USER MANUAL for the SG-0007B SYSTEM
1
This product is meant to be used for electronic control of functions for spa baths. Please read all of the
instructions carefully before enjoying the spa. WARNING: Operating the system without water will cause severe
damage. Contains electronic components, shock hazard. Does not contain user serviceable parts. Do not try to repair
the control unit. Contact your dealer or service center for help. Follow all user instructions.
I. Installation
1) Open the door / cover according to the instructions and connect the power supply correctly.
Warning
A. Installation is only to be made by qualified persons.
B. Read the instructions carefully before beginning the installation.
C. We are not responsible if the product does not work or is damaged when the
instructions are not followed during installation.
D. Ensure that the system is not damaged during transportation when it is unpacked.
Note!
A. 1 x 16A (Read “Interlocked system between the heater and pumps”), 2 x 16A or 3 x 16 should be connected
to the control system. Do not connect the power before the installation is complete.
B. Install a maintenance switch close to the control system for use during maintenance work.
C. An earth switch must be installed. Check that the earth switch works when the power is connected.
(Figure 1)
WIRING DIAGRAM 3-phase, 2-phase, 1-phase
SG0007B Sketch Of Linking Wires For The System

USER MANUAL for the SG-0007B SYSTEM
2
II. Operating instructions
(Fig 2)
ON/OFF key (power key): Connect the power supply and press the ON/OFF key. All the control systems are now
ready to run (indicator light is on), and the circulation and Ozone disinfection system (if one exists) will start working
automatically (if the water temperature is not at the pre-set temperature, the heating system will start to work in 60
seconds). The panel will display the circulation and Ozone symbols (a symbol for the heating system will also
be displayed on the panel if the heating system is working). The panel will also display the detected water temperature.
Note! If no button is pressed within 60 seconds, the displays backlight goes off, it reactivates if a button is pressed.
PUMP key: press the (JET1) key. Its symbol will now appear on the panel, signifying that massage pump 1 has
been activated. JET2 and JET3 work in the same way and have their own symbols with numbers 2 and 3 on them.
JET1, JET2 AND JET3 are accessories for some spa models. NOTE: The massage system will shut down
automatically in 20 minutes. NOTE: There are some air valves on the topside of spas near the seats. They are to
control the strength of the hydro-massage in the respective seats.
BUBBLE key: Press the key. Its symbol will appear on the panel, meaning that the air massage system has
started working. NOTE: The blower automatically shuts down after 20 minutes.
03 key (Ozone): Pressing the O3 key will turn on or off the Ozone disinfection system (Ozone and circulation pump
work automatically when activating the spa). NOTE! Ozone can be an accessory and another alternative is the UV-C
ozone cleaner. See “UV-C Ozone Cleaner” under “Summary”.
LAMP key: When the control systems are ready to work, first press the key. Its symbol will now appear on the
panel, signifying that the underwater lights are on, the colour will change automatically; with a second press, the color
will be fixed on a certain color; press for the third time to shut it off. NOTE! The lamp shuts off automatically after 60
minutes.
TEMP key (needs to be used together with ▲/▼key): If the TEMP key is pressed for 5 seconds, the panel will
display the water temperature set last time. This temperature will keep flashing: Press the “▲” key to adjust the
temperature to the highest at 42°; press the “▼” key to adjust the temperature to the lowest at 10°. The new
temperature will be automatically stored and the display will then return to show the current water temperature after
flashing for 60 seconds or if the or button is used.
RADIO/AV key (Radio/DVD/Control and display of temperature): When the control systems are ready to work,
press the RADIO/AV key to activate the Radio function. The panel will now show the radio channel set last time
(under Radio status, press +/- key to select pre-stored radio stations); a second press will activate the TV function (this
function is optional). The panel will now show a TV symbol. A third press will activate the DVD function (this

