Speco CVC-635CR User manual

CVC-635CR
Color Weatherproof Bullet Camera
with Sunshield
Specifications
Resolution 350 lines
Minimum Illumination 1.0 lux
Image Device 1/4" color CCD image sensor
Lens/Angle o View 2.9mm, horizontal 74º vertical 57º
Lens Options 6, 8 and 12mm
Electronic Shutter Auto 1/60-1/100,000 seconds
Number o Pixels 512 horizontal x 492 vertical
Operating Temperature 23º F to 104º F
Output Video-BNC, Power- DC jack
Video S/N Ratio Greater than 48 dB
White Balance/Gain Control Auto
Housing Black metal
Power Consumption 140 mA
Power Supply Regulated 12V DC power supply included
(UL and CSA listed)
Video Output Level 1.0 Vp-p 75 ohm
Scanning Frequency Horizontal 15.75 kHz vertical 60 Hz
Scanning System NTSC Color 525 line 60 ields/second
Humidity Within 95 % RH
Dimensions 2.6"L x 1"W x 1"H
Weight 10 oz
Speci ications subject to change
For more information contact us at:
Speco Technolo ies 200 New Highway, Amityville, NY 11701 Web: www.specotech.com
Toll Free: 1-800-645-5516 In Metro NY: 631-957-8700 Fax: [phone] or 631-957-3880
The model CVC-635CR color weatherproo bullet camera is the per ect choice when a
tight budget must meet high-end surveillance . Featuring 350 lines o resolution and
light sensitivity down to 1 lux, the CVC-635CR will it in many applications. With it’s
built-in 2.9mm wide angle lens, a three-way mounting bracket and regulated 12 VDC
power supply, the CVC-635CR is there or your most demanding needs.
