SPIERINGS AT6 User manual

MANUAL SPIERINGS TRUCK AT6
AT6-EN-061031.doc I
Preface
Dear user,
This operating manual provides the user of the Spierings folding crane with information concerning the crane's
construction and operation. You will find detailed technical specifications and maintenance instructions in the
maintenance part of this manual.
© Copyright Spierings Cranes.
All rights reserved.
No part of this publication may be reproduced or published, in any form or in any way, by print, photo print, microfilm or any other means without prior permission from the
manufacturer.

MANUAL SPIERINGS TRUCK AT6
AT6-EN-061031.doc II
Liability clause
SECTION 1. OPERATION
1.1 The Spierings truck may only be used for the purpose it was manufactured and designed for and only as
described in the user manual or in the additions to it.
1.2 Any use of the Spierings truck that differs from its design purpose or as described in the use manual or
the additions to it, will cause the product warranty and the manufacturer’s liability, for any direct or
indirect damage, to expire.
1.3 Only qualified, skilled personnel are allowed to operate the truck. The driver should have a special
driving license for driving heavy vehicles. The driver/operator must be in good physical and mental
health, so that he/she is able to carry out the work without restrictions and react with responsibility in all
given situations.
1.4 The driver/operator/user of the Spierings truck should be informed immediately of any additions/changes
to the user manual.
SECTION 2. SAFETY
2.1 For safety reasons the driver/operator/user should carry out all operations as stated in the user manual
or in the additions to it.
2.2 If more stringent safety demands are locally placed on the truck/crane than specified in the Spierings
truck user manual or additions to it, these more stringent requirements must be strictly complied with. If
not, all warranty will expire and the manufacturer will not be liable for any damage or costs.
2.3 The Spierings truck manufacturer points out explicitly, that the driver/operator/user and local personnel
should not enter the cranes/trucks danger zone. If, for any reason or cause, an unexpected situation
occurs during operation one should contact the technical department or Spierings Service department
first before proceeding.
SECTION 3. WARRANTY
3.1 It is prohibited to carry out modifications or welding to the Spierings truck without prior written permission
of the manufacturer of the Spierings truck.
3.2 Frequent maintenance and periodic checks should be carried out in accordance with the user manual, or
in the additions to it. If maintenance or checks are carried out otherwise, or less frequent, without prior
written permission of the manufacturer of the Spierings truck, all warranty will expire and any liability, for
direct or indirect damage, is explicitly excluded.

MANUAL SPIERINGS TRUCK AT6
AT6-EN-061031.doc III
Explanation of the symbols used
CAUTION!
Wear safety goggles!
Wear safety gloves!
Wear safety boots!
Wear head protection!
Use safety belt!
Check!
Manual action!
Automatic action!
Wrong!
Right!
Information!