USER MANUAL for the SG-0007B SYSTEM
3
function is optional). The panel now shows a DVD symbol at the same time (Under DVD status, press the +/- key to
adjust the volume of the DVD). Press for the fourth time to show the detected water temperature.
TUN/VOL key (needs to be used together with the +/- key): Under Radio status, first press the TUN/VOL key. The
panel will now show a 2-digit volume, pressing +/- will adjust the volume upwards or downwards (the panel will
automatically show the radio frequency when you stop adjusting for 3 seconds). With a second press，the current
frequency will flash. Pressing the +/- key will adjust the current frequency. This frequency will be stored
automatically after flashing for 3 seconds. With a third press, the panel will show the radio channel. Press the +/- key
to select pre-stored radio stations ( the panel will automatically show the previous radio frequency after you stop
adjusting for 3 seconds). With a long press for 5 seconds, the system will automatically search for radio frequencies
again and store the searched frequencies at a different channel sequentially.
Heating system: After the control systems are ready to work, the heater will start working 60 seconds after the
circulation pump is activated, unless the temperature sensor detects that the set temperature is lower than the detected
one. When the water temperature reaches a set temperature, the heater will stop working automatically. When the
water temperature is under 2°of the preset one, the heater will reactivate. The symbol for the heater is located above
the circulation pump symbol , it appears as pulsing bubbles.
NOTE: The heater will not be activated if there is not enough water flow.
Interlocked system between the heater and pumps: Pressing and holding the ON/OFF key again for 20 seconds
will change the system between interlock mode or non-interlock mode (the indicator light on the ON/OFF key shows
RED in interlock mode; while it shows GREEN in non-interlock mode). When in interlock mode, the heater will stop
when you press any of the pump and bubble keys. This feature is meant to reduce the power needed for the spa so that
it can match the power limit of some countries (1 x 16A). In non-interlocked mode, the heater will keep running when
the other pumps are activated unless the water temperature reaches the set temperature. NOTE! That requires at least
a 2-phase connection if the total effect for pumps and heating exceeds 3680 W.
Temperature sensor self-checking system: If E1 is displayed on the panel, then the temperature sensor is
disconnected. In this situation check the wiring of the temperature sensor to see if it’s properly connected. If E0 is
displayed on the panel, then the temperature sensor has short-circuited. In this case, the temperature sensor must be
replaced. The heating system cannot be activated under the two above situations.
Water-lacking protection system for circulation pump and heater: In daily usage, a blockage of the filtration
medium (cartridge filter or filter bag) will eventually occur. A severe blockage will lead to a lack of water for the
filtration pump. Air in the system often leads to the same problem. For instance, during startup if aeration has not been
performed according to the instructions in the manual. When there is a lack of water, the filtration pump and heater
will stop working automatically. At this moment, the symbol of the filtration pump on the control panel will
flash continuously, to remind the user that it is time to clean or replace the filtration medium. After cleaning or
replacing the filtration medium, press ON/OFF several times to expel the air inside the pipe until the filtration pump
works normally.
Anti-freezing system: After power on to enter standby status (the indicator light on ON/OFF key flashes), the
anti-freezing system will be activated instantly. The circulation pump and heating system will automatically stop at the
default temperature of above 10°. When the water temperature in the spa drops below 9°, the circulation pump,
heater and air blower will work automatically, Jet1 (accessory) will automatically start to work in about 85 seconds;
and it will stop after working about 85 seconds; then Jet2 (if equipped) will start to work for about 85 seconds and
stop; finally Jet3 starts to work (if equipped) for about 85 seconds then stops. Pump1, Pump2 and Pump3 will
continuously cycle among themselves. When the detected water temperature reaches 10°, all the pumps and heater
will stop working. When this system is running, the screen background light is on. When the water temperature
reaches 10°, the screen returns to the standby status.

USER MANUAL for the SG-0007B SYSTEM
4
Manual working mode: Turn on the spa, then press and hold the key for 3 seconds to enter manual mode (the
indicator light on the key will show GREEN when in manual mode, indicator key 3 will light up). If is
selected the filtration pump (and thus the filtration) is on continuously, 24h per day without stopping in between.
Automatic working mode: Automatic working mode is on by default. Press and hold the key for 3 seconds to switch
over to automatic mode (The button will light up). The circulation pump starts and runs for 1 hour (the display panel
will cycle between "ON" and water temperature, indicator key 1 will light up). After 1 hour the pump will stop for 3 hours
(the display panel will cycle between "OFF" and water temperature, indicator key 2 will light up). As long as the system is
in automatic mode this filtration cycle will repeat indefinitely.
The keys 1, 2 and 3 (FILTER PROGRAM) are non-functional keys and only act as indicators.
NOTE:
If the spa is in automatic working mode, please don’t turn off the spa when not in use. Make sure the spa
is always “on”.
When in automatic mode, the filtration pump will also be controlled by temperature. If the water
temperature is lower than the preset level, during the “OFF” period, the filtration pump and heater will
work until the water temperature has reached the preset level. Then, the filtration pump will return to
work for 1 hour and stop for 3 hours repeatedly. When the automatic mode is not in use the circulation
pump is always on. If the water temperature drops 2° under the pre-set level the heater will activate.
Each time the spa is switched on, the system will go into the previously set mode. Press and hold the
or key for 3 seconds (the indicator will show GREEN) to switch between automatic mode and
manual mode.
Summary: and
If is selected the filtration is handled automatically in cycles of “1 hour on, 3 hours off”.
If is selected the filtration pump (and thus the filtration) is on continuously, 24h per day without stopping in between.
If the preset temperature is higher than the actual water temperature then both the circulation pump and heater are
activated until the water temperature reaches the chosen setting. The Ozone will automatically work together with the
filtration pump and heater. This applies in both and modes.
WARNING! The circulation pump also generates heat and if it is running a long time (eg, continuous filtration TM) it can
raise the temperature by several degrees in one day when the tub is well insulated. Avoid using the TM function other
times than when the water needs to be filtered further. Always check water quality and temperature after using TM for one
day.
FILTRATION PUMP - NOTE! If the hot tub is equiped with a massage pump it will connected to "WATER PUMP 1".
If there are two massage pumps the second is connected to "WATER PUMP 2".
UV-C OZONE CLEANER If an UV-C ozoner cleaner is installed, connect it so that it activates the same time as the
circulatory pump.
BLOWER (BUBBLE) - ATTENTION! If the blower is used often and for prolonged periods of time, the blowers built in
thermal protection might activate. The blower will stop and not restart until it's cooled down enough. You can speed up the
cooling by opening the service hatch(es). In doing so, please protect the equipment from potential freezing damage.
