1. About This Document
This document explains how to configure and maintain one or more NetLink SVP
Servers (models SVP100, SVP020, SVP010) within IP telephony environments.
1.1 SpectraLink Corporation Model Numbers
This document covers the following registered model number:
SVP100
1.2 Related Documents
NetLink Wireless Telephone: Configuration and Administration
for Cisco CallManager and IP Phone 7960 Emulation (72-1082-02)
for ITU H.323 Protocol (72-1085-02)
for Media Gateway Control Protocol (MGCP) (72-1088-02)
for Mitel Networks 3300 and SX-200 ICP with 5220 IP Phone emulation
(72-1084-02)
Available at http://www.spectralink.com/consumer/resources/manuals.jsp.
Access Point Configuration Note (72-99xx-00 where xx indicates a number
corresponding to the type of access point.). Available at
http://www.spectralink.com/consumer/resources/wifi_compatibility.jsp.
Deploying NetLink Wireless Telephones: Best Practices white paper. Available at
http://www.spectralink.com/consumer/resources/white_papers.jsp.
1.3 Customer Support Hotline
SpectraLink wants you to have a successful installation. If you have questions please
contact SpectraLink Customer Support Hotline at [phone]. The hotline is
open Monday through Friday, 6 a.m. to 6 p.m. Mountain time.
1.4 Icons and Conventions
This manual uses the following icons and conventions.
Caution! Follow these instructions carefully to avoid danger.
Note these instructions carefully.
NORM This typeface indicates a key, label, or button on the NetLink SVP Server.

SpectraLink Corporation Installation, Configuration, and Administration
NetLink SVP Server (within IP environments)
PN: 72-0178-01-C.doc Page 6
2. NetLink SVP Server Overview
The NetLink SVP Server is an Ethernet LAN device that works with access points
(APs) to provide QoS on the wireless LAN. Voice packets to and from the NetLink
Wireless Telephones are intercepted by the NetLink SVP Server and encapsulated
for prioritization as they are routed to and from an IP telephony server.
2.1 SpectraLink Voice Priority (SVP)
SpectraLink Voice Priority (SVP) is the SpectraLink quality of service (QoS)
mechanism that is implemented in the Wireless Telephone and access point (AP) to
enhance voice quality over the wireless network. SVP gives preference to voice
packets over data packets on the wireless medium, increasing the probability that all
voice packets are transmitted efficiently and with minimum delay. SVP is fully
compatible with IEEE 802.11b standards.
NetLink Wireless Telephones support basic WMM (Wi-Fi Multimedia) if also
supported by the AP as part of the 802.11e protocol. If the AP supports WMM, the
Wireless Telephone automatically discovers and uses it. WMM does not replace the
NetLink SVP Server.
2.2 SVP Server Models
The SVP Server is available in three models. Which model is selected for your facility
depends on current and expected capacity. All SVP Servers within a subnet must be
the same model type.
•SVP100: Serves 80 calls simultaneously.
•SVP020: Serves 20 powered-on handsets.
•SVP010: Serves 10 powered-on handsets.
See the following capacity tables for multiple SVP Server system capacities.
All SVP Server models are installed, configured and administered according to the
instructions in this document. The model information is available on the Software
Version screen. See section 7.3 Software Version .
2.3 The Timing Function
NetLink SVP Servers provide the connection or "gateway" to the IP PBX for the
Wireless Telephones and the "timing" function for active calls. This "gateway"
function is distributed across the SVP Servers.
The number of active SVP Servers is determined dynamically. Whenever SVP
Servers are added to or removed from the system, the distribution of "timing"
function for active calls is affected.
2.4 Internal Gatekeeper
A gatekeeper is required in certain H.323 protocol systems. The gatekeeper that
resides on the SVP Server is designed for small applications using the NetLink
Wireless Telephones under the H.323 protocol as explained in NetLink