MANUAL SPIERINGS TRUCK AT6
AT6-EN-061031.doc IV
Index
PREFACE ................................................................................................................................................................ I
LIABILITY CLAUSE................................................................................................................................................ II
EXPLANATION OF THE SYMBOLS USED.......................................................................................................... III
INDEX ....................................................................................................................................................................IV
1. GENERAL DATA AT6.............................................................................................................................. 1-1
2. OPERATION............................................................................................................................................. 2-1
2.1. Getting to know the truck............................................................................................................. 2-1
2.2. Truck cab .................................................................................................................................... 2-4
2.2.1. Getting in....................................................................................................................... 2-4
2.2.2. Doors............................................................................................................................. 2-4
2.2.3. Wing mirrors.................................................................................................................. 2-4
2.2.4. Seats............................................................................................................................. 2-4
2.2.5. Safety belts....................................................................................................................2-4
2.2.6. Storage room.................................................................................................................2-4
2.2.7. Sun blind .......................................................................................................................2-4
2.2.8. Fuse box........................................................................................................................2-5
2.2.9. Reservoir windscreen washer fluid................................................................................ 2-5
2.2.10. Middle console............................................................................................................. 2-5
2.2.11. Battery charger remote control batteries ..................................................................... 2-6
2.2.12. Fire extinguisher.......................................................................................................... 2-6
2.3. Control Panel .............................................................................................................................. 2-7
2.4. Air-conditioning operation (Option)............................................................................................2-17
2.5. Driving the Spierings crane....................................................................................................... 2-18
2.5.1. Starting........................................................................................................................2-18
2.5.2. Driving off ....................................................................................................................2-19
2.5.3. Driving in reverse......................................................................................................... 2-19
2.5.4. Stopping ...................................................................................................................... 2-19
2.5.5. Switching off the engine .............................................................................................. 2-20
2.6. Shifting gear.............................................................................................................................. 2-20
2.6.1. Automatic gear shift..................................................................................................... 2-20
2.7. Manual gear shift....................................................................................................................... 2-21
2.7.1. Display indications....................................................................................................... 2-21
2.8. Brakes....................................................................................................................................... 2-22
2.8.1. Operating brake...........................................................................................................2-22
2.8.2. Parking brake ..............................................................................................................2-22
2.8.3. Vacuum brake ............................................................................................................. 2-22
2.8.4. Braking with the retarder .............................................................................................2-22
2.9. Retarder/ESC/CC...................................................................................................................... 2-23
2.9.1. The Bremsomat........................................................................................................... 2-23
2.9.2. Cruise Control (CC)..................................................................................................... 2-23
2.9.3. Variable vehicle speed limit......................................................................................... 2-24
2.9.4. Speed control (ESC).................................................................................................... 2-24
2.10. Driving off the road.................................................................................................................... 2-25
2.10.1. All-terrain mode transfer case.................................................................................... 2-25
2.10.2. Longitudinal differential lock ...................................................................................... 2-25
2.10.3. Transverse differential lock........................................................................................ 2-26
2.10.4. Hydraulically driven front axle.................................................................................... 2-26

MANUAL SPIERINGS TRUCK AT6
AT6-EN-061031.doc V
2.11. Parking...................................................................................................................................... 2-26
2.12. Axle height adjustment.............................................................................................................. 2-27
2.12.1. Suspension blocking.................................................................................................. 2-27
2.12.2. All-terrain mode......................................................................................................... 2-27
2.12.3. Levelling .................................................................................................................... 2-27
2.13. Independent rear axle steering..................................................................................................2-28
2.13.1. Switching on the independent rear axle steering....................................................... 2-28
2.13.2. Manual steering......................................................................................................... 2-28
2.13.3. Synchronized steering............................................................................................... 2-28
2.13.4. Driving in crab steering mode....................................................................................2-28
2.13.5. Switching off the separate rear axle steering............................................................. 2-28
2.14. Driving with erected crane......................................................................................................... 2-29
2.15. Driving with trailer...................................................................................................................... 2-29
2.16. Towing the crane....................................................................................................................... 2-30
2.16.1. Towing when the diesel engine can still run .............................................................. 2-30
2.16.2. Towing when the diesel engine is out of order........................................................... 2-30
3. MAINTENANCE........................................................................................................................................ 3-1
3.1. Safety.......................................................................................................................................... 3-1
3.1.1. Clothing ......................................................................................................................... 3-1
3.1.2. Surroundings................................................................................................................. 3-1
3.1.3. Diesel engine................................................................................................................. 3-1
3.1.4. Moving parts.................................................................................................................. 3-1
3.1.5. Oils and coolant............................................................................................................. 3-2
3.1.6. Environment ..................................................................................................................3-2
3.1.7. Change oil cooling system............................................................................................. 3-2
3.1.8. Fire hazard ....................................................................................................................3-2
3.1.9. Cleaning components.................................................................................................... 3-2
3.2. Maintenance plan for the AT6 truck ............................................................................................ 3-3
4. DIESEL ENGINE....................................................................................................................................... 4-1
4.1. Maintenances at commencement of operations.......................................................................... 4-1
4.2. Access to the diesel engine......................................................................................................... 4-2
4.3. Engine oil .................................................................................................................................... 4-3
4.3.1. Check the engine oil level.............................................................................................. 4-3
4.3.2. Top up engine oil........................................................................................................... 4-3
4.3.3. Change engine oil.......................................................................................................... 4-4
4.4. Oil filter engine............................................................................................................................ 4-5
4.4.1. Oil filter replacement...................................................................................................... 4-5
4.4.2. Centrifugal filter replacement......................................................................................... 4-6
4.5. Cooling........................................................................................................................................ 4-7
4.5.1. Check the coolant level ................................................................................................. 4-7
4.5.2. Top up Coolant.............................................................................................................. 4-8
4.5.3. Changing coolant........................................................................................................... 4-8
4.5.4. Antifreeze ......................................................................................................................4-9
4.5.5. Radiator/intercooler/oil cooler........................................................................................ 4-9
4.6. Air inlet system.......................................................................................................................... 4-10
4.6.1. Clean air cleaner ......................................................................................................... 4-10
4.6.2. Air cleaner cartridge replacement................................................................................ 4-11
4.7. Fuel system............................................................................................................................... 4-11
4.7.1. Replace fuel filter......................................................................................................... 4-11
4.8. Fuel filter/water separator.......................................................................................................... 4-12
4.8.1. Drain the water separator............................................................................................ 4-13

