SpectraLink PIVOT 87-series Instruction Manual

721-0011-000 Rev B
June 2014
Spectralink 87-Series Wireless Telephone
Administration Guide
Configuration Management System

Spectralink 87-Series Wireless Telephones Administration Guide
721-0011-000_B.docx
June 2014 2
Copyright Notice
© 2014 Spectralink Corporation All rights reserved. SpectralinkTM, the Spectralink logo and the names
and marks associated with Spectralink’s products are trademarks and/or service marks of Spectralink
Corporation and are common law marks in the United States and various other countries. All other
trademarks are property of their respective owners. No portion hereof may be reproduced or transmitted
in any form or by any means, for any purpose other than the recipient’s personal use, without the express
written permission of Spectralink.
All rights reserved under the International and pan-American Copyright Conventions. No part of this
manual, or the software described herein, may be reproduced or transmitted in any form or by any
means, or translated into another language or format, in whole or in part, without the express written
permission of Spectralink Corporation.
Do not remove (or allow any third party to remove) any product identification, copyright or other notices.
Notice
Spectralink Corporation has prepared this document for use by Spectralink personnel and customers.
The drawings and specifications contained herein are the property of Spectralink and shall be neither
reproduced in whole or in part without the prior written approval of Spectralink, nor be implied to grant any
license to make, use, or sell equipment manufactured in accordance herewith.
Spectralink reserves the right to make changes in specifications and other information contained in this
document without prior notice, and the reader should in all cases consult Spectralink to determine
whether any such changes have been made.
NO REPRESENTATION OR OTHER AFFIRMATION OF FACT CONTAINED IN THIS DOCUMENT
INCLUDING BUT NOT LIMITED TO STATEMENTS REGARDING CAPACITY, RESPONSE-TIME
PERFORMANCE, SUITABILITY FOR USE, OR PERFORMANCE OF PRODUCTS DESCRIBED
HEREIN SHALL BE DEEMED TO BE A WARRANTY BY SPECTRALINK FOR ANY PURPOSE, OR
GIVE RISE TO ANY LIABILITY OF SPECTRALINK WHATSOEVER.
Warranty
The Product Warranty and Software License and Warranty and other support documents are available at
http://support.spectralink.com.
Contact Information
US Location European Location
800-775-5330 [phone]
Spectralink Corporation Spectralink Europe ApS
2560 55th Street Langmarksvej 34
Boulder, CO 80301 8700 Horsens, Denmark
[e-mail] [e-mail]

721-0011-000_B.docx
June 2014 3
Contents
About This Guide............................................................... 7
Product Support ............................................................................................................... 7
Spectralink References .................................................................................................... 8
Specific Documents......................................................................................................... 8
Conventions Used In This Document.............................................................................. 9
Icons ............................................................................................................................... 9
Typography....................................................................................................................10
Part I: Using CMS............................................ 12
Chapter 1: Getting Started with CMS...................................... 13
Saving your settings.......................................................................................................13
Admin Tips.....................................................................................................................13
How Secure is CMS?.......................................................................................................14
Logging into CMS............................................................................................................15
Installing the CMS License..............................................................................................15
The Home Page................................................................................................................16
Major groups..................................................................................................................16
Chapter 2: Initial Setup....................................................... 18
Certificates.......................................................................................................................18
Wireless Profiles..............................................................................................................20
Over the Air Provisioning................................................................................................21
Chapter 3: Device Management ............................................ 23
Device List........................................................................................................................23
Column headings ...........................................................................................................24
Summary column: Change device..................................................................................25
Device List: Select device to change..............................................................................26
Configure Device(s).........................................................................................................27
Enterprise/Group/Device tabs.........................................................................................28
Wireless Profiles.............................................................................................................29
SIP Service ....................................................................................................................29
LDAP..............................................................................................................................35
SAFE and Panic Button..................................................................................................38
Emergency Contacts......................................................................................................44
PTT................................................................................................................................44
Quick Barcode Connect..................................................................................................48

