Spearhead 200F Assembly instructions

8999124EN: v2.0 27/10/2021
1 Original instructions (ENGLISH)
Website: www.spearheadmachinery.com
Spearhead Machinery
Operator Instruction Manual For
2.00m cut width, 540 or 1000 PTO input

8999124EN: v2.0 27/10/2021
2 Original instructions (ENGLISH)
Website: www.spearheadmachinery.com
IMPORTANT
Verification Of Warranty Registration
Dealer Warranty Information & Registration Verification
It is imperative that the selling dealer registers this machine with Spearhead before delivery to the end user.
Failure to do so may affect the validity of the machine warranty.
To register machines go to the Spearhead Machinery Limited web site at:
https://my.spearheadmachinery.com/warranty/machine-registration/
Should you experience any problems registering a machine in this manner please contact the Spearhead
Service Department on 01789 491860.
Confirm to the customer that the machine has been registered in the section below.
Registration Verification
Model Type:
Destroyer Flail
Model Number:
99___________
Serial Numbers:
Machine:
S__________
Cutting Implement:
S__________
Other:
Name Of Owner:
Name Of Installing Dealer:
Dealer Address:
Dealer Signature:
Date Of Delivery / Installation:
Date Of Warranty Registration:
IMPORTANT
At the point of transfer of ownership record the above information. Note the serial number of your machine and
always quote it in any communication with us or your dealer. (The serial number plate is located on the machine
mainframe.) This is particularly important when ordering spares. Remember to include all numbers and letters.
The information given throughout this manual is correct at the time of publication. However, in the course of
constant development of Spearhead machines, changes in specification are inevitable. Should you find the
information given in this book to be at variance with the machine in your possession, you are advised to contact
the Spearhead Service department where up-to-date information will be provided.
The manual can contain standard and optional features and is not to be used as a machine specification.
The machine has been tested and is considered safe if carefully used. Ensure your operator is properly trained
in its use and maintenance.

8999124EN: v2.0 27/10/2021
3 Original instructions (ENGLISH)
Website: www.spearheadmachinery.com
(This pageis left blank intentionally)

8999124EN: v2.0 27/10/2021
4 Original instructions (ENGLISH)
Website: www.spearheadmachinery.com
Destroyer Flail Flail Mulcher
This manual contains the instructions for installation, use and maintenance of the Destroyer Flail 200F Flail
mulcher hereafter more simply called the ''Mulcher.''
The Mulcher is designed and built to mulch branches, overgrown vegetation and logs up to 18 cm in
diameter. Any different use should be considered improper and therefore potentially dangerous to the safety
of the operator and any exposed persons. This manual is integral to the Mulcher, defines the purpose for
which it was built and contains all the information required for proper and safe use.
Regular machine operation depends on its correct use and adequate maintenance: it is advisable, therefore,
to follow these instructions carefully to prevent any situation that could compromise the machine’s operation
and durability. It is also important to follow that which is described in this manual since Spearhead declines
any liability resulting from negligence of from not observing these norms, since it would result in the warranty
being annulled.
It is mandatory to verify upon delivery that the mulcher is integral and complete in all its parts. Any
complaints must presented in written within 8 (eight) days from receiving the machine. Spearhead can
however be contacted at any time for immediate and precise technical assistance and anything required for
optimum operation and maximum performance of the equipment. Upon receiving the product, carefully read
the manual and carefully follow the instructions contained in it.
IMPORTANT
This operator’s manual should be regarded as part of the machine. Suppliers of both new and second-hand
machines are advised to retain documentary evidence that this manual was provided with the machine.
This machine is designed solely for ground vegetation control and must not be used for any other purpose.
Use in any other way is considered as contrary to the intended use. Compliance with, and strict adherence
to, the conditions of operation, service, and repair, as specified by the manufacturer, also constitute
essential elements of the intended use.
This machine should be operated, serviced, and repaired only by persons who are familiar with its
characteristics and who are acquainted with the relevant safety procedures.
Accident prevention regulations, all other generally recognised regulations on safety and occupational
medicine, and all road traffic regulations must always be observed.
Any arbitrary modifications carried out to this machine may relieve the manufacturer of liability for any
resulting damage or injury.
It is potentially hazardous to fit or use any parts other than genuine Spearhead parts.
The company disclaims all liability for the consequences of such use which, in addition, voids the machine
warranty.

