Sper scientific 850039 User manual

1
Datalogging Conductivity/
TDS Meter
850039
Instruction Manual

2
TABLE OF CONTENTS
1. INTRODUCTION..................................................................................3
2. PANEL DESCRIPTION.........................................................................4
3. MEASURING PROCEDURE................................................................5
3-A General Measurement ...................................................................5
3-B Auto and Manual Range Modes ....................................................5
3-C Data Hold ......................................................................................5
3-D Maximum / Minimum .....................................................................6
3-E Data Logger...................................................................................6
4. ADVANCED ADJUSTMENTS...............................................................6
4-A Check Remaining Available of Data Points....................................7
4-B Clear Memory ................................................................................7
4-C Date/Time Setting..........................................................................7
4-D Sample Time Setting .....................................................................7
4-E Auto Power O󰀨 Default Setting ......................................................7
4-F Temperature Unit Default Setting...................................................8
4-G Temperature Compensation Default Setting .................................8
4-H Conductivity (uS, mS), TDS (PPM) Default Setting.......................8
4-I Escape from Advanced Adjustments ............................................8
5. BATTERY REPLACEMENT .................................................................9
6. TROUBLESHOOTING .........................................................................9
7. OPTIONAL ACCESSORIES.................................................................9
8. OFFSET (ZERO) PROCEDURE..........................................................9
9. CONDUCTIVITY CALIBRATION........................................................10
10. SPECIFICATIONS............................................................................ 11
11. WARRANTY ....................................................................................12

3
1. INTRODUCTION
Automatically records up to 16,000 (!) data points in the eld along with
time and date.
Features
• reads total dissolved solids in TDS or PPM
• simultaneously displays conductivity and temperature
• manual or auto-range
• min-max
• adjustable ATC coe󰀩cient
• calendar/clock
• auto power o󰀨
• hold function
• detachable probe
• fold-out tripod
• large easy to read LCD
Comes ready to use in a protective foam lined carrying case complete
with probe, 4 AA batteries, and one 3V button cell battery.

4
2. PANEL DESCRIPTION
1 DISPLAY
2 POWER button
3 HOLD / ESC button
4 REC / ENTER button
5 ▲(UP) button
6 RANGE / ▼(DOWN) button
7CLOCK/ SEND button
8 LOGGER / SET button
9 TRIPOD SCREW
10 STAND
11 BATTERY COMPARTMENT/COVER
12 PROBE INPUT
13 LCD BRIGHTNESS ADJUSTMENT VR
14 SYSTEM RESET
15 RS232 OUTPUT TERMINAL
16 DC 9V POWER AD APTOR SOCKET
17 PROBE PLUG
18 SENSOR HEAD
19 PROBE HANDLE
1
2
3
5
7
4
6
8
12
13
14
15
16
9
10
11
18
17
19
2. PANEL DESCRIPTION
1. DISPLAY
2. POWER button
3. HOLD / ESC button
4. REC / ENTER button
5. ▲(UP) button
6. RANGE / ▼(DOWN) button
7. CLOCK/ SEND button
8. LOGGER / SET button
9. TRIPOD SCREW
10. STAND
11. BATTERY COMPARTMENT/COVER
12. PROBE INPUT
13. LCD BRIGHTNESS ADJUSTMENT VR
14. SYSTEM RESET
15. DC 9V POWER ADAPTOR SOCKET
16. PROBE PLUG
17. SENSOR HEAD
18. PROBE HANDLE
1.
10.
2.
3. 4.
5. 6.
7. 8.
9.
11.
12.
13.
14.
15.
16.
17.
18.

5
8. LOGGER / SET button
9. TRIPOD SCREW
10. STAND
11. BATTERY COMPARTMENT/COVER
12. PROBE INPUT
13. LCD BRIGHTNESS ADJUSTMENT VR
14. SYSTEM RESET
15. DC 9V POWER ADAPTOR SOCKET
16. PROBE PLUG
17. SENSOR HEAD
18. PROBE HANDLE
3. MEASUREMENT PROCEDURES: See page 4 for button locations.
Factory Preset Meter Defaults: Conductivity (uS, mS), °C, Temperature
Compensation (ATC) Factor of 2% per °C, Auto Range, Auto Power O󰀨,
and 2-Second Data Logger Sampling Time. To change default settings, see
“ADVANCED ADJUSTMENT PROCEDURES” on page 6.
3-A. General Measurement
• Insert the PROBE PLUG into the PROBE INPUT and turn the meter on
pressing the POWER button.
• Hold the PROBE HANDLE and immerse the SENSOR HEAD into the
solution sample to be measured. Gently shake the probe to release any
air bubbles.
• The sample’s conductivity mS (uS) and the temperature are displayed.
• See item 4-F, page 8 for instructions on changing between °C and °F.
• See item 4-G, page 8 for instructions on changing the Automatic
Temperature Compensation (ATC) Factor.
• The instructions for measuring TDS are the same as the instructions for
measuring Conductivity. See item 4-H, page 8 for instructions on changing
between Conductivity (uS, mS) and TDS (PPM) measurement.
• To display the time (h-m-s) or date (y-m-d) during use, press the
CLOCK button.
• Press the POWER button to turn the unit o󰀨.
3-B. Auto and Manual Range Modes
• “Auto Range” or “Manual Range” is displayed
under the measurement.
• To switch to Manual Range, press and hold the
RANGE button for at least 2 seconds. When
the meter beeps, release the RANGE button.
• Press the RANGE button again to switch
between the available ranges: 200uS, 2MS 20 mS and 200 mS.
• If the out-of-range indicator “- - - - -” appears at the bottom of the display,
select a lower range, and if it appears at the top of the display, select a
higher range.
• To switch to Auto Range, press and hold the RANGE button for at least 2
seconds. When the meter beeps, release the RANGE button.
3-C. Data Hold
• While measuring, press the HOLD button to freeze the displayed value.
• “HOLD” and the measurement are displayed.
• Press the HOLD button again to exit.
1.46
20.00 mS
Auto Range
66.5°
F

