Speco HT - INTB8/9/10 User manual

Intensifier Series
Camera
HT - INTB8/9/10
Please read this manual throughly before operation and keep
it handy for further reference.

2
CONTENTS
Camera Set Up P33
How to Install P34
MOTION DET. P23
Package Contents P3
Precautions P4
O S D Menu P5
Operating Your Camera P6
MENU SET UP P6
LENS SET UP P7
SHUTTER SPEED P9
MANUAL P10
E L C P11
B L C P12
A
G C P13
WHITE BAL. P14
S L C P16
INTENSIFIER P17
NEXT P18
CAMERA TITLE P19
C O L O R P21
S Y N C P22
PRIVACY P25
REVERSE P27
DETAIL P28
Troubleshooting P30
Specification P32
Warranty P35

3
Please make up sure that the following items are
included in the package:
1 HT - INTB CAMERA
PACKAGE CONTENTS
4 MOUNTING SCREW
1 MOUNTING BASE
1 SUNSHIELD
1 USER'S MANUAL
1 L - WRENCH
1 VIDEO TEST CABLE
1 POWER PIGTAIL
1 HT - INTB8 CAMERA

4
TO PREVENT A FIRE OR ELECTRONICAL HAZARD PLEASE
USE PROPER POWER CABLE
PLEASE USE A UL APPROVED REGULATED 24 VOLT AC
OR 12 VOLT DC POWER SUPPLY
PLEASE USE APPROPRIATE LOW VOLTAGE POWER
CABLE TO PREVENT FIRE OR ELECTRICAL SHOCK.
INSTALLATION SHOULD BE PERFORMED BY QUALIFIED
PERSONNEL
PLEASE INSURE THAT YOUR INSTALLATION AREA CAN
SUPPORT THE WEIGHT OF THE CAMERA
PLEASE HANDLE THIS CAMERA CAREFULLY:
- DON'T USE A STRONG OR ABRASIVE DETERGENT WHEN
CLEANING THE CAMERA.
- USE A SOFT TISSUE OR LENS CLOTH TO CLEAN THE
FRONT GLASS.
- DON'T EXPOSE THE CAMERA TO DIRECT SUN
PRECAUTIONS

5
◈ Function
SET UP MENU LENS OPTION
●DC ●MANUAL
SHUTTER
●OFF ●F/L ●MANUAL
WHITE BALANCE
●ATW ●AWC ●MANUAL
SLC - ( Speco Light Compensation )
●OFF ●LOW ●MIDDLE ●HIGH
A
UTO GAIN
●OFF ●LOW ●MIDDLE ●HIGH
REDUCE NOISE
●OFF ●LOW ●MIDDLE ●HIGH
INTENSIFIER
●AUTO ●OFF
NEXT PAGE
●CAMERA TITLE ●DAY/ NIGHT ●SYNC
●MOTION ●PRIVACY ●REVERSE
●DETAIL ●DEFAULT ●PAGE1
EXIT
OSD MENU

6
MENU SET UP
SPECO TECH
LENS TYPE DC IRIS
SHUTTER SPEED MANUAL
WHITE BAL ATW
SLC HIGH
AUTO GAIN OFF
REDUCE NOISE -----
INTENSIFIER -----
NEXT PAGE
EXIT
Menu is adjusted by the OSD button on the camera
1. Press the SET button to access the SETUP mode.
●SETUP menu should be displayed on the monitor screen.
2. Select the desired feature using the UP or DOWN buttons
●Move the arrow indicator UP or Down to indicate onto desired feature
by pressing the UP or Down button.
SPECO TECH
LENS TYPE MANUAL
SHUTTER SPEED MANUAL
WHITE BAL ATW
SLC HIGH
AUTO GAIN OFF
REDUCE NOISE -----
INTENSIFIER -----
NEXT PAGE
EXIT
Select
desired
Changr the adjustment
By Left or Right Button

MANUAL : Manual Lens
7
CAUTION
A
ccess to submenu by moving arrow to desired feature
A
ccess is not available to submenu on the mode o
f
" -----".
3. MENU SETUP change by using button
●Available value or status should be displayed by pressing the Left or Right button.
●Please press the button until desired features appears.
4. When adjustment is completed, move the arrow indicator to " EXIT " and press the
"SET" button.
SPECO TECH
LENS TYPE MANUAL
SHUTTER SPEED ELC
WHITE BAL ATW
SLC HIGH
AUTO GAIN OFF
REDUCE NOISE -----
INTENSIFIER -----
NEXT PAGE
EXIT
LENS SETUP
Select the lens by pressing the RIGHT button
1. Move the arrow indicator to " LENS " by UP or Down button on the
SETUP menu.