SpectraLink Corporation Installation, Configuration, and Administration
NetLink SVP Server (within IP environments)
PN: 72-0178-01-C.doc Page 7
e340/h340/i640 Wireless Telephone: Configuration and Administration with ITU
H.323 Protocol.
The internal gatekeeper is not designed to scale beyond the capacity of a single SVP
Server and does not provide the advanced features required for larger installations. It
has a limit of 1000 registration records.
2.5 Multiple SVP Servers/Master SVP Server
Multiple SVP Server environments are those which have more than one NetLink
SVP Server. Up to four SVP010 models or up to two SVP020 models may be
installed in any one subnet. Up to 16 models of SVP100 Servers may be installed in
any one subnet. All SVP Servers must be in the same subnet.
In a system comprised of multiple SVP Servers, a master SVP Server must be
identified. The master SVP Server must have a static IP address. The Wireless
Telephones and the other SVP Servers locate the master by using a static IP address,
DHCP, or DNS.
The master SVP Server performs important coordinating functions. The loss of a
non-master SVP Server does not significantly affect the operation of the remaining
SVP Servers but results in the re boot of all handsets. However, the loss of the
master SVP Server results in a loss of all communication between all of the SVP
Servers. This also means that the loss of the master SVP results in the loss of all
active calls and Wireless Telephones cannot check-in until communication with
master is reestablished.
2.6 Multiple NetLink SVP Server Capacities
The system capacity of each SVP Server model is shown in the below tables. Note
that SVP Server models may not be combined within one subnet.
NetLink SVP010 and SVP020 Server Capacity
The system capacity of the SVP010 and SVP020 is measured by number of powered
on handsets. If this number exceeds the maximum, the handset that cannot be
served will display an error and will not connect to the SVP Server. Other handsets
will not be affected.
Number of handsets
Number of SVP
Servers SVP010 SVP020
1 10 20
2 20 40
3 30 N/A
4 40 N/A

SpectraLink Corporation Installation, Configuration, and Administration
NetLink SVP Server (within IP environments)
PN: 72-0178-01-C.doc Page 8
NetLink SVP100 Server Capacity
The capacity of the SVP100 Server is determined by active calls. The table below
shows the capacity of an IP gateway in a multiple SVP Server environment.
SVP Servers Calls per server Total Calls Erlangs 10% use 15% use 20% use
1 80 80 65 500 433 325
2 64 128 111 1000 740 555
3 60 180 160 1500 1067 800
4 58 232 211 2000 1407 1055
5 57 285 262 2500 1747 1310
6 56 336 312 3000 2080 1560
7 56 392 367 3500 2447 1835
8 55 440 415 4000 2767 2075
9 55 495 469 4500 3127 2345
10 55 550 524 5000 3493 2620
11 55 605 578 5500 3853 2890
12 54 648 621 6000 4140 3105
13 54 702 674 6500 4493 3370
14 54 756 728 7000 4853 3640
15 54 810 782 7500 5213 3910
16 54 864 836 8000 5573 4180

SpectraLink Corporation Installation, Configuration, and Administration
NetLink SVP Server (within IP environments)
PN: 72-0178-01-C.doc Page 9
2.7 Notes on System Configuration
In an IP system using subnets to differentiate telephony areas, each subnet
must have its own access points. Each subnet may require an SVP Server
to maintain voice quality, but this depends on traffic volume and router
capacity.
Multiple SVP Server environments are those which have more than one
SVP Server. A master SVP Server must be identified in a multiple SVP
Server environment.
SVP Server models may not be combined within one subnet. More than
one SVP Server model type may be used within a facility if installed on
different subnets.
Wireless Telephones cannot roam with uninterrupted service between
subnets unless specific LAN components are present. Certain
AP/Ethernet switch combinations establish a layer-2 tunnel across subnets
that enables the handsets to roam. Without this capability, any call in
progress will be dropped when the user moves out of range and the
handset must be power cycled in order to resume functionality in the new
subnet area.
Please see Deploying NetLink Wireless Telephones: Best Practices for
detailed configuration information when installing multiple SVP Server
models across several different subnets.
IP multicast addresses are used by the NetLink i640 Wireless Telephone
system. This requires that multicasting be enabled on the subnet used for
the NetLink Wireless Telephones, SVP Server, and telephony gateways.
Routers are typically configured with filters to prevent multicast traffic
from flowing outside of specific domains. The wireless LAN can be placed
on a separate VLAN or subnet to reduce the effects of broadcast and
multicast traffic from devices in other network segments.
The NetLink SVP Server requires a Cat. 5 cable connection between its
network port and the Ethernet switch. The NetLink SVP Server auto-
negotiates to the type of port on the Ethernet switch and supports 10Base-
T, 100Base-T, full-duplex and half-duplex port types.

