SpectraLink IP-DECT SERVER 400 Operator's manual

14215700-IG, Edition 7.0
January 2018, Original document
Spectralink IP-DECT Server 400/6500
Installation and Configuration
Guide

Copyright Notice
© 2013 - 2017 Spectralink Corporation All rights reserved. SpectralinkTM, the Spectralink logo and
the names and marks associated with Spectralink’s products are trademarks and/or service marks of
Spectralink Corporation and are common law marks in the United States and various other coun-
tries. All other trademarks are property of their respective owners. No portion hereof may be repro-
duced or transmitted in any form or by any means, for any purpose other than the recipient’s
personal use, without the express written permission of Spectralink.
All rights reserved under the International and pan-American Copyright Conventions. No part of this
manual, or the software described herein, may be reproduced or transmitted in any form or by any
means, or translated into another language or format, in whole or in part, without the express written
permission of Spectralink Corporation.
Do not remove (or allow any third party to remove) any product identification, copyright or other
notices.
Notice
Spectralink Corporation has prepared this document for use by Spectralink personnel and cus-
tomers. The drawings and specifications contained herein are the property of Spectralink and shall
be neither reproduced in whole or in part without the prior written approval of Spectralink, nor be
implied to grant any license to make, use, or sell equipment manufactured in accordance herewith.
Spectralink reserves the right to make changes in specifications and other information contained in
this document without prior notice, and the reader should in all cases consult Spectralink to determ-
ine whether any such changes have been made.
NO REPRESENTATION OR OTHER AFFIRMATION OF FACT CONTAINED IN THIS
DOCUMENT INCLUDING BUT NOT LIMITED TO STATEMENTS REGARDING CAPACITY,
RESPONSE-TIME PERFORMANCE, SUITABILITY FOR USE, OR PERFORMANCE OF
PRODUCTS DESCRIBED HEREIN SHALL BE DEEMED TO BE A WARRANTY BY
SPECTRALINK FOR ANY PURPOSE, OR GIVE RISE TO ANY LIABILITY OF SPECTRALINK
WHATSOEVER.
Warranty
The Product Warranty and Software License and Warranty and other support documents are avail-
able at http://support.spectralink.com/.
Contact Information
US Location
+ 1 800-775-5330
Spectralink Corporation
2560 55th Street
Boulder, CO 80301
USA
[e-mail]
UK Location
[phone]
Spectralink Europe UK
329 Bracknell, Doncastle Road
Bracknell, Berkshire, RG12 8PE
United Kingdom
[e-mail]
Denmark Location
[phone]
Spectralink Europe ApS
Bygholm Søpark 21 E Stuen
8700 Horsens
Denmark
[e-mail]

Contents
About This Guide 9
Important Information Before You Begin 9
Related Documentation 10
Terminology and Acronyms 11
About DECT 14
DECT Frequency Bands 14
Spectralink IP-DECT Server Solution 15
Types of Servers 15
Description - Spectralink IP-DECT Server 400 15
Description - Spectralink IP-DECT Server 6500 16
Other Solution Component 18
Description - Spectralink DECTMedia Resource 18
Description - Spectralink IP-DECT Base Station 19
Description - Spectralink DECT Repeater 20
System Capacity Overview 20
System Capacity - Servers 20
System Capacity - Media Resources 21
Spectralink Server Solution Overview and Comparison 21
Product Overview 21
Spectralink Handset Portfolio Overview 22
Total Configuration Overview 22
Server Comparison Matrix 23
Base Station Comparison Matrix 24
Configuration Overview - Spectralink IP-DECT Server 400 25
Configuration Overview - Spectralink IP-DECT Server 6500 27
Communication Ports - Spectralink IP-DECT Server 400/6500 28
Service Codes - Spectralink IP-DECT Server 29
Licenses 29
Licenses for Spectralink IP-DECT Server 400/6500 29
Ordering Licenses 33
Loading Licenses 34
Installation Requirements 35
Requirements for Spectralink IP-DECT Server 400 35
Requirements for Spectralink IP-DECT Server 6500 and Spectralink
DECTMedia Resource 35
Environmental Requirements 35
Requirements for Spectralink IP-DECT Base Station and Spectralink
DECT Repeater 35
Environmental Requirements 36
14215700-IG, Edition 7.0
January 2018, Original document

