Speco H2LT1 User manual

User Manual
Thank you for purchasing our product. Speco Technologies is constantly developing and
improving products. We reserve the right to modify product design and specifications
without notice and without incurring any obligation.
H2LT1/H2LB1

Warnings
■
Speco Technologies is not responsible for any problems caused by improper operation or repair.
■
■ All installation and operation here should conform to local electrical safety codes.
■ Make sure the power supply voltage is correct before using the camera.
■ Do not drop the camera or subject it to physical shock.
■ Do not use the device beyond specified voltage range.
■ Do not place the camera in extremely hot, cold (the operating temperature shall be (-22˚F~122˚F), dusty or
damp locations, and do not expose it to high electromagnetic radiation.
■ To avoid heat accumulation, good ventilation is required for operating environment.
If the product does not work properly, please contact the dealer or where the product was purchased.
Keep away from liquid while in use.
sensitivity, low noise and distortion and supports HD video transmission with the common coaxial cable,
ensuring the requirement of the HD monitoring in the traditional surveillance system.
This camera series is the latest technology and advanced circuit design, which features high definition and
Introduction
● High Resolution
Adopt high performance sensor, providing high definition and clear image.
● High Transmission Performance
Real-time transmission with high speed and long distance.
● DNR
Reduce noise from brightness and color signal.
● OSD
Access the camera settings which can be clearly displayed through the main menu.
● White Balance
Adjust the color temperature according to the environment automatically.
● AGC
Adjust the gain of amplifier, enabling the camera to output the standard video signal in different
lighting condition.
● Backlight Compensation (BLC)
When the back of the captured object is too much bright, you can set BLC for the captured object to
make it clearer.
1

Cables
Power Cable
Video Output
Video Switch Cable
Video Switch: Four video output modes can be optional--AHD, TVI, CVI and CVBS
(a) remove the cover of the video switch cable; (b) hold and press the button in the video
switch cable for 5 seconds to switch the current video output.
2
Before you start, please make sure that the wall or ceiling is strong e nough to withstand three times
the weight of the camera. Please install and use the camera in the dry environment.
You’d better install back the lens cover or lower dome less than 4 hours after removing it.
The mounting types of cameras are only for reference.
Installation
►Mounting for H2LB1
1. Drill the screw holes and the cable hole on the wall according to the drill template.
2. Route and connect the cables .
3. Secure the mounting base with camera to the wall with screws as shown below.
48mm
48mm
∅4.5

4. Bracket adjustment. Before adjustment, preview the image of the camera on a monitor and then loosen the
fixed ring to adjust the view angle of the camera. Tighten the fixed ring after the adjustment.
►Mounting for H2LT1
1.
and the cable hole on the wall according to the drill template.
Attach the drill template to the place where you want to fix the camera and then drill the screw holes
Fixed Ring
Pan 360°
Tilt 80°
(mm)
Ø4.5
Ø51.0
Ø91.6
44.2
38.2

4
2. Loosen the fixed screw to disassemble the camera.
3. Secure the mounting base to the ceiling or wall with the screws
provided.
4. Install the dome and enclosure to the mounting base.
Fixed Screw
Mounting Base
Enclosure
Dome

Then adjust the dome to obtain an optimum view angle.
0 ~75° °
0 ~360° °
0 ~360° °
5. Finally, fix the camera with the fixed screw.
Fixed screw

6
Specifications
Camera
Image Sensor
Resolution
Image size
Video Output
Image System
Electronic Shutter
IR Distance (feet)
Frame Rate
Min. Illumination
Lens
Lens Mount
S/N Ratio
Ingress Protection
Functions
Function Control
Smart LED
WDR
Digital NR
AGC
Auto White Balance
Defog
BLC
Contrast
Saturation/Color Gain
Sharpness
Exposure
Image Setting
Defect Correction
Others
Power Supply
1/2.8" CM S
2MP
1920×1080
AHD/TVI/CVI/CVBS (*camera comes defaulted to HD-TVI)
PAL/NTSC
Auto; 1/50s~1/100000s(PAL);1/60s~1/100000s (NTSC)
65~98
30fps(60Hz); 25fps(50Hz)
0 lux (LED ON)
M12
O
2.8 mm
≥ 52dB(AGC OFF)
IP67
OSD (UTC control)
Manual or auto mode
Digital WDR
Yes
No
Yes
No
Yes
Yes
Yes
Yes
Global exposure or central exposure supported
Yes
Auto
DC12V (± 15%)
IR OFF: < 1W;
Specifications
Models H2LB1
6.52 2.71× × 2.71
Power Consumption
Dimensions (inch)
Working Environment
IR ON : < 3W
-22 °F ~ 122 °F, 10 % ~ 90 %(relative humidity)
H2LT1
Ф3.72 3.25×

7
Model:
Federal Communications Commission (FCC) Statements
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
This device must accept any interference received, including interference that may
cause undesired operation.
FCC Responsible Party:
Speco Technologies
200 New Highway
Amityville, NY 11701
www.specotech.com
H2LT1/H2LB1