DC / VIDEO : DC Auto IRIS Lens
MANUAL : Manual Lens
8
2. Select the desired lens type by LEFT or RIGHT button.
SPECO TECH
LENS TYPE DC IRIS
SHUTTER SPEED ELC
WHITE BAL ATW
SLC HIGH
AUTO GAIN OFF
REDUCE NOISE -----
INTENSIFIER -----
NEXT PAGE
EXIT
CAUTION
You can control the brightness when DC is selected, Brightness control range will be 1~70.
LENS
BRIGHTNESS 1--------1---------1 35
Press Set to Return
CAUTION
Color mode is not available when AGC OFF
LENS SETUP

OFF : Deactivation
FLK (1/100):Flicker mode
9
SHUTTER SPEED CONTROL
SPECO TECH
LENS TYPE DC LENS
SHUTTER SPEED
WHITE BAL ATW
SLC HIGH
AUTO GAIN OFF
REDUCE NOISE -----
INTENSIFIER -----
NEXT PAGE
EXIT
SPECO TECH
LENS TYPE MANUAL
SHUTTER SPEED MANUAL
WHITE BAL ATW
SLC HIGH
AUTO GAIN OFF
REDUCE NOISE -----
INTENSIFIER -----
NEXT PAGE
EXIT
You can control brightness of screen by the shutter speed.
①Press the SET button to display the setup menu and move the arrow
indicator to " SHUTTER " by the UP or DOWN button.
②Set " SHUTTER " to the desired mode by the LEFT or RIGHT button

When setting the shutter speed manually,
You can select from " 1/60 " to " 1/200,000" sec
10
MANUAL
SPECO TECH
LENS TYPE MANUAL
SHUTTER SPEED MANUAL
WHITE BAL ATW
SLC HIGH
AUTO GAIN OFF
REDUCE NOISE -----
INTENSIFIER -----
NEXT PAGE
EXIT
SHUTTER TYPE
MANUAL 1/60
Press SET to Return

You can control the BRIGHTNESS.
11
SPECO TECH
LENS TYPE MANUAL
SHUTTER SPEED ELC
WHITE BAL ATW
SLC HIGH
AUTO GAIN OFF
REDUCE NOISE -----
INTENSIFIER -----
NEXT PAGE
EXIT
Brightness
BRIGHTNESS I I I 35
Press SET to Return
ELC
③When completed, press " SET "
CAUTION
A
void pointing the camera directly at a fluorescent lamp.
When the SUTTER menu is set to FLK mode, the INTENSIFIER will not work.
CAUTION

BLC ON BLC OFF
12
BLC( Back Light )
3) SLC ( Speco Light Compensation )
A built - in SR chip provides intelligent light level control to overcome
severe Backlight conditions.
①Press the SET button to display the SETUP menu and move the arrow
indicator to " SLC " by the UP or DOWN button.
②SET " SLC " to desired mode by the LEFT or RIGHT button.
OFF LOW MIDDLE HIGH
SPECO TECH
LENS TYPE DC
SHUTTER SPEED
WHITE BAL ATW
SLC HIGH
AUTO GAIN OFF
REDUCE NOISE -----
INTENSIFIER -----
NEXT PAGE
EXIT

13
AGC(Auto Gain
4) AGC ( Auto Gain Control )
AGC allows a brighter picture in low light conditions. Higher GAIN level will
yield a brighter screen, but you might notice an increase in noise.
①Press the SET button to display the SETUP menu and move the arrow
indicator to " SLC " by the UP or DOWN button.
②SET " SLC " to desired mode by the LEFT or RIGHT button.
OFF LOW MIDDLE HIGH
SPECO TECH
LENS TYPE DC
SHUTTER SPEED
WHITE BAL ATW
SLC HIGH
AUTO GAIN OFF
REDUCE NOISE -----
INTENSIFIER -----
NEXT PAGE
EXIT

14
WHITE BAL.
5) WHITE BALANCE
①Press the SET button to display the SETUP menu and move the arrow
indicator to " WHITE BALANCE " by the UP or DOWN button.
②SET " WHITE BAL " to desired mode by the LEFT or RIGHT button.
SPECO TECH
LENS TYPE DC
SHUTTER SPEED
WHITE BAL AWC
SLC HIGH
AUTO GAIN OFF
REDUCE NOISE -----
INTENSIFIER -----
NEXT PAGE
EXIT
A
TW(Auto Tracking White Balance)
: When color temperature is 2400 ~ 12000K, select this mode.
(ex. A fluorescent lamp, or outdoors)
A
WC(Auto White Balance Control)
: The white balance is automatically adjusted in a specific environment.
In order to obtain the best result, press the set button while the camera
focuses on the white paper. If the environment including the light source
is changed, you have to adjust the white balance again.