8999124EN: v2.0 27/10/2021
5 Original instructions (ENGLISH)
Website: www.spearheadmachinery.com
(This pageis left blank intentionally)

8999124EN: v2.0 27/10/2021
6 Original instructions (ENGLISH)
Website: www.spearheadmachinery.com
Contents List
1Description and Main Characteristics.....................................................................................................8
1.1 Mulcher Description ..................................................................................................................8
1.2 Intended Usage.........................................................................................................................9
1.2.1 Allowed Uses...............................................................................................................9
1.2.2 Improper Uses.............................................................................................................9
1.3 Machine Identification ...............................................................................................................9
1.4 Technical Data........................................................................................................................10
1.5 Sound Level ............................................................................................................................10
2General Safety And Accident Prevention Standards...........................................................................12
2.1 Level Of Danger......................................................................................................................12
2.2 Terminology.............................................................................................................................12
2.3 Danger Plates And Warning...................................................................................................14
2.3.1 Proposition 65............................................................................................................16
2.4 Clothing ...................................................................................................................................17
2.5 Ecology And Pollution.............................................................................................................17
2.5.1 Disposal.....................................................................................................................17
2.5.2 Storage......................................................................................................................17
2.6 Safe Use..................................................................................................................................18
2.7 Safe Maintenance...................................................................................................................19
3Installing The Mulcher...........................................................................................................................20
3.1 Delivery....................................................................................................................................20
3.2 First Use..................................................................................................................................21
3.2.1 Prior To Installation....................................................................................................21
3.2.2 Application To The Tractor........................................................................................21
3.2.3 Input PTO Shaft.........................................................................................................22
4Usage Instructions................................................................................................................................26
4.1 Before Use ..............................................................................................................................26
4.2 Machine Settings.....................................................................................................................27
4.2.1 Adjustment Of The Skids And Roller ........................................................................27
4.2.2 Adjustment Of Working Height..................................................................................28
4.3 Using The Mulcher..................................................................................................................28
4.4 After Use..................................................................................................................................30
4.5 Safety Devices........................................................................................................................31
4.6 Machine Transport Procedure................................................................................................32
5Maintenance .........................................................................................................................................34
5.1 Periodic Maintenance..............................................................................................................35
5.1.1 Maintenance On The Teeth ......................................................................................35
5.1.2 Belt Maintenance.......................................................................................................36
5.2 Cleaning The Mulcher.............................................................................................................37
5.3 Lubricants................................................................................................................................37
6Troubleshooting....................................................................................................................................40
7Spare Parts...........................................................................................................................................42
7.1 How To Obtain The Correct Spare Part Numbers.................................................................42
7.2 Spare Parts Ordering..............................................................................................................43
7.3 Dealer Network .......................................................................................................................43

8999124EN: v2.0 27/10/2021
7 Original instructions (ENGLISH)
Website: www.spearheadmachinery.com
(This pageis left blank intentionally)

8999124EN: v2.0 27/10/2021
8 Original instructions (ENGLISH)
Website: www.spearheadmachinery.com
1 Description and Main Characteristics
1.1 Mulcher Description
With reference to Figure 1, the mulcher is a machine designed and built exclusively for mulching operations
directly on the field. It shreds plant remains, allowing you to mulch branches, overgrown vegetation and logs. It
must not be used for other uses or with other materials. The mulcher consists of the following parts:
Figure 1
Item No.
Description
Item No.
Description.
1
Input PTO
7
Skid
2
Headstock
8
Cutting Tooth
3
Input PTO Protection Cone
9
Protection Chains
4
Gearbox
10
Push Frame (Manual)
5
Belt Guard Cover
11
Stand
6
Rotor Shaft
12
Rear Opening Hood
Table 1

