Speco WDRB10H User manual

INSTRUCTION
MANUAL
SPECO 960H WDR Series
Speco Technologies is constantly developing product improvements.
We reserve the right to modify product design and specifications without notice and without incurring any obligation. Rev. 12/01/2013
WDRB10H
(Outdoor IR Bullet Camera)
WDRD10H
(Outdoor IR Dome Camera)
WDRD20H
(Indoor IR Dome Camera)
WDRB11H
(Outdoor Bullet Camera with mount plate)
WDRD11H
(Outdoor Dome Camera)
WDRD21H
(Indoor Wall & Ceiling Mount Dome Camera)
WDRD21HW
(Indoor Wall & Ceiling Mount Dome Camera)

- 1 -
◑
Contents...................................................... 1
◑
Precautions................................................. 2, 3
◑
Safety Instructions ...................................... 4
◑
Package Contents....................................... 5
◑
Camera Installation..................................... 6-15
◑
Specications.............................................. 16-21
◑
Camera Dimension ..................................... 22-24
◑
Features...................................................... 25
◑
OSD Menu Details ...................................... 26-56
◑
Trouble Shooting......................................... 57
Precautions

- 2 -
Precautions
Do not install the camera in
extreme temperature conditions.
Do not touch the front lens of the
camera.
Never keep the camera pointed
directly at strong light.
Do not expose the camera to
radioactivity.
Do not install the camera under
unstable lighting conditions.
Do not drop the camera or subject
it to physical shocks.
Only use the camera under conditions
where temperatures are between
-10°C and +50°C. Be especially careful to
provide ventilation when operating under
high temperatures.
This is one of the most important parts of
the camera. Be careful not to leave
fingerprints on the lens cover.
It can cause malfunctions to occur. If exposed to radioactivity the CCD
will fail.
Severe lighting change or flicker can
cause the camera to work improperly.
Housing damage can compromise
weatherproof ratings.
NOTE
* If the camera is exposed to spotlight or object reflecting strong light,
smear or blooming may occur.
* please check that the power satisfies the normal specification before
connecting the camera.

- 3 -
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER(OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
ISO14001
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER(OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
ISO14001
The lightning flash with an arrowhead symbol, within an equilateral
triangle is intended to alert the user to the presence of uninsulated
dangerous voltage within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER(OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
ISO14001
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
INFORMATION - This equipment has been tested and found to comply with
limits for a Class A digital device, pursuant to part 15 of the FCC Rules & CE Rules.
These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
their own expense.
WARNING - Changes or modifications not expressly approved by the
manufacturer could void the user’s authority to operate the equipment.
CAUTION : To prevent electric shock and risk of fire hazards:
☞Do NOT use power sources other than those specified.
In USA and Canada, Use Class 2 Power Supply Only

- 4 -
Safety Instructions
Precautions for use
Please handle this camera carefully :
◑ This camera should be installed by qualied personnel only
◑There are no user serviceable parts inside
◑Do not disassemble this camera other than to make initial adjustments
◑Use a UL approved regulated 24 volt AC or 12 volt DC power supply
◑
Use appropriate low voltage power cable to prevent re or electrical shock
◑
Please insure that your installation area can support the weight of the camera
◑Do not use a strong or abrasive detergent when cleaning the camera
◑Do not install near cooling or heating device

- 5 -
Package Contents
Please make sure that the following items are included in the Package:
1) WDRB10H
• 1 Video Test Connector, Power Jack
• 1 Focus Adjustment
• 1 Bracket Base
• 1 Wrench
• Set Screw
- 4 Tapping Screws 4x25
- 4 Hexagon Socket Screws M5x10
2) WDRD10H
• 1 Video Test Connector, Power Jack
• 1 Chameleon Cover
• 1 Wrench
• Set Screw
- 3 Tapping Screws 4x40
- 1 Hexagon Socket Screw M4x8
3) WDRD20H
• 1 Video Test Connector, Power Jack
• 1 Chameleon Cover
• Set Screw
- 3 Tapping Screws 4x25
4) WDRB11H
• 1 Video Test Connector, Power Jack
• 1 Bracket Base
• 2 Wrenches
• Set Screw
- 4 Tapping Screws 4x25
- 4 Hexagon Socket Screws 5x10
5) WDRD11H
• 1 Video Test Connector, Power Jack
• 1 Chameleon Cover
• 1 Wrench
• Set Screw
- 3 Tapping Screws 4x40
- 1 Hexagon Socket Screw M4x8
6) WDRD21H
• 1 Video Test Connector, Power Jack
• 2 Screws
- 2 Tapping Screws 4x20
7) WDRD21HW
• 1 Video Test Connector, Power Jack
• 2 Screws
- 2 Tapping Screws 4x20

