XBT32-3FTP
Benchtop DC Power Supply
Operation Manual

About AMETEK
AMETEK Programmable Power, a Division of AMETEK, Inc., is a global leader in the design and
manufacture of precision, programmable power supplies for R&D, test and measurement, process
control, power bus simulation and power conditioning applications across diverse industrial
segments. From bench top supplies to rack-mounted industrial power subsystems, AMETEK
Programmable Power is the proud manufacturer of Elgar, Sorensen, California Instruments and
Power Ten brand power supplies.
AMETEK, Inc. is a leading global manufacturer of electronic instruments and electromechanical
devices with annualized sales of $2.5 billion. The Company has over 11,000 colleagues working at
more than 80 manufacturing facilities and more than 80 sales and service centers in the United
States and around the world.
Trademarks
AMETEK is a registered trademark of AMETEK, Inc.
Other trademarks, registered trademarks, and product names are the property of their respective
owners and are used herein for identification purposes only.
Notice of Copyright
XBT32-3FTP Benchtop DC Power Supply Operation Manual © 2007-2009 AMETEK
Programmable Power, Inc. All rights reserved.
Exclusion for Documentation
UNLESS SPECIFICALLY AGREED TO IN WRITING, AMETEK PROGRAMMABLE
POWER, INC. (“AMETEK”):
(a) MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR SUITABILITY OF ANY
TECHNICAL OR OTHER INFORMATION PROVIDED IN ITS MANUALS OR OTHER
DOCUMENTATION.
(b) ASSUMES NO RESPONSIBILITY OR LIABILITY FOR LOSSES, DAMAGES, COSTS OR EXPENSES,
WHETHER SPECIAL, DIRECT, INDIRECT, CONSEQUENTIAL OR INCIDENTAL, WHICH MIGHT
ARISE OUT OF THE USE OF SUCH INFORMATION. THE USE OF ANY SUCH INFORMATION
WILL BE ENTIRELY AT THE USER’S RISK, AND
(c) REMINDS YOU THAT IF THIS MANUAL IS IN ANY LANGUAGE OTHER THAN ENGLISH,
ALTHOUGH STEPS HAVE BEEN TAKEN TO MAINTAIN THE ACCURACY OF THE TRANSLATION,
THE ACCURACY CANNOT BE GUARANTEED. APPROVED AMETEK CONTENT IS CONTAINED
WITH THE ENGLISH LANGUAGE VERSION, WHICH IS POSTED AT
WWW.PROGRAMMABLEPOWER.COM.
Date and Revision
April 2010 Revision J
Part Number
M370187-01
Contact Information
Telephone: [phone] (toll free in North America)
858 450 0085 (direct)
Fax: [phone]
Email: [e-mail]
[e-mail]
Web: www.programmablepower.com
i

This page intentionally left blank.
ii

Important Safety Instructions
Before applying power to the system, verify that your product is configured properly for your
particular application.
WARNING
Hazardous voltages may be present when covers are removed. Qualified
personnel must use extreme caution when servicing this equipment.
Circuit boards, test points, and output voltages also may be floating above
(below) chassis ground.
WARNING
The equipment used contains ESD sensitive ports. When installing
equipment, follow ESD Safety Procedures. Electrostatic discharges might
cause damage to the equipment.
Only qualified personnel who deal with attendant hazards in power supplies, are allowed to perform
installation and servicing.
Ensure that the AC power line ground is connected properly to the Power Rack input connector or
chassis. Similarly, other power ground lines including those to application and maintenance
equipment must be grounded properly for both personnel and equipment safety.
Always ensure that facility AC input power is de-energized prior to connecting or disconnecting any
cable.
In normal operation, the operator does not have access to hazardous voltages within the chassis.
However, depending on the user’s application configuration, HIGH VOLTAGES HAZARDOUS TO
HUMAN SAFETY may be normally generated on the output terminals. The customer/user must
ensure that the output power lines are labeled properly as to the safety hazards and that any
inadvertent contact with hazardous voltages is eliminated.
Guard against risks of electrical shock during open cover checks by not touching any portion of the
electrical circuits. Even when power is off, capacitors may retain an electrical charge. Use safety
glasses during open cover checks to avoid personal injury by any sudden component failure.
Neither AMETEK Programmable Power Inc., San Diego, California, USA, nor any of the subsidiary
sales organizations can accept any responsibility for personnel, material or inconsequential injury,
loss or damage that results from improper use of the equipment and accessories.
SAFETY SYMBOLS
iii