8999124EN: v2.0 27/10/2021
9 Original instructions (ENGLISH)
Website: www.spearheadmachinery.com
1.2 Intended Usage
1.2.1 Allowed Uses
The mulcher is designed and built to mulch branches, overgrown vegetation and trunks up to 18 cm in
diameter.
When the mulcher works it guarantees the required level of safety even in the presence of an insignificant
malfunction of its components or hazardous operating conditions, however, always within the permitted uses.
With reference to the above, the following are considered allowed uses:
•Using the mulcher to mow crop residue.
The mulcher must not be used for purposes other than those described in this manual.
1.2.2 Improper Uses
The mulcher, due to its typical construction, may also be suitable for uses other than from those foreseen by
the manufacturer. For this reason Spearhead has selected, as non-exhaustive examples, a series of
improper uses that can be reasonably foreseen, which are:
•Using the mulcher to mulch trunks with a diameter exceeding 18 cm;
•Using the mulcher to mulch or cut hedges;
•Using the mulcher for shredding purposes near frequented areas.
The uses listed above and those not specifically indicated in this manual, including reasonably foreseeable
improper uses, are strictly prohibited.
Spearhead declines any and all liability for damages caused by the Mulcher to persons, animals or
property, resulting from use other than that described in this manual, or due to damage caused by
negligence or by not observing the instructions contained in this manual.
1.3 Machine Identification
Each machine is equipped with a serial plate; see Figure 2 that includes the following data in this order:
1. UKCA Conformity Marking.
2. Machine Whole Goods Code (WGC).
3. Serial number of the machine.
4. Mass in kg.
5. Production Year (year of construction).
6. Design conformity standard.
7. Machine Product Group Code.
8. EU Authorised Representative QR scan code.
9. Manufacturer marking with name and address.
10. EAC Eurasian/Russian Conformity Marking.
11. EC European Conformity Marking.
12. Product Group Code.
Figure 2 –Serial Plate

8999124EN: v2.0 27/10/2021
10 Original instructions (ENGLISH)
Website: www.spearheadmachinery.com
Data on the Spearhead manufacturer’s plate should always be referred to when requesting assistance and/or
requiring replacement spare parts.
This data can identify the machine and its characteristics and specification for its particular time of manufacture,
certifying that it responds to current regulations. For this reason the plate should never therefore be removed nor
be used for other purposes; if the machine is dismantled, it should be destroyed to prevent any form of abuse.
By utilising a smart phone and scanning the Authorised Representative QR scan code found on the right-hand
side of the serial plate (ref 8, Figure 2) using a suitable QR scanning App, you can find details for Spearhead
Machinery authorised representatives for its various territories.
1.4 Technical Data
Model
Working Width
(cm)
Minimum
Tractor HP
Requirement
Number of
Teeth
Weight (kg)
Dimensions
(W x L x H) cm
Destroyer Flail
200F
190
80
60
1150
234 x 112 x112
Table 2
Hitch to the tractor
3-point universal
Hitch category
CAT 1-2
PTO input speed
540/1000 rpm
Primary transmission
Input Shaft
Secondary transmission
Belts
Cut height adjustment
Mechanical
Minimum tractor weight
See Section 4.6
1.5 Sound Level
The air noise level created by the Mulcher under operating conditions was detected using a sound level meter
with integrator.
The measurements were carried out at the operator station with the Mulcher activated empty. Tests performed
under the conditions indicated by the standard produced the following results:
Tractor with open cab:
Equivalent weighted sound pressure average level: LpAm = 80.7 dB(A).
Tractor with closed cab:
Equivalent weighted sound pressure average level: LpAm = 78.8 dB(A).
-Sound power level: LwA = 107.1 dB(A).

8999124EN: v2.0 27/10/2021
11 Original instructions (ENGLISH)
Website: www.spearheadmachinery.com
(This pageis left blank intentionally)

