Sony Playstation vr cuh-zvr2 User manual

CUH-ZVR2

4-743-854-21(1)

WARNING

Before using the product, carefully read this instruction manual and

any manuals for compatible hardware and follow the warnings and

instructions for set up. Retain this instruction manual for future

reference.

• Do not use PlayStation®VR if you are tired, dizzy, light-headed,

nauseous, sick, under the inﬂuence of alcohol or drugs, or have an

impaired sense of motion or balance. Consult a doctor before using

PS VR if you suer from a serious medical condition.

• Wearing the VR headset will restrict your view of your actual

surroundings. The VR headset does not detect obstacles. Review

surroundings and clear obstacles from an area larger than the Play

Area before use. Please refer to the "About the Play Area" section in

the Quick Start Guide for more information on how to set up the

Play Area. Make sure you are not near any walls, stairs, furniture, or

other obstacles that you may collide with or trip over.

• Take steps to prevent pets, persons, or other obstacles entering the

play area during use.

• Remain in the center of the Play Area and do not walk around while

wearing the VR headset. Remain seated whenever possible and

avoid extreme or excessive movements of the head, limbs or body

whilst wearing the VR headset. If an application requires you to

stand while wearing the VR headset, ensure that you follow the

application instructions carefully.

• Before beginning play, check that the VR headset cable is not

wrapped around your body or limbs, and check frequently during

play.

• IMMEDIATELY DISCONTINUE USE and consult your doctor before

resuming gameplay if you or your child experience any of the

following health problems or symptoms: Dizziness, altered vision,

eye or muscle twitches, loss of awareness, disorientation, seizures,

or any involuntary movement or convulsion. RESUME GAMEPLAY

ONLY ON APPROVAL OF YOUR DOCTOR.

• Some people may experience motion sickness, nausea,

disorientation, blurred vision or other discomfort. If experienced,

stop using immediately and remove the VR headset. Rest, and do

not engage in any activities that require unimpaired vision, balance

or coordination until after symptoms have completely disappeared.

• Do not use the product when you are tired or need sleep.

• Do not use the product in a location that may be subject to shaking

or other unstable conditions.

• It may take some time to become accustomed to virtual reality

experiences. During initial use, it is recommended that you use the

product for short periods of time.

• Generally we recommend that you take 15 minute breaks for every

hour of play. However, when viewing virtual reality content, the

length and frequency of necessary breaks may vary from person to

person - please take breaks that are long enough to allow any

feelings of discomfort to subside.

• If you experience any discomfort after use, rest until the discomfort

subsides.

Seizures induced by light stimulation (Photosensitive Epilepsy)

If you have an epileptic condition or have had seizures, consult your

doctor prior to playing. Some individuals may experience eye

soreness, altered vision, migraine, muscle twitching, convulsion,

blackout, loss of awareness or disorientation when exposed to

ﬂashing or ﬂickering lights or other light stimulation on a television

screen or while playing video games. If you experience any of the

above symptoms while playing, discontinue use immediately and

consult your doctor.

Stop playing immediately when you experience the following

symptoms

In addition to the above symptoms, whilst playing if you have a

headache, dizziness, nausea, fatigue, similar symptoms to motion

sickness, or if you feel a discomfort or pain in any body part such as

eyes, ears, hands, arms, feet, discontinue use immediately. If the

condition persists, seek medical attention.

Device software

The device software of the PS VR is licensed to you under the terms of

a separate end user license agreement. For details, visit

doc.dl.playstation.net/doc/psvr-eula/.

Precautions

Safety

• Do not damage the AC power cord and AC adaptor.

• For more information on product safety and support, visit our

website ( "Further information").

Use and handling

• Before connecting, check that the connectors are free of dust and

small particles.

• Do not swing the VR headset or the AC adaptor around by their

cables.

• Do not unplug the VR headset cable until the tracking lights

("Part names") are turned o. Removing or unplugging while the

lights are on may cause a malfunction.

• Do not place objects on the product, throw or drop the product, or

otherwise expose it to strong physical impact.

• Keep the product out of the reach of small children. Small children

may swallow small parts, may pull on cables and cause the

processor unit or VR headset to fall, or may wrap the cables around

themselves, which may inﬂict injury or cause an accident or a

malfunction.