PowerRequirements 36
Requirements for Spectralink DECT Handset 36
Requirements for Spectralink Maintenance Software 36
Software Requirements 36
Installation Prerequisites 37
About ARI and IPEI Identification 38
Identifying IPEI on Spectralink Handset 38
Identifying ARI on Spectralink IP-DECT Server 38
Installing the Spectralink IP-DECT Server 400 39
Installing the Spectralink IP-DECT Server 6500 and Spec-
tralink DECTMedia Resource 40
Server Appearence and Components 40
Server and Media Resource LED Indicators 41
Server and Media Resource Reset Button 42
Resetting or Restarting the Spectralink IP-DECT Server and Spectralink
DECTMedia Resource 42
Mounting in aRack 42
Adding Aditional Spectralink DECTMedia Resources 43
How to Add a Spectralink DECTMedia Resource 44
Installing the Spectralink IP-DECT Base Station 47
Power Requirements for the Base Station 47
Base Station Appearence and Components 48
Base Station LED Indicators 50
Front Cover 50
LAN Port on Face Plate 50
Base Station Reset Button 50
Mounting the Base Station 51
Wall Mounted (Vertical) Installation RF Coverage 51
Installing the Spectralink DECT Repeater 53
Repeater Appearance and Components 54
Repeater LED Indicators 55
Front Cover 55
Site Installation Considerations 55
Environmental Considerations 55
How to Wall Mount the Repeater 56
Programming a Spectralink DECT Repeater with the Spectralink Pro-
gramming Kit 56
Content of the Spectralink Programming Kit Repeater 56
Set up of the Hardware for Repeater Programming 57
Programming the Spectralink DECT Repeater with the Service Tool 57
Numbering of Base Stations and Repeaters in a Normal Configuration 58
Numbering of Repeaters in a Repeater Jump Configuration 58
14215700-IG, Edition 7.0
January 2018, Original document

Using the Spectralink DECT Repeater With ExternalAntenna 59
Alternative Synchronization Ways 60
Technical Specifications - External Antenna 60
Configuration Steps Overview 61
Configuring the Spectralink IP-DECT Server/Spectralink
DECTMedia Resource Solution 63
Recommended Network Configuration 63
Assigning DHCP Server Options 64
Discovering the Spectralink IP-DECT Components via UPnP 65
Assigning DHCP Server Reservations 65
Accessing the Web Based Administration Page 66
Password 66
About the Main Page of the Web Based Administration Page 67
Configuring Network Settings 69
To Configure a Dynamic IP address 70
To Configure a Static IP Address and Other Network Settings 71
Configuring Security Settings and Changing System Password 75
Strict Password Requirements 76
Configuring SIP and IP-PBX Settings 77
To Configure SIP Settings 77
Configuring Wireless Server Settings 82
To Configure Wireless Server Settings 82
Configuring Media Resource Settings 88
Configuring Certificates (if Using TLS) 89
Handling Host and/or CA Certificates 89
Configuring Clusters 90
Defining a Cluster for the Media Resource and Base Stations 91
Assigning Media Resources to Clusters 92
Assigning Base Stations to Clusters 93
Assigning Server Address to Spectralink IP-DECT Base Station and Spec-
tralink DECTMedia Resource 96
Manually IP-DECT Server Address Configuration for Base Stations 96
Manually IP-DECT Server Address Configuration for Media Resources 97
Administration of Spectralink IP-DECT Base Stations 98
Connecting Base Station to System 99
Radio BasedSynchronization 99
LAN Based Synchronization (License Required) 102
Precision Time Protocol Background 102
Configuration Settings through the Web BasedAdministration Page 102
14215700-IG, Edition 7.0
January 2018, Original document

Checking Sync State of Spectralink IP-DECT Base Station 109
Checking for Loops 109
Registering Users and Subscribing Spectralink DECT Hand-
sets 110
Registering a User 110
To Register/Create a New User 110
Subscribing a Spectralink DECT Handset 113
About Handset Management 114
User List Information 115
Tasks to Perform from User List 116
To View or Change Handset/User Configuration 116
To Search Handset/User Information 117
To Disable/Enable User 117
To Delete/Deregister User 117
To Re-register User 117
To Un-subscribe User 118
To Update Handset Firmware 119
Import/Export of Users or Delete Users 119
Example of Handset Registration Data - CSV Format 121
About System Management 122
Making a Back-Up and Restore of System 123
To Make a Back-Up or Restore of Configuration File 123
Updating Firmware 124
To Update Spectralink IP-DECT Server Firmware 124
To Update Spectralink IP-DECT Base Station Firmware 126
To Update Spectralink DECTMedia Resource Firmware 129
To Update Spectralink DECT Handset Firmware Over The Air (SUOTA) 131
Restarting System or Block Calls during Firmware Update 133
To Restart System or Block New Calls 133
Reading System Information 133
General Status Information 134
Logs Information 135
Wireless Server Information 136
Statistics 136
Changing Administration Password 140
Resetting System to Factory Settings 142
To Reset System 142
Exporting/Importing ConfigurationFile 143
To Import/Export Configuration File 143
14215700-IG, Edition 7.0
January 2018, Original document