8999124EN: v2.0 27/10/2021
12 Original instructions (ENGLISH)
Website: www.spearheadmachinery.com
2 General Safety And Accident Prevention Standards
2.1 Level Of Danger
The safety of the operator and exposed persons is the main concern of the designer and the manufacturer of the
machine. When designing a new machine, one tries to plan for all possible danger situations and risks
connected to using the machine, adopting the steps necessary to make the equipment as safe as possible. The
number of accidents remains very high however, especially due to incautious and awkward use of the
machine. It is therefore recommended to carefully read this manual and this section, regarding safety
standards, avoiding behaviour that is inappropriate or in contrast with the instructions contained in this
manual
Pay attention to the following danger signal where contained in this manual and follow safety
instructions.
DANGER! This signal warns that if the described operations are not carried out properly, they will
cause serious injury, death or long-term health risks.
WARNING! This signal warns that if the described operations are not carried out properly, they may
cause serious injury, death or long-term health risks.
CAUTION! This signal warns that if the described operations are not carried out properly, they may
cause damage to the machine.
2.2 Terminology
The indicated levels of danger refer to specific risk situation that may occur during machine use and may involve
the same machine, the operator and any exposed persons. With the purpose of highlighting situations or
operations that may result in risks, the meanings of terms used in this manual are indicated here:
•HAZARDOUS AREA: Any area in and/or around a machine where the presence of an exposed person
constitutes a risk to the health and safety of said person.
•EXPOSED PERSON: A person fully or partly in a hazardous area.
•OPERATOR: The person or personnel in charge of the installation, the operation, the adjusting, the
cleaning, the repairing and the moving of the machine.
•USER: the person, entity or company, who purchased or rented the machine and intends to use it
according to the intended use foreseen by the manufacturer.
•SPECIALISED PERSONNEL: any person specifically trained and approved to carry out maintenance
or repair interventions that require particular knowledge of the machine, its operation, the installed safety
devices, intervention modes. It must be capable of recognising danger present on the actual machine,
therefore avoiding at risk situations.
•RISK: a combination of the probability and seriousness of injury or damage to health which can arise in
a dangerous situation.
•GUARD: a part of the machine that is used to specifically guarantee protection by way of a material
barrier.

8999124EN: v2.0 27/10/2021
13 Original instructions (ENGLISH)
Website: www.spearheadmachinery.com
•PROTECTION DEVICE: a device that reduces risk (unlike the guard) either on its own or together with
the guard.
•INTENDED USE: the use of the machine in accordance with the information provided in the operator’s
manual.
•REASONABLE FORESEEABLE MISUSE: the use of the machine different to the information provided
in the operator’s instructions, which may be the result of readily predictable human behaviour.
•GENUINE SPEARHEAD DEALER/ AUTHORIZED TRACTOR DEALER: The Genuine Spearhead
Dealer/ Authorized Tractor Dealer, legally authorised by the Manufacturer, is formed by specialised staff
able to carry out all types of assistance, maintenance and repair work, even of a certain complexity,
required to maintain the machine in perfect working order.
WARNING! Carefully read the following rules. If the instructions described are not followed, a situation
may arise which causes irreparable damage to the machine or property, or injury –even severe –to
people or animals.
Spearhead declines all responsibility for damage caused by not complying with the safety and injury
prevention regulations described below. Spearhead also declines any responsibility for damage caused
by improper use of the machine and/ or as a result of modifications made without authorisation by the
manufacturer.

8999124EN: v2.0 27/10/2021
14 Original instructions (ENGLISH)
Website: www.spearheadmachinery.com
2.3 Danger Plates And Warning
The Mulcher is equipped with pictograms (labels) warning about residual risks present on the machine that it
were not possible to eliminate. Figure 3 shows the meaning of symbols contained in the pictograms. The
operator must memorise the meaning of the symbols.
The labels should always be kept clean and replaced immediately if they are fully or partially detached or
damaged.
Plates with indications and particular warnings for
maintenance and a correct use of some parts of the
machine. The respect of these plates lengthens the
duration and the efficiency of the Mulcher.
Check the oil level the first time the machine is used.
Indicates the correct functioning of the input PTO shaft.
Keep clear from the moving machine;
Keep at a safe distance.
Keep away from moving parts.
Lifting point
PTO maximum operating speed.
Do not exceed the stated maximum operation speed
as stated on the decal near the gearbox of the
machine.

8999124EN: v2.0 27/10/2021
15 Original instructions (ENGLISH)
Website: www.spearheadmachinery.com
Read the use and maintenance
manual with care prior to
starting up the machine.
Risk of cutting off feet.
Keep at a safe
distance.
Do not remove
protections before
halting and
disconnecting the
machine.
Always disconnect the machine
from the tractor prior to any
maintenance and/or lubrication
work.
Risk of cutting off
hands.
Keep at a safe
distance.
Do not remove
protections before
halting and
disconnecting the
machine.
Risk of falling.
It is prohibited to climb onto the
machine.
Risk of entanglement
in the PTO shaft.
Keep away from
moving parts.
Risk of ejected objects.
Stay at a safe distance.
Risk of crushing.
Do not stand between
the machine and the
tractor.
Risk of entanglement on belts.
Do not approach moving parts.
Greasing point.
Use the protection mask
Use protection gloves
Use protection muffs
Use the protective overalls
Use protective footwear
Indicates maximum adjustment movement
(1cm = 5 Kg) of the belt, for correct
transmission.
Operating, servicing and maintaining this
equipment can expose you to chemicals
which are known to the State of California to
cause cancer and birth defects or other
reproductive harm.
Figure 3