• Do not touch the AC power cord, AC adaptor or processor unit

during an electrical storm.

• Do not allow liquid or small particles to get into the product (ports,

vents, etc.). If this happens, stop use and disconnect it from the

electrical outlet immediately.

• Do not expose the product to dust, smoke or steam. Dust or other

matter can cause ﬁre or electric shock.

• Avoid prolonged bodily contact with the processor unit, AC adaptor,

or air from the vents when the product is turned on. Extended

contact may cause low-temperature burns*.

* Low-temperature burns are burns that occur when the skin is in contact

with objects of relatively low temperatures (40 °C or more) for an

extended period of time.

• Do not use the VR headset, stereo headphones, or stereo headset if

they cause discomfort to your skin. If the headset or headphones

cause discomfort to your skin, discontinue use immediately. If

symptoms do not subside even after discontinuing use, seek

medical attention.

• The product and its parts are made from metal and plastic materials.

When disposing of the product, follow local regulations for the

proper disposal of such materials.

• Follow the precautions below to help prevent the product exterior

from deteriorating or discolouring.

– Do not use solvents or other chemicals on the product.

– Do not allow rubber or vinyl materials to be in prolonged contact

with the product.

• Permanent hearing loss may occur if the headset or headphones are

used at high volume. Set the volume to a safe level. Over time,

increasingly loud audio may start to sound normal but can actually

be damaging your hearing. If you experience ringing or any

discomfort in your ears or mued speech, stop listening and have

your hearing checked. The louder the volume, the sooner your

hearing could be aected. To protect your hearing:

– Limit the amount of time you use the headset or headphones at

high volume.

– Avoid raising the volume to block out noisy surroundings.

– Lower the volume if you can't hear people speaking near you.

• When using the headset or headphones in particularly dry air

conditions, you may sometimes experience a small and quick (static)

shock on your ears. This is a result of static electricity accumulated

in the body, and is not a malfunction of your headset or

headphones.

Use by children

The VR headset is not for use by children under age 12.

Wearing the VR headset

• It is important that you place the VR headset on your head properly

during use.

– To see instructions on how to wear the headset, go to the

PlayStation®4 system's function screen, and then select

(Settings) > [Devices] > [PlayStation VR].

– Do not overtighten the adjustment dial ( "Part names").

– You can wear the VR headset over your glasses but take care

when adjusting the scope ( "Part names"). Having your glasses

touch the lens could result in damage to your glasses, VR headset

lens or both. Do not push in or pull out the scope excessively.

• Regularly check the VR headset's to ensure it is being worn properly.

VR headset screen

• Do not expose the lenses ( "Part names") of the VR headset to

direct sunlight or intense light. Doing so may damage the VR

headset screen and cause a malfunction.

• Keep the VR headset’s attachment sensor ( "Part names") free

from any obstacles. If the attachment sensor is blocked, the screen

will not turn o automatically even if you remove the headset. If an

image appears on the screen for an extended period of time, it

might cause a screen burn and a faint image might remain

permanently on the screen.

• Black (dark) pixels and continuously lit pixels may appear in certain

locations on the screen. The appearance of such spots is a normal

occurrence associated with screens and is not a sign of a system

malfunction. Screens are made using highly precise technology.

However, a very small number of dark pixels or continuously lit

pixels may exist and color irregularities or brightness irregularities

may be visible on each screen.

Never disassemble or modify the product or accessories

Use the product and accessories according to the instructions in this

manual. No authorization for the analysis or modiﬁcation of the

product, or the analysis and use of its circuit conﬁgurations, is

provided. Disassembling will void the product warranty. Additionally,

there is a risk of ﬁre, electrical shock or malfunction if the product is

disassembled or modiﬁed.

Moisture condensation

If PS VR is brought directly from a cold location to a warm one,

moisture may condense inside the VR headset and the processor unit.

Should this occur, the product may not operate properly. In this case,

turn o the VR headset and unplug the AC power cord from the

electrical outlet. Do not use the product until the moisture evaporates

(this may take several hours). If the product still does not operate

properly, visit our website ( "Further information").