SpectraLink Corporation Installation, Configuration, and Administration
NetLink SVP Server (within IP environments)
PN: 72-0178-01-C.doc Page 10
2.8 System Diagram
The following diagram shows multiple NetLink SVP Servers residing on a network
with an IP telephony gateway and IP telephony server, wireless LAN access points,
and Ethernet switch:
(IP telephony system example)
NetLink SVP Server
access point
Wireless
POS
Wireless
Telephones
access point
IP Telephony
Server
IP
Phones
optional
IP Gateway
PSTN
or
PBX
Device supplied by
SpectraLink Ethernet cable
Phone cable
NetLink SVP Server
NetLink SVP Server
Master
Ethernet switch
(showing
optional
multiple
SVP
Servers)

SpectraLink Corporation Installation, Configuration, and Administration
NetLink SVP Server (within IP environments)
PN: 72-0178-01-C.doc Page 11
2.9 System Components
NetLink e340/h340 and i640 Wireless Telephones
Employees can carry Wireless Telephones to make and receive calls as they move
throughout the building. The Wireless Telephones are to be used on-premises; they
are not cellular or satellite phones. Just like wired telephones, they can receive calls
directly, receive transferred calls, transfer calls to other extensions, and make outside
and long distance calls (subject to the restrictions applied in your facility.)
The NetLink e340/h340 Wireless Telephone is a lightweight, durable handset
specifically designed for mobile workplace use within a facility. The NetLink i640
Wireless Telephone offers a durable design with push-to-talk functionality.
NetLink Wireless Telephones can operate on an 802.11b wireless network and can
operate at a transmission rate of up to 11Mb/s.
Access Points
Supplied by third party vendors, access points provide the connection between the
wired Ethernet LAN and the wireless (802.11) LAN. Access points (AP) must be
positioned in all areas where Wireless Telephones will be used. The number and
placement of access points will affect the coverage area and capacity of the wireless
system. Typically, the requirements for use of NetLink Wireless Telephones are
similar to that of wireless data devices. Contact SpectraLink, or a certified
SpectraLink distributor, for specific information about your facility’s needs.
The NetLink system must connect to access points that utilize SpectraLink Voice
Priority (SVP). Contact SpectraLink, or a certified SpectraLink distributor, to verify
that your AP and its software version are supported.
Ethernet Switch
A component in the wired Ethernet LAN infrastructure. Switches interconnect
multiple network devices, including access points and other components. Ethernet
switches are required to provide the higher performance network connections
needed to handle combined voice and data traffic.
Router
An optional component in the wired Ethernet LAN infrastructure that separates a
wired LAN into segments so that network traffic is restricted to those segments that
are directly involved in the communication. Installation of a network router is
recommended in larger networks, where there may be significant network traffic not
related to the wireless LAN. A router will isolate the wireless LAN from the
associated wired LAN so that they are not impacted by each others’ traffic. The
NetLink SVP Servers, the APs, and their associated Ethernet switch must all be on
the same “side” of the router.
NetLink SVP Server
The NetLink SVP Server manages call network traffic as detailed in this document.