This page intentionally left blank.
iv

Product Family: XBT32-3FTP
Warranty Period: Three (3) Years
WARRANTY TERMS
AMETEK Programmable Power, Inc. (“AMETEK”), provides this written warranty covering the
Product stated above, and if the Buyer discovers and notifies AMETEK in writing of any defect in
material or workmanship within the applicable warranty period stated above, then AMETEK may,
at its option: repair or replace the Product; or issue a credit note for the defective Product; or
provide the Buyer with replacement parts for the Product.
The Buyer will, at its expense, return the defective Product or parts thereof to AMETEK in
accordance with the return procedure specified below. AMETEK will, at its expense, deliver the
repaired or replaced Product or parts to the Buyer. Any warranty of AMETEK will not apply if the
Buyer is in default under the Purchase Order Agreement or where the Product or any part thereof:
•is damaged by misuse, accident, negligence or failure to maintain the same as
specified or required by AMETEK;
•is damaged by modifications, alterations or attachments thereto which are not
authorized by AMETEK;
•is installed or operated contrary to the instructions of AMETEK;
•is opened, modified or disassembled in any way without AMETEK’s consent; or
•is used in combination with items, articles or materials not authorized by METEK.
The Buyer may not assert any claim that the Products are not in conformity with any warranty until
the Buyer has made all payments to AMETEK provided for in the Purchase Order Agreement.
PRODUCT RETURN PROCEDURE
1. Request a Return Material Authorization (RMA) number from the repair facility (must be
done in the country in which it was purchased):
•In the USA, contact the AMETEK Repair Department prior to the return of the
product to AMETEK for repair:
Telephone: [phone], ext. 2295 or ext. 2463 (toll free North America)
858-450-0085, ext. 2295 or ext. 2463 (direct)
•Outside the United States, contact the nearest Authorized Service Center (ASC).
A full listing can be found either through your local distributor or our website,
www.programmablepower.com, by clicking Support and going to the Service
Centers tab.
2. When requesting an RMA, have the following information ready:
•Model number
•Serial number
•Description of the problem
NOTE: Unauthorized returns will not be accepted and will be returned at the shipper’s expense.
NOTE: A returned product found upon inspection by AMETEK, to be in specification is subject to
an evaluation fee and applicable freight charges.
v

vi
This page intentionally left blank

M370187-01 Rev J vii
Contents
About AMETEK.........................................................................................................i
Safety Information................................................................................................... iii
Warranty ..................................................................................................................v
1.INTRODUCTION........................................................................ 1-1
1.1Overview ................................................................................................ 1-1
1.2Features and Functions.......................................................................... 1-1
Minimum System Requirements for Ethernet Option.............................. 1-2
1.3Specifications ......................................................................................... 1-3
2.INSTALLATION AND MAINTENANCE...................................... 2-1
2.1Initial Inspection...................................................................................... 2-1
2.2Conditions of Use ................................................................................... 2-1
2.3Power-Line Voltage ................................................................................ 2-2
2.4Fuse ....................................................................................................... 2-2
2.5Connections ........................................................................................... 2-2
2.6Warming Up............................................................................................ 2-2
2.7Maintenance or Repair ........................................................................... 2-3
3.OPERATION .............................................................................. 3-1
3.1XBT32-3FTP Front Panel ....................................................................... 3-1
3.2XBT32-3FTP Rear Panel.......................................................................3-11
4.OPERATION SETTING.............................................................. 4-1
4.1Voltage Setting ....................................................................................... 4-1
4.2Current Setting ....................................................................................... 4-1
4.3Set OVP ................................................................................................. 4-2
4.4Set OCP ................................................................................................. 4-2
4.5Adjust Voltage......................................................................................... 4-2
5.REMOTE INTERFACE PROTOCOL AND PACKAGE MODE... 5-1
5.1Introduction............................................................................................. 5-1
5.2Definition of Parameters ......................................................................... 5-1
5.3Error Message List ................................................................................. 5-2
5.4SCPI Compatible Information ................................................................. 5-3
SCPI Common Command ...................................................................... 5-3
SCPI Command for Subsystem.............................................................. 5-4
5.5Rules of Status Definition ..................................................................... 5-17
6.CALIBRATION PROCEDURE................................................... 6-1
6.1Requirement of calibration instrument .................................................... 6-1
6.1.1How to enter calibration mode of CH1 : Press the

