SpectraLink NetLink 8020 User manual

Copyright © 2006, 2007 SpectraLink Corporation. All rights reserved.
PN: 72-9965-00-G.doc Page 1
Aruba Mobility Controller
Configuration and Deployment Guide
SpectraLink’s Voice Interoperability for Enterprise Wireless (VIEW) Certification
Program is designed to ensure interoperability and high performance between NetLink
Wireless Telephones and WLAN infrastructure products. The products listed below
have been thoroughly tested in SpectraLink’s lab and have passed VIEW Certification.
This document details how to configure the Aruba mobility controller with NetLink
Wireless Telephones.
Certified Product Summary
Manufacturer: Aruba Networks http://www.arubanetworks.com
Approved products: Wireless Controllers Access Points
A200
A800
A2400
A6000†
AP41
AP60
AP61
AP65
AP70†
RF technology: 802.11b/g/a
Radio: 2.4 GHz (802.11 b/g), 5 GHz (802.11a)
Security: WPA2-PSK
AP firmware version tested: 2.5.4.0
Handset models tested: e340/h340/i640 8000 Series
Handset software tested: 89.134 122.010 or greater
Radio mode: 802.11b 802.11b 802.11g 802.11a
Maximum telephone calls tested per AP: 12 12*
Network topology: Switched Ethernet (recommended)
†Denotes products directly used in Certification Testing.
* Maximum calls tested during VIEW Certification and the recommended setting in the SVP Server. The
certified product may actually support a higher number of calls for 802.11a and 802.11g radio modes.
Service Information
If you encounter difficulties or have questions regarding the configuration process,
please contact Aruba Networks technical support at 1-800-943-4526, visit
www.arubanetworks.com/support or e-mail [email protected].

PN: 72-9965-00-G.doc Page 2
Network Topology
The following topology was tested during VIEW Certification testing.
Deployment Description
It is a SpectraLink requirement that voice users be placed on a separate VLAN (e.g.,
VLAN 10) and data users on a separate VLAN (e.g., VLAN 25). The voice and data
VLANs reside on the Aruba mobility controller and not on the access points (APs). The
user traffic is tunneled back to the Aruba controller for processing. The edge network
thus does not have to be modified to accommodate the WiFi clients and the VoWiFi
network. Map each VLAN to a unique subnet. The mobility controller (switch) IP
address needs to be set via the loopback interface setting. The Controller’s loopback
address must be a routable address so that the APs can reach this address.
Interface setting
Identify the mobility controller port that serves as the uplink port for the data VLAN.
The physical port used in this example is Fast Ethernet 1/0. This port is configured as a
trunk port with both the voice and data VLAN.
Default route
The L3 switch connected to the Aruba controller serves as the default gateway for all the
WiFi clients. Configure the default route to the next-hop gateway connected to the
mobility controller.
Physical interface
All interfaces that connect to the core networks, routers, servers and gateways need to be
set as trusted ports.

PN: 72-9965-00-G.doc Page 3
Connecting the APs
The APs need an IP address for communication with the mobility controller. The APs
can connect to the controller over a L2 or L3 network. Ensure that DHCP is enabled on
the subnets the APs are connected to and the APs can ping the Aruba mobility
controller’s “switch IP address” from their current subnet.
Known Limitations
No limitations were discovered during VIEW Certification testing.
VIEW Certification testing verifies that the wireless telephone and the AP interoperate
at the packet level; therefore, no add-on vendor features were tested in the scope of
VIEW.
Connecting to the Mobility Controller
Command, comment, and screen text key
In the sections below you will find commands, comments, prompts, system responses,
or other screen-displayed information involved in the configuration process. This key
explains the text styles and symbols used to denote them.
Text Style Denotes:
xxxxxxxx Typed command
<xxxxxxxx>Encryption key, domain name or other information specific to
your system that needs to be entered
(xxxxxxxx) Comment about a command or set of commands
xxxxxxxx Prompt, system response or other displayed information
Via console
1. Using a standard RS-232 cable, connect the Aruba mobility controller to the serial
port of a terminal or PC.
2. Run a terminal emulation program (such as HyperTerminal™) or use a VT-100
terminal with the following configuration:
Bits per second: 9600
Data bits: 8
Parity: None
Stop bits: 1
Flow control: None
3. Press Enter to display the Aruba mobility controller login screen.
4. Enter the default login: admin and the default password: admin. These are case
sensitive.
5. Enter enable and the default password: admin to get into the command mode.