15
MANUAL : To fine adjust, select the manual mode.
You can increase the red or blue factor while monitoring the difference
on the screen. Set the "MANUAL" mode and press the SET button.
Increase or decrease the value for RED(R-Gain) and BLUE(B-Gain),
watching the color of the picture and press the SET button when you
obtain the best color.
Proper White Balance may not be obtained under the following conditions.
in these case, select the AWC mode.
- When the scene contains mostly high color temperature object, such as
bule sky or sunset.
- When the scene is dim.
- If your camera faces a fluorescent lamp directly or is installed in an area
with constantly changing illumination.
CAUTION
WHITE BAL.

16
D N R
6) REDUCE NOISE ( Digital Noise Redution )
DNR reduce the video noise on the screen.
①Press the SET button to display the SETUP menu and move the arrow
indicator to " REDUCE NOISE " by the UP or DOWN button.
②SET " REDUCE NOISE " to desired mode by the LEFT or RIGHT button.
SPECO TECH
LENS TYPE DC
SHUTTER TYPE
WHITE BAL AWC
SLC HIGH
AUTO GAIN OFF
REDUCE NOISE
INTENSIFIER -----
NEXT PAGE
EXIT
OFF : Deactivation
LOW : Low reduction of the noise
MIDDLE : Middle reduction of the noise
HIGH : High reduction of the noise
If you change the "GAIN" menu from AGC-L to AGC-H, sensitivity is increased
as well as noise on the screen.
When the selected "GAIN" menu is OFF, REDUCE NOISE will not work.
CAUTION

17
INTENSIFIER
7) INTENSIFIER
Allows you to get clear images with this function under night or low light conditions.
①Press the SET button to display the SETUP menu and move the arrow
indicator to " INTENSIFIER " by the UP or DOWN button.
②SET " INTENSIFIER " to desired mode by the LEFT or RIGHT button.
SPECO TECH
LENS TYPE DC
SHUTTER TYPE
WHITE BAL AWC
SLC HIGH
AUTO GAIN OFF
REDUCE NOISE
INTENSIFIER
NEXT PAGE
EXIT
OFF : Deactivation
A
UTO : When your camera is under night or low light conditions,
select this mode. This mode allows the camera to switch
into B/W in low light conditions.
Increasing the amount of intensification results in brighter pictures under
low light conditions, and may increase image lag.
CAUTION
If you press"AUTO" button in the intensifier mode, you can control
the amount of intesification from 2X ~ X128.
Increasing the amount of intensification may cause image noise which is to
be expected as a normal condition.

18
NEXT PAGE
8) NEXT PAGE
①Press the SET button to display the SETUP menu and move the arrow
indicator to " NEXT PAGE " by the UP or DOWN button.
②SET " NEXT PAGE " to desired mode by the LEFT or RIGHT button.
SPECO TECH
LENS TYPE DC
WHITE BAL AWC
SLC HIGH
AUTO GAIN OFF
EXIT
NEXT PAGE
SHUTTER TYPE
REDUCE NOISE
INTENSIFIER
1) CAMERA TILTE
①Press the SET button to display the SETUP menu and move the arrow
indicator to " CAMERA TITLE " by the UP or DOWN button.
②SET " ON " to desired mode by the LEFT or RIGHT button.
If the CAMERA TITLE feature is set to " OFF", the name will not be
displayed on the monitor.
CAUTION

19
CAMERA TITLE
NEXT PAGE
SYNC INT
MOTION OFF
PRIVACY OFF
DEFAULT
PAGE 1
DAY / NIGHT
REVERSE OFF
CAMERA TITLE ON
DETAIL ON
③Press SET button to access the SETUP mode.
④You can enter up to 15 characters.
ⒶMove the cursor to character-enter location by using LEFT
or RIGHT button.
ⒷSelect the desired character by using UP or DOWN button.
ⒸPress the SET button to confirm the blinking charactor. The first
character is saved and the cursor in the bottom of the screen
moves to the next position.
