Sony CM-ZS300 User manual

1
3-864-802-11
CDMA PCS
Telephone
Operating Instructions
Draft Tuesday, February 09, 1999
CM-ZS300
capri.book Page 1 Tuesday, February 9, 1999 5:20 PM

2▼
capri.book Page 2 Tuesday, February 9, 1999 5:20 PM

iii
Contents
Getting Started
Features ......................................................................................................................7
Unpacking Your Phone............................................................................................8
Phone Overview........................................................................................................9
Charging the Battery ..............................................................................................13
Turning On the Phone............................................................................................16
Activating the Phone..............................................................................................17
Using Basic Functions
Making Calls............................................................................................................19
Receiving Calls........................................................................................................20
Saving Names and Numbers
Saving a Phone Number........................................................................................21
Editing a Saved Name............................................................................................24
Changing the Phone Book Location of a Saved Name......................................24
Viewing a Saved Number......................................................................................25
Restricting All Phone Numbers Assigned to a Saved Name............................25
Restricting One Phone Number Assigned to a Saved Name ...........................26
Unrestricting All Phone Numbers Assigned to a Saved Name.......................26
Unrestricting One Phone Number Assigned to a Saved Name.......................27
Erasing a Saved Name............................................................................................27
Creating a Voice Label to a Saved Name ............................................................28
Changing the Type of a Saved Number ..............................................................28
Setting a Saved Number as the Main Phone Book Number.............................29
Editing a Saved Phone Number............................................................................29
Erasing a Saved Phone Number...........................................................................30
Calling a Saved Number
Calling a Saved Number........................................................................................31
Finding a Saved Phone Number...........................................................................32
Speed Dialing...........................................................................................................33
Touch Dialing..........................................................................................................33
Adding a Prefix to a Saved Phone Number........................................................34
Sending Tones .........................................................................................................34
Using Fast 4 Dialing................................................................................................35
capri.book Page iii Tuesday, February 9, 1999 5:20 PM

iv ▼Contents
Checking Your Call History
Call History..............................................................................................................38
Viewing Detailed Information of Calls List Entries...........................................38
Changing the Phone Settings
Settings Options......................................................................................................39
Displaying the Settings Menu...............................................................................40
Sounds .............................................................................................................................41
Display.............................................................................................................................42
Security............................................................................................................................43
Timers..............................................................................................................................44
Network...........................................................................................................................44
Misc..................................................................................................................................45
Hands Free Kit................................................................................................................45
Speakerphone.................................................................................................................46
Headset............................................................................................................................46
Customizing Your Phone
Date/Time................................................................................................................47
Using the Scratchpad..............................................................................................48
Using Short Messaging Services
Receiving Messages................................................................................................49
Checking Message Storage Capacity ..................................................................49
Accessing Messages................................................................................................50
Reading Voice Mail Message Notifications.........................................................50
Reading New Text Messages.................................................................................51
Reading Old Text Messages ..................................................................................51
Erasing Old Text Messages [F14]..........................................................................53
Additional Information
Troubleshooting......................................................................................................55
Accessories...............................................................................................................57
Specifications...........................................................................................................59
Rules and Regulations............................................................................................60
Safety Precautions...................................................................................................61
FCC/Battery/Legal Statement..............................................................................65
[back cover]
800 Numbers/Web Address .........................................................................66
capri.book Page iv Tuesday, February 9, 1999 5:20 PM