PN: 72-9965-00-G.doc Page 4
Via the CLI
By default, only SSH (Secure Shell) access to the switch (mobility controller) is
permitted.
1. From a management system that has network connectivity to the switch, connect to
the switch using SSH:
ssh admin@<switch IP address>
2. Enter the admin password at the password prompt.
3. Type enable at the >prompt to enter the enable mode.
4. Type the enable password when prompted for a password.
Via the Web interface
Once the connectivity to the switch is verified, open a Web browser and enter the
switch’s IP address in the navigator bar.
The switch can be accessed using http, http://<switch IP Address>
or https, https://<switch IP Address>:4343.
The user is prompted with the username and password configured (in the example
above, the username/password configured is admin/admin). On successful login the
following Network Summary screen is displayed:

PN: 72-9965-00-G.doc Page 5
Initial Setup
Before starting, please ensure that the Policy Enforcement Firewall module license is
enabled on the Aruba mobility controller. Please contact Aruba Networks for licenses
and installation information.
On power-up, the user is presented with the startup wizard:
Enter System name [Aruba800]: Aruba
Enter VLAN 1 interface IP address [172.16.0.254]:
Enter VLAN 1 interface subnet mask [255.255.255.0]:
Enter IP Default gateway [none]:
Enter Switch Role, (master|local) [master]: master
Enter Country code (ISO-3166), <ctrl-I> for supported list: US
You have chosen Country code US for United States (yes|no)?: yes
Enter Password for admin login (up to 32 chars): admin
Re-type Password for admin login: admin
Enter Password for enable mode (up to 15 chars): enable
Re-type Password for enable mode: enable
Do you wish to shutdown all the ports (yes|no)? [no]: no
Current choices are:
System name: Aruba
VLAN 1 interface IP address: 172.16.0.254
VLAN 1 interface subnet mask: 255.255.255.0
IP Default gateway: none
Switch Role: master
Country code: US
Ports shutdown: no
If you accept the changes the switch will restart!
Type <ctrl-P> to go back and change answer for any question
Do you wish to accept the changes (yes|no)yes
. . . . .
<<<<< Welcome to Aruba Wireless Networks - Aruba 800 >>>>>
. . . .
(Aruba)
User:

PN: 72-9965-00-G.doc Page 6
Assigning an IP to the Mobility Controller
1. Connect to the switch via the CLI.
2. Login with the configured username and password, admin/admin in this example.
3. Type enable at the >prompt.
4. Type the enable password, enable in this example.
5. Type configure terminal at the #prompt.
6. Create the VLAN for the voice (vlan 25) using the VLAN command:
(Aruba) (config) #vlan 25
7. Create the VLAN interface.
(Aruba) (config) #interface vlan 25
8. Assign the IP address to the interface.
(Aruba) (config-subif)#ip address 10.168.10.2 255.255.255.0
9. Create the loopback interface and assign an IP address to the loopback. For more
information about the loopback interface refer to the user guide.
(Aruba) (config) #interface loopback
(Aruba) (config-loop)#ip address 10.168.10.1
Switch IP Address is Modified. Switch should be rebooted now
(Aruba) (config-loop)#!
(Aruba) (config) #ip default-gateway 10.168.10.10
10. Assign a physical interface to the VLAN. In this example, the interface connecting to
the network is a trunk interface. Configure the mode on the interface to a trunk
mode.
(Aruba) (config) #interface fastethernet 1/0
(Aruba) (config-if)#trusted
(Aruba) (config-if)#no shutdown
(Aruba) (config-if)#switchport mode trunk
(Aruba) (config-if)#switchport trunk allowed vlan add 10,25
(Aruba) (config-if)#!
(Aruba) (config)#
11. Ping the default gateway from the switch’s console.
12. Ping the switch’s IP address from the management station.
Connecting APs
Provisioning APs
The APs need to be provisioned. The Aruba APs can be provisioned manually or be
configured for automatic provisioning. For manual provisioning, use the Web-based AP
provisioning Web page. Refer to the AP Provisioning User Guide for instructions on
provisioning the AP.
The APs can communicate with the controller over a L2 or L3 network. The only
requirement is that each AP be assigned an IP address and default gateway using DHCP.