SpectraLink Corporation Installation, Configuration, and Administration
NetLink SVP Server (within IP environments)
PN: 72-0178-01-C.doc Page 12
Administrative computer
Required for setup and maintenance of the NetLink SVP Server. This computer may
be temporarily connected directly to the component or to the network, a dedicated
computer is not required. Some installations use a laptop to configure and maintain
system components.
TFTP Server
Required in an IP system to distribute software to the Wireless Telephones and SVP
Server. May be on a different subnet than the IP gateway, IP telephony server, and
APs.

SpectraLink Corporation Installation, Configuration, and Administration
NetLink SVP Server (within IP environments)
PN: 72-0178-01-C.doc Page 13
2.10 The Front Panel of the NetLink SVP Server
The NetLink SVP Server’s front panel contains ports to connect to power, the LAN,
and an administrative computer via an RS-232 port. Status LEDs supply information
about the NetLink SVP Server’s functioning.
RS-232 Port: male DB-9 connector (DTE) used for RS-232 connection to a terminal,
terminal emulator, or modem for system administration.
Link LEDs:
LNKOK: Lit when there is a network connection.
ACT: Lit if there is system activity.
COL: Lit if there are network collisions.
NETWORK: Port to wired (Ethernet) LAN.
ERROR: Lit when the system has detected an error.
STATUS: Indicate system error messages and status.
1: Heartbeat, indicates gateway is running.
2: If active calls.
3,4,5: Currently unused
PWR (power jack): Connects to the AC adapter supplying power to the system.
Use only the SpectraLink-provided Class II AC Adapter with output
24VDC, 1A.
Note that the model designation may be found on the label which is on the side of
the SVP Server.
L
N
K
O
K
A
C
T
C
O
L
Status
E
R
R
O
R
34 51 2 PWR
NETWORK
RS-232

SpectraLink Corporation Installation, Configuration, and Administration
NetLink SVP Server (within IP environments)
PN: 72-0178-01-C.doc Page 14
3. Installing the NetLink SVP Server
As shown in the system diagram the NetLink SVP Server is connected to the
Ethernet switch. The specifications covered here allow for great flexibility in physical
placement of the components within stated guidelines.
See the Configuration and Administration document for your vendor’s IP system for
information on LAN requirements, network infrastructure and IP addressing.
3.1 Required Materials
The following equipment must be provided by the customer.
•Power Outlet:Must accept SpectraLink provided AC adapter.
•Backboard space: The NetLink SVP Server is designed to be wall mounted to
¾” plywood securely screwed to the wall.
•Screws: Required to mount the NetLink SVP Server to the wall. Four #8 -
¾” panhead wood screws (or similar device) are required.
•Cat. 5 Cable: RJ-45 connector at the NetLink SVP Server. Connection to
Ethernet switch.
3.2 Locate the NetLink SVP Server
The NetLink SVP Server measures approximately 4 x 12.5 x 7 inches, and weighs
about five pounds. The unit can be wall mounted, vertically or horizontally, over ¾”
plywood. The SVP Server can also be rack mounted using a rack mount kit (sold
separately).
Locate the NetLink SVP Server in a space with:
•Sufficient backboard mounting space (for wall mount) and proximity to the
LAN access device (switched Ethernet hub) and power source.
•Easy access to the front panel, which is used for cabling.
•A maximum distance of 325 feet (100 meters) from the Ethernet switch.
3.3 Install the NetLink SVP Server
The NetLink SVP Server may be mounted on a rack or to a wall.
Mount the SVP Server on a rack
The rack mount kit is designed for mounting equipment in a standard 19” rack and
should contain the following equipment:
•Mounting plates: Two for each SVP Server to be mounted.
•Screws: Four rack mount screws for each SVP Server to be mounted.
To rack mount the NetLink SVP Server:
1. Remove the corner screws from the SVP Server
2. Screw the U-shaped end (round screw holes) of the two mounting plates to the
SVP Server.