Spectralink 87-Series Wireless Telephones Administration Guide
721-0011-000_B.docx
June 2014 4
Web API.........................................................................................................................48
Web Applications............................................................................................................51
General Settings.............................................................................................................52
Over the Air Updates......................................................................................................52
Device Security ..............................................................................................................54
Syslog............................................................................................................................55
Config Manager..............................................................................................................57
Phone Groups..................................................................................................................58
Configure Feature Licenses............................................................................................58
Add or change installed licenses....................................................................................59
Add feature license.........................................................................................................60
Select handsets to activate the feature...........................................................................60
Batch Configure Extensions...........................................................................................61
Reset Device Password(s) ..............................................................................................62
Quick RMA Replacement.................................................................................................63
Part II Administrative Procedures....................... 65
Chapter 4: CMS Administrative............................................. 66
CMS Users........................................................................................................................66
Authenticating CMS users with LDAP.............................................................................66
Personal info..................................................................................................................69
Permissions....................................................................................................................69
Delete a User.................................................................................................................69
Server Settings ................................................................................................................70
Active Directory Settings ................................................................................................70
General Settings.............................................................................................................71
Self Signed Public Key...................................................................................................72
Update this software (CMS software).............................................................................73
License for this software.................................................................................................73
Import / Export CMS data...............................................................................................74
CMS/Handset Interaction.................................................................................................74
Active handsets..............................................................................................................75
Inactive handsets ...........................................................................................................75
Chapter 5: Updating the Handset Software .............................. 77
Updating the Handsets....................................................................................................77
Updating the software on the handset............................................................................78
Verifying the update .......................................................................................................79

Spectralink 87-Series Wireless Telephones Administration Guide
721-0011-000_B.docx
June 2014 5
Chapter 6: How to Use Logs as Generated by Your 87-Series
Handset.......................................................................... 80
Syslog Server Compatibility............................................................................................80
Severity Levels.................................................................................................................81
What Severity Level to Use ............................................................................................81
Syslog Message Structure..............................................................................................82
CMS format....................................................................................................................82
As stored internally in the handset..................................................................................82
Syslog format .................................................................................................................82
Definitions ......................................................................................................................83
Viewing Logs in the CMS ................................................................................................84
Retrieving Syslog Messages from the Handset via USB ..............................................85
Setting up Your Syslog Filters in CMS...........................................................................85
Using a Filter to Refine Logging Results .......................................................................86
Logging Examples and Tips ...........................................................................................86
Wireless related tags......................................................................................................87
SIP related tags..............................................................................................................87
Audio related tags ..........................................................................................................88
Over-the-air downloader related tags .............................................................................88
Battery and Charging related tags..................................................................................89
Barcode related tags......................................................................................................90
CMS related tags............................................................................................................91
QBC related tags............................................................................................................91
Web API related tags......................................................................................................92
Licensing related tags.....................................................................................................92
Part III Supporting Your Users............................ 93
Chapter 7: Syncing to Email, Calendar and Contacts ................. 94
Chapter 8: User Access...................................................... 95
USB Access......................................................................................................................95
Web Access......................................................................................................................95
Chapter 9: Applications...................................................... 96
Text to Speech.................................................................................................................96
Chapter 10: Chargers and Battery Packs................................. 97
How usage affects Battery Pack life ...............................................................................97
About Battery Packs.......................................................................................................98

Spectralink 87-Series Wireless Telephones Administration Guide
721-0011-000_B.docx
June 2014 6
Battery Safety Notices....................................................................................................99
Notes on Battery Packs..................................................................................................99
Appendix A: Open Source Information ................................. 101
OFFER for Source for GPL and LGPL Software ..........................................................101
Contact Information for Requesting Source Code.........................................................101
Appendix B: Products Mentioned in this Document ................ 102