viii M370187-01 Rev J
rotary & numerical key “1” simultaneously. ............................................. 6-1
6.1.2How to enter calibration mode of CH2 : Press the
rotary & numerical key “2” simultaneously. ............................................. 6-2
6.1.3How to enter calibration mode of CH3 : Press the
rotary & numerical key “3” simultaneously. ............................................. 6-4
Figures
Figure 3-1. XBT32-3FTP Front Panel..................................................................3-1
Figure 3-2. XBT32-3FTP Rear Panel ................................................................3-11

1. INTRODUCTION
The XBT32-3FTP is a programmable benchtop power supply that provides
variable DC low voltage power to devices and assemblies in a laboratory setting.
This section provides an overview of the XBT32-3FTP DC Power Supply and
lists its features, functions and specifications.
1.1 Overview
The XBT32-3FTP is a programmable DC power supply with three (3) outputs:
Channel 1 and Channel 2 are linear power supplies and Channel 3 is a switching
mode power supply. XBT32-3FTP comes with 16 bits resolution. The maximum
total output power is 222 watts with both Channel 1 and Channel 2 providing 96
watts each (0 ~ 32V/3A) and Channel 3 providing a maximum of 30 watts (0 ~
15V/5A). This means that when the Channel 3 output voltage is set to 6 volts or
less, the output current can be up to 5A. If the Channel 3 output voltage is set
above 6 volts then the maximum output current depends on the voltage setting
with the output power of 30 watts. This is a unique feature that differs from
traditional power supplies.
1.2 Features and Functions
In addition to the triple independent output, other important features and
functions include:
•parallel mode for an output current up to 6A
•series mode for an output voltage up to 64V
•precision voltage and current measurement
•dual tracking
•digital rotary and push button controls
•LCD display
M370187-01 Rev J 1-1

Introduction
1-2 M370187-01 Rev J
•memory to store 100 configurations for recall
•built-in timer (1sec – 100 hrs) to disable power
•over voltage protection (OVP)
•over current protection (OCP)
•key lock
•load and line regulation within .01%
•remote control mode with less than 50 ms transient time
•USB and RS232 control standard
•GPIB optional interface
•Ethernet/LAN connectivity, 10/100 base-T compatible
•16-bit programming and 16-bit readback of voltage and current
•SCPI compliant command set
Minimum System Requirements for Ethernet Option
PC Connection
•Pentium-based laptop or desktop computer running Microsoft Windows XP
•Ethernet-based Network Interface Card (NIC) or built-in port capable of
10/100 Mbit operation
•Standard CAT 5 cable Ethernet interconnect cable
•Microsoft Internet Explorer version 6.0 or later
LAN Connection
•Pentium-based laptop or desktop computer running Microsoft Windows XP
•Ethernet-based Network Interface Card (NIC) or built-in port capable of
10/100 Mbit operation
•Switch or hub (Linksys brand strongly recommended) for LAN connection
•Standard CAT 5 cable Ethernet interconnect cable
•Microsoft Internet Explorer version 6.0 or later

Introduction
M370187-01 Rev J 1-3
1.3 Specifications
Model XBT32-3FTP
Channel NO. CH1 & CH2 CH3
Output Voltage 0 - 32V 0 - 15V
Output Current 0 - 3A 0 - 5A
Output Power
(CH3 Auto Ranging) 96W 30W
Line Regulation ±(% of output +offset)
Voltage 0.01% + 2mV
Current 0.01% + 300uA
Load Regulation ±(% of output +offset)
Voltage 3mV 5mV
Current 0.01% + 300uA
Ripple and Noise ( 20Hz ~ 20MHz )
Normal Mode Voltage 500uVrms / 5mVpp 1mVrms / 20mVpp
Normal Mode Current 1mA 5mA
Resolution
Programming 1mV / 100uA
Readback 1mV / 100uA
Programming Accuracy ±(% output +offset)
Voltage 0.01% + 5mV
OVP 0.1%+50mV, trigger time 400ms
Current 0.01% + 3mA
OCP 0.1%+50mA, trigger time 400ms
Readback Accuracy ±(% output +offset)
Voltage 0.01% + 5mV
Current 0.01% + 3mA 0.01% + 3mA
Temperature Coefficient per C°±(% output +offset)
Voltage 0.01% + 3mV
Current 0.02% + 2mA