PN: 72-9965-00-G.doc Page 7
SSID Configuration
CLI command configuration
APs can be configured using the CLI or the Web interface. Each AP is identified by a
unique location code. The APs can either be configured per location with unique settings
using the AP’s unique location code or globally using the wildcard location. “0” is used
as the wildcard.
Example: ap location 0.0.0 will configure all Aruba APs on the WLAN system.
Both the Aruba APs and the Spectralink handsets support the 802.11a and the
802.11b/g radios. To apply the SSID to both bands configure the SSID as follows:
configure terminal
ap location x.y.z
virtual-ap aruba vlan-id 26 opmode wpa2-aes-psk
wpa-passphrase thisisthekey dtim-period 3
If the voice network needs to exist only in the 802.11a band , configure the virtual AP
under the 802.11a settings on the controller.
configure terminal
ap location x.y.z
phy-type a virtual-ap aruba vlan-id 26 opmode wpa2-aes-psk
wpa-passphrase thisisthekey dtim-period 3
If the voice network needs to exist only in the 802.11g band, configure the virtual AP
under the 802.11g settings on the controller.
configure terminal
ap location x.y.z
phy-type g virtual-ap aruba vlan-id 26 opmode wpa2-aes-psk
wpa-passphrase thisisthekey dtim-period 3
To save changes, enter:
write mem
Web-based configuration
1. Click the Configuration button.
2. In the navigation pane, select Network from the WLAN sub-menu.
a. To edit an existing AP profile, click the Edit button corresponding to the SSID.
b. To add a new profile, click the Add button.
3. Under Add SSID, enter aruba in the SSID field.
4. Select 802.11a/b/g from the Radio Type drop-down list to apply the SSID settings
to the a/b/g radio.
5. For the SSID Default VLAN, enter the voice VLAN number.

PN: 72-9965-00-G.doc Page 8
6. For the DTIM Period, enter 3.
7. Select the AES-CCM option for WPA2-AES-PSK encryption.
8. Under WPA2, select the PSK AES-CCM option.
9. Select PSK Passphrase (alphanumeric) from the Format drop-down list before
typing in the passphrase.
10. Enter the PSK AES Key/Passphrase.
11. Click the Apply button.
Navigating to other pages without saving/applying the changes will result in
the loss of the changes.
Access Point Configuration
Radio setting 802.11b or 802.11g
When using the 802.11b/g band for the VoWiFi network, set the radio settings to
802.11b/g mixed mode.
Preamble settings
The tests on the Aruba system were run with the short preamble setting.
The short preamble setting can be used, as this supports both short and long
preambles. NetLink Wireless Telephones only support long preamble when
using the 802.11b radio.
When using a dual-radio AP, use the 802.11a radio for data and 802.11b/g for
voice if possible, as this will improve the overall performance.