6
3-D. Maximum / Minimum
To record the maximum and minimum readings:
• Press the REC button once. “REC” appears on the LCD.
• Press the REC button again. “MAX”, “REC” and the maximum
measurement appear on the LCD.
• Press the REC button again. “REC Min” and the minimum measurement
appear on the LCD.
• To exit this function, press and hold the REC button for at least 2 seconds.
The display reverts to the current reading.
3-E. Data Logger
The data logger function can save up to 16,000 data points along with the
time (hour-min-sec) and date (year-month-day). When there are 16,000 data
points in memory, the display indicates “FULL.”
• To momentarily display the set sampling time, press the LOGGER
button once.
• To change the sampling time, see item 4-D on page 7.
• Press the REC button once, “REC” will be displayed.
• Depending on your set sampling time, continue to step “a” or “b” (below).
a. Auto Data Logger (sampling time can be set for 2 seconds to
8 hours, 59 minutes, 59 seconds):
• Press the LOGGER button once, “REC DATA” is displayed and
“Recording. . . .” ashes at each set interval.
• Press the LOGGER button again to exit. “REC” is still displayed, but
“DATA” is no longer shown.
• To resume data logging, simply press the LOGGER button again.
• To exit the “REC” function, press and hold the REC button for at least
2 seconds.
b. Manual Memory (sampling time MUST be set to “0” zero)
• Press the LOGGER button once to save each data point.
• Up to 250 data points can be saved and reviewed on the meter’s LCD by
pressing and holding the SEND button and then using ▲ and ▼ to scroll.
• To exit the this function, press and hold the ESC button for at
least 2 seconds.
4. ADVANCED ADJUSTMENT PROCEDURES
Press the SET button for at least two seconds to enter the advanced
adjustment procedures. Press the ESC button to exit.
Before executing the advanced adjustment procedures,
exit the HOLD and RECORD functions.

7
4-A. Check Remaining Number of Data Points
Press the SET button at least 2 seconds until
the lower display shows:
“XXXXX” is the number of free data points.
4-B. Clear Memory
• Press the SET button as needed to reach the
“clear memory” screen. The number of saved data points is displayed.
• To delete saved data from memory, press the ENTER button once, then
press the ENTER button again to conrm. The display shows:
“0 Ok ESC:Quit”.
• If you DO NOT want to clear the memory, press the ESC button to exit, OR
press the SET button to advance to the next option.
4-C. Date/Time Setting
• Press the SET button as needed to reach the
“date/time set” screen.
• Use the ▲, ▼, and ENTER buttons to select the year, month, date, hours,
minutes and seconds.
• Press the ENTER button to save the settings.
• Press the SET button to advance to the next option, or press the ESC
button to exit.
4-D. Sample Time Setting
• Press the SET button as needed to reach the
“sample time” screen.
• Use the ▲, ▼, and ENTER buttons to select the sample time (hour-min-
sec).
• Press the ENTER button to save the settings.
• Press the SET button to advance to the next option, or press the ESC
button to exit.
4-E. Auto Power O󰀨 Default Setting
The meter will automatically shut o󰀨 after
about 10 minutes without activity.
• Press the SET button as needed to reach the “auto power o󰀨” screen.
• Use the ▲ or ▼ buttons to enable / disable this feature.
• Press the ENTER button to save the settings.
• Press the SET button to advance to the next option, or press the ESC
button to exit.
Clear Memory
Esc:N Enter:Y
107
06:01:03 Date/Time Set
y-m-d ^, v ENTER(→)
00:00:02 Sample Time
h-m-s ^, v ENTER(→)
1=Auto Power O󰀨 - Enabled
0=Auto Power O󰀨 - Disabled
XXXXX Memory Space