721-0011-000_B.docx
June 2014 7
About This Guide
This document covers every aspect of administering the Spectralink 87-Series handsets, also
known as PIVOT™by Spectralink. The primary tool for administering the handsets is the CMS,
the Configuration Management System. This GUI program is opened in a browser and provides
an easy and intuitive way to configure the handsets and manage the deployment.
This guide covers the administration of the handsets using the CMS as well as information
about managing the CMS. Initial installation of the CMS and handset deployment is covered in
the Spectralink 87-Series Wireless Telephone Deployment Guide.
This Guide is divided into three Parts:
Part I describes how to use CMS
○Logging in, installing the license, orientation
○Initial setup for Certificates, Wireless Profiles and Over the air (OTA) provisioning
○Device management –configuring and supporting the handsets
Part II covers administrative procedures
○Administration of the CMS Users and server settings
○Updating handset code
○Using logs for troubleshooting and understanding handset processes
Part III covers user support functions
○Syncing to Outlook
○USB access to the handsets by the user
○Web access
○Applications
○Battery Packs and chargers
Product Support
Spectralink wants you to have a successful installation. If you have questions please contact the
Customer Support Hotline at 1-800-775-5330.
The hotline is open Monday through Friday, 6 a.m. to 6 p.m. Mountain time.
For Technical Support: mailto:[e-mail]
For Knowledge Base: http://support.spectralink.com
For Return Material Authorization: mailto:[e-mail]

Spectralink 87-Series Wireless Telephones Administration Guide
721-0011-000_B.docx
June 2014 8
Spectralink References
All Spectralink documents are available at http://support.spectralink.com.
To go to a specific product page:
Select the Product Category and Product Type from the dropdown lists and then select the
product from the next page. All resources for that particular product are displayed by default
under the All tab. Documents, downloads and other resources are sorted by the date they were
created so the most recently created resource is at the top of the list. You can further sort the
list by the tabs across the top of the list to find exactly what you are looking for. Click the title to
open the link. PIVOT documents are available at http://support.spectralink.com/pivot.
Specific Documents
AP Configuration Guides show you how to correctly configure access points and WLAN
controllers (if applicable) and identify the optimal settings that support Spectralink 87-Series
handsets. The guides can be found at the View Certified page.
Spectralink 87-Series Installation and Configuration Tool Administration Guide The SLIC tool
provides step-by-step instructions for configuring wireless settings required for the handsets to
associate with the wireless LAN.
Spectralink 87-Series Wireless Telephone Deployment Guide The Deployment Guide provides
sequential information for provisioning and deploying the handsets. It covers deployment using
the SLIC tool and CMS as well as manual deployment.

Spectralink 87-Series Wireless Telephones Administration Guide
721-0011-000_B.docx
June 2014 9
Spectralink 87-Series Wi-Fi Security Implementation Guide Wi-Fi security prevents
unauthorized over-the-air access to network components and the sensitive data that resides
there. This Guide discusses the various method and explains how to implement each of them.
Spectralink 87-Series Wireless Telephone Application Installation Guide The Applications Guide
provides detailed information about deploying any type of application, using an app store or
MDM and manual processes for loading applications on the Spectralink 87-Series handset.
Spectralink 87-Series Wireless Telephone User Guide The User Guide provides detailed
information about using the features of the 87-Series handsets.
For information on IP PBX and softswitch vendors, see PIVOT by Spectralink Call Server
Interoperability Guide.
Conventions Used In This Document
Icons
Icons indicate extra information about nearby text.
Warning
The Warning icon highlights an action you must perform (or avoid) to avoid
exposing yourself or others to hazardous conditions.
Caution
The Caution icon highlights information you need to know to avoid a hazard that
could potentially impact device performance, application functionality, successful
feature configuration and/or affect handset or network performance.
Spectralink recommends:
A recommendation from the experts at Spectralink.
Note
The Note icon highlights information of interest or important information that will
help you be successful in accomplishing a procedure or understanding a concept.
CMS hint
When you see the hint icon, you will also find a footnote on the same page that
gives you additional information or a recommendation.