8999124EN: v2.0 27/10/2021
16 Original instructions (ENGLISH)
Website: www.spearheadmachinery.com
Figure 4 shows an indication of the precise points on the machine where labels are usually applied by the
manufacturer.
Figure 4
2.3.1 Proposition 65
Operating, servicing and maintaining this equipment can expose you to chemicals including gasoline, diesel fuel,
lubricants, petroleum products, engine exhaust, carbon monoxide, and phthalates, which are known to the State
of California to cause cancer and birth defects or other reproductive harm.
To minimize exposure, avoid breathing exhaust, do not idle the engine except as necessary, service your vehicle
in a well-ventilated area and wear gloves and wash your hands frequently when servicing your vehicle. Battery
posts, terminals and related accessories contain lead and lead compounds, chemicals known to the state of
California to cause cancer, birth defects or other reproductive harm.
For more information go to www.P65Warnings.ca.gov.
This website, operated by California's Office of Environmental Health Hazard Assessment, provides information
about these chemicals and how individuals may be exposed to them.

8999124EN: v2.0 27/10/2021
17 Original instructions (ENGLISH)
Website: www.spearheadmachinery.com
2.4 Clothing
In general, it is necessary to wear suitable clothing for the work to be carried out. In particular, as far as Mulcher
use, obey the following provisions:
•It is mandatory to use clothing, which is as suitable as possible, meaning not too loose and without any
protruding or moving parts (for example ties or necklaces). Do not wear belts, rings and chains. Always
use sturdy safety footwear. Long hair must be tied using a specific cap.
•It is mandatory to use protective goggles or a mask before proceeding with the work in order to protect
the face and eyes from vegetable fragments which may be projected outwards during mowing.
•It is mandatory to use protective muffs in order to safeguard hearing from noise from the equipment
during work
2.5 Ecology And Pollution
Below are the minimum provisions to be followed in order to reduce the risk of environmental impact connected
to the use of the machine:
•If the Country where the machine is used foresees specific sound emission limits, it is best to adapt to
the provisions in these standards, if necessary, being supplied with suitable protective equipment
(earplugs, muffs, etc.).
•It is mandatory to respect current legislation of the Country where the Mulcher is used, related to use
and disposal of lubricants and products used for machine cleaning and maintenance, observing the
recommendations of the manufacturer of those products.
•If replacing worn parts or during demolition, one must follow anti-pollution laws foreseen in the country
where the Mulcher is used.
•It is prohibited to pour products used for cleaning or polluting substances into the sewerage drain, on
the ground, in watercourses, or into the environment.
•It is mandatory to collect products used for cleaning and polluting substances in appropriate
containers, store them and deliver them to companies authorised for their disposal.
2.5.1 Disposal
If deciding not to use the Mulcher, it is best to take a few precautions in order to avoid the risk of environmental
pollution. The various parts of the machine must be treated as if they were special waste. One must proceed by
taking apart the equipment, grouping the various parts and components in similar parts (rubber, metal, plastic,
etc.), providing for disposal of these parts separately, according to existing anti-pollution laws of the Country
where the machine was used. Please note that, in general, exhausted lubricating oil, rubber parts and scrap
metals are special waste.
2.5.2 Storage
If the machine is to be set aside for a long period, it is recommended to:
•Treat the Mulcher according to the instructions contained in the "5.2. Cleaning the Mulcher" paragraph;
•Check the machine and have any damaged parts replaced;
•Fully tighten all screws and bolts, in particular those which secure the teeth;
•Perform a general thorough lubrication;
•Place the Mulcher in a dry area where it cannot be touched by persons not authorised to use it and rest
it on struts of wood.
•Protect the entire machine with a tarpaulin.
If these operations are carried out properly, the user will find the Mulcher in perfect condition when it is required
again.
If the Mulcher is to be dismantled, comply with the relative anti-pollution legislation of the Country of use.
It should not be forgotten that the Manufacturer is always available if you require any assistance or spare parts.