- 6 -
CAMERA INSTALLATION
jvuulj{Gwv~lyGjhislG
XUG~oluG|zpunGXYG}vs{zGkjGOGG\WWGhPG
YUG~oluG|zpunGY[G}vs{zGhjGO[WG}GhP
ZUGjvuulj{G}pklvGjhislG
Tjvuulj{GiujGjhislG{vG{olGiujGqhjrUG
[UGjvuulj{GhGGOyGP
TjGORGSGjvtPGGwGGGOTUGjvtPGG
uGGGlGhGkGGtG
kGG˄vu˅GGGU
kjGXY}GwGz
wGpGaylk
jGaGORP
ishjraOTP
ylkORP
wGz
hjGY[}
R
T
jvtG
hGvG
wGhGkG
uGhGk

- 7 -
CAMERA INSTALLATION
Compatibility
2) WDRD10H / WDRD20H
CVCJBD INTPMDFM INTCMINTWM
1) WDRB10H
INTCM INTJBS CVCJBB

- 8 -
CAMERA INSTALLATION
Compatibility
3) WDRB11H
CVCJBB INTJBS INTCM
4) WDRD11H
CVCJBD INTPMDFM INTCMINTWM

- 9 -
CAMERA INSTALLATION
Compatibility
5) WDRD21H / WDRD21HW
DFM

- 10 -
1. WDRB10H
TAPPING SCREW 4X25, 4EA
HEXAGON SOCKET SCREW M5X10, 4EA
CAMERA ASSEMBLY
CAMERA INSTALLATION
CAUTION : The installation instructions in this manual are for use by qualified service
personnel only. To reduce the risk of electric shock, do not perform any servicing other
than that contained in the operating instructions unless you are qualified to do so.

- 11 -
2. WDRD10H
BASE ASSEMBLY
TAPPING SCREW 4X25, 3EA
DOME COVER ASSEMBLY
CAMERA INSTALLATION

- 12 -
3. WDRD20H
TAPPING SCREW 4X25, 3EA
DOME COVER ASSEMBLY
BASE ASSEMBLY
CAMERA INSTALLATION

- 13 -
4. WDRB11H
HEXAGON SOCKET SCREW M5X10, 4EA
TAPPING SCREW 4X25, 4EA
BASE ADAPTOR BRACKET
CAMERA INSTALLATION
CAMERA ASSEMBLY

- 14 -
5. WDRD11H
CAMERA INSTALLATION
BASE ASSEMBLY
TAPPING SCREW 4X25, 3EA
DOME COVER ASSEMBLY

- 15 -
6. WDRD21H / WDRD21HW
TAPPING SCREW 4X20, 2EA
DOME COVER ASSEMBLY
BASE ASSEMBLY
CAMERA INSTALLATION

- 16 -
SPECIFICATIONS
Speco Technologies
(Outdoor IR Bullet Camera)
DC Auto Iris Varifocal Lens 2.8-12mm
WDRB10H
■
MODEL WDRB10H
1/3'' SONY HAD CCD 960H (DUAL SCAN)
NTSC
1,028(H) x 508(V)
976(H) x 494(V)
2:1 Interlace
Internal
Available
ON/OFF
700 TV Lines
52dB (AGC off, Weight on)
0.000006LUX(IR LED ON)
ATW(1,800K ~ 10,500K) / PUSH / USER1 / USER2 / ANTI CR / MANUAL / PUSH LOCK
AUTO / (1/60SEC~ 1/100,000SEC)
AUTO(x2~ x512)
Level Adjustable (MAX 42dB)
OFF, LOW, MIDLOW, MID, MIDHIGH, HIGH (2D+3D)
OFF / ON (CONTRAST: LOW, MIDLOW, MID, MIDHIGH, HIGH)
ON/OFF (4 Zone)
ON/OFF (15 Zone)
OFF , V-FLIP, H-FLIP, HV-FLIP
0 ~15 Level Adjustable
COLOR, AUTO_(EXT ON/OFF)
SMART- IR(AUTO, CENTER Adjustable) , ATR WD-EX ON/OFF
0 ~ 255 Level Adjustable (x1 ~ x16) PAN / TILT
ON/OFF
Auto: 64 Points
Coaxial
ENGLISH,JAPANESE,DEUTSCH,FRENCH, RUSSIAN, PORTUGUESE, SPANISH
Dual Voltage
IR LED ON:700mA Max
DC Auto Iris Varifocal Lens (2.8-12mm)
-4ºF ~ 140ºF RH 95% Max
-4ºF ~ 140ºF RH 95% Max
3.94"(W) * 3.94"(H) * 8.27"(D)
3.09 Ibs
Image Sensor
TV System
Total Pixels
Effective Pixels
Scanning System
Synchronization
O.S.D
BLC / HLC
Horizontal Resolution
S/N (Y Signal)
Minimum Illumination
White Balance
Electronic Shutter Speed
Slow Shutter (Sense-Up)
Gain Control
2D.3DNR
WDR
Motion Detection
Privacy
Mirror
Sharpness
Day/Night switch
IR OPT (SMART- IR, ATR WD-EX)
Digital E-ZOOM
DIS
DEFECT ADJ
Communication
Language
Power
Power Consumption
Lens
Storage Temperature
Operating Temperature
Dimension
Weight