Spectralink 87-Series Wireless Telephones Administration Guide
721-0011-000_B.docx
June 2014 10
Tip
The Tip icon highlights information that may be valuable or helpful for users to
know, such as special techniques, shortcut methods, or information that will make
user tasks easier to perform.
Web
The Web Info icon highlights supplementary information available online such as
documents or downloads on support.spectralink.com or other locations.
Timesaver
A time-saving tip is typically used to mention or highlight a faster or alternative
method for users who may already be familiar with the operation or method being
discussed.
Admin Tip
This tip advises the administrator of a smarter, more productive or alternative
method of performing an administrator-level task or procedure.
Power User
A Power User Tip is typically reserved for information directed specifically at high-
level users who are familiar with the information or procedure being discussed and
are looking for better or more efficient ways of performing the task. For example,
this might highlight customization of a feature for a specific purpose.
Troubleshooting
This element can be used in any type of document and is typically used to highlight
information to help you solve a relevant problem you may encounter, or to point to
other relevant troubleshooting reference information.
Settings
The Settings icon highlights information to help you zero in on settings you need to
choose for a specific behavior, to enable a specific feature, or access customization
options.
Typography
A few typographic conventions, listed next, are used in this guide to distinguish types of in-text
information.

Spectralink 87-Series Wireless Telephones Administration Guide
721-0011-000_B.docx
June 2014 11
Convention
Description
Bold
Highlights interface items such as menus, soft keys, file names, and
directories. Also used to represent menu selections and text entry to the
handset.
Italics
Used to emphasize text, to show example values or inputs, and to show
titles of reference documents available from the Spectralink Support Web
site and other reference sites.
Underlined blue
Used for URL links to external Web pages or documents. If you click on
text in this style, you will be linked to an external document or Web page.
Bright orange text
Used for cross references to other sections within this document. If you
click on text in this style, you will be taken to another part of this
document.
Fixed-width-font
Used for code fragments and parameter names.
This guide also uses a few writing conventions to distinguish conditional information.
Convention
Description
<MACaddress>
Indicates that you must enter information specific to your installation,
handset, or network. For example, when you see <MACaddress>, enter
your handset’s 12-digit MAC address. If you see <installed-directory>,
enter the path to your installation directory.
>
Indicates that you need to select an item from a menu. For example,
Settings> Basic indicates that you need to select Basic from the
Settings menu.

721-0011-000_B.docx
June 2014 12
Part I: Using CMS
CMS is a powerful interface for configuring and managing Spectralink 87-Series handsets. Part I
details each page of the CMS and each setting on each page.
Installing the CMS is fully covered in the Spectralink 87-Series Wireless Telephone Deployment
Guide. Please refer to that document if you are just getting started.
Settings: Is CMS necessary?
The question will arise if CMS is strictly necessary for configuring and managing
the handsets. The short answer is “No, not if you are deploying only a few phones.”
The handsets Settings app includes an Admin menu behind a password. This
menu can be used to manually set parameters and view handset usage data. This
document covers nearly all the settings you will find in the Admin menu. For
specific information about configuring the handsets manually see Spectralink
87-Series Wireless Telephone Deployment Guide.
The longer answer is “Yes; if you are deploying many handsets, have complex
settings such as security certificates, phone groups, etc., or if the handsets cannot
be easily retrieved for user support functions.” The CMS is a boon to Wi-Fi and IT
administrators as it can keep track of and manage any number of handsets
remotely.
Settings: Not using CMS?
If you are not deploying a CMS, please refer to Spectralink 87-Series Wireless
Telephone Deployment Guide Appendix B: Manual Configuration for the sequence
of steps to take when manually configuring the handsets.
Use this document for more complete information about the settings you have to
configure whether you are using CMS or doing it manually.