Deleting Licenses 143
Messaging Over MSF 144
XML-RPC SDK Documentation 144
About Redundancy 145
Firmware Compatibility (Redundancy) 145
Design of Redundant Server Solution 146
How This Works 146
Configuring Redundancy 147
Redundancy Licenses 147
Configuring a Master Spectralink IP-DECT Server 6500 149
Configuring a Backup Spectralink IP-DECT Server 6500 151
Base Station and Media Resource Configuration 153
Administration Scenarios 154
Upgrading an Existing Spectralink IP-DECT Server 6500 Solution into a
Redundant Solution 154
Temporary Failure on the Master Spectralink IP-DECT Server 6500 154
Permanent Failure on the Master Spectralink IP-DECT Server 6500 154
Failure on the Backup Spectralink IP-DECT Server 6500 155
Configuring Corporate Phone Book/Directory 156
To Get Phone Book Data through LDAP Server or CSV File 156
Example of LDAP Configuration 158
Example of CSV File Format 159
Handset Sharing 160
Handset Sharing - Firmware Compatibility 162
Adding Handset Sharing License 163
Configuration of Handset Sharing 163
User Sign-in/Sign-out 164
Configuring Handset Login 164
Signing into a Device from the Handset 170
Signing out from a Device from the Handset 170
Adding Devices to Server 171
Adding Users to Server 174
Handset Sharing and Provisioning 175
Handset Sharing Setup Examples 175
Example of Setting Up Handsets for Handset Sharing 178
14215700-IG, Edition 7.0
January 2018, Original document

Product Compatibility 179
Troubleshooting 182
Packet Capture 182
Network Diagnose 183
Parameter Overview 184
Status - General 184
Status - Logs 185
Status - Wireless Server 186
Status - Packet Capture 186
Status - Network Diagnose 187
Configuration - General 187
Configuration - Wireless Server 191
Configuration - Media Resource 195
Configuration - Security 196
Configuration - Certificates 197
Configuration - SIP 197
Configuration - Redundancy 202
Configuration - Provisioning 203
Configuration - Import/Export 205
Users - List Users - User 206
Users - List Devices - Device 209
Users - List User - Handset firmware update 210
Users - Import/Export 211
Administration - Wireless Server 211
Administration - License 212
Administration - Media Resource - Media Resource 0 213
Administration - Base Station - Base Station 0 214
Administration - Clusters - Cluster 0 215
Administration - Phonebook 216
Administration - Backup 217
Firmware - Wireless Server 218
Firmware - Media Resource 218
Firmware - Base Station 220
Firmware - Handset 221
14215700-IG, Edition 7.0
January 2018, Original document

14215700-IG, Edition 7.0
January 2018, Original document
9
About This Guide
This guide is intended for qualified technicians who will install, configure and maintain the Spectralink
IP-DECT Server 400/6500 Solution. To qualify to install the Spectralink IP-DECT Server 400/6500
Solution, you must have successfully completed the Spectralink IP-DECT Server 400/6500 tech-
nical training. The guide provides all the necessary information for successful installation and main-
tenance of the wireless solutions.
This includes the installation and configuration of:
lSpectralink IP-DECT Server 400/6500
lSpectralink DECTMedia Resource (only Spectralink IP-DECT Server 6500)
lSpectralink IP-DECT Base Station
lSpectralink DECT Repeater
The guide also provides you with information about:
lWeb based Administration Page of the Spectralink IP-DECT Server 400/6500, Spectralink
DECTMedia Resource, and Spectralink IP-DECT Base Station.
Important Information Before You Begin
This guide assumes the following:
lthat users have a working knowledge of the call handler’s operations
lthat the call handler is installed and initialized and is working correctly
lthat you have a working knowledge of deployment in general
lthat a site survey has been conducted and that the installer has access to these plans
Note:
The site survey should determine the number of handsets, base stations and repeaters
are needed and where to place them. The site survery should also determine how many
RF channels are needed. For more information, see Synchronization and Deployment
Guide and Site Survey Function in Handset User Guide.
Spectralink IP-DECT Server 400/6500 Installation and Configuration Guide