8999124EN: v2.0 27/10/2021
18 Original instructions (ENGLISH)
Website: www.spearheadmachinery.com
2.6 Safe Use
•It is prohibited to use the Mulcher in ways that are different from the indications contained in the
paragraph "1.6. Intended use".
•It is prohibited to use or have the Mulcher used by anyone who has not read and completely
understood the information contained in this manual.
•It is prohibited to use or have the Mulcher used by personnel that are not competent or properly trained
or not in good health or physical condition.
•It is forbidden to drive the agricultural tractor attached to the Mulcher or have it driven by personnel
without an appropriate driving licence.
•It is forbidden to approach or stop near the Mulcher when the machine is running.
•It is forbidden to stop between the agricultural tractor and the Mulcher (area taken up by the input PTO
shaft) if the combustion engine is running.
•It is forbidden to abandon the driver’s seat on the agricultural tractor with the combustion engine
running when the Mulcher is running.
•It is forbidden to alter, tamper with or bypass the safety devices provided by the manufacturer.
•It is forbidden to operate when the labels indicating the warning signs are missing or damaged. Have
them immediately replaced with other labels having the same meaning.
•It is forbidden to use the Mulcher when even one split pin, elastic pins or shims supplied with the
machine is missing.
•It is prohibited to come close and/or touch moving parts during the work.
•It is prohibited to tamper with, remove, damage or exclude any part of the machine.
•It is forbidden to deposit items on the Mulcher which can harm persons or animals, or damage property
should they fall.
•It is forbidden to abandon the Mulcher and leave it unattended. The machine and the work area should
always be monitored.
•It is forbidden to transport persons or items on board the Mulcher while driving with the tractor.
•It is mandatory to check that all the safety devices of the Mulcher are intact and functional before using
it.
•It is mandatory to check that the agricultural tractor on which the Mulcher is installed is of adequate
power, weight and configuration, compatible with the model fitted.
•It is mandatory to disconnect the input PTO shaft from the PTO and set the control lever of the tractor
hydraulic lifter in the blocked position when driving on the road with the Mulcher lifted.
•It is mandatory to use the type of input PTO shaft indicated by the manufacturer of the Mulcher.
•It is mandatory to set the control lever of the lifter in the blocked position before connecting or
disconnecting the Mulcher from the three-point hitch of the tractor.
•It is mandatory to comply with highway regulations in force in the country where the Mulcher is used.
•It is mandatory to verify that the ground on which the tractor moves is level and sturdy, before using the
machine.
•It is mandatory for the environment where the machine operates to have adequate lighting. Insufficient
or excessive lighting may pose a risk to the operator.
•It is mandatory to familiarize yourself with the control devices and their functions prior to starting work;
•It is mandatory to make sure that the maximum number of revolutions of the PTO is set to 540/1000
rpm before powering it.
•It is mandatory to make sure that the input PTO shaft is connected properly and is fitted with the
security devices required before powering the PTO.
•It is mandatory to use suitable clothing. Strictly avoid long or loose clothing that could be caught in any
way by moving parts. Wear suitable helmets, glasses, gloves, footwear, etc.
•It is mandatory to disconnect the input PTO shaft connecting the gearbox of the Mulcher to the tractor
PTO before starting any maintenance.
•It is mandatory to lower the Mulcher attached to the lifter unit, switch the combustion engine off and
remove the ignition key from the dashboard of the tractor before leaving the driver’s seat and engaging
the parking brake.
•It is mandatory for the interventions and adjustments to always be performed with the machine
switched off and disconnected from the power.
•It is mandatory to stop the machine and inspect it if abnormal vibration is noted or have it inspected by
personnel assigned by the manufacturer until the causes are identified and eliminated.
•It is mandatory to contact a dealer if the machine stops during operations or a component malfunction.
•It is mandatory to always verify, before starting up the Mulcher, that no persons and/or animals are
within 50 metres in any direction from the machine.