Introduction
1-4 M370187-01 Rev J
Tracking Accuracy ±(% of output +offset)
Voltage 0.02% + 10mV
Transient Response Time
For 50% load change (25 to
75% to within 20mV
50µS
Stability,constant output & temperature ±(% of output +offset), 8hrs
Voltage 0.02% + 2mV
Current 0.01% + 1mA
Voltage Programming Speed
Rising Time at Full Load 3mSec
Rising Time at No Load 3mSec
Falling Time at Full Load 8mSec
Falling Time at No Load 250mSec
Environmental Requirements
Temperature Ratings Operating( 0°C to 40°C)
Storage (- 10°C to 70°C)
Relative Humidity Range 20% to 80%, non-condensing
Pollution Degree 2
Altitude 2000 m / 6600 ft
Transient Overvoltage
Protection 2500V at AC Input
General
AC Line Input Voltage Ranges 115/230 VAC ± 10%(50/60Hz)
Common-Mode Voltage ±240Vdc
Dimensions ( W×H×D )mm 216W × 135H × 432D
Communication port RS232/USB
Option communication port GPIB, LAN, I/O
Weight 18.7 lbs / 8.5 kg
Regulatory Compliant to CE mark, Certified to CETLUS

2. INSTALLATION AND
MAINTENANCE
This section describes installation and maintenance requirements.
2.1 Initial Inspection
Remove device from packaging; inspect for any physical damage incurred during
shipment; report any such damage to the carrier.
2.2 Conditions of Use
•Operate indoors only.
•Refer to Section 1.3, Specifications, of this manual.
•Select the correct voltage setting (see Section 2.3, Power-Line Voltage).
•Ensure that the operating environment power supply is free of dust, vibration,
direct sunlight and corrosive gas.
•Ensure clearance of at least 10 cm for adequate ventilation.
•Install a power filter if noise from the AC power source is inevitable.
•Calibrate annually.
M370187-01 Rev J 2-1

Installation and Maintenance
2-2 M370187-01 Rev J
2.3 Power-Line Voltage
The power supply uses AC power 115V/230V 50Hz/60Hz. Before plugging in the
power cord, make sure the POWER switch (see Section 3.1) is in the OFF
position and the voltage input selection switch on the bottom of the unit is the
same as the required voltage.
Caution
Exceeding the maximum rated AC input voltage could result
in damage to the unit.
2.4 Fuse
There is one fuse installed in the rear panel. If and when it becomes necessary to
replace the fuse, first turn off the power and disconnect the AC power cord and
all other connections to the power supply. Open the fuse cover, located on the
rear panel below the AC socket, using a flat-head screwdriver or by holder from
under the AC socket.
Mark Range Fuse Max Power
115 104V~126V T5A /250V 500VA
230 207V~253V T2.5A /250V 500VA
50/60 Hz
Caution
For continuous protection against fire hazard, replace fuse
only with the same type and rating specified.
2.5 Connections
Of the interface connections available, RS-232 and USB are standard interfaces,
and the GPIB and Ethernet interfaces are options.
2.6 Warming Up
This supplypower supply activates at power on. However, in order to meet the

Installation and Maintenance
M370187-01 Rev J 2-3
accuracy in the specification, 30 minutes or longer is necessary.
2.7 Maintenance or Repair
When the power supply is not in use or is unattended, make sure to turn off the
power switch. When necessary, remove dust with a damp cloth. If the power
supply needs repair, follow the Warranty instructions (page v) in this manual.

Installation and Maintenance
2-4 M370187-01 Rev J
This page intentionally left blank.