14215700-IG, Edition 7.0
January 2018, Original document
10
Related Documentation
All Spectralink documents are available at http://support.spectralink.com/products.
Safety and Handling information is available online at http://support.spectralink.com/products.
Regulatory information is available online at http://support.spectralink.com/products.
Subject Documentation
Spectralink DECT Handset For more information about the handset, refer to the user
guide available online at http://sup-
port.spectralink.com/products.
Site Survey Function in Handset For more information about the site survey function in
handset, refer to the guide available online at http://sup-
port.spectralink.com/products.
Synchronization and Deployment For more information about synchronization and deploy-
ment, refer to the guide available online at http://sup-
port.spectralink.com/products.
Provisioning For more information about provisioning, refer to the
guide available online at http://sup-
port.spectralink.com/products.
Spectralink Technical Bulletins Available online at http://sup-
port.spectralink.com/products.
Release Notes Document that describes software changes, bug fixes,
outstanding issues, and hardware compatibility con-
siderations for new software releases. Available online
at http://support.spectralink.com/products.
Spectralink DECT Training material In order to gain access to the Spectralink training mater-
ial, you must attend training and become Spectralink Cer-
tified Specialist.
Please visit http://-
partneraccess.spectralink.com/training/classroom-train-
ing for more information and registration.
Spectralink IP-DECT Server 400/6500 Installation and Configuration Guide

14215700-IG, Edition 7.0
January 2018, Original document
11
Terminology and Acronyms
The table below refers to common terms and acronyms that are related to the Spectralink IP-DECT
solutions.
Term Definition
Deployment The act of locating the mounting location and installing base
stations and repeaters. System performance is dependant
on the deployment made - and, therefore, the survey per-
formed.
Handover A process initiated by the handset in which the speech chan-
nel carrying an active conversation is passed from one base
station to another.
Erlang The erlang is a dimensionless unit that is used in telephony
as a measure of offered load or carried load on service-
providing elements such as telephone circuits or telephone
switching equipment.
LED Light Emitting Diode
LI-Ion Lithium-Ion
Ni-MH Nickel -Metal Hydride
Q Value Signal Quality Factor value. An expression of the bit failure
rate in the communication between the handset and a base
station. The value has a max. of 64, equal to no bit errors
measured.
LAN synchronization Method for synchronizing IP base stations over LAN
Synchronization Over the Air (OTA) Method for synchronizing IP base stations over Air (radio)
SUOTA Software Update Over The Air
RF Radio Frequency
RSSI Value Radio Signal Strength Indication value. A relative expres-
sion for the signal strength of a base station as measured
by the handset at a given location.
Site survey A site survey comprises the act of locating the best places
for base stations by measuring RSSI levels with DECT
handsets. Complete survey consists of measuring with mul-
tiple base stations, combining RSSI and Q value reading in
real surroundings.
Spectralink IP-DECT Server 400/6500 Installation and Configuration Guide

14215700-IG, Edition 7.0
January 2018, Original document
12
Term Definition
Speech channel A speech channel is used to carry communication between
the handset and the base station or repeater.
AC Authentication Code
ARI no. Access Rights Identity - Serial number of the Spectralink
IP-DECT Server.
CLI Command Line Interface
dB Decibels (deciBells)
DECT Digital Enhanced Cordless Telecommunications
DHCP Dynamic Host Configuration Protocol
DNS Domain Name System
e.i.r.p. Equivalent Isotropic Radiated Power
GAP Generic Access Profile
HW PCS Hardware Product Change Status - Hardware edition
IP Internet Protocol
IPEI International Portable Equipment Identity - Serial number
of the handset - SN
IWU Inter Working Unit
Spectralink IP-DECT Server Spectralink IP-DECT Server400/6500
LAN Local Area Network
MAC Media Access Control - hardware address of a device con-
nected to a network
MTU Maximum Translation Unit
MWI Message Waiting Indication
NIC Network Interface Card
NTP Network Time Protocol
PBX Private Branch eXchange
PCS Product Change Status (Edition)
PoE Power over Ethernet
PP Portable Parts - wireless handset
Spectralink IP-DECT Server 400/6500 Installation and Configuration Guide