MANUAL SPIERINGS TRUCK AT6
AT6-EN-061031.doc VI
4.8.2. Fuel filter/water separator replacement....................................................................... 4-13
4.9. V-belts....................................................................................................................................... 4-14
4.9.1. V-belts inspection........................................................................................................ 4-14
4.9.2. V-belt adjustment......................................................................................................... 4-15
4.10. Exhaust system......................................................................................................................... 4-15
4.11. Valve clearance check and adjustment.....................................................................................4-15
4.12. DEB-clearance check and adjustment ...................................................................................... 4-16
5. DRIVE SYSTEM........................................................................................................................................ 5-1
5.1. Transmission............................................................................................................................... 5-1
5.1.1. General transmission maintenance ............................................................................... 5-2
5.1.2. Check the oil level in the transmission...........................................................................5-2
5.1.3. Changing oil in the transmission.................................................................................... 5-2
5.1.4. Renew oil filter retarder ................................................................................................. 5-3
5.2. Transfer case.............................................................................................................................. 5-4
5.2.1. General maintenance transfer case............................................................................... 5-4
5.2.2. Check oil level transfer case.......................................................................................... 5-5
5.2.3. Change oil in transfer case............................................................................................ 5-5
5.3. Axles ........................................................................................................................................... 5-6
5.3.1. General maintenance axles........................................................................................... 5-6
5.3.2. Check oil level differentials............................................................................................ 5-7
5.3.3. Oil change in differentials .............................................................................................. 5-8
5.3.4. Check oil level axle hubs............................................................................................... 5-8
5.3.5. Change oil axle hubs..................................................................................................... 5-9
5.4. Tyres........................................................................................................................................... 5-9
5.4.1. General maintenance tyres ........................................................................................... 5-9
5.4.2. Tyre pressure ................................................................................................................ 5-9
5.5. Check the brake linings............................................................................................................. 5-10
5.5.1. Brakes .........................................................................................................................5-10
6. STEERING SYSTEM................................................................................................................................ 6-1
6.1. Rear axle steering....................................................................................................................... 6-2
6.1.1. Function of Rear Axle Steering...................................................................................... 6-2
6.1.2. Rear axle steering malfunction...................................................................................... 6-2
6.2. Checking the steering system..................................................................................................... 6-2
6.3. Align............................................................................................................................................ 6-2
7. ELECTRICAL SYSTEM............................................................................................................................ 7-1
7.1. Lighting........................................................................................................................................ 7-1
7.2. Dashboard Lighting..................................................................................................................... 7-1
7.3. Batteries...................................................................................................................................... 7-2
7.3.1. Check batteries.............................................................................................................. 7-2
7.3.2. Charging the Batteries................................................................................................... 7-2
7.3.3. Batteries replacement.................................................................................................... 7-3
8. HYDRAULIC SYSTEM ............................................................................................................................. 8-1
8.1. Check the oil level in the hydraulic oil tank..................................................................................8-1
8.2. Changing hydraulic oil................................................................................................................. 8-2
8.3. Replace hydraulic oil filter ........................................................................................................... 8-3
8.3.1. Hydraulic fine filter......................................................................................................... 8-3
8.3.2. Hydraulic filters..............................................................................................................8-4
8.4. Check the suspension accumulators........................................................................................... 8-4
8.5. Hoses and couplings hydraulic system ....................................................................................... 8-5