7
Getting Started
Features
Your Sony D-WAVE Zuma™phone has many special features to make mobile
calling easy and fun. Here are just a few of the features available:
❑Phone Book: You can store up to 199 names and up to 400 phone
numbers. Use the Jog Dial navigator to easily locate and call your most
frequent contacts. See page xx for more information.
❑Voice Label: You can record a short message with up to 20 of your phone
book entries. You can locate your favorite contacts by hearing a message
you've recorded. Using the Jog Dial navigator you can recall a phone
number and make a call without ever having to look at the phone. See
page xx for more information.
❑Vibration Ringer: This convenient feature won't disturb those around
you when you're receiving a call. See page xx for more information.
❑Ringer Options and Melodies: Choose from a variety of ringer sounds
and melodies. You won't confuse someone else's ringing phone with
your own when you select a unique ringer. See page xx for more
information.
❑One Touch Ringer Mute: To instantly mute the ringer as you are
receiving a call, just turn the Jog Dial navigator down. See page xx for
more information.
❑Automatic On and Off: You can have your phone turn on and off at a
certain time everyday. This feature allows your phone to “wake up” or
“go to sleep” when you want it to. See page xx for more information.
❑Keypad Lock: To avoid any accidental operations while you are carrying
your phone around, press and hold the Jog Dial navigator to lock the
keypad. See page xx for more information.
❑Phone Lock: If you have to leave your phone unattended, you can lock it
with a security code. See page xx for more information.
❑Language Selection: Your phone speaks more than one language. See
page xx for more information.
❑Banner: Create your own text to display on your phone. See page xx for
more information.
❑Accessories: Sony Authorized Accessories are available to carry, charge
and communicate with your phone. See page xx for more information.
❑Service Provider Features: Your service provider may be able to
“activate” other special features in your Sony phone. Caller ID and
Short Message Services are examples of features provided by many
service providers.
capri.book Page 7 Tuesday, February 9, 1999 5:20 PM

8▼Getting Started
Unpacking Your Phone
Your phone package includes the following items. If anything is missing,
contact your nearest Sony dealer.
Additional accessories and different AC adapters may be supplied with
phones outside North America. See “Accessories” on page 57 for more
information about accessories.
CM-ZS300 Telephone (1) QN-029BPL Li-Ion Battery (1)
QN-001AC AC Adapter
capri.book Page 8 Tuesday, February 9, 1999 5:20 PM

Getting Started ▼9
Phone Overview
Telephone (Front)
1 LED
Lights when there is an incoming call; lights green when charging; lights red
when charging is complete.
2Earpiece
3Display
4Keypad
Use the keypad to enter numbers. Press and hold a number button for touch
dialing.
5 Folding microphone arm
Open to make/receive a call. Close to end a call.
6
Press to make and receive calls when the microphone arm is open.
7 (Clear)
Press to clear the last digit on the display, or to exit the current menu. Press and
hold to clear all digits on the display.
8
Press to end calls or cancel an operation.
9 (Power)
Press and to turn the phone on or off.
SEND
CLR
END
PWR
capri.book Page 9 Tuesday, February 9, 1999 5:20 PM

10 ▼Getting Started
Telephone (Back and Sides)
0Ringer speaker
Allows ringer sounds to be heard.
qa Battery
qs Battery release tab
Push up to remove the battery.
qd Antenna
qf Jog Dial™navigator
Push and turn to navigate menus and to change settings.
qg Connector
Use to connect the phone to either the AC adapter or to one of the other
accessories available for your phone.
capri.book Page 10 Tuesday, February 9, 1999 5:20 PM

Getting Started ▼11
Using the Jog Dial
Use the Jog Dial to navigate through the displays, as shown below.
Navigating through the Displays
m
,
+
m
–
To select an option, push
in the Jog Dial
To scroll up to an option,
turn the Jog Dial up
To scroll down to an
option, turn the
Jog Dial down
The standby screen (left),
is the first screen you see
when you turn on the
phone.
199 Name 199
Scratch Pad
Calls Made
Received Calls
Missed Calls
Messages
Date and Time
Sony
Settings ,Settings
Search/Sort Sounds
01 Name 1 Display
02 Name 2
03 Name 3
capri.book Page 11 Tuesday, February 9, 1999 5:20 PM

12 ▼Getting Started
Display
Icons and text appear on the display to show the status of the phone.
2 (in-use)/ (out-of-service)
The in-use icon appears during a call. A slash through the in-use icon appears
when no signal is received. You cannot make or receive calls when the out-of-
service icon is visible.
3(digital)
Appears when your phone is receiving a digital signal.
4(signal strength)
Tells you the approximate strength of the signal being received.
5(roam)
Appears when you are roaming outside your home service area.
6(message)
Appears when you have new text or voice mail messages pending. The icon
flashes if the new message is urgent.
7(battery)
Shows the approximate amount of charge power remaining in the battery.
Recharge the battery before it is fully discharged.