8
4-F. Temperature Unit Default Setting
• Press the SET button as needed to reach the “temp. unit” screen.
• Use the ▲ and ▼ buttons to switch between °F and °C. Press
the ENTER button.
• Press the SET button to advance to the next option, or press the ESC
button to exit.
4-G. Temperature Compensation Factor (ATC) Default Setting
The ATC Factor is adjustable between 0 to 5.0% per °C.
• Press the SET button as needed to reach the “Temp.
Comp.” screen.
• Use the ▲, ▼, and SEND buttons to set the ATC Factor.
• Press the ENTER button to save the settings.
• Press the SET button to advance to the next option, or press the ESC
button to exit.
4-H. Conductivity (uS, mS), TDS (PPM) Default Setting
• Press the SET button as needed to reach the “CD/TDS” screen.
• Use the ▲ and ▼ buttons to switch between uS, mS and PPM.
• Press the ENTER button.
• Press the SET button to advance to the next option, or press the ESC
button to exit.
4-I. Escape from Advanced Adjustments
For the above procedures, press the ESC button before pressing the
ENTER button to exit advanced adjustments without saving the changes.
1=°F
0=°C
Temp. Comp.
^, v SEND(→)
1=PPM
0=uS, mS

9
5. BATTERY REPLACEMENT
When the left corner of the LCD displays the low battery icon install 4 new
AA 1.5V batteries. Slide the BATTERY COVER away from the instrument
to remove the old batteries. When the clock is not accurate, replace the 3V
button cell battery located in the compartment behind the AA’s. Re-attach the
battery cover when you have nished. In-spec measurements may be made
for several hours after the low battery indicator appears.
6. TROUBLESHOOTING
Gently insert a pin or small object into the SYSTEM RESET while turning on
the meter.
7. OPTIONAL ACCESSORIES
850040 Replacement Conductivity/TDS Probe
840058 USB Power Cable
840097 AC to DC 9V Adapter
840090 Water Resistant Instrument Pouch
840093 Field Tripod
8. OFFSET (ZERO) PROCEDURE
With the SENSOR HEAD completely dry, press the ▲ button for at least two
seconds until the meter beeps and the display changes to zeros.

10
9. CONDUCTIVITY CALIBRATION
Although calibration is not generally needed, the following procedures
should be performed the rst time a new probe is used, when the electrode
is changed, or after the meter has been in use for a long period of time.
• Prepare a 1.413 µS calibration solution, or
any standard conductivity solution.
• Press the POWER button to turn the meter on.
• Select the auto range mode, see item 3-B, page 5.
• Immerse the SENSOR HEAD into the solution.
• Press both the REC and HOLD buttons at the same time. Release the
buttons when “0:Temp.,1:CD” is displayed.
• Use the ▲ and ▼ buttons to select “1” for Conductivity Calibration or “0” for
Temperature Calibration.
• Press the ENTER button.
• Use the ▲ and ▼ buttons to select the desired calibration value, for
example 1.413.
• Press the ENTER button twice to save the setting and exit the function.
The same steps are used to calibrate 200uS, 2mS, 20mS, and 200mS.
Each range can be independently calibrated.
1.408
2.000 µS
°C
1.413
2.000 µS
°C
1=Conductivity Calibration
0=Temp. Calibration

11
Range Resolution Accuracy
Conductivity
0 to 200.0 us 0.1 us
±(2% full scale +1d)
0.2 to 2.000 ms 0.001 ms
2 to 20.00 ms 0.01 ms
20 to 200.0 ms 0.1 ms
TDS
0 to 132 ppm 0.1 ppm
132 to 1,320 ppm 1 ppm
1,320 to 13,200 10 ppm
13,200 to 132,000 100 ppm
ºC 0 to 60ºC 0.1º 0.8ºC
ºF 32 to 140ºF 1.5ºF
10. SPECIFICATIONS
Operating Conditions 0 to 50°C, Less than 80% RH
Display Sampling Time Approximately 1 second
Display Size LCD size 2 1/4" x 1 3/8" (58 x 34 mm)
Meter dimensions:
Meter: 7 ¾" x 3" x 1½" (200 x 76 x 37 mm)
Probe handle diameter: 1” (26 mm)
Probe handle length: 5” (127 mm)
Cable length: 44” (1118 mm)
Weight: 31 oz (515g)
Sampling Time
of Display
Approx 1 second
Power Current Approx. DC 19.0 mA
Circuit Custom one-chip microprocessor LSI

12
11. WARRANTY
Sper Scientic warrants this product against defects in materials and
workmanship for a period of ve (5) years from the date of purchase, and
agrees to repair or replace any defective unit without charge. If your model
has since been discontinued, an equivalent Sper Scientic product will be
substituted if available. This warranty does not cover probes, batteries,
battery leakage, or damage resulting from accident, tampering, misuse, or
abuse of the product. Opening the meter to expose its electronics will break
the waterproof seal and void the warranty. To obtain warranty service, ship
the unit postage prepaid to:
SPER SCIENTIFIC LTD.
8281 E. Evans Rd., Suite #103
Scottsdale, AZ 85260
[phone]
The defective unit must be accompanied by a description of the problem and
your return address. Register your product online at www.sperwarranty.com
within 10 days of purchase.
Rev 3/8/2018