PN: 72-9965-00-G.doc Page 9
Channel and Tx power
Channel and Tx power level can be manually set or configured to be assigned
automatically depending on the RF environment. Please consult your facility’s RF site
survey designed for voice to determine the correct channel, power and data rate settings.
NetLink Wireless Telephones require the following minimum dBm reading to support
the corresponding “Required” data rate setting in the access point.
802.11
Radio Standard
Minimum Available
Signal Strength (RSSI)
Maximum
"Required" Data Rate
-70 dBm 1 Mb/s
802.11b
-60 dBm 11 Mb/s
-63 dBm 6 Mb/s
802.11g -47 dBm 54 Mb/s
-60 dBm 6 Mb/s
802.11a -45 dBm 54 Mb/s
For additional details on RF deployment please see the
Deploying NetLink
Wireless Telephones: Best Practices document at:
http://www.spectralink.com/resources/white_papers.jsp.
Recommended AP configuration settings
CLI Commands Required Settings Default
Settings
Description
Max-clients <x> 40 0 Max clients that can associate
with the AP.
Beacon-interval <x> Set to default 100
milliseconds
The interval at which beacons are
sent out .
dtim-period <x> 3 1 Delivery Traffic Indication
Message interval in terms of
beacon interval.
hide-essid <enable /
disable>
Enable Disable To disable the ESSID from being
broadcasted.
Max-retries 2 4 Maximum number of times the
AP tries to send a packet to the
client before discarding the
packet.
b/g-mode Mixed Mixed The radio mode of the b/g radio.
Tx-power <0-4> 0 As per the environment. This
need not be set if ARM is
enabled.
Channel <x> 1 This is the channel assigned to
the radio. Need not be set if ARM
is enabled.

PN: 72-9965-00-G.doc Page 10
CLI Commands Required Settings Default
Settings
Description
802.11b/g rates These rates should be
determined from RF site survey.
Verify you have sufficient
coverage to support data rates.
5,11
802.11b/g Tx rates These rates should be
determined from RF site survey.
Verify you have sufficient
coverage to support data rates.
1,2,5,11 The supported Tx rates for
802.11b/g.
802.11b/g rates (if
all wireless client are
802.11g)
These rates should be
determined from RF site survey.
Verify you have sufficient
coverage to support data rates.
5,11
802.11b/g Tx rates
(if all wireless client
are 802.11g)
These rates should be
determined from RF site survey.
Verify you have sufficient
coverage to support data rates.
1,2,5,11
802.11a rates These rates should be
determined from RF site survey.
Verify you have sufficient
coverage to support data rates.
6,9,12,24
802.11a Tx rates These rates should be
determined from RF site survey.
Verify you have sufficient
coverage to support data rates.
6,9,12,18,24,
36,48,54
The supported Tx rates for
802.11a.
ESSID <voice ssid as configured> Aruba This is the ESSID that the voice
devices would associate with.
Short preamble Tested: Enable
Recommended: Disable
Enable Set the short preamble to
disable, to enable long-
preamble-only support.
CLI command configuration
All of the commands listed in the CLI Commands column above must be entered under
the ap location command.
The format is:
ap location x.y.z
phy-type g (To make the changes for the “g” radio.)
commands
!
phy-type a (To make the changes for the “a” radio.)
commands
!

PN: 72-9965-00-G.doc Page 11
Web-based configuration
1. Click the Configuration button.
2. In the navigation pane, select Radio from the WLAN sub-menu.
3. Click the 802.11b/g tab.
4. For Max Retries, enter 2 for voice.
5. Select the Short Preamble check box.
6. For the DTIM period, enter 3.
7. For Basic Rates and Supported Rates, consult the facility’s RF site survey to
determine if coverage is sufficient to support all data rates.
8. To assign the power and channel setting manually:
a. For ARM Assignment, select Disabled.
b. Clear the ARM Scanning check box.
c. Set the Default Channel and Initial Transmit Power from their drop-down lists.
9. For Mode, click the Access-point option.
10. Click the Apply button.

PN: 72-9965-00-G.doc Page 12
11. Click the 802.11 a tab.
12. For Max Retries, enter 2 for voice.
13. For the DTIM period, enter 3.
14. For Basic Rates and Supported Rates, consult the facilities RF site survey to
determine if coverage is sufficient to support all data rates.
15. To assign the power and channel setting manually:
a. For ARM Assignment, select Disabled.
b. Clear the ARM Scanning check box.
c. Set the Default Channel and Initial Transmit Power from their drop-down lists.
16. For Mode, click the Access-point option.
17. Click the Apply button.

