Quick Start Guide
O5T2M

Welcome
Thank you for purchasing this network camera!
This owner's manual is designed to be a reference tool for your system.
Please read this manual carefully before operating the unit and retain it for future reference.
Should you require any technical assistance, contact Speco Technologies Tech Support at
1-800-645-5516
1. Electrical safety
All installation and operation here should conform to local electrical safety codes.
Use a certified/listed 12VDC Class 2 power supply only.
Please note: Do not connect two power supplying sources to the device at the same time;
it may result in device damage! The product must be grounded to reduce the risk of
electric shock.
Improper handling and/or installation could run the risk of fire or electrical shock.
2. Environment
Heavy stress, violent vibration or exposure to water is not allowed during transportation,
storage and installation.
This product should be installed in a cool, dry place away from direct sunlight and heat
sources.
Do not install the product in extreme temperature conditions.
Do not expose the camera to electromagnetic radiation. Otherwise it may result in CMOS
sensor failure.
Do not block any ventilation openings.
Do not allow water and liquid intrusion into the camera.
3. Operation and Daily Maintenance
Please shut down the device and then unplug the power cable before you begin any
maintenance work.
Do not touch the CMOS sensor optic component. You can use a blower to clean the dust on
the lens surface.
Always use the dry soft cloth to clean the device. If there is too much dust, use a cloth
Important Safeguards and Warning

Warning
Statement
This camera should be installed by qualified personnel only.
All the examination and repair work should be done by qualified personnel.
Any unauthorized changes or modifications could void the warranty.
.
This guide is for reference only.
Product, manuals and specifications may be modified without prior notice. Speco
Technologies reserves the right to modify these without notice and without incurring
any obligation.
Speco Technologies is not liable for any loss caused by improper operation.
Note:
Before installation, check the package and make sure that all components are included.
Contact your rep or Speco customer service department immediately if something is
broken or missing in the package.
dampened with a small quantity of neutral detergent. Finally use the dry cloth to clean
the device.
Please use a professional optical cleaning method to clean the enclosure. Improper enclosure
cleaning (such as using cloth) may result in poor IR functionality and/or IR reflection.
The grounding holes of the product are recommended to be grounded to further enhance
the reliability of the camera.
Dome cover is an optical device, please don't touch or wipe cover surface directly during
installation and use, please refer to the following methods if dirt is found:
Stained with dirt: Use oil-free soft brush or hair dryer to remove it gently.
Stained with grease or fingerprint: Use oil-free cotton cloth or paper soaked with alcohol
or detergent to wipe from the lens center outward. Change the cloth and wipe several
times if it is not clean enough.
Package
1

Overview
3
Junction box
Overview
2
Camera Quick start guide
CD Plastic plug ×4 Drill template
Screwdriver
Tapping screw ×4
1
2
3
4
5
6
7
8
Ethernet connector
Audio input connector
Power connector
Mounting base
Fixed screw
Microphone
Micro SD card slot
Reset
78
1
2
3
4
5
6

* 1 It is recommended to install the security cap for outdoor installations.
* 2 DC 12V power supply is not required if a PoE switch or injector is used to power
the camera.
► Connecting Network Cable
① Loosen the nut from the main element.
② Run the network cable (without RJ 45 connector) through both
elements. Then crimp the cable with RJ 45 connector.
③ Connect the cable to the hermetic connector. Then tighten the nut
and the main cover.
2
13
Security Cap
DC12V

Installation
3
* Before you start, please make sure that the wall or ceiling is strong enough
to withstand three times the weight of the camera and the junction box.
① Open the mounting base and the upper cover of the junction box.
② Install junction box onto the wall by using the screws provided.
Mounting base
Upper cover

③ Loosen the fixed screw to disassemble the camera. Then remove
the cover from the dome to insert the SD card. After that, install the
cover back to the dome and fix it firmly with the screws. (Note that
the cover should not be installed unevenly .)
⑤
Then reinstall the upper cover onto the junction box.
Route the cables through the cable hole and connect the cables.
④ Fasten the camera onto the junction box.
Fixed Screw
Mounting Base
Enclosure
Dome
Insert a micro SD card
Cover

⑥
preview the image of the camera on a monitor. After that, tighten the
fixed screw to finish the installation.
Adjust the camera to obtain an optimum angle. Before adjustment,
Web Operation and Login
4
IP Scanner can search for the device on the local network.
Fixed screw

③In the device list, you can view the IP address, model number, and
MAC address of each device. Select the applicable device and double
click to open up the web viewer. You can also manually enter the IP
address in the address bar of the web browser.
The login interface is shown above. Default user name is admin and
password is 1234. After logging in, follow directions to install
applicable plugins if prompted.
●Operation
①Make sure that the camera and the PC are connected to the same
local network. The camera is set to DHCP by default.
②Install IP Scanner from the CD and run it after installation. Or
download from https://www.specotech.com/ip-scanner/
5C :F 2:07:34 :6 8: 9A
O5 T2 M