Unusual or unresponsive behavior

Press the (power) button ( "Part names") on the VR headset for

at least 7 seconds to force a shutdown, and then turn on the headset

again. If the problem persists, restart the PS4™ system.

High temperature message

• If the processor unit’s internal temperature becomes elevated, a

message will be displayed. In this case, turn o the PS4™ system

and leave it unused for a while. After the processor unit cools down,

move it to a location with good ventilation, and then resume use.

• Do not use the product in a closed cabinet or other locations where

heat may build up.

AC adaptor and AC power cord use

• Use an electricity supply that is easily accessible, so the AC power

cord can be unplugged quickly if the need arises. Stop use, unplug

the AC power cord from the electricity supply and disconnect any

other cables immediately if the product functions in an abnormal

manner, produces unusual sounds or smells or becomes too hot to

touch.

• Unplug the AC power cord from the electricity supply when the

status indicator on the processor unit is red. Unplugging the cord

while the indicator is white or ﬂashing red may cause a malfunction.

• Do not use an AC adaptor or AC power cord other than those

supplied with the product. The supplied AC adaptor and AC power

cord are designed exclusively for use with this product. They cannot

be used with other products. In addition, other AC adaptors or AC

power cords cannot be used with this product. Failure to follow

these precautions may cause the product to overheat and may lead

to ﬁre or electric shock.

– Do not plug the AC power cord for the product into an electricity

supply until you have connected the HDMI™ cables.

– Do not touch the plug of the AC power cord with wet hands.

– Do not use the AC adaptor when it is covered by a cloth, as it may

overheat, causing ﬁre or malfunction.

– Unplug the AC power cord from the electricity supply before

cleaning or when you do not intend to use the product for an

extended period of time.

– Do not connect the AC power cord to a voltage transformer or

inverter.

Storage conditions

• Do not expose the product or accessories to high temperatures,

high humidity or direct sunlight.

• Do not place the product or accessories on surfaces that are

unstable, tilted or subject to vibration.

Using PS VR

• Used with your PS4™ system and PlayStation®Camera, PS VR brings

you the excitement of virtual reality. You can interact with games

more directly because the camera captures the position, angle, and

movement of the VR headset.

• Be sure to always update your PS4™ system software and PS VR

device software to the most recent version.

• Be sure to connect your VR headset to the supplied CUH-ZVR2

processor unit. The headset will not work if connected to a

CUH-ZVR1 processor unit.

Your position while using the VR headset

Remain seated wherever possible. For applications with a standing

mode, follow the application instructions carefully.

PS VR settings

To conﬁgure PS VR settings, go to the PS4™ system's function screen,

and then select (Settings) > [Devices] > [PlayStation VR].

Hints

• These settings are available only when PS VR is connected to the PS4™

system.

• You can also conﬁgure some settings from the quick menu that appears

when you press and hold the (PS) button on the controller.

• For more information about setting up your PS VR, refer to the user's

guide for the PS4™ system. Select (Settings) > (User’s Guide/

Helpful Info) > (User’s Guide) from the function screen.

Parental controls

The PS4™ system contains settings that parents or guardians can

conﬁgure as necessary to restrict use of the product by children. To

conﬁgure settings for each child, go to the PS4™ system's function

screen, and then select (Settings) > [Parental Controls/Family

Management].

Part names

VR headset

Front

ABCD

A ) Tracking lights (front)

Rear lights Blue: Powered on

Front and rear lights blue: VR mode

Front and rear lights o: Powered o

B ) Scope adjustment button

C ) Front head support

D) Rear head support

E ) HDMI connector

F ) AUX connector

G) Scope

Rear

ABCDE

A ) Headband

B ) Attachment sensor

C ) Lenses

D) Adjustment dial

E ) Headband release button

F ) Tracking lights (rear)

G) Earpiece holder

Bottom

A ) Stereo headphone jack

B ) Headphone attachment hole

C ) (power) button

D) Light shield

E ) Microphone

F ) Tracking lights (front)

G) Volume + button

H ) (Microphone mute) button

I ) Volume - button

Processor unit

Front

A ) Status indicator

White: Powered on

Red: Rest mode

B ) AUX port

C ) HDMI output port

Rear

A B C

A ) HDMI TV port

B ) HDMI PS4 port

C ) (USB) port

D) DC IN 12V connector

E ) Vent

Stereo headphones

A ) Earpiece

B ) Stereo headphone plug

C ) Fastener

Changing the earpieces

The stereo headphones are supplied with M size earpieces attached.

