Speco HT-INTB1 User manual

Intensifier Series
Camera
HT-INTB1
HT-INTB2
Please read this manual thoroughly before operation and keep
it handy for further reference.
200 New Highway
Amityville, NY 11701
631-957-8700
www.specotech.com

Package Contents Operating Your Camera
Troubleshooting
3
35~36
1 2
Contents
* SET UP --------------------------------------------------------------11~12
* SET UP LENS ------------------------------------------------------13~14
* SHUTTER SPEED CONTROL ----------------------------------15~18
* BACK LIGHT--------------------------------------------------------------19
* AUTO GAIN (AGC) -----------------------------------------------------20
* WHITE BALANCE --------------------------------------------------21~22
* REDUCE NOISE---------------------------------------------------------23
* INTENSIFIER-------------------------------------------------------------24
* CAMERA TITLE-------------------------------------------------------25~26
* DAY/NIGHT/SYNC----------------------------------------------------27~28
* MOTION DETECTION-----------------------------------------------29~30
* PRIVACY-------------------------------------------------------------------31
* REVERSE------------------------------------------------------------------32
* DETAIL----------------------------------------------------------------------33
* DEFAULT/RETURN-----------------------------------------------------34
Precautions 4
Camera Installation 5
Focusing 6
Features 7~8
------------------------9
Specifications / Dimensions 37~38
Warranty 39

PRECAUTIONS
PACKAGE CONTENTS
Please make sure that the following items are included
in the package:
1 HT-INTB CAMERA
1 SUNSHIELD
1 REMOTE CONTROLLER
1 IR RECEIVER
4 MOUNTING SCREWS
1 M2.6 WRENCH (“L" TYPE)
1 VIDEO TEST CABLE
1 POWER CABLE ADAPTOR (for optional use)
Please leave this manual with the end-user for future
reference.
TO PREVENT A FIRE OR ELECTRICAL HAZARD PLEASE
USE PROPER POWER CABLE
INSTALLATION SHOULD BE PERFORMED BY QUALIFIED
PERSONNEL
PLEASE USE A UL APPROVED REGULATED 24 VOLT AC
OR 12 VOLT DC POWER SUPPLY
PLEASE USE APPROPRIATE LOW VOLTAGE POWER
CABLE TO PREVENT FIRE OR ELECTRICAL SHOCK.
PLEASE INSURE THAT YOUR INSTALLATION AREA CAN
SUPPORT THE WEIGHT OF THE CAMERA.
PLEASE HANDLE THIS CAMERA CAREFULLY:
- DON’T USE A STRONG OR ABRASIVE DETERGENT WHEN
CLEANING THE CAMERA.
- USE A SOFT TISSUE OR LENS CLOTH TO CLEAN THE
FRONT GLASS
- DON’T EXPOSE THE CAMERA TO DIRECT SUN
3 4

CAMERA INSTALLATION
CONNECT POWER CABLE
1. WHEN USING 12 VOLTS DC (constant voltage 600 mA)
2. WHEN USING 24 VOLTS AC (40 Volt Amps)
3. CONNECT VIDEO CABLE
-CONNECT BNC CABLE TO THE BNC JACK.
POWER SUPPLY
CONNECT
YELLOW:VIDEO OUT
CONNECT
BLACK:(-)
POWER RED(+)
POWER SUPPLY
FOCUSING
1. SET THE ZOOM OR FIELD OF VIEW BY USING THE
ZOOM CONTROLLER (3-9mm or 5~50mm)
SET THE FOCUS BY USING THE FOCUS CONTROLLER.
LOCK BOTH RINGS INTO POSITION USING THE SET-
SCREWS.
▣3~9 mm ▣5~50 mm
5 6

♣SLC
When the image is in front of strong background lighting,
your camera allows you to get the best image.
♣INTENSIFIER
1/3 inch high density CCD and digital processor permit
high quality pictures to be captured in very low light
conditions.
♣High Resolution
Horizontal resolution of 530 TV lines is
achieved by using a SONY Double Speed CCD with
410,000 pixels, yielding pictures with a high S/N ratio.
♣Motion Detection
Built in motion detector with adjustable areas of coverage will
flash a warning on the screen when motion is detected.
♣Dynamic Noise Reduction
The Intensifier camera has a DSP chip that can
remove image noise efficiently showing clean
images in low light conditions.
♣ELECTRONIC DAY / NIGHT
The Intensifier camera can show color pictures in all lighting
conditions, or you can have it automatically switch to a B/W
picture in low light conditions
♣MANUAL / AUTO IRIS LENS
The Intensifier camera will work with auto iris,manual iris and
fixed iris lenses.
♣OSD
All camera functions are menu driven for ease of use.
7 8
Features