- 17 -
SPECIFICATIONS
Speco Technologies
(Outdoor IR Dome Camera)
DC Auto Iris Varifocal Lens 2.8-12mm
WDRD10H
■
MODEL WDRD10H
1/3'' SONY HAD CCD 960H (DUAL SCAN)
NTSC
1,028(H) x 508(V)
976(H) x 494(V)
2:1 Interlace
Internal
Available
ON/OFF
700 TV Lines
52dB (AGC off, Weight on)
0.000006LUX(IR LED ON)
ATW(1,800K ~ 10,500K) / PUSH / USER1 / USER2 / ANTI CR / MANUAL / PUSH LOCK
AUTO / (1/60SEC~ 1/100,000SEC)
AUTO(x2~ x512)
Level Adjustable (MAX 42dB)
OFF, LOW, MIDLOW, MID, MIDHIGH, HIGH (2D+3D)
OFF / ON (CONTRAST: LOW, MIDLOW, MID, MIDHIGH, HIGH)
ON/OFF (4 Zone)
ON/OFF (15 Zone)
OFF , V-FLIP, H-FLIP, HV-FLIP
0 ~15 Level Adjustable
COLOR, AUTO_(EXT ON/OFF)
SMART- IR(AUTO, CENTER Adjustable) , ATR WD-EX ON/OFF
0 ~ 255 Level Adjustable (x1 ~ x16) PAN / TILT
ON/OFF
Auto: 64 Points
Coaxial
ENGLISH,JAPANESE,DEUTSCH,FRENCH, RUSSIAN, PORTUGUESE, SPANISH
Dual Voltage
IR LED ON:500mA Max
DC Auto Iris Varifocal Lens (2.8-12mm)
-4ºF ~ 140ºF RH 95% Max
-4ºF ~ 140ºF RH 95% Max
5.12"(Dia) * 3.94"(H)
1.98 Ibs
Image Sensor
TV System
Total Pixels
Effective Pixels
Scanning System
Synchronization
O.S.D
BLC / HLC
Horizontal Resolution
S/N (Y Signal)
Minimum Illumination
White Balance
Electronic Shutter Speed
Slow Shutter (Sense-Up)
Gain Control
2D.3DNR
WDR
Motion Detection
Privacy
Mirror
Sharpness
Day/Night switch
IR OPT (SMART- IR, ATR WD-EX)
Digital E-ZOOM
DIS
DEFECT ADJ
Communication
Language
Power
Power Consumption
Lens
Storage Temperature
Operating Temperature
Dimension
Weight