Replace the earpieces with the S or L size earpieces for a better ﬁt. To

remove, twist then pull the earpiece o the headphones.

Hint

Install the earpieces ﬁrmly to help prevent them from accidentally detaching

during use.

Care and cleaning

Be sure to follow the instructions below to clean and maintain your

product.

• For safety reasons, unplug the AC power cord from the electrical

outlet and disconnect any other cables before cleaning.

• Do not use solvents or other chemicals to clean the exterior

surfaces.

• Do not use a chemically-treated cleaning cloth to wipe the product.

Processor unit exterior, VR headset exterior, head supports,

connectors

If they are dirty, wipe them with a soft, dry cloth.

Hint

If the connectors on the processor unit, AC power cord, or other parts are

dirty, signals may not be sent or received properly. You may also experience

noise or interruptions in the sound if the connectors on the headphones or

headset are dirty.

Lenses

Wipe only with a soft, dry cloth made speciﬁcally for cleaning lenses.

Do not use paper products such as paper towels, or tissues not

speciﬁcally intended for lenses.

Hint

Prolonged contact with water or dust may damage the lenses and shorten

their life.

Light shield

Remove the light shield from the VR headset and wash it with water.

Dry it completely with a soft cloth before reattaching it to the headset.

Reattach the light shield by matching the nubs on the shield to the

13holes on the VR headset.

Light shield

VR headset

Vents

Remove dust build-up from the vents using a vacuum cleaner or

similar product.

Earpieces

Remove the earpieces from the stereo headphones and wash them by

hand with a mild detergent. Dry them completely with a soft cloth

before reattaching them to the headphones.

For details on removing the earpieces, refer to "Changing the

earpieces".

Specifications

Design and speciﬁcations are subject to change without notice.

Functional descriptions and illustrations in this document may vary

from your PS4™ system software and/or PS VR devise software,

depending on the version in use.

VR headset

Screen 1920 × RGB × 1080

(960 × RGB × 1080 per eye)

Sensor 6-axis motion sensing system

(3-axis gyroscope, 3-axis accelerometer)

Port Stereo headphone jack

External dimensions

Approx. 187 × 185 × 277 mm

(width × height × depth / excluding

projecting parts / at shortest headband

length)

Mass Approx. 600 g (excluding cables)

Operating temperature 5 °C to 35 °C

Processor unit

Input/output

HDMI TV port

HDMI PS4 port

(USB) port

HDMI output port

AUX port

Maximum rated power Approx. 20 W

Input power rating 12 V 1.7 A

External dimensions

Approx. 150 × 39 × 114 mm

(width × height × depth / excluding

projecting parts)

Mass Approx. 300 g

Operating temperature 5 °C to 35 °C

AC adaptor

Input 100–240 V 1 A

50/60 Hz

Output 12 V 3 A

External dimensions

Approx. 108 × 46 × 30 mm

(width × height × depth / excluding

projecting parts)

Mass Approx. 146 g

Supported video input signals

For information about supported video input signals, visit

rd.playstation.com/psvr/zvr2/.

You can also access this information by using the QR code.

HARDWARE WARRANTY

For warranty terms and conditions of respective regions, please refer

to the "Support" page of the ocial website asia.playstation.com/, or

call our Customer Service Hotline ( "Further information").

" " and "PlayStation" are registered trademarks or trademarks of

Sony Interactive Entertainment Inc.

"SONY" and " " are registered trademarks or trademarks of Sony

Corporation.

The terms HDMI and HDMI High-Deﬁnition Multimedia Interface, and

the HDMI Logo are trademarks or registered trademarks of HDMI

Licensing Administrator, Inc. in the United States and other countries.

All other trademarks are the property of their respective owners.

Further information

Step-by-step setup video

Visit rd.playstation.com/psvr/zvr2/ to view a step-by-step setup video. You

can also access the video using the QR code.

Support

The ocial site (see below) for PlayStation®product support provides the

latest questions and answers about your product.

