Spedal CL786 User manual

CL786/CL787
028C3602-EN
Spedal NaviCam User Manual
Smart Car Stereo

English-01
1. Safety Guidelines
· Do not operate this product while driving.
· Do not install or operate this product with wet hands.
· Do not install this product in a place with high temperature,
humidity, flammable, explosive gas or liquid.
· Do not install this product in an area that interferes with the
driver's sight or driving safety.
· Do not install this product on the airbag cover or within the
working range of the airbag.
· Do not leave this product in a closed vehicle with high tem-
perature for a long time.
· Do not operate this product over rated voltage.
· Do not use non-original cables and accessories.
· Do not use sharp objects such as awls or scissors to cut this
product and its accessories.
· Do not disassemble, repair or modify this product and acces-
sories by yourself.
· Do not install, use or place this product within the reach of
children under 16 years of age.
1.1 Warnings
· Do not press the lens too hard to avoid damage or dislocation of
the lens.
· Do not directly touch the lens surface, so as not to affect the
recording effect.
· Do not remove the memory card during the shutdown process to
avoid file damage.
· When using the memory card for the first time, please format it
on this product to ensure stable reading and writing.
· When not using the product for a long time, please pull out the
memory card to ensure the performance of the memory card.
1.2 Precautions
Scan the QR code, select the corresponding model,
and view the User Manual.
https://spedal.cc/html/support/download/navicam.html
For any questions please contact [email protected]

English-02
2. User Guide
2.1 Package List
◆ Audio Cable ◆ Quick Guide◆ Dashboard Pad
Mounting Disk
◆ Device ◆ Suction Bracket ◆ Power Cable
◆ USB Type-C Cable
（Optional）
◆ TF Card（Optional）
◆ Camera（Optional） ◆ Camera Cable
（Optional）
Note
Do not use cables and components that are not original. Gifts
and accessories are not covered under warranty. The package
contents of this product may change without prior notice, and
the actual contents of the package shall prevail.
2.2 Product Introduction
USB-C Port TF Card Slot
AUX OUT PortAV IN Port
Screen
Charger/Wired Android Auto port
（Model CL786 supports charging only）

English-03
Note
The installation position of equipment and brackets should not
block the driver's sight and affect driving safety.
2.3 Suction Bracket Installation
1.Align the suction bracket clips with the holes on the back of
the device and push them up to secure the bracket.
2.Thoroughly clean and dry the car dashboard surface, remove
dust or debris, and make sure the surface is flat.
3.Remove the 3M adhesive release paper from the dashboard
pad mounting disk and adhere it to a clean instrument panel
surface.
4.Allow to sit for 3 hours or more to ensure a strong bond. Then
remove the protective film from the dashboard pad.
5.Tear off the protective film from the suction bracket, place the
suction cups firmly in the center of the dashboard pad mount-
ing disk, and press the lock button.
6.Adjust the angle of the device screen.
Note
Depending on the vehicle, the cigarette lighter socket may be located in
a different position. The figure provided is for reference only.
2.4 Device Installation
Insert the power cable into the car cigarette lighter, and connect the
other end to the power interface of the device.

English-04
2.7 Camera Installation-1（Optional）
1. Tear off the protective film of
the camera lens.
2.Peel off the 3M adhesive
release paper from the
camera mount, attach the
camera to the windshield,
and press firmly to secure it.
3.Connect the device via the
camera connection cable.
4.Adjust the angle of the
camera lens.
2.8 Camera Installation-2（Optional）
1. Tear off the protective film of
the camera lens.
2.Peel off the 3M adhesive
release paper from the
camera mount, attach the
camera on car rear wind-
shield, and press firmly to
secure it.
3.Connect the device via the
camera connection cable.
4 . Adjust the angle of the
camera lens.
2.5 Audio Cable Installation
1. Insert the audio cable into the
car AUX port, and connect the
other end to the AUX OUT port
of the device.
2. Set the car's audio input mode
to AUX audio input. After the
connection is successful, you
can play music, navigation,
calls and more through your
car's audio system.
2.6 TF Card Installation（Optional）
· Insert the TF card into the TF
card slot.
· The self-provided TF card
should meet the following
requirements: Class 10 or
above, the capacity does not
exceed 128GB.
Note
Please confirm if your car supports AUX IN and note that the
location of the AUX may vary depending on the car model. Please
consult your manufacturer for more details.