- 18 -
SPECIFICATIONS
Speco Technologies
(Indoor IR Dome Camera)
DC Auto Iris Varifocal Lens 2.8-12mm
WDRD20H
■
MODEL WDRD20H
1/3'' SONY HAD CCD 960H (DUAL SCAN)
NTSC
1,028(H) x 508(V)
976(H) x 494(V)
2:1 Interlace
Internal
Available
ON/OFF
700 TV Lines
52dB (AGC off, Weight on)
0.000006LUX(IR LED ON)
ATW(1,800K ~ 10,500K) / PUSH / USER1 / USER2 / ANTI CR / MANUAL / PUSH LOCK
AUTO / (1/60SEC~ 1/100,000SEC)
AUTO(x2~ x512)
Level Adjustable (MAX 42dB)
OFF, LOW, MIDLOW, MID, MIDHIGH, HIGH (2D+3D)
OFF / ON (CONTRAST: LOW, MIDLOW, MID, MIDHIGH, HIGH)
ON/OFF (4 Zone)
ON/OFF (15 Zone)
OFF , V-FLIP, H-FLIP, HV-FLIP
0 ~15 Level Adjustable
COLOR, AUTO_(EXT ON/OFF)
SMART- IR(AUTO, CENTER Adjustable) , ATR WD-EX ON/OFF
0 ~ 255 Level Adjustable (x1 ~ x16) PAN / TILT
ON/OFF
Auto: 64 Points
Coaxial
ENGLISH,JAPANESE,DEUTSCH,FRENCH, RUSSIAN, PORTUGUESE, SPANISH
Dual Voltage
IR LED ON:500mA Max
DC Auto Iris Varifocal Lens (2.8-12mm)
-4ºF ~ 140ºF RH 95% Max
-4ºF ~ 140ºF RH 95% Max
5.12"(Dia) * 3.94"(H)
1.32 Ibs
Image Sensor
TV System
Total Pixels
Effective Pixels
Scanning System
Synchronization
O.S.D
BLC / HLC
Horizontal Resolution
S/N (Y Signal)
Minimum Illumination
White Balance
Electronic Shutter Speed
Slow Shutter (Sense-Up)
Gain Control
2D.3DNR
WDR
Motion Detection
Privacy
Mirror
Sharpness
Day/Night switch
IR OPT (SMART- IR, ATR WD-EX)
Digital E-ZOOM
DIS
DEFECT ADJ
Communication
Language
Power
Power Consumption
Lens
Storage Temperature
Operating Temperature
Dimension
Weight

- 19 -
SPECIFICATIONS
Speco Technologies
(Weatherproof Bullet Camera with mount plate)
DC Auto Iris Varifocal Lens 2.8-12mm
WDRB11H
■
MODEL WDRB11H
1/3'' SONY HAD CCD 960H (DUAL SCAN)
NTSC
1,028(H) x 508(V)
976(H) x 494(V)
2:1 Interlace
Internal
Available
ON/OFF
700 TV Lines
52dB (AGC off, Weight on)
0.000006LUX
ATW(1,800K ~ 10,500K) / PUSH / USER1 / USER2 / ANTI CR / MANUAL / PUSH LOCK
AUTO / (1/60SEC~ 1/100,000SEC)
AUTO(x2~ x512)
Level Adjustable (MAX 42dB)
OFF, LOW, MIDLOW, MID, MIDHIGH, HIGH (2D+3D)
OFF / ON (CONTRAST: LOW, MIDLOW, MID, MIDHIGH, HIGH)
ON/OFF (4 Zone)
ON/OFF (15 Zone)
OFF , V-FLIP, H-FLIP, HV-FLIP
0 ~15 Level Adjustable
COLOR, AUTO_(EXT ON/OFF)
SMART- IR(AUTO, CENTER Adjustable) , ATR WD-EX ON/OFF
0 ~ 255 Level Adjustable (x1 ~ x16) PAN / TILT
ON/OFF
Auto: 64 Points
Coaxial
ENGLISH,JAPANESE,DEUTSCH,FRENCH, RUSSIAN, PORTUGUESE, SPANISH
Dual Voltage
DC 12V 400mA / AC24V 170mA
DC Auto Iris Varifocal Lens (2.8-12mm)
-4ºF ~ 140ºF RH 95% Max
-4ºF ~ 140ºF RH 95% Max
3.46"(W) * 4.01"(H) * 11.02"(D)
3 lbs
Image Sensor
TV System
Total Pixels
Effective Pixels
Scanning System
Synchronization
O.S.D
BLC / HLC
Horizontal Resolution
S/N (Y Signal)
Minimum Illumination
White Balance
Electronic Shutter Speed
Slow Shutter (Sense-Up)
Gain Control
2D.3DNR
WDR
Motion Detection
Privacy
Mirror
Sharpness
Day/Night switch
IR OPT (SMART- IR, ATR WD-EX)
Digital E-ZOOM
DIS
DEFECT ADJ
Communication
Language
Power
Power Consumption
Lens
Storage Temperature
Operating Temperature
Dimension
Weight