PN: 72-9965-00-G.doc Page 13
Dynamic RF Management - ARM Aware Scanning
If Adaptive Radio Resource Management (ARM) Aware Scanning (RF scanning) is
included in your firmware release, it can be enabled through the command line interface
as follows:
configure terminal
ap location x.y.z
phy-type g
arm scanning enable
arm assignment single-band
arm voip-aware-scan enable
phy-type a
arm scanning enable
arm assignment single-band
arm voip-aware-scan enable
write mem
This feature was enabled during VIEW Certification testing in a screen room
(strong signals in a clean environment). A real-world test with interfering RF
signals was not simulated.
Security Policies and QoS
Once the basic infrastructure is configured, it is necessary to configure the security
policies to ensure that the data network and the voice network are secured and access to
these networks is limited as required.
The steps are as follows:
1. Setup aliases for the SVP Server.
2. Set policies for the wireless telephone user to the required voice server, DHCP and
TFTP servers. Add other ACLs as required to permit other traffic from the wireless
telephones.
3. Assign policies to the role.

PN: 72-9965-00-G.doc Page 14
Create an alias for the SVP Server
1. Click the Configuration tab.
2. In the navigation pane, select Advanced from the Security sub-menu.
3. Click the Destinations tab.
4. To add a new destination, click the Add button.
5. Create a new net-destination at Destination Name (e.g. svp_server), and add the SVP
servers as hosts.
For more details on configuring the net-destinations, refer to the user guide.
Create policies for the wireless telephone user
The policies shown in the above example can be configured using the Web interface as
follows:

PN: 72-9965-00-G.doc Page 15
Assign policies to the role
Create a role, for example phones, and assign the policies to this role. This is the role
that would be assigned to the handsets when they are authenticated successfully.
The Security Policies and QoS can also be configured through the command line
interface (CLI). The CLI commands corresponding to this section are as follows:
configure terminal
netdestination tftp-server
host 10.168.0.20
!
netdestination svp_server
host 10.168.0.11
host 10.168.0.12
!
netdestination dhcp-server
host 10.168.0.21
!
ip access-list session phone_acl
user user any deny
user alias svp_server svc-svp permit queue high
alias svp_server user svc-svp permit queue high
user alias tftp-server svc-tftp permit
user alias dhcp-server svc-dhcp permit
user host 224.0.1.116 any permit

PN: 72-9965-00-G.doc Page 16
!
user-role phones
session-acl phone_acl
!
Authentication
In addition to the encryption, Aruba recommends the use of MAC authentication to
authenticate the Spectralink handsets. On the Aruba System, the roles for NetLink
Wireless Telephones are derived using MAC-authentication. The wireless telephones can
be authenticated individually using MAC-authentication or as a group using the vendor
OUI and derivation rules. For instruction on enabling MAC-authentication refer to
Aruba’s user guide.
For the OUI based derivation rule, configure the following from the CLI:
aaa derivation rules user
set role condition macaddr starts-with "00:90:7a" set-value phone
Quality of Service (QoS)
Quality of service is achieved by prioritizing the SpectraLink voice traffic over data
traffic. To prioritize the voice traffic over data traffic in the AP traffic queues, the
“queue high” tag is used at the end of each ACL to prioritize the traffic matching the
ACL over all other traffic. In the example shown above:
user alias svp_server svc-svp permit queue high
alias svp_server user svc-svp permit queue high
The traffic that matches the above two rules is prioritized over all other traffic. In
addition, a DiffServ tag or a Dot1p tag can be configured at the end of each ACL to
indicate the relative priority of the traffic to the traffic to the network.
Example :
user alias svp_server svc-svp permit dot1p 4 queue high dot1p-
priority 4 tos 4 queue high
alias svp_server user svc-svp permit queue high dot1p-priority 4
tos 4 queue high
By default, the packets are not tagged.
In addition multicast/bradcast traffic in the air can be limited by turning on the firewall
voip-prox-arp. This command is available on the CLI alone.
(Aruba)# configuration terminal
(Aruba) (config)# firewall voip-proxy-arp
Subnet Roaming
The Aruba system can be set up to support inter-switch inter-subnet roaming. The
topology is as shown in the figure on page 2.
When two or more switches are used in the Aruba WLAN system, one switch has to be
identified as the master and the others as the local switch. During VIEW Certification