8999124EN: v2.0 27/10/2021
19 Original instructions (ENGLISH)
Website: www.spearheadmachinery.com
•It is mandatory, if the agricultural tractor has no closed cabin, for the operator to use ear protectors and
a dust mask if the working ground lifts a considerable amount of dust. Ensure that the tractor is fitted
with a Rollover Protection Structure (ROPS).
•It is mandatory to periodically verify that the screws and bolts are tightened and secure, especially
those that secure the teeth.
•It is mandatory to use the types of lubricating oils indicated by the manufacturer.
•It is mandatory to periodically check the integrity and functionality of the safety devices.
•It is mandatory to comply with the laws in force in the country of installation on the use and disposal of
products used for cleaning and performing maintenance on the machine, considering the
recommendations of the manufacturer of the given products.
•It is mandatory for the Mulcher to be handled without being subjected to impact with other objects
which could compromise the optimal functionality.
•It is mandatory for the Mulcher to be lifted adequately and with suitable lifting accessories and harness
and according to the regulations in force in the country where these operations take place.
•It is mandatory for maintenance on the Mulcher to only be performed by skilled and specialized
personnel, in strict compliance with the instructions in this manual, and any worn or damaged parts
should be replaced.
•It is mandatory to always use original spare parts when carrying out repairs and maintenance.
•It is mandatory to set the Mulcher in a safe place which is protected from the elements, when the work
is completed.
The Mulcher has been designed and built in accordance with current safety regulations. Special maintenance
(repairs) must only be performed by qualified personnel and original spare parts must be used.
2.7 Safe Maintenance
In order to guarantee safe maintenance of the Mulcher it is necessary to respect the following provisions:
•It is prohibited to remove or tamper with the safety devices.
•Periodically check safety device integrity and operation.
•Periodically check screws and bolts tightness.
•It is mandatory to periodically verify the condition of the hoses. They must not be cut or have
abrasions, otherwise immediately replace them with other hoses having the same characteristics.
•It is mandatory to comply with the recommended oils.
•It is mandatory to switch the tractor engine off and always disconnect the input PTO shaft before
cleaning or performing maintenance on the Mulcher.
•It is mandatory to strictly perform maintenance on the Mulcher according to the instructions in this
manual and replace the damaged or worn parts with original spare parts only.
•It is mandatory for maintenance on the Mulcher to only be performed by skilled and specialized
personnel, in strict compliance with the instructions in this manual.
•It is mandatory to always use original spare parts when performing repairs and maintenance on the
Mulcher. Using non-original parts immediately renders the warranty null and void and can compromise
the durability and reliability of the machine.
•It is mandatory for parts or components of the Mulcher to be lifted adequately and with suitable lifting
accessories and harness and according to the regulations in force in the country where these operations
take place.
•It is forbidden to perform welding, flame-cutting or with a tool or holes on the structure of the Mulcher.
•The dangers signalled on the machine by way of pictograms (labels) of suitable dimensions, applied on
the Mulcher in easy to see places.
•These signals give the proper indications in an essential manner in order to avoid danger and prevent
the risk of damage or injury. These signs must always be kept clean and immediately replaced when
removed, even partially, or damaged: it is prohibited to operate the Mulcher when even one of these
signs is missing from the spot where it was installed by the Manufacturer.
•It is mandatory to save and keep this manual for the entire life of the Mulcher.

8999124EN: v2.0 27/10/2021
20 Original instructions (ENGLISH)
Website: www.spearheadmachinery.com
3 Installing The Mulcher
Before starting to use the Mulcher, it is mandatory to read and perfectly understand the instructions contained
below.
WARNING! Read the instructions contained in the chapter,"2. General Safety And Accident Prevention
Standards".
3.1 Delivery
The Mulcher is supplied fully assembled and protected with a “heat-shrink” plastic cover. Handles protrude from
the cover for lifting and vertical handling of the Mulcher with straps or cables able to withstand the machine’s
weight, as illustrated in Figure 5.
To transport by carriage, make sure that the Mulcher is securely anchored to the floor with suitable standard
ropes or straps, in accordance with the requirements set out in the "4.4. After Use" paragraph.
Figure 5
WARNING! The machine must be lifted with maximum care and by using lifting devices suitable for the
weight and size of the same.
WARNING! Due to the danger of this operation, it must be performed by expert and responsible
personnel. For the lifting device to be used it is mandatory to comply with the safety regulations
prescribed by the laws in force in the country where the machine is used. Do not touch the Mulcher and
do not stop within the operating range of the crane.