SpectraLink Corporation Installation, Configuration, and Administration
NetLink SVP Server (within IP environments)
PN: 72-0178-01-C.doc Page 15
3. Screw the other end of the two mounting plates (oblong screw holes) to the rack.
4. Repeat steps 1-3 for each additional SVP Server. The mounting plate is designed
to provide the correct minimum spacing between units. When mounting multiple
units, stack the units in the rack as closely as possible.
Mount the NetLink SVP Server to a wall
The NetLink SVP Server can be mounted either horizontally or vertically.
To mount the NetLink SVP Server to a wall:
1. Using a 1/8” drill bit, drill four pilot holes, on 1.84 by 12.1” centers
(approximately equivalent to 1-13/16” by 12-1/8”).
2. Insert the #8 x 3/4” screws in the pilot holes and tighten, leaving a 1/8 to 1/4”
gap from the wall.
Connect NetLink SVP Server to LAN
Using a Cat. 5 cable, connect the NETWORK port on the NetLink SVP Server to
the connecting port on the Ethernet switch.
Connect Power
1. Connect the power plug from the AC adapter to the jack labeled PWR on the
NetLink SVP Server.
Use only the provided Class II AC Adapter with output 24VDC, 1A.
2. Plug the AC adapter into an 110VAC outlet to apply power to the NetLink SVP
Server.
3. The system will cycle through diagnostic testing and the LEDs will blink for
about one minute. When the system is ready for use:
•The ERROR LED should be off.
•Status 1 should be blinking.

SpectraLink Corporation Installation, Configuration, and Administration
NetLink SVP Server (within IP environments)
PN: 72-0178-01-C.doc Page 16
4. Configuring the NetLink SVP Server
During initial setup of the NetLink SVP Server the IP address is established and the
maximum number of active calls per access point is set. Optionally, you may enter a
hostname and a location for software updates via TFTP.
4.1 Connecting to the NetLink SVP Server
The initial connection to the NetLink SVP Server must be made via a serial
connection to establish the NetLink SVP Server’s IP address. After the IP address is
established, connection to the NetLink SVP Server may be done via the network
using telnet. It is recommended that the basic setup actions occur while the serial
connection is made.
Connect via the Serial Port
1. Using a DB-9 female, null-modem cable, connect the NetLink SVP Server to the
serial port of a terminal or PC.
2. Run a terminal emulation program (such as HyperTerminal™) or use a VT-100
terminal with the following configuration:
Bits per second: 9600
Data bits: 8
Parity: None
Stop bits: 1
Flow control: None
3. Press Enter to display the NetLink SVP Server login screen.
4. Enter the default login: admin and default password: admin. These are case
sensitive.
5. The NetLink SVP-II System menu will display.
Connecting Via Telnet
Telnet can only be used after the NetLink SVP Server’s IP address is
configured.
The telnet method of connection is used for routine maintenance of the NetLink
Server for both local and remote administration, depending on your network.
To connect via telnet, run a telnet session to the IP address of the NetLink SVP
Server. Once you connect and log in, the NetLink SVP-II System menu displays.

SpectraLink Corporation Installation, Configuration, and Administration
NetLink SVP Server (within IP environments)
PN: 72-0178-01-C.doc Page 17
4.2 The NetLink SVP-II System Menu
The main menu displays as shown here:
System Status
Menu for viewing error messages, status of operation and software code version.
SVP-II1Configuration
Allows you to set the mode and reset the system.
Network Configuration
Allows you to set network configuration options, including IP address and
hostname.
Change Password
Allows you to change the password for NetLink SVP Server access.
1SVP-II is a designation used internally by SpectraLink Engineering.

