below with the front panel removed. The front panel must remain in place and
closed during normal system operation to keep maximum cooling efficiency.
3
2
1
32
Slots on
the front side
1-3. System Description
MVS-8000
Multi Format Switcher Processor

1-6 MVS-8000 System
SYSTEM SETUP
1-3. System Description
Power, control, and video connectors are at the rear chassis of MVS-8000. The illustration below shows a
full loaded rear board. Some of the modules shown below are optional and may not be included in your
system configuration.
GPI connector
TERMINAL connector
REMOTE 1 to 4 connectors
AC IN A, B, C, and
D connectors
terminal
REF INPUT connectors
REF OUTPUT connectors
EXT connector
DATA connector
CTRL connector
DME 1A, 1B, 2A, 2B connectors
PRIMARY INPUTS
69 to 80 connectors
MONITOR OUTPUTS
49 to 56 connectors
PRIMARY INPUTS
1 to 68 connectors
OUTPUTS 1 to 48 connectors
MVS-8000
Multi Format Switcher Processor

1-7
MVS-8000 System
SYSTEM SETUP
1-3. System Description
MVS-8000 options
The following lists the plug-in boards that may be purchased as options.
MVS-8000 option configuration
Front side
Option name Board name Slot No. Descriptions
MKS-8210HD/SD DO-41/DO-42 3, 7, 12, 16 Mix/Effect Board Set
MIX-45 4, 8, 13, 17 M/E1: Slot 12 to 15
KPC-16 5, 9, 14, 18 M/E2: Slot 7 to 10
DI-40/DI-41 6, 10, 15, 19 M/E3: Slot 3 to 6
M/E4: Slot 16 to 19
MKS-8170HD/SD DIF-119/DIF-122 11 DME I/F Board
MKS-8160HD/SD OUT-23/OUT-24 24 to 29 8 Outputs Board
1 to 8 output: Slot 24
9 to 16 output: Slot 25
17 to 24 output: Slot 26
25 to 32 output: Slot 27
33 to 40 output: Slot 28
41 to 48 output: Slot 29
MKS-8440HD/SD DIO-62/DIO-63 31 Frame Memory Board Set
MY-102 32
Rear side
Option name Board name Printed characters Description
MKS-8110HD/SD CNI-9/CNI-10 IN 1 to 17 17 Inputs Board
IN 18 to 34
IN 35 to 51
IN 52 to 68
MKS-8160HD/SD CNO-11/CNO-17B 8 Outputs Board
I nsert a real board into the slot that corresponds
to the slot in the front.
MKS-8161HD/SD CNO-12/CNO-17A OUT 49 to 56 8 Monitor Outputs Board
MKS-8111SD CNI-17 IN 69 to 80 12 Additional Input Board

1-8 MVS-8000 System
SYSTEM SETUP
1-3. System Description
Power supply unit
The MVS-8000 Power Supply Units are supplied with MVS-8000 processor.
Three power supply units are required to run the MVS-8000 system. An optional fourth unit is added to
provide redundant power. With fourth unit mounted, one unit can fail without causing system failure.
It is recommended that each unit’s AC input be connected to the AC supply circuit of a separated power
source system. Any unit (s) for which a separate power source system is not available, is (are) recom-
mended to be connected to a UPS (Uninterruptible Power Supply).
Option
Option name Description
HK-PSU04 Power Supply Unit
The power cord is not supplied with the MVS-8000.
It is necessary that the power cord should be applicable to places in the area.
Power cord
Area Specification Length Part No.
Japan 125 V 10 A 2.5 m 1-776-997-11
*3P - 2P (adaptor) *1-750-686-11
USA/Canada 125 V 10 A 2.4 m 1-557-377-11
All Europian countries 250 V 10 A 2.4 m 1-782-929-21

1-9
MVS-8000 System
SYSTEM SETUP
1-3. System Description
1-3-2. MVE-8000
MKS-8800 (Mutlti Format DME Processor) is a 5 rack unit chassis which can be mounted in the standard 483 mm (19
inch) rack.
External dimensions of MKS-8800
Unit : mm
14.5
146.2 37.4
221 (5U)
375
17.5
465
482
440
35 27
206
38061 115.5115.5144.5
520

1-10 MVS-8000 System
SYSTEM SETUP
1-3. System Description
n
The MVE-8000 has a built-in cooling system consisting of four fans in total mounted on the rear and right
side of the frame, and an air filter on the rear of the front panel. Cooling air is drawn in at the front side of
the frame, through the filter, boards, and modules, and then expelled out the rear and right side of the
frame at the fan unit.
If dust is accumulated at the intake of the fan or the cables doesn't keep off over 10 cm from the fans, air
is prevented from flowing smoothly that result in rise of temperature inside the machine. It may result in
adverse effects on performance and life of the machine.
The MVE-8000 has the slots for plug-in boards in its front and rear. It contains of 6 slots in total for
standard/option boards.
n
The MVE-8000 is shown below with the front panel removed. The front panel must remain in place and
closed during normal system operation to keep maximum cooling efficiency.
Fans
Fans
2
1
5
6
Slots on
the front side
MVE-8000
DME Processor Pack
MVE-8000
DME Processor Pack