MANUAL SPIERINGS TRUCK AT6
AT6-EN-061031.doc VII
9. PNEUMATIC SYSTEM............................................................................................................................. 9-1
9.1. Primary system: brake system....................................................................................................9-1
9.2. Secondary system: accessories and transmission...................................................................... 9-1
9.3. Air dryer....................................................................................................................................... 9-2
9.3.1. Air dryer filter replacement............................................................................................. 9-2
9.4. Air vessels................................................................................................................................... 9-3
9.5. Oil atomizer/water separator ....................................................................................................... 9-3
9.5.1. Replenish oil atomizer ................................................................................................... 9-4
9.5.2. Water separator............................................................................................................. 9-4
9.6. Check brake pressure................................................................................................................. 9-5
9.7. Hoses and couplings pneumatic system..................................................................................... 9-5
10. LUBRICATION........................................................................................................................................ 10-1
10.1. Central lubricating system......................................................................................................... 10-1
10.1.1. Time switch central lubricating system ...................................................................... 10-1
10.1.2. Grease reservoir central lubricating system .............................................................. 10-1
10.1.3. Grease Points Central Lubricating System................................................................ 10-2
10.2. Manual lubrication..................................................................................................................... 10-3
10.2.1. Extension cylinders outrigger beams......................................................................... 10-3
10.2.2. Cardan shafts............................................................................................................ 10-3
10.2.3. Steering system......................................................................................................... 10-4
10.2.1. Tower supports..........................................................................................................10-4
11. MISCELLANEOUS................................................................................................................................. 11-1
11.1. Check windscreen washer fluid................................................................................................. 11-1
11.2. Fire extinguisher........................................................................................................................ 11-1
11.3. Air-conditioning (Option)............................................................................................................ 11-1
12. TECHNICAL DATA................................................................................................................................. 12-1
13. ENCLOSURES ....................................................................................................................................... 13-1

MANUAL SPIERINGS TRUCK AT6
AT6-EN-061031.doc 1-1
1. General data AT6
The AT6-truck is especially designed for the Spierings SK1265 folding crane. Extra attention was paid to a
smooth and comfortable transport to the work site. The crane is suitable for driving on public roads fully fitted with
counterweight and tools. The chassis is an especially rigid structure to create a good crane support.
Picture 1-1 shows the measurements of the SK1265 with AT6-carriage. It states the overall dimensions, axles
distances and turning circle.
Picture 1-1
Measurements
•length: 15,5m
•Width: 3m
•Height: 4m
Drive system
•12.6 ltrs DAF diesel engine with turbo compressor and intercooler (type XE-390C1).
•ZF automatic transmission retarder; sixteen forward gears and one reverse gear.
•STEYR transfer case with a high (road) and a low (all-terrain) drive.
•Electronic accelerator pedal "E-gas” with speed control.
•Six Kessler & Co axles, where axle one, two, three and six are driven.
Steering:
•Axle 1, 2, 3, 5 and 6 are steered.
•Axle 5 and 6 are steered in opposite direction of axle 1, 2 and 3 to reduce the turning circle.