SpectraLink Corporation Installation, Configuration, and Administration
NetLink SVP Server (within IP environments)
PN: 72-0178-01-C.doc Page 18
4.3 Network Configuration
The IP address and other network settings are established via the Network
Configuration screen. This is also where you may optionally establish a hostname and
enter the IP address of the location of any software updates you may obtain from
SpectraLink. See section 6, the Software Maintenance section, of this document for
more information about installing software updates via TFTP.
Scroll to Network Configuration and select by pressing Enter. A screen similar to the
following appears:
Note the navigation options at the bottom of the screen. Press Enter to change a
value, ESC to exit the screen, and the arrow keys to move the cursor.
Send All
In an IP system with multiple NetLink SVP Servers, the SendAll option is provided
to speed configuration and ensure identical settings. The S=SendAll option allows you
to send that configuration parameter to every NetLink SVP Server on the LAN.
SendAll can only be used after the IP address is established on EACH NetLink SVP
Server via the serial connection. If you anticipate identical settings across the LAN,
set just the IP address and custom hostname (if desired) for each NetLink SVP
Server using the initial serial connection. Then connect via the LAN and use SendAll
to set identical configuration options for all NetLink SVP Servers.
If SendAll is to be utilized in your system, all passwords must be identical. DO NOT
CHANGE THE PASSWORD AT THE INITIAL CONFIGURATION IF THE
SEND ALL OPTION IS DESIRED. Use the default password and change it
globally if desired after a LAN connection is established for all NetLink SVP Servers.
If independent administration of each NetLink SVP Server is desired, the passwords
may be set at initial configuration.

SpectraLink Corporation Installation, Configuration, and Administration
NetLink SVP Server (within IP environments)
PN: 72-0178-01-C.doc Page 19
To change the IP address of the master SVP Server, change it in this menu
and reboot the system. Then you may change alias IP addresses in each of
the other SVP Servers without error.
The following options must be configured:
IP Address
Enter the IP address of the NetLink SVP Server, defined by your network
administrator. Enter the complete address including digits and periods. DHCP
may be entered.
A master SVP Server must have a static IP address.
The NetLink SVP Server will automatically lock for maintenance if the IP
address is changed. When this Maintenance Lock occurs, the NetLink SVP
Server must be reset upon exit. All active calls are terminated during a reset.
Hostname
(Optional) change the default host name, if desired. This is the name of the
NetLink SVP Server to which you are connected, for identification purposes
only. You cannot enter spaces in this field.
Subnet Mask
The network administrator must define the subnet mask.
Default Gateway
The IP address of a router on the local subnet.
SVP-II TFTP Download Master
This entry indicates the source of software updates for the NetLink SVP Server.
See section 5, the Software Maintenance section, for more information.Valid
source location entries are:
•NONE: disables.
•IP Address: The IP address of a network TFTP server that will be used to
transfer software updates to the NetLink SVP Server.
DNS server and DNS domain
These settings are used to configure Domain Name services. Consult your
system administrator for the correct settings. These can also be set to DHCP. This
will cause the DHCP client in the NetLink SVP Server to attempt to
automatically get the correct setting from the DHCP server. The DHCP setting
is only valid when the IP address is also acquired using DHCP.
WINS servers
These setting are used for Windows Name Services. Consult your system
administrator for the correct settings. These can also be set to DHCP. This will
cause the DHCP client in the NetLink SVP Server to attempt to automatically
get the correct setting from the DHCP server. The DHCP setting is only valid
when the IP address is also acquired using DHCP.

SpectraLink Corporation Installation, Configuration, and Administration
NetLink SVP Server (within IP environments)
PN: 72-0178-01-C.doc Page 20
When the name services are set up correctly, the NetLink SVP Server can
translate hostnames to IP addresses. Using telnet, it is also possible to
access the NetLink SVP Server using its hostname instead of the IP
address.
Workgroup
As set in WINS.
Syslog Server
Logging can be set to Syslog or NONE. If Syslog is set, a message is sent to the
syslog server when an alarm is triggered.
Disable Telnet Service
Prevents Telnet access into the SVP Server. Reset the SVP Server for the change
to take effect. Upon reset the Telnet protocol server is not started.
The NetLink SVP Server must be reset in order to set the configuration options. If
the NetLink SVP Server is in Maintenance Lock, you must manually reset it by
selecting the Reset option in the SVP-II Configuration screen and then pressing Y upon
exit.