14215700-IG, Edition 7.0
January 2018, Original document
13
Term Definition
RSSI Received Signal Strength Indicator
RTP Real-time Transport Protocol
SIP Session Initiated Protocol
SW PCS Software Product Change Status - Software edition
TFTP Trivial File Transfer Protocol
UDP User Datagram Protocol
VoIP Voice over Internet Protocol
WLAN Wireless Local Area Network
WRFP Wireless Radio Fixed Part - Wireless Repeater
Spectralink IP-DECT Server 400/6500 Installation and Configuration Guide

14215700-IG, Edition 7.0
January 2018, Original document
14
About DECT
DECT stands for Digital Enhanced Cordless Telecommunications.
DECT is the standard for short-range cordless communications developed by the European Tele-
communications Standards Institute (ETSI): ETSI EN 300 175-1.
DECT is used in all countries in Europe and in most of Asia, Australia, South-America and North
America.
DECT is a low power technology and can be used in radio sensitive environments. Both handsets
and base stations have an average power output of 10mW, but can deliver a burst power output of
250mW.
Note:
The entire Spectralink 7000 Portfolio is built on DECT technology.
DECT Frequency Bands
The following frequency bands are dedicated to DECT:
lEMEA, Australia & New Zealand: 1G8: 1880 – 1900 MHz
lSouth America: 1G9: 1910 – 1930 MHz
lUSA & Canada: 1G9: 1920 – 1930 MHz (DECT 6.0)
Note:
Because DECT has its own dedicated frequency band, it is not subject to interference
from other radio transmitters such as GSM phones, Bluetooth, microwave ovens and
widely used Wi-Fi equipment.
Spectralink IP-DECT Server 400/6500 Installation and Configuration Guide

14215700-IG, Edition 7.0
January 2018, Original document
15
Spectralink IP-DECT Server Solution
Types of Servers
Following types of servers are available:
lSpectralink IP-DECT Server 400
lSpectralink IP-DECT Server 6500
Note:
Besides the Spectralink IP-DECT Server solutions, a Spectralink DECT Server solution
is also available. The Spectralink DECT Server solution is out of the scope of this Install-
ation and Configuration Guide but will be mentioned in "Spectralink Server Solution Over-
view and Comparison" on page21.
Description - Spectralink IP-DECT Server 400
The Spectralink IP-DECT Server 400 is in its basic edition a single cell system (one built-in base sta-
tion in the server) supporting SIP lines only. Additional Spectralink IP-DECT Base Stations can be
added to the Spectralink IP-DECT Server 400 to expand the covered area.
Note:
A license is required to enable the multi cell function. For more information, see "Licenses
for Spectralink IP-DECT Server 400/6500" on page29.
All Spectralink IP-DECT Base Station models can be used. Up to 3 additional Spectralink IP-DECT
Base Stations can be added to the Spectralink IP-DECT Server 400 system and up to 3 additional
Spectralink DECT Repeaters can be added to each Spectralink IP-DECT Base Station.This results
in up to 12 Spectralink DECT Repeaters if all Spectralink IP-DECT Base Stations are registered.
The Spectralink IP-DECT Server 400 without any licenses supports up to 12 registered handsets
and 6 simultaneous calls.
Spectralink IP-DECT Server 400/6500 Installation and Configuration Guide

