Speco HTINT58K User manual

INSTRUCTION
MANUAL
HTINT58K
HTINT58KW
Speco Technologies is constantly developing product improvements.
We reserve the right to modify product design and specifications without notice and without incurring any obligation. Rev.
11/01/2014

To avoid electrical shock, do not open the case of this product.
Only use a regulated DC 12V Power supply to operate this product.
Do not overload electrical outlets or extension cords. This can result in a fire or
electrical shock.
Keep this product away from strong magnetic fields.
Do not expose this product in direct sunlight or strong reflected rays.
Refer servicing to qualified personnel only.
Do not change or modify this product. This will void the warranty.
Precautions
Features
Dimension
1/3” 1.3Mega SONY Exmor Sensor
1000TV Lines Super High Resolution
5Th Generation DSP Chip
Min. Illumination : 0.00001Lux
No Noise, Ghosting Effect with DNR
Highest Resolution : Vivid Sharp Picture in completely darkness
Power DC 12V
•
•
•
•
•
•
•
•
•
•
•
•
•
•
3.94”Dia 3.94”Dia
3.15

Specifications
Cable Connection
Camera Connection
Package
•Sensor type
•Effective pixels
•Total pixels
•Resolution
•Scanning system
•Min. illumination
•Video Output
•S/N Ratio
•Power Source
•Power Consumption
•Lens
•Storage Temperature
•Operating Temperature
•Dimension(W x H x D)
•Weight
1/3" 1.3Mega SONY Exmor Sensor (Imx138)
1305(H) X 1049(V), 1.37M Pixels
1312(H) X 1069(V), 1.40M Pixels
1000TV Lines
2:1 Interlace
0.00001Lux
1.0Vp-p Composite. 75 Ohms
52dB
DC 12V
210mA
DC Auto Iris Varifocal Lens(2.8mm~12mm)


3.94” Dia * 3.15”
1.32Ibs
SCREW
3EA
Camera
1EA