SET UP MENU
◈Function
LENS OPTION
●DC ●MANUAL
SHUTTER
●OFF ●F/L ●MANUAL
WHITE BALANCE
●ATW ●AWC MANUAL●
SLC – ( Speco Light Compensation )
●OFF ●LOW ●MIDDLE ●HIGH
Auto Gain
●OFF ●LOW ●MIDDLE ●HIGH
REDUCE NOISE
●OFF ●LOW ●MIDDLE ●HIGH
INTENSIFIER
●AUTO ●OFF
NEXT PAGE
●CAMERA TITEL ●DAY/NIGHT ●SYNC
●MOTION ●PRIVACY ●REVERSE
●DETAIL ●DEFAULT ●PAGE 1
EXIT
9
Operating your camera
10

11 12
When you call Camera Address
01
->Push 0 Button
->Push 1 Button
->Push CAM Button
Power Connector
(DC12V in)
485(+),(-)
Baud Rate Setting
Buzzer On/Off
Operating your camera
1. When controlled by RS-485, Pelco-D protocol (Option), refer to the
following.
A. DIP Switch Setting on the Camera
(Factory default : Camera Address = 01, Baud Rate = 2400bps)
B. Receiver Setting to use with IR Remote Controller
(Factory default : Baud Rate = 2400bps, Chart is same as
above)
C. System Integration
D. IR Remote Controller
- Can call and control each camera on the monitor by the following.
•Up to 15 Cameras can be
controlled by 1 IR Remote
Controller & 1 Receiver. You
must set up each camera’s
address by DIP Switches for
proper addressing.
Multiplexer
CCD Camera
Monitor
SET / Menu buttonUP button
DOWN
button
RIGHT button
LEFT button
Receiver
IR Remote
Controller
485(+)
485(-)
①②
RS485 Address Set
①
RS485 Baud rate Set
②
•Please Observe Polarity!

Operating your camera
1. Press the SET button to access the SETUP mode.
●SETUP menu is displayed on the monitor screen.
2. Select the desired feature using the UP or DOWN buttons.
●Each time you press the UP or DOWN button, the arrow
indicator moves up or down.
●Move the arrow indicator to the desired feature item.
3. Change the status of the selected feature using the LEFT
or RIGHT button.
4. When completed, move the arrow indicator to ‘EXIT’ and press
the SET button.
•●You can access the submenu by using SET button.
•●For the mode with ’---’, you may not access submenu.
13 14
Notes
Operating your camera - LENS
1) Setting up the LENS
Select the lens pressing the RIGHT button.
①On the SETUP menu screen, move the arrow indicator to the lens
using the UP or DOWN button.
②Select the desired feature using the LEFT or RIGHT button.

▶When DC LENS is selected, press SET button to control
the BRIGHTNESS.
●AUTO IRIS LENS (DC TYPE) is recommended
Notes
15 16
Operating your camera – SHUTTER SPEED CONTROL①
2) Shutter status and speed control
You can control brightness of the screen by the shutter speed.
①Press the SET button to display the setup menu and move the arrow
indicator to ‘SHUTTER’ using the UP or DOWN button.
②Set ‘SHUTTER’ to the desired mode using the LEFT or RIGHT
button.
▶OFF : Deactivation
▶FLK (1/100) : Flicker mode

▶MANUAL : When setting the shutter speed manually.
You can select speed from ‘1/60’ to ‘1/200,000’sec
17 18
Operating your camera –SHUTTER SPEED CONTROL ②
▶ELC : You can control the BRIGHTNESS.
③When completed, press ‘SET’
●Avoid pointing the camera directly at a fluorescent lamp.
●When the SHUTTER menu is set to FLK mode, the INTENSIFIER
will not work.
Notes

19 20
Operating your camera - BACKLIGHT
▶HIGH▶MIDDLE▶LOW▶OFF
4) AUTO GAIN (AGC)
AGC allows a brighter picture in low light conditions. Higher GAIN level,
will yield a brighter screen, but you might notice an increase in noise.
①Press the SET button to display the SETUP menu and move the arrow
indicator to ‘AGC’ using the UP or DOWN button.
②SET ‘AUTO GAIN’ to the desired mode using the LEFT or RIGHT button.
▶HIGH▶MIDDLE▶LOW
▶OFF
3) SLC (Speco Light Compensation) - BACKLIGHT
A built-in SR chip provides intelligent light level control to overcome
severe Backlight conditions.
①Press the SET button to display the SETUP menu and move the
arrow indicator to ‘SLC’ using the UP or DOWN button.
②SET ‘SLC’ to the desired mode using the LEFT or RIGHT buttons.