14215700-IG, Edition 7.0
January 2018, Original document
16
Below is a list of characteristics of the Spectralink DECT Server 400- Multi cell solution:
lPure IP solution for SIP with 12 full duplex on-boardspeech channels (MR12)
lMulti cell device with built-in DECT radio
lExtremely scalable – can be upgraded via purchase of licenses
lSupports up to 30 registered handsets, 12 simultaneous calls with a maximum of 3 Spectralink
IP-DECT Base Stations
lSupports entire Spectralink DECT Handset series
lSupports Spectralink DECT Repeaters and external antenna
lActs as a gateway to an IP-PBX (no switching)
l10/100Mb ethernet RJ45 connection
lPowered via PoE (802.3af) or separate PSU port
lWeb based management similar to Spectralink IP-DECT Server 6500
lDefault RFP and RPN number: 0
lDefault IP address: 192.168.0.1
lDHCP or static IP address
lCUCM and Skype for Business (SfB) support
lProvisioning – easy configuration and user administration
lSupports Handset Firmware Update Over The Air (SUOTA)
lMessaging via XML-RPC
Description - Spectralink IP-DECT Server 6500
The Spectralink IP-DECT Server 6500 controls the wireless infrastructure. It manages Spectralink
DECTMedia Resources, Spectralink IP-DECT Base Stations and the IP interface to the call hand-
ler.
The communication protocol between the Spectralink IP-DECT Server 6500 and the call handler is
a SIP line interface.
A Spectralink IP-DECT Server 6500 is installed directly on the LAN and must be managed as part of
the corporate network.
The Spectralink IP-DECT Server 6500 is a multi cell solution in a 19” cabinet. It is shipped from the
factory as an Spectralink IP-DECT Server 6500 with one Ethernet port and 32 on-board speech
channels, which allows for up to 32 full duplex simultaneous media streams (RTP streams) depend-
ing on the codec being used. There is no radio part in the Spectralink IP-DECT Server 6500. This
Spectralink IP-DECT Server 400/6500 Installation and Configuration Guide

14215700-IG, Edition 7.0
January 2018, Original document
17
means that at least one Spectralink IP-DECT Base Station must be part of the Spectralink IP-DECT
Server 6500 solution.
Note:
The Spectralink IP-DECT Server 6500 is extremely scalable and is very easy to scale in
order to meet customer demands. If it is upgraded to its full potential via licenses, it sup-
ports up to 4096 registered handsets and with a maximum of 32 Spectralink
DECTMedia Resources, it supports up to 1024 simultaneous calls.
Up to 1024 Spectralink IP-DECT Base Stations can connect with the Spectralink IP-
DECT Server 6500, but requires multicast to be enabled on the network. For more
information, see "Licenses for Spectralink IP-DECT Server 400/6500" on page29.
Below is a list of characteristics of the Spectralink IP-DECT Server 6500:
lPure IP Installation for SIP with 32 full duplex on-board speech channels (MR32)
lNo radio part in Spectralink IP-DECT Server 6500 – requires base stations
lExtremely scalable – can be upgraded via purchase of licenses
lUp to 4096 registered handsets, 1024 simultaneous calls
lUp to 1024 Spectralink IP-DECT Base Stations – requires multicast (IP address 224.0.1.129)
lUp to 3 modules per cabinet (e.g. 1 x Spectralink IP-DECT Server 6500 and 2 x Spectralink
DECTMedia Resource)
lSupports entire Spectralink DECT Handset series
lSupports Spectralink DECT Repeaters and external antenna
lActs as a gateway to an IP-PBX (no switching)
l10/100Mb ethernet RJ45 connection
lBuild-in power adaptor
lWeb based management similar to Spectralink IP-DECT Server 400
lDefault IP address: 192.168.0.1
lDHCP or static IP address
lCUCM and skype for Busines (SfB) support
lProvisioning – easy configuration and user administration
lRedundancy and load balancing (requires license)
lSupports Handset Firmware Update Over The Air (SUOTA)
lMessaging via XML-RPC
Spectralink IP-DECT Server 400/6500 Installation and Configuration Guide

14215700-IG, Edition 7.0
January 2018, Original document
18
Other Solution Component
In addition to the Spectralink IP-DECT Server, a Spectralink IP-DECT Server configuration can
include a number of the following components:
lSpectralink DECTMedia Resources (only Spectralink IP-DECT Server 6500)
lSpectralink IP-DECT Base Stations
lSpectralink DECT Repeaters
To handle the calls in the solution a call handler (IP-PBX SIP) is used.
Note:
For more information about system compatibility, see "Product Compatibility" on
page179.
For configuration overview, see "Total Configuration Overview" on page22.
Description - Spectralink DECTMedia Resource
The Spectralink DECTMedia Resource is a print board that is placed within the same rack next to
the Spectralink IP-DECT Server 6500 board. Up to 2 Spectralink DECTMedia Resources can be
placed in the same rack that houses the Spectralink IP-DECT Server 6500 board.
The Spectralink DECTMedia Resource performs media conversion between the call handler and
the Spectralink IP-DECT Server 6500 and is the media termination point for incoming and outgoing
calls. Each Spectralink IP-DECT Server 6500 contains one built in media resource. The Spectralink
IP-DECT Server 6500 can support a total of 32 Spectralink DECTMedia Resources.
Each Spectralink DECTMedia Resource adds 32 voice channels. The maximum number of sim-
ultaneous calls for a fully loaded system is 1024 calls at the same time. Depending on SRTP settings
and codec choise, the number of voice channels per Media Resource card can vary from 12 - 32.
G.726 allows for 32 duplex speech channels as this codec requires no processing and is routed dir-
ectly to the Spectralink IP-DECT Base Station. Other codecs such as G.711 or G.729 must be con-
verted to G.726 before routed further on to the Spectralink IP-DECT Base Station and this affects
the total number of available speech channels on the Spectralink DECTMedia Resource.
The Spectralink DECTMedia Resource connects directly with the LAN and must operate in con-
junction with the Spectralink IP-DECT Server 6500. If using clusters, the Spectralink DECTMedia
Resources can be placed at different locations.
Spectralink IP-DECT Server 400/6500 Installation and Configuration Guide