888
1 2 3 4 5 6 7
8
capri.book Page 12 Tuesday, February 9, 1999 5:20 PM

Getting Started ▼13
Charging the Battery
Charge the battery before using the phone. A new battery is not fully
charged. To charge the battery, attach it to the phone, then connect the
supplied AC adapter.
Attaching the Battery
To remove the battery
NOTE You can also use the accessories listed on page 57 to charge the battery.
1Hook the battery onto the bottom of the
phone 1, and lower the battery down 2.
2Snap the battery in place.
1Push the battery release tab down.
2Lift up the top of the battery 1, and pull it
out 2.
capri.book Page 13 Tuesday, February 9, 1999 5:20 PM

14 ▼Getting Started
Charging the Battery
You can charge the battery using the AC adapter that is supplied with some
phones. You can also use one of the accessories listed on page XX to charge
your battery.
Connect the AC adapter to the phone and the other end to a standard AC
outlet as illustrated below.
When the power
is turned on As the battery charges, the battery icon ( ) pulses and
the LED remains green to indicate that the phone is
charging.
When the power
is turned off The message Battery is Charging is displayed,
pulses, and the LED remains green.
When the battery is
fully charged The LED turns from green to red and stops
pulsing.
NOTE • If you make or receive a call when the battery is not charged sufficiently, the call will be
cut off. In that case, you will hear an alert, indicating that the battery is low.
• You can turn on the phone without the battery, but you cannot make or receive a call,
even if you connect the AC adapter to an AC outlet.
• It is normal for the battery to become warm during charging or after use.
CAUTION • Avoid charging for long periods of time, since this reduces battery life.
• Avoid charging in temperatures below 32°F (0?C) or over 104°F (40°C).
• Avoid charging the battery in direct sunlight or in places with highhumidity (such as a
bathroom).
• Do not use any battery other than the one specified in these instructions.
• Do not expose the batteryto temperatures above 140°F (60°C). For example, do not
leave the battery in the sun on the dashboard of a vehicle.
• Do not dispose of the battery in a fire or short-circuit it. Doing so may cause the battery
to leak or get hot, which could cause personalinjury.
• Do not try to disassemble the battery.
• Do not remove the battery while the phone is turned on.
To the connector on the phone
To an AC outlet
Display
capri.book Page 14 Tuesday, February 9, 1999 5:20 PM

Getting Started ▼15
Checking the Battery
Battery life
A new, fully charged battery lasts approximately as long as described below
before it needs to be recharged. Battery life may vary depending on
conditions of use.
Battery status
The battery icon indicates the battery level as follows (when the power is on):
Note that the battery icon displays the approximate charge level and that the
consumption may vary depending on conditions of use, such as ambient
temperature, network coverage, and usage patterns.
Standby time 80 hours
Talk time 3.5 hours
When the battery is empty The battery icon flashes, a message is displayed, the LED
blinks red, and a beep sounds to indicate the battery is
near empty. Shortly thereafter, the phone turns off. To
start using your phone sgain, recharge the battery.
t t t
Full
t t
Empty
capri.book Page 15 Tuesday, February 9, 1999 5:20 PM

16 ▼Getting Started
Turning On the Phone
To use your phone, the power must be turned on. It is preferable to extend
the antenna, since this maximizes signal strength and minimizes interference.
Extending the Antenna
Hold the end of the antenna and pull up until fully
extended.
Turning On the Power
Hold down until the phone displays POWERING ON. The LED turns on
and then off, a beep sounds, and the phone starts searching for a signal.
When the phone has found a service signal, the standby display appears.
Now the phone is ready for use.
Turning Off the Power
Hold down until the phone displays POWERING OFF .
NOTE For improved improved perfomance, the phone’s antenna extends
at a slight backward angle. Do not attempt to straighten the
antenna by bending it.
To retract the antenna Push the antenna down until it
is fully retracted.
To check the
signal strength The signal strength icon indicates various levels of signal
strength. It is best to make calls when the signal is strong,
although calls can be made when the signal strength is weak.
If you are out
of the service area The out-of-service ( ) icon appears and the phone searches
for a service signal. If a signal cannot be found, the phone will
not be able to make or receive a call. If it cannot find a signal
after some time, the phone enters a power saving mode. It will
"wake up" periodically to search for a service signal.
PWR
Strong Weak
PWR
capri.book Page 16 Tuesday, February 9, 1999 5:20 PM