MANUAL SPIERINGS TRUCK AT6
AT6-EN-061031.doc 1-2
•Axle 5 and 6 can be disengaged. The axles may be steered in the same direction as the 3 front axles either
by means of a steering knob or fully automatic. This way you can drive in crab steering mode.
•The 2-circuit steering system is hydraulically powered by means of a 2-circuit steering gear housing and 3
auxiliary cylinders.
•The steering system is fitted with a emergency steering pump, so in case of a defect in the main steering
pump or stalling of the diesel engine, the truck remains steerable until it stands still.
•Provisions for driving off the road:
- adjustable axle height
- transfer case can be shifted in all-terrain gear
- longitudinal and transverse differentials can be locked
Suspension:
•Hydro-pneumatic suspension.
•Suspension can be blocked.
Brakes:
•Pneumatic operated brakes.
4-point outrigger support:
•Wide: 7.95m x 7.66m
•Narrow: 7.95m x 5.72m
Other data:
•Maximum speed limited to 85 km/h.
•Minimum speed at 1250 rpm: 1.9 km/h (is 32 m/min)
•Truck weight incl. superstructure approx. 72,000 kg
•The axle load is 12,000 kg each axle.
Numbers:
•Engine number: at the left on the engine block above the fuel pump.
•Vehicle identification number: on the ID-plate in the co-driver's legroom (see Picture 1-2) and engraved in the
right-hand frame girder in front of the 1st axle (see Picture 1-3).
Picture 1-2 Picture 1-3

MANUAL SPIERINGS TRUCK AT6
AT6-EN-061031.doc 2-1
2. Operation
2.1. Getting to know the truck
Picture 2-1
1. Bumper
If desired a bumper can be mounted, which enables you to take along an extra sling box or spare wheel. When
the bumper is folded up, the tow hook can be used.
2. Rear and side view cameras
To broaden your view at the rear and right-hand side of the truck cameras are installed. A monitor in the cab
shows the views.
3. Truck cab
Besides driving the crane, with the control panel in the truck cab the crane can be supported on outriggers and
the axle height can be adjusted.
4. Work lamps
At the rear of the engine compartment work lamps are
mounted at the right-hand side as well as at the left-
hand side. They can be operated from the cab.
By loosening knob (A) on the bracket the lamp can be
adjusted further (Picture 2-2).
Picture 2-2

MANUAL SPIERINGS TRUCK AT6
AT6-EN-061031.doc 2-2
5. Left engine cowling
At this side under the engine cowling you will find
the following parts:
1. Electrical cabinet
2. Button box
3. Grease reservoir central lubrication system
4. Ladder
5. Oil top up pipe
Picture 2-3
6. Ladder
Via the ladder at the back of the truck you can mount the truck frame. The ladder inside the left engine cowling
can also be used for this purpose.
Mind your safety.
7. Outriggers
At both sides of the truck there are 2 extending outrigger beams (4), and to each beam a hydraulically operated
outrigger (1). These outriggers provide stability during hoisting operations. The outrigger beams have an antiskid
coating (5) to prevent skidding. The outrigger pad holders (3) can be used to facilitate stepping on the outrigger
beam.
With a separate (remote) control box the outriggers can be radio controlled. Check to make sure the crane is level
by using the levels.
Picture 2-4

MANUAL SPIERINGS TRUCK AT6
AT6-EN-061031.doc 2-3
8. Right engine cowling
Underneath the engine cowling at the right-hand side
of the truck you will find the following parts:
1. Air filter
2. Combined cooler unit (Intercooler/radiator/oil
cooler) with hydraulically driven fans.
3. Noise isolating wall
Picture 2-5
9. Fuel tank
The fuel tank is integrated in the frame at the rear end of the truck. The tank capacity is 600 ltrs and can be filled
through the filler neck at the rear of the truck (Picture 2-6).
Picture 2-6
10. Rear box
The rear box contains both on the left as well as on the right and rear a lockable storage compartment. In the
centre under the outrigger support plates you will find a sling box.
11. Outrigger support plates
On top of the rear box you can store four outrigger support plates. They can be put in operating position by means
of a hoisting arm, which is mounted to the outer tower.