721-0011-000_B.docx
June 2014 13
Chapter 1: Getting Started with CMS
Instructions for installing CMS are in Spectralink 87-Series Wireless Telephone Deployment
Guide. Please refer to that document if you are just getting started. This Chapter assumes that
you have successfully installed CMS and are ready to use it for handset provisioning.
CMS navigation follows web browser standards. This document assumes that you are familiar
with browsers and web pages and can find your way around with relative ease. We show the
navigation path for the sequence of clicks that will get you to a page that may be deeper in the
GUI. E.g. navigate to Home> CMS Administrative> Server Settings> Self Signed Public
Key. Clickable text is blue.
Saving your settings
○Save and add another allows you to save the setting you just entered and stay on
this page to add another setting.
○Save and continue editing allows you to save the setting you just entered and edit
any of the fields for this setting.
○Save will save this setting and take you back to the previous page.
Admin Tips
What user settings are saved by the CMS?
When changes are made in the Settings app on the handset, those changes are
immediately sent to the CMS. User settings such as ring tone, volumes, etc. are not
configured by the CMS but are stored by the CMS and seamlessly pushed back to
the handset when it reboots. The CMS allows both user and admin settings to be
downloaded to a different handset through the Quick RMA replacement option.
When does the handset get new settings?
New/changed settings are available to the handsets when the Save/Send Config
button is clicked. The handset will retrieve the new settings when it checks in at the
next heartbeat. If the handset is inactive when the Save/Send button is clicked, the
next time the handset checks in it will retrieve any new or changed options at its
first heartbeat.

Spectralink 87-Series Wireless Telephones Administration Guide
721-0011-000_B.docx
June 2014 14
What does the dashed line indicate?
You will see some settings that use a dashed line in the text field, such as
Enable / Disable Spectralink SIP. When you see this, it indicates that whatever the
current setting is should be retained or “use whatever is currently configured in the
handset” or in the group or enterprise level setting.
Default values are not displayed
A blank field in the CMS means that the default value in the handset is retained.
CMS does NOT display “default values”. Leaving settings as blank in the CMS
allows the handset to retain the default value, it does not “blank out” the defaults.
Admin Tip: How to capture a screen
Screen captures can be valuable training and debugging tools. Press the power
button and volume down buttons simultaneously to capture the current screen. You
will see the screen being captured. It will appear in the notification drawer where
you can share it. You can also browse to the handset via USB (Computer> [Model
#]> Internal storage> Pictures> Screenshots) and download/copy the capture.
How Secure is CMS?
CMS transfers configuration information to the handsets over the air which could expose the
data to unauthorized parties. CMS uses both HTTP and HTTPS protocols. If your facility uses
the HTTPS protocol, you can take advantage of the mutual authentication feature built into
CMS.
Mutual authentication is implemented by generating a public key on the CMS and loading it into
the handset using SLIC. This is the “server key” that ensures the handset recognizes the CMS
as genuine. The handset contains a device certificate that is loaded during manufacturing. The
CMS can recognize this key and therefore knows that the handset is genuine. Once this
authentication handshake is complete, the handset and the CMS exchange information over a
secure connection. For a comprehensive explanation of Wi-Fi security see Spectralink
87-Series Wi-Fi Security Implementation Guide.
HTTPS is set on the handset by setting the https://[IP address] for CMS and using SLIC to
install the CMS key. See Spectralink 87-Series Installation and Configuration Tool
Administration Guide. Encryption for CMS is set at Home> CMS Administrative> Server
Settings> General settings. These three settings are required when using HTTPS to establish
the secure tunnel.
This secure connection is not possible using HTTP.

Spectralink 87-Series Wireless Telephones Administration Guide
721-0011-000_B.docx
June 2014 15
Logging into CMS
1 Enter the IP address in your browser. Use Chrome® for best results. Microsoft® Internet
Explorer™is not compatible and must not be used.
2 Enter the username and password.
Default is admin/admin.
Installing the CMS License
You will need to install a license when you first set up CMS. Licenses are obtained from
Spectralink, sometimes through a distributor or VAR. Contact Spectralink support if you need
help obtaining a license.
Installing the license
1 The customer receives the APK (Authorization Product Key) and CMS serial number via
an email which also includes a URL.
2 Click the URL to generate the license key and register with Spectralink. Copy the license
key.
3 Open CMS and navigate to Home> CMS Administrative> Server Settings> License
for this software. Enter the serial number and paste the license key into the appropriate
fields. Click Update license.
4 CMS is now operational.