Ocial Website

asia.playstation.com/

Customer Service Hotline

Mon to Sun: 9:00-20:00

Hong Kong: 852-2341-2356

Singapore: 800-8523-663

Taiwan: 0809-079-888

警告

使用本產品以前，請先詳細閱讀本使用說明書及對應裝置的說明書，並請

遵照各項安裝的警告及使用說明。請妥善保存，以備將來參考之用。

• 在您感覺疲勞、暈眩、輕微頭痛、噁心、不適，或因酒醉、藥物引致的

身體狀態不佳，或有運動或平衡感覺障礙時，請勿使用PlayStation®VR。

若為患有重病者，使用PS VR前請先洽詢醫生。

• 戴上VR頭戴裝置後會阻擋您實際的周圍視線。VR頭戴裝置無法偵測障礙

物。使用前，請在比遊玩空間更大的範圍內進行確認並清除障礙物。關

於設置遊玩空間的方法，詳情請參閱快速參考指南中「關於遊玩空間」

的部分。為避免意外受傷，請確認您周圍是否有可能導致碰撞或絆倒的

牆壁、樓梯、家具或任何障礙物。

• 請事先做好預防其他人、寵物或障礙物在遊玩時進入遊玩空間的措施。

• 戴上VR頭戴裝置後，請留在遊玩空間的中央位置，並避免到處走動。同

時請盡量坐著遊玩，避免過度或激烈的頭部、四肢或身體動作。若應用

程式指示您在戴著VR頭戴裝置時站立，請小心遵照應用程式的指示。

• 開始使用前及遊玩時，請經常確認VR頭戴裝置線沒有纏繞您的身體或四

肢。

• 如果您或您的孩子有以下任何一種健康問題或症狀，請立即停止使用並

洽詢醫生，才能繼續遊玩遊戲：暈眩、視覺障礙、眼睛或肌肉抽動、意

識不清、精神恍惚、突發性疾病或者不自主的動作或肌肉抽動。必須經

醫生許可才能繼續遊玩遊戲。

• 有些人可能會感覺暈眩、噁心、意識不清、視覺模糊或其他不適。若您

感到不舒服，請立即停止使用並脫下VR頭戴裝置。請休息並避免從事任

何需要在正常視力、平衡或協調狀態下進行的活動，直至不適感消退。

• 請勿在疲勞或需要睡眠時使用本產品。

• 請勿在可能產生搖晃或不安定的場所使用本產品。

• 適應虛擬實境效果可能需要一些時間。建議初期使用本產品時，每次時

間不要過長。

• 一般建議每玩1小時休息15分鐘。但觀看虛擬實境效果的內容時，休息

的需要時間及頻率會因人而異。請充分休息以讓任何不適感消退。

• 使用後若感覺不適，請休息至不適感消退。

光刺激誘發的癲癇（光敏性癲癇）

若您有癲癇狀況或曾經癲癇發作，遊玩前請洽詢醫生。有些人看到閃光或

亮光，或是遊玩遊戲時電視機出現其他光線刺激，可能會產生眼睛痠痛、

視力失常、偏頭痛、肌肉抽動、抽搐、暫時性眼前昏黑、失去意識或迷失

方向等症狀。若您在遊玩時出現上述任何一項症狀，請立即停止使用並洽

詢醫生。

若您感到下列症狀時請立即停止遊玩：

除上述症狀以外，遊玩時您若感覺頭痛、暈眩、噁心、無力、類似暈車

感，或身體任一部位如眼睛、耳朵、手、手臂、腳感覺不適，請立即停止

使用。若症狀持續，請洽詢醫生。

裝置軟件

PS VR的裝置軟件乃受個別終端使用授權承諾條款限制授權。詳情請閱覽

以下網站：doc.dl.playstation.net/doc/psvr-eula/

以下規定僅適用於台灣

使用過度恐傷害視力

製造年月：請見產品本體標示

製造號碼：請見產品本體標示

設備名稱：PlayStation®VR頭戴裝置，型號（型式）：CUH-ZVR2

單元

限用物質及其化學符號

鉛

(Pb)

汞

(Hg)

鎘

(Cd)

六價鉻

(Cr+6)