21 22
Operating your camera - WHITE BALANCE
5) WHITE BALANCE (WHITE BAL.)
①Press the SET button to display the SETUP menu and move the
arrow indicator to ‘WHITE BALANCE’ using the UP or DOWN button.
②Set ‘WHITE BAL.’ to the desired mode using LEFT or RIGHT button.
●Proper White Balance may not be obtained under the following
conditions. In these cases select the AWC mode.
-When the scene contains mostly high color temperature objects, such
as a blue sky or sunset.
-When the scene is dim.
-If your camera faces fluorescent lamp directly or is installed in an
area with constantly changing illumination.
▶ATW (Auto Tracking White Balance)
: When color temperature is 2400~12000K, select this mode.
(ex. A fluorescent lamp, or outdoors)
▶AWC (Auto White Balance Control)
: The white balance is automatically adjusted in a specific environment.
In order to obtain the best result, press the set button while the camera
focuses on white paper. If the environment including the light source is
changed, you have to adjust the white balance again.
▶MANUAL : To fine adjust, select the Manual mode. You can increase
or decrease the red or blue factor while monitoring the difference on
the screen. Set to ‘MANUAL’ mode and press the SET button. Increase
or decrease the value for RED(R-Gain) and BLUE(B-Gain), watching
the color of the picture, and press the SET button when you obtain the
best color.
Notes

23 24
Operating your camera - DNR
6) REDUCE NOISE( Dynamic Noise Reduction)
DNR reduces the video noise on the screen.
①Press the SET button to display the SETUP menu and move
the arrow to ‘REDUCE NOISE’ using the UP or DOWN button.
②SET ‘REDUCE NOISE’ to the desired mode using the LEFT
or RIGHT button.
▶HIGH : High reduction of the noise
▶MIDDLE : Middle reduction of the noise
▶LOW : Low reduction of the noise
▶OFF : Deactivation
●If you change the ‘GAIN’ menu from AGC-L to AGC-H, sensitivity is
increased as well as noise on the screen.
●When the selected ‘GAIN’ menu is OFF, REDUCE NOISE will not work.
Notes
Operating your camera - INTENSIFER
7) INTENSIFIER
Allows you to get clear images with this function under night
or low light conditions.
①Press the SET button to display the SETUP menu and move the
arrow indicator to ‘INTENSIFIER’ using the UP or DOWN button.
②SET ‘INTENSIFIER’ to the desired mode using the LEFT or RIGHT
button.
▶AUTO : When your camera is under night or low-lighting
conditions select this mode. This mode allows the
camera to switch into B/W in low light conditions.
▶OFF : Deactivation
●If you press “auto” button in the Intensifier mode, you can
Control the amount of intensification from 2X ~ X128.
●Increasing the amount of Intensification results in brighter pictures
Under low light conditions, and may increase image lag.
●Increasing the amount of intensification may cause image noise
which is to be expected as a normal condition..
Notes

8) NEXT PAGE
①Press the SET button to display the SETUP menu and move the
arrow indicator to ‘NEXT PAGE’ using the UP or DOWN button.
②SET ‘NEXT PAGE’ to the desired mode using the LEFT or RIGHT
button.
(1) CAMERA TITLE
①Press the SET button to display the SETUP menu and move the arrow
indicator to ‘CAMERA TITLE’ using the UP or DOWN button.
②SET ‘ON’ using the LEFT or RIGHT button.
●If the CAMERA TITLE feature is set to ‘OFF’, the name will not
be displayed on the monitor.
Notes
25 26
Operating your camera - CAMERA TITLE②
③Press SET button to access the SETUP mode.
④You can enter up to 15 characters.
a. Move the cursor to character-enter location by using the LEFT
or RIGHT button.
b. Select the desired character by using the UP or DOWN button.
c. Press SET button to confirm the blinking character. The first
character is saved and the cursor in the bottom of the screen
moves to the next position.
d. Repeat above steps until you create the full name you want.
e. Select the position at which the CAMERA TITLE will be located on
the screen.
-Move the cursor to ‘POS’ and press SET button.
-Select the position by using the 4-directional buttons, then press
the SET button to confirm the position.
f. When completed, move the cursor to ‘END’ and press SET button.
●If you make a mistake while entering name
Move the cursor to ‘CLR’, press ‘SET’ button.
After erasing the character from right to left, correct the character
again.
Notes
Operating your camera – CAMERA TITLE①