Spectralink 87-Series Wireless Telephones Administration Guide
721-0011-000_B.docx
June 2014 16
The Home Page
Major groups
Initial Setup allows you to load certificates, configure Wireless Profiles and set up over the air
(OTA) provisioning for the handsets.
Device Management allows you to view and configure devices, set up phone groups, reset
device passwords, and move a configuration to a different device when a user’s handset must
be replaced.

Spectralink 87-Series Wireless Telephones Administration Guide
721-0011-000_B.docx
June 2014 17
Tip: What is a “device”?
“Device” is the term used by Android to refer to the hardware using the Android
platform. In this document, we use the word “device” interchangeably with
“handset”.
CMS Administrative is where you set up CMS users and manage the CMS software and other
settings for the CMS server itself.

721-0011-000_B.docx
June 2014 18
Chapter 2: Initial Setup
Certificates
Certificates are used by several different types of programs. Load and manage them on the
Certificates page. Certificates are loaded on the Wireless Profiles pages when you configure a
type of Wi-Fi security that requires a certificate.
Caution: Certificate validity
The validity of the certificate is not verified by the handset, SLIC or CMS. Ensure
you have a valid certificate before adding it to this list and trying to use it for
authentication.
Three types of certificates are identified: CA, PAC and Other. Refer to Spectralink 87-Series
Wireless Security Implementation Guide for more information on certificates and their use in Wi-
Fi security methods. Other or non-Wi-Fi certificates are available in Device Security or Home>
Device Management> Configure Device(s)> Device Security> Non-wifi Certificates.

Spectralink 87-Series Wireless Telephones Administration Guide
721-0011-000_B.docx
June 2014 19
Deleting a certificate
1 Check the certificate you wish to delete.
2 Click the Action dropdown and select Delete this certificate.
3 Go through the confirmation page to finish deleting the selected certificate(s).
Adding a certificate
1 Ensure the certificate is located where you can browse to it from the computer running
your browser.
2 Click the Add certificate button.
3 Complete the fields and browse to the certificate that you want to add to the certificate
list.
4 Click one of the Save buttons at the bottom of the screen.

Spectralink 87-Series Wireless Telephones Administration Guide
721-0011-000_B.docx
June 2014 20
Wireless Profiles
A handset may be required to associate to several SSIDs. Only one SSID is configured during
initial deployment with SLIC. Use this page to configure additional SSIDs. Wireless profiles are
added to the handset in Device Management> Configure Devices. Any SSIDs entered here
will appear on the Wireless Profiles list on that page.
Admin Tip: Roaming between SSIDs?
The handset is not designed to roam between different networks. A different SSID
usually means that the handset will need a new IP address with different network
conditions.
The handset must be rebooted to change SSIDs. Do not expect continuous
connectivity.
Installing multiple wireless profiles allows the handset to associate to a new SSID
when it is turned on at a new site.
Wireless profiles ask for the security type used by the SSID. For a full discussion of the various
security methods and how they are implemented on this page, see Spectralink 87-Series
Wireless Security Implementation Guide.
Admin Tip: SSID proxy settings
You may need to configure proxy settings to allow a handset to access the internet.
Proxy settings are configured on the handset Admin menu, not through CMS. On
the handset go to Settings> Admin settings> [Enter Password]> Wi-Fi and tap
the SSID where proxy settings are required. Tap the Modify network option. Scroll
down and tap Show advanced options. Scroll down and tap Proxy settings. Tap
Manual and enter the hostname and port.
If you are setting up a new SSID, tap Advanced options per the above.