多溴聯

苯

(PBB)

多溴二

苯醚

(PBDE)

頭戴裝置單元殼

體- ○○○○○

訊號處理器單元

殼體 - ○○○○○

線路板 - ○ ○ ○ ○ ○

有機發光二極體 - ○ ○ ○ ○ ○

鏡頭 - ○ ○ ○ ○ ○

發光二極體 - ○ ○ ○ ○ ○

其他附件（交流

電轉接器等） - ○○○○○

備考1.〝超出0.1 wt %〞及〝超出0.01 wt %〞係指限用物質之百分比含量

超出百分比含量基準值。

備考2.〝○〞係指該項限用物質之百分比含量未超出百分比含量基準值。

備考3.〝-〞係指該項限用物質為排除項目。

使用前須知事項

關於安全

• 請勿損壞交流電源線及交流電轉換器。

• 關於產品的安全與支援的詳細資訊，請瀏覽官方網站

（「更多資訊」）。

使用與保養

• 連接前請確認端子沒有任何灰塵或細微異物。

• 請勿抓取連接線來甩動VR頭戴裝置或交流電轉換器。

• 追蹤燈（「各部名稱」）熄滅前，請勿拔除VR頭戴裝置線。若在訊

號燈亮燈時移除或拔除，可能會造成故障。

• 請勿在本產品上放置其他物品。並請勿投擲或掉落本產品，或使其受到

強烈的外力撞擊。

• 請將本產品放在兒童拿不到的地方保管。兒童可能會誤吞小零件或拉扯

連接線而使訊號處理器或VR頭戴裝置滑落，或會用連接線纏繞自己，而

導致受傷或意外發生、機器故障。

• 請勿在雷雨天氣中觸摸交流電源線、交流電轉換器或訊號處理器。

• 請勿讓液體、小零件或其他異物掉入本產品（如連接埠或通風孔）。若

不慎發生此情況，請立刻停止使用，並從電源插座拔除連接線。

• 請勿將本產品曝露在灰塵、煙霧或蒸氣中。灰塵或其他異物可能會引起

火災或觸電。

• 請勿讓身體長時間接觸使用中的訊號處理器、交流電轉換器或從通風孔

所排出的氣體。長時間接觸這些可能導致低溫灼傷*。

* 低溫灼傷是指皮膚長時間接觸低溫物體（40 ℃或以上）所造成的灼傷。

• VR頭戴裝置、立體聲耳機或立體聲耳機組對皮膚造成不適時請停止使

用。若耳機組或耳機對您的皮膚造成不適，請立即停止使用。停止使用

後，若症狀仍舊沒有改善，請立即就醫。

• 本產品及零件使用金屬或塑膠製造。若要丟棄本產品，請遵循當地法規

正確處理。

• 請遵循以下使用說明，以避免產品外殼變形或變色。

– 請勿在本產品上使用溶劑或其他化學藥劑。

– 請勿讓橡膠或乙烯基材質長時間接觸本產品。

• 若使用耳機組或耳機時音量調整過高，可能會導致永久失聰。請將音量

調整至安全水平。持續聆聽一段時間後，即使是音量不斷增大的嘈吵聲

音，聽起來可能會與一般無異，但實際上卻可能會損害聽覺。若您感到

耳鳴或耳部不適，或出現口齒不清的情況，請立即停止使用耳機組或耳

機，並洽詢醫生檢查聽覺。音量越高，會越快對聽覺造成影響。為保護

聽覺：

– 使用耳機組或耳機時請盡量避免將音量調整過高。

– 避免調高音量來阻隔身邊的聲音。

– 若無法聽清楚身邊的人的說話聲，請調低音量。

• 當在空氣乾燥的氣候下使用耳機組或耳機時，耳朵可能會感到輕微並短

暫的（靜電）觸電。此情形並非耳機組或耳機發生故障，而是人體內累

積靜電所造成。

關於兒童使用

未滿12歲的兒童請勿使用此VR頭戴裝置。

配戴VR頭戴裝置

• 在您使用VR頭戴裝置時，正確配戴是非常重要的。

– 若要確認如何配戴頭戴裝置，請到PlayStation®4主機的機能畫面，選

擇（設定）＞［周邊機器］＞［PlayStation VR］。