PN: 72-9965-00-G.doc Page 17
testing, the Aruba 800 was configured as the master switch and the Aruba 6000 was
configured as a local switch; therefore, this configuration is used in the following
examples.
For instructions on setting up a switch as a local switch refer to Aruba’s user guides.
Ensure that both switches have IP connectivity. A simple ping from each of the
switches to the other switch can be used to verify connectivity. In a master local setup all
AP, authentication, and firewall configurations will be made on the master and pushed
down to the local switch.
In the configuration tested, all APs with location code 1.1.0 were configured to boot off
of the master switch and all APs with location code 1.2.0 were configured to boot off of
the local switch.
To use the Web interface to configure this, do the following:
1. From the master switch, navigate to the Configuration > WLAN > Advanced tab.
2. Add a new location 1.1.0 and click the Apply button.
3. In the next page click the General tab and set the LMSIP to the “switch IP” address
of the master.
4. Apply the configurations.
5. Configure location 1.2.0 in a similar manner and set the LMSIP address to the
“switch IP” address of the local switch.
6. Create a default route for multicast traffic re-direction on the switch that acts as the
Mobility Home Agent for the Voice group (this was done on the master switch in the
test example).
CLI commands to set up subnet roaming
Commands for the master switch (the Aruba 800)
Configure terminal
ip default-gateway <ip_addr of router>
ap location 1.1.0 (#ap connected to 800)
lms-ip <ip_addr of 800 switch>
ap location 1.2.0 (#ap connected to 6000)
lms-ip <ip_addr of 6000 switch>
ip route 224.0.0.0 255.0.0.0 <ip_addr of netlink gateway>
exit
write mem

PN: 72-9965-00-G.doc Page 18
Commands for the local switch (the Aruba 6000)
The AP’s IP address must be on the same sub-net as the switch.
Configure terminal
masterip <ip address of the master >
interface loopback
ip address <ip_addr of the 6000>
vlan 1
interface vlan 1
ip address <ip_addr of the 6000> <netmask>
interface fastethernet <port>
switchport access vlan 1 (only if the port is an access port)
trusted
no shut
!
ip default-gateway <ip_addr of router>
!
exit
write mem
After the master switch IP address and the local switch IP address are configured on the
local switch, the switch needs to be rebooted prior to use.
It’s also necessary to set the default gateway of the SpectraLink SVP Server and NetLink
Telephony Gateway to the IP address of the router connected to the master switch.
Commands to verify setup for sub-net routing
From the Aruba 800
show master ip (should be 800’s ip)
show stm connectivity (shows the APs connected to the
Aruba 800 switch)
Ping the local switch.
Pings should be successful.
From the Aruba 6000
show master ip (should be 800’s ip)
show stm connectivity (shows the APs connected to the
Aruba 6000 switch)
show running configuration (shows the AP & aaa rules are carried
from the master to the slave)

PN: 72-9965-00-G.doc Page 19
Checking the Configuration
Verify connectivity by pinging between the switches, the APs, and the server and
gateway.
The switch and AP are now ready for use with the NetLink Wireless Telephones.
To show AP settings:
show ap config location x.y.z
To show all APs connected to a switch:
show stm connectivity
To show clients associated to all APs:
show station-table
To show clients associated to a specific AP:
show ap status <ip of ap>