MANUAL SPIERINGS TRUCK AT6
AT6-EN-061031.doc 2-4
2.2. Truck cab
2.2.1. Getting in
Use the step under the door. Make use of the steering wheel to hold on to.
2.2.2. Doors
Turn the handle up to open the door from the inside. The door can only be locked up from the outside. There is an
ashtray on the inside of the door. After opening the ashtray, you push the locking device down to remove the
ashtray from the holder to empty it.
The windows can be operated with the switches on the dashboard.
2.2.3. Wing mirrors
The wing mirrors may be adjusted by hand. Make sure the mirrors are adjusted before driving off, so that you
have satisfactory view. The mirror heating can be switched on with a switch on the control panel.
2.2.4. Seats
The cab has room for the driver and a co-driver. The driver's seat has pneumatic
suspension, the co-driver's seat does not. The seats' position can be adjusted.
This should only be done when the vehicle stands still.
(See Picture 2-7).
A) Back adjustment
B) Lumbar support adjustment (pressing = inflate and pull = deflate)
C) Height adjustment (pulling the handle = up and pushing it = down)
D) Tipping the seat
E) Handle fast lowering
F) Seat adjustment
Picture 2-7
2.2.5. Safety belts
The seats are fitted with safety belts. Driver and co-driver must wear them while driving. Do not modify the belt or
its attachment by yourself. Regularly check its operation by jerking the belt from its winding mechanism. The belt
must lock when doing this. Have the lock repaired or replaced when it does not function properly. When the belt
was heavily loaded during a collision, it must be completely replaced, even if it looks like there is nothing wrong
with it.
2.2.6. Storage room
In the middle of the cab ceiling is a storage compartment. It has a lockable lid at the driver's side and at the side
of the co-driver. Also in the dashboard at co-driver's side you will find a storage compartment.
2.2.7. Sun blind
To prevent sunlight from blinding you, a sun blind is mounted above the windscreen for the driver and the co-
driver. Pull down the blind with the joggle in the middle of the blind. The blind will remain in the desired position.
Push the button on the side of the blind to roll it up.

MANUAL SPIERINGS TRUCK AT6
AT6-EN-061031.doc 2-5
2.2.8. Fuse box
The fuse box is situated in the dashboard at co-driver's
side. (Picture 2-8)
Picture 2-8
2.2.9. Reservoir windscreen washer fluid
It is found at the left of the co-driver's side.
Picture 2-9
2.2.10. Middle console
All components underneath the middle console at the co-drivers side can be reached by two covers. The next
component can be found (Picture 2-10):
1. Timer central lubrication system
2. Display rear axle steering
3. Adjustment knobs for rear axle steering
4. Transfer case neutral (Used during towing
the truck)
5. Reset button ABS-system
6. Switch off EMAS-system (rear axle steering)
Picture 2-10

MANUAL SPIERINGS TRUCK AT6
AT6-EN-061031.doc 2-6
2.2.11. Battery charger remote control batteries
You will find the battery charger for the remote controls on the left under the dashboard at the drivers’ side.
Picture 2-11
Every remote control comes with 2 batteries each.
While the batteries are being charged, the indicator lamp lights. As soon as they are fully charged, the lamp starts
flashing.
2.2.12. Fire extinguisher
The fire extinguisher is situated behind the co-driver's seat.