1-11
MVS-8000 System
SYSTEM SETUP
REF INPUT connectors
DATA connector
CTRL connector
EDITOR connector
GPI connector
terminal AC IN connector
SWITCHER A and B connectors
Power, control, and video connections are at the rear of MVE-8000. The illustration below shows a full
loaded rear board. Some of the modules shown below are optional and may not be included in your
system configuration.
1-3. System Description
MVE-8000
DME Processor Pack

1-12 MVS-8000 System
SYSTEM SETUP
1-3. System Description
MVE-8000 options
The following lists the plug-in boards that may be purchased as options.
MVE-8000 option configuration
Front side
Option name Board name Slot No. Descriptions
MKS-8810M DVP-21 1 to 2, 4 to 5 Basic Effect Board
(MKS-8830M) (VSE-39: daughter board) CH1: Slot 1
CH2: Slot 2
CH3: Slot 4
CH4: Slot 5
MKS-8820M VIF-26 3 Input/Output Board
Rear side
Option name Board name Slot No. Descriptions
MKS-8820M CN-2153 _Input/Output Board
Insert a real board into the slot that corresponds
to the slot in the front.
Power supply unit
The MVE-8000 Power Supply Unit is supplied with MVE-8000 processor.
One power supply unit is required to run the system.
The power cord is not supplied with the MVE-8000.
It is necessary that the power cord should be applicable to places in the area.
Power cord
Area Specification Length Part No.
Japan 125 V 10 A 2.5 m 1-776-997-11
*3P - 2P (adaptor) *1-750-686-11
USA/Canada 125 V 10 A 2.4 m 1-557-377-11
All Europian countries 250 V 10 A 2.4 m 1-782-929-21

1-13
MVS-8000 System
SYSTEM SETUP
1-3. System Description
1-3-3. CCP-8000
The modular design of MVS-8000 system control panel provides flexibility for locating the desired
module in their preferred area of each M/E base plate. M/E base plates are offered in the three types of
16, 24 and 32 button style, while M/E bank are available in 2 M/E, 3 M/E, and 4M/E configuration.
It also have some module of DME control, Key Frame Control, Memory Card/USB, Flexi Pad and etc.
The CCP-8000 consists of System Control Unit (MKS-8010), Menu Panel (MKS-8011), and Main Panel.
System Control unit (MKS-8010) is a 3 rack unit chassis, which can be mounted in the standard 483 mm
(19 inch) rack.
Main panel
The main panel, comprised of various types of operation modules, provides the operating controls of the
system. It can be fleely laid out, with variable numbers of M/E banks (2 to 4) and cross-point buttons (16,
24 or 32) and variable layout of the AUX bus module. Operation modules can be mounted in the MKS-
8075 Extension Adaptor and MKS-8076 Memory Card/USB Adaptor for installation apart from the main
panel. The AUX bus module can also be removed from the main panel and used as an AUX panel.
Menu panel (MKS-8011)
The menu panel provides a GUI interface for operating the menus.
CCP-8000 IM
AUX PANEL
MENU PANEL
MIAN PANEL
POWER A
SYSTEM CONTROL UNIT MKS-8010
MKS-8010
CCP-8000

1-14 MVS-8000 System
SYSTEM SETUP
1-3. System Description
System control unit (MKS-8010)
The system control unit provides control functions for the center control panel as a whole. It also supplies
power to the various panels
Shows the modules for CCP-8000.
Model Name Description
MKS-8013 32 AUX Bus Module
MKS-8014 24 AUX Bus Module
MKS-8015 16 AUX Bus Module
MKS-8017 32 XPT Module
MKS-8018 24 XPT Module
MKS-8019 16 XPT Module
MKS-8020 Standard Transition Module
MKS-8021 Simple Transition Right Module
MKS-8022 Simple Transition Left Module
MKS-8023 Compact Key Transition Module
MKS-8024 Flexi Pad Module
MKS-8025 Memory Card/USB Module
MKS-8026 10 Key Pad Module
MKS-8030 Key Frame Module
MKS-8031TB Track Ball Module
MKS-8032 DSK Fader Module
MKS-8034FB FTB Module
MKS-8035 Key Control Module
MKS-8031JS Joy Stick Module
MKS-8033 Utility/Shotbox Module
Main panel
Main Panel installation requires careful attention to the console support structure and the console cutout
dimensions necessary to accommodate the mounting flanges located on the front and sides of the tub.
Menu panel (MKS-8011)
The Menu Panel includes a touch screen display, buttons for accessing menus, and knobs for adjusting
parameter values.
n
The Main Panel weighs approximately 16 to 30 kg (depending on the configuration). Prior to installation,
ensure that your console is structurally capable of supporting the Main Panel.
The Main Panel was designed to be flush mounted in a console, but it may also be surface mounted to be
protruded above the surface of the console.

1-15
MVS-8000 System
SYSTEM SETUP
1-3. System Description
External dimensions of MKS-8010
POWER A
POWER B
SYSTEM CONTROL UNIT MKS-8010
375
482
440 132.4 17.5
7520
38061
ø26
Unit : mm

1-16 MVS-8000 System
SYSTEM SETUP
1-3. System Description
External dimensions of main panel/AUX panel/menu panel MKS-8011
1304
652
1407
69.569.5
782
49 59.7
59
98
73
72
4873
300 104
9.5
57
80
220
160
213
424
132
46
1444
528
Unit : mm