Getting Started ▼17
Activating the Phone
Before you can begin making and receiving calls, you need to obtian service
from from a service provider. For information about service providers, check
with the dealer from which you purchased the phone.
capri.book Page 17 Tuesday, February 9, 1999 5:20 PM

18 ▼Getting Started
capri.book Page 18 Tuesday, February 9, 1999 5:20 PM

19
Using Basic Functions
Making Calls
You can call any number up to 32 digits from within your service area.
1Use the number buttons to enter the number.
2If the microphone arm is closed, open it to dial.
If the microphone arm is open, press to dial the number.
3To end the call when you are finished, press or close the
microphone arm.
Related Functions
If you enter a wrong number Press .
To clear all entered digits Press .
To return to the standby display Hold down .
TIP You can also make calls from the list of saved names and numbers (see page 31) and from the
call history lists (see page 38).
To adjust the earpiece volume During a call, turn up to increase
volume or down to decrease volume
To mute/unmute the microphone During a call, push and hold .
To redial the last number automatically After a call. on the standby display, press
when the microphone arm is open.
CLR
END
CLR
SEND
END
+
–
SEND
capri.book Page 19 Tuesday, February 9, 1999 5:20 PM

20 ▼Using Basic Functions
Receiving Calls
You can receive calls as long as the out-of-service ( ) icon is not displayed.
When you receive a call, the ringer sounds or the phone vibrates. Incoming
Call flashes, and the LED blinks.
1If the microphone arm is closed, open it to answer the call. If the
microphone arm is open, press any button (except ) to answer the
call.
2To end the call, press or close the microphone arm.
Related Functions
NOTE If the ringer is turned off, you will not hear the ringer. Ringer Off is displayed. See
“Sounds” on page 41 for details.
To adjust the earpiece volume During a call, turn up to increase
volume or down to decrease volume.
To mute/unmute the microphone During a call, push and hold .
To mute the ringer while it is ringing Turn down.
If caller ID is available The caller’s phone number appears.
If you missed a call The message You have missed XX Calls
appears. To return to the standby display,
press , , or . If caller ID was
available, the caller’s phone number is
stored in the Missed Calls list. (For
details, see “Checking Your Call History”
on page 37.)
PWR
END
+
–
–
SEND END
capri.book Page 20 Tuesday, February 9, 1999 5:20 PM

21
Saving Names and Numbers
Your phone can store up to 199 name entries with up to 400 phone numbers.
Name entries can include one or more phone numbers. Each phone number
can contain up to 32 digits.
Saving a Phone Number
1On the standby display, use the keypad to enter the phone number you
want to save.
2Push .
3Turn to select Save Number, and then push .
When Number Type? appears, select the type of number that you want to
save, as follows:
4Turn to select the number type, and then push .
When Under what Name appears:
Type Icon Type Icon
Home Voice Mail
Work Fax
Pager Modem
Cell Misc None
To save the number to a new name Push to select New Name and then
follow the procedures under “Saving a
New Name” on page 23.
To save the number to a name you
already created Turn to select the name from the list and then push .
NOTE You can also .... default number shown in the phone list .. how to change then number or
name or which number to show in the display
capri.book Page 21 Tuesday, February 9, 1999 5:20 PM

22 ▼Saving Names and Numbers
Entering hyphens and pauses
In addition to digits, you can insert hyphens, time pauses, and hard pauses
into phone numbers. (See “To release a pause or link during a call” on
page 31 for information on releasing a pause or link during a call.)
1While entering the digits of a phone number, push .
2To select one of the following, turn and then push .
After inserting a hyphen or pause, the display returns to number entry mode.
Hyphens When you enter a hyphen manually (for example, when you want to
store a number that does not follow the US/Canada standard),
autohyphenation is turned off for that number.
Pauses A time pause (T) automatically sends additional digits about two
seconds after a call is connected. A hard pause (H) allows you to
send additional digits after a call is connected. For example, you may
want to enter a phone number in your phone book as follows: 1-800-
555-1212H123 . The hard pause character in the phone number
allows you to dial the extension 123 after you have reached 1-800-
555-1212.
To Enter Select The Display Shows
A hard pause Insert Hard Pause H
A time pause Insert Time Pause T
A hyphen Insert Hyphen –
capri.book Page 22 Tuesday, February 9, 1999 5:20 PM