– 請勿過度旋緊調整旋鈕（「各部名稱」）。

– 當您戴著眼鏡時仍可配戴VR頭戴裝置，但調整眼罩時請小心

（「各部名稱」）。若您的眼鏡碰觸到VR頭戴裝置的鏡片，可能

會造成眼鏡、鏡片或兩者發生損壞。請勿過度向內或向外調整眼罩位

置。

• 戴上後，請定期確認VR頭戴裝置是否配戴舒適以確保配戴方法正確。

VR頭戴裝置螢幕

• 請勿讓VR頭戴裝置的鏡片（「各部名稱」）受到日光或強光直射。

否則可能會損壞VR頭戴裝置螢幕及導致機能異常。

• 請不要讓任何障礙物阻礙到VR頭戴裝置的安裝感測器（「各部名

稱」）。若安裝感測器受到阻礙，即使取下頭戴裝置，螢幕也不會自動

關閉。若讓螢幕長時間顯示畫像，可能會導致影像烙印，使螢幕永久留

下模糊殘像。

• 螢幕上部分位置可能會出現黑點或持續發亮的光點，此屬於螢幕的正常

現象並非故障。螢幕採用高精密度技術製作，但每個螢幕都可能發生看

到非常小量的黑點或經常發亮的點出現，或是顏色濃度、明亮程度不一

的情況。

切勿分解、改造本產品或附屬品

使用本產品與附屬品時請務必遵守本使用說明書所記載的指示說明。嚴禁

擅自分解或改造本產品，並禁止分解和使用其電路結構。擅自分解產品將

喪失所有保證權益。此外，若分解或改造本產品，可能會有引起火災、觸

電或故障的危險。

結露現象

若把PS VR從寒冷的地方直接搬放到溫暖的場所，VR頭戴裝置及訊號處理

器內可能會凝結水氣。此現象可能會導致產品無法正常運作。此時，請關

閉VR頭戴裝置的電源並從電源插座拔除交流電源線。水氣尚未蒸發時，切

勿使用本產品（水氣蒸發可能需要數小時）。若產品仍無法恢復正常，請

瀏覽官方網站（「更多資訊」）。

出現非正常反應或無法操作的狀況時

按下VR頭戴裝置上的（電源）按鈕（「各部名稱」）7秒以上以強制

關閉電源，接著重新啟動頭戴裝置。若問題依舊存在，請重新啟動PS4™

主機。

顯示溫度升高的訊息時

• 若訊號處理器內部溫度升高，將顯示溫度升高訊息。此時，請關閉

PS4™主機電源，並請停止使用一段時間。待訊號處理器冷卻後，請將

訊號處理器移動至通風良好處，再繼續使用。

• 請勿在密閉空間或可能無法散熱的場所使用本產品。

使用交流電轉換器及交流電源線

• 請使用鄰近的電源插座，以在需要時可迅速拔除交流電源線。若產品機

能出現異常，發出異常聲響、氣味或變得過熱，請立即停止使用，並從

電源插座拔除交流電源線及所有的其他連接線。

• 請在訊號處理器上的狀態指示燈亮紅燈時，從電源插座拔除交流電源

線。若在狀態指示燈亮白燈或閃爍紅燈時拔除交流電源線，可能會導致

故障。

• 請勿使用隨附之交流電轉換器或交流電源線以外的其他轉換器或電源

線。隨附之交流電轉換器及交流電源線是專為本產品所設計，切勿使用

於其他產品。此外，其他交流電轉換器及交流電源線亦不得使用於本產

品。若未遵照這些注意事項，可能會導致產品過熱，亦或引起火災或觸

電。

– 連接HDMI™連接線前，請勿將本產品的交流電源線插入電源插座。

– 請勿用濕手觸摸交流電源線的端子。

– 當交流電轉換器被布料覆蓋時請勿使用。否則可能會過熱，引起火災

或機能異常。

– 清潔前或打算長時間不使用本產品時，請從電源插座拔除電源交流

線。

– 請勿將交流電源線插入變壓器或反相器。

儲存環境

• 請勿將本產品或附屬品放在高溫、濕氣極重或受日光直射的地方。

• 請勿將本產品或附屬品放在傾斜、不平穩或易受震動的地方。

使用PS VR