(2) COLOR : You can choose color and B/W mode electronically.
①Press the SET button to display the setup menu and move the arrow
indicator to ‘COLOR’ using the UP and DOWN button.
②SET ‘COLOR’ to the desired mode using the LEFT or RIGHT button.
▶COLOR : The camera will always display a color picture
▶AUTO : The camera will switch into the B/W mode under
low light conditions.
(3) SYNC : Two SYNCHRONIZATION modes are available INTERNAL and
EXTERNAL LINE-LOCK.
①Press the SET button to display the setup menu and move the arrow indicator
to ‘SYNC’ using the UP and DOWN button.
②SET to the desired mode using the LEFT or RIGHT button.
▶INT : Internal synchronization
▶L/L : If you choose ‘L/L’, you can adjust the desired phase.
-Press the SET button.
-You can adjust the desired phase from 0 to 270.
●When it used in AC power, L/L mode can be used.
●In 12V DC, the SYNC menu defaults to ‘Internal.
●OSD key may not work for 3 seconds when
COLOR/BW mode is changed.
27 28
Notes
Notes
Operating your camera – COLOR/SYNC

(4) Whenever your camera detects motion, THE WORDS “motion detected’
will appear on the screen.
①Press the SET button to display the setup menu and move the arrow
indicator to ‘MOTION’ using the UP and DOWN button.
②SET ‘MOTION’ to the desired mode using the LEFT or RIGHT button.
▶OFF : Deactivation
▶ON : MOTION. activated
-Press SET button.
-Move the arrow indicator to ‘AREA SET’ using UP and
DOWN button, and then press the SET button.
- Set the areas you want to observe.
29 30
Operating your camera – MOTION DETECTION
Max. Min.

(5) PRIVACY : To mask an area that you want to be private.
①Press the SET button to display the setup menu and move the arrow
to ‘PRIVACY’ using the UP and DOWN button.
②SET ‘PRIVACY’ to the desired mode using the LEFT or RIGHT button.
▶OFF : Deactivation
▶ON : PRIVACY mode activated
-Press the SET button.
-Move the arrow to the area you want to mask.
-Set ‘ON’ using LEFT or RIGHT button.
-Press the SET button and then set the area’s
bounds as for Motion detection.
31 32
Operating your camera - PRIVACY
(6) REVERSE
①Press the SET button to display the setup menu and move the
arrow indicator to ‘REVERSE’ using the UP and DOWN button.
②SET ‘REVERSE’ to the desired mode using the LEFT or RIGHT
button.
▶OFF : Deactivation
▶ON : Reverse the image RIGHT or LEFT.
Operating your camera - MIRROR

33 34
Operating your camera – DETAIL
(7) DETAIL
①Press the SET button to display the setup menu and move the arrow
indicator to ‘DETAIL’ using the UP and DOWN button.
②SET ‘DETAIL’ to the desired mode using the LEFT or RIGHT button.
▶OFF : Deactivation
▶ON : DETAIL control mode (level 0~31)
When the level is up, the sharpness will increase.
Control this level to get your best picture quality.
If the level is too high, you can get an unnatural image
with video noise.
Operating your camera - RESET/RETURN
(8) DEFAULT : Use to reset your camera to FACTORY DEFAULT
SETTING.
(9) PAGE 1 : Save the setting of NEXT PAGE function, and then
move to SET UP menu.

35 36
Troubleshooting
●Have you set ‘MOTION DET.’ menu to off?
●Have you set ‘MD ARAEA’ properly
MOTION DETECTION
function is not active.
●Check that you have properly connected
the camera to an appropriate power source.
The camera is not
working properly,
and the surface of
the camera is not.
●Adjust the contrast feature of the monitor.
●If you have an intermediate device, set the
75Ω/Hi-z properly.
The image on the
screen is dark.
●Is the lens stained with dirt? Clean your lens with
a soft, clean cloth.
●Adjust the monitor as required.
●If the camera is exposed to very strong light
change the camera position.
●Adjust the lens’ focus properly.
The image on the
screen is dim.
●Check that the power cord and line connection
between the camera and monitor are proper.
●Check that you have properly connected the
VIDEO cables.
Nothing appears on
the screen.
SolutionProblem
●Have you connected your camera to DC power
source? Connect it to AC power source.
L/L mode isn’t able
to be selected.
●Is the camera facing to direct sunlight or
fluorescent lighting? Change the camera position.
The image on the
screen flickers.
●Check that you have properly set the ‘WHITE
BAL’ menu
The color of the
picture is not
matched.
Solution
Problem
If you have trouble operating your camera, refer to the following.