14215700-IG, Edition 7.0
January 2018, Original document
19
The Spectralink DECTMedia Resource contains no radio parts. It ships from the factory with default
IP address 192.168.0.1. Should it enter an unrecoverable state, it can be reset to factory default set-
tings when the reset button is pressed and held for more than 5 seconds.
Below is a list of characteristics of the Spectralink DECTMedia Resource:
lEach Spectralink DECTMedia Resource adds 32 full duplex voice channels and allows for a
total of 1024 simultaneous calls (32 channels x 32 MR on G.726)
l10/100Mb ethernet RJ45 connection
lMust operate in conjunction with the Spectralink IP-DECT Server 6500
lCan be placed at different locations to form clusters
lThere is no radio part in the Spectralink DECTMedia Resource
lDefault IP address: 192.168.0.1
lVery easy to configure
lDHCP or static IP address
lOptional codec license provides G.729 on all Spectralink DECTMedia Resources if loaded on
the Spectralink IP-DECT Server. Reduces the amount of simultaneous calls to 12 x G.729
calls per Spectralink DECTMedia Resource
Description - Spectralink IP-DECT Base Station
The Spectralink IP-DECT Base Station is to be used with both Spectralink IP-DECT Server
400/6500 and Spectralink DECT Server 2500/8000.
The Spectralink IP-DECT Base Station is designed with two internal antennas and supports
antenna diversity.
The Spectralink IP-DECT Base Station is designed with connector for External Antenna.
The Spectralink IP-DECT Base Station is also able to carry out a handover between the RF chan-
nels under the same Spectralink IP-DECT Base Station, and handles 11 DECT speech channels
simultaneously.
The Spectralink IP-DECT Base Station is able to frame synchronize with other Spectralink IP-DECT
Base Stations under the same Spectralink IP-DECT/DECT Server. Cable length is up to 100 m/330
feet on a twisted pair, cat. 5e or higher, between the Spectralink IP-DECT Base Station and Spec-
tralink IP-DECT/DECT Server.
The Spectralink IP-DECT Base Station can be powered over ethernet or separate power supply.
Spectralink IP-DECT Server 400/6500 Installation and Configuration Guide

14215700-IG, Edition 7.0
January 2018, Original document
20
The DECT radius of coverage is up to 600 meters/2000 feet with a handset in free sight.
Description - Spectralink DECT Repeater
The Spectralink DECT Repeater is a building block to be used to extend the coverage area in a wire-
less Spectralink DECT solution. The repeater does not increase the number of traffic channels, how-
ever it provides a larger physical spreading of the traffic channels and thereby increases the
coverage area established with the Spectralink IP-DECT Base Stations.
The repeaters are mainly used in areas with limited traffic. The Spectralink DECT Repeater is avail-
able with either 2 or 4 voice channels. It is wireless and does not need physical connection to the
Spectralink IP-DECT Server, making it very easy to install. The repeaters can be supplied with an
external antenna making it possible to create radio coverage in a remote area without cabling to the
rest of the installation.
The base station can support up to 3 repeaters.
System Capacity Overview
Below you will find an overview of the system capacity of the Spectralink IP-DECT Server:
System Capacity - Servers
Description IP-DECT Server 400 IP-DECT Server 6500
IP-DECT Servers 1 1
Media Resources - 32
IP-DECT Base Stations - 1024
Protocol supported SIP SIP
Max number of simultaneous SIP
calls via license
12 1024
Simultaneous calls - 11 Radio Base Stations
32 Media Resources
Codecs supported G.711a, G.711u G.711a, G.711u, G.729