• PS VR配合PS4™主機與PlayStation®Camera使用，能為您帶來虛擬實境

的刺激體驗。攝影機會捕捉VR頭戴裝置的位置、角度和動作，讓您可更

直接地與遊戲互動。

• 請隨時將PS4™主機的系統軟件及PS VR的裝置軟件更新為最新版本。

• 請確定將VR頭戴裝置連接至隨附的CUH-ZVR2訊號處理器。若頭戴裝置

連接到CUH-ZVR1訊號處理器，將無法使用。

使用VR頭戴裝置時的姿勢

請盡量坐著使用VR頭戴裝置。若應用程式內有站立模式，請小心按照應用

程式的使用說明。

設定PS VR

在PS4™主機的機能畫面上，選擇（設定）＞［周邊機器］＞

［PlayStation VR］，再選擇想設定的PS VR項目。

提示

• 此設定僅在PS4™主機與PS VR連接時顯示。

• 部分項目亦可在按住（PS）按鈕顯示快捷選單時進行設定。

• 關於PS VR的詳細設定方法，請閱覽PS4™主機的用戶指南。從機能畫面選擇

（設定）＞（用戶指南／便利資訊）＞（用戶指南)。

家長監控

PS4™主機內含讓家長或監護人視需要限制兒童使用本產品的設定。前往

PS4™主機的機能畫面選擇（設定）＞［家長監控／家庭管理］。

各部名稱

VR 頭戴裝置

正面

ABCD

A ) 追蹤燈（正面）

後方亮起藍燈：電源啟動

前後方亮起藍燈： VR模式中

前後方熄燈：電源關閉

B ) 眼罩調整按鈕

C ) 前方頭部支撐墊

D) 後方頭部支撐墊

E ) HDMI端子

F ) AUX端子

G) 眼罩

背面

A ) 頭帶

B ) 安裝感測器

C ) 鏡片

D) 調整旋鈕

E ) 頭帶解鎖按鈕

F ) 追蹤燈（背面）

G) 耳塞槽

底面

A ) 立體聲耳機連接端

B ) 耳機固定孔

C ) （電源）按鈕

D) 遮光器

E ) 麥克風

F ) 追蹤燈（背面）

G) 音量 + 按鈕

H ) （麥克風靜音）按鈕

I ) 音量 - 按鈕

訊號處理器

正面

A ) 狀態指示燈

亮起白燈：電源啟動

亮起紅燈：待命模式

B ) AUX 連接埠

C ) HDMI 輸出連接埠

背面

A B C

A ) HDMI TV 連接埠

B ) HDMI PS4 連接埠

C ) （USB）連接埠

D) DC IN 12V 端子

E ) 通風孔

立體聲耳機

A ) 耳塞

B ) 立體聲耳機插頭

C ) 固定栓

更換耳塞

立體聲耳機上最初裝附M尺寸的耳塞。若感覺耳塞大小與耳朵不合，請更

換為隨附的S尺寸或L尺寸耳塞。更換時，請扭動耳塞並從耳機取下。

提示

請牢固地裝上耳塞以確保使用時不會意外脫落。

保養與清潔

請遵照下列說明來保養及清潔您的產品。

• 為安全起見，清潔前請務必先從電源插座拔除電源交流線插頭，並請勿

連接任何連接線。

• 請勿使用溶劑或其他化學物質來清潔外殼表面。

• 請勿使用經化學處理的擦布擦拭本產品。

訊號處理器表面、VR頭戴裝置表面、支撐墊及端子類

若髒汙時，請用柔軟的乾布擦拭。

提示

若訊號處理器或交流電源線的端子或其他部分髒汙，可能會無法正常收發訊號。

此外，耳機或耳機組的端子若髒汙，也可能導致雜音或聲音斷續的現象。

鏡片

請用鏡片專用的柔軟乾布擦拭。請勿使用非鏡片專用的餐巾紙或紙巾等紙

製品。

提示

若鏡片長期沾水或灰塵，可能會造成損壞或縮短鏡片壽命。

Instruction Manual

使用說明書

사용설명서