MANUAL SPIERINGS TRUCK AT6
AT6-EN-061031.doc 2-7
2.3. Control Panel
1. Longitudinal differential lock
2. Transverse differential lock
3. Transfer case high/low
4. Switch alarm light
5. Aeronautical warning light
6. Blank
7. Light switch off/dipped beam
8. Dimmer dashboard lighting
9. Switch worklamps
10. Switch mirror heating
11. Switch rotating beacons
12. Switch fog tail light
13. Switch axles up/down
14. Switch axles 1 and 2 up/down
15. Switch axles 3, 4, 5 and 6 left up/down
16. Switch axles 3, 4, 5 and 6 right in/out
17. Switch levelling
18. Switch driving/blocking
19. Switch outrigger beam front left retract/extend
20. Switch outrigger front left retract/extend
21. Switch outrigger beam rear left retract/extend
22. Switch outrigger rear left retract/extend
23. Switch outrigger beam front right-hand side
retract/extend
24. Switch outrigger front right-hand side
retract/extend
25. Switch outrigger beam rear right-hand side
retract/extend
26. Switch outrigger rear right-hand side
retract/extend
27. Switch outrigger controls on/off
28. Indicator lamp full beam headlight
29. Indicator lamp dimlight
30. Indicator lamp winker left
31. Display automatic transmission
32. Indicator lamp blinker right
33. Indicator lamp oil pressure
34. Indicator lamp coolant level
35. Revolution counter
36. Mileage counter
37. Fuel gauge
38. Coolant temperature gauge
39. Air-pressure gauge circuit 1
40. Oil pressure gauge diesel oil circuit
41. Oil pressure temperature circuit retarder
42. Air-pressure gauge circuit 2
43. Indicator gear box (transmission)
44. Steering system error announcement
45. Error indicator electronic rear axle steering
46. Error indicator diesel engine
47. Manual rear axle steering
48. Indicator lamps A) Steering circuit 1
B) Steering circuit 2
C) Air pressure
D) Parking brake
49. Indicator lamps A) Mirror heating
B) Work lamps
C) Rota flare light
D) Fog tail light
50. Indicator lamps A) Transversal lock axle 1
B) Transversal lock axle 2
C) Transversal lock axle 3
D) Transversal lock axle 6
51. Indicator lamps A) Long.lock transfer case
B) Longitudinal lock axle 3
C) Off-the-road gear
D) Road gear
52. Indicator lamps A) Axle blocking
B) Levelling
C) All-terrain mode suspen.
D) Maximum oil pressure
suspension and outriggers
53. Indicator lamps A) Outrigger control
B) Warning lights
C) Aeronautical lamp
D) Retarder
54. Indicator lamps A) Pre-heating
B) Charging current
batteries
C) Air cleaner
D) Blank
55. A, B, C and D blank or not present
56. A) Rear axle disengaged manual steering
B) Switch rear axle manual steering
C) Switch rear axle automatic steering
D) Rear axle disengages automatic steering
57. Door window left
58. Door window right
59. Interior lighting driver's side
60. Interior lighting co-driver's side
61. Front axle-drive
62. Blank
63. Ignition switch
64. Steering wheel
65. Control lever blinker/windscreen wiper interval
66. Control lever retarder/cruise control/ESC
67. Vacuum brake
68. Brake pedal
69. Gas pedal
71. Navigation system
72. Switch camera view rear/side
73. Digital tachograph
74. Radio
75. 12V branch box
76. Cigarette lighter
77. Temperature control cab heater
78. Fan control
79. Parking brake
80. Speed lever manual gear shifting
81. Selector switch transmission
82. Battery switch
83. Camera monitor
84. Pressure control valve front wheel drive
85. general oil pressure gauge
Picture 2-12

MANUAL SPIERINGS TRUCK AT6
AT6-EN-061031.doc 2-8
1. Switch longitudinal differential lock
Switch on the longitudinal lock when, while driving off the road, you have no or little grip. The
longitudinal locks will be locked.
2. Switch transverse differential lock
Switch on the transverse lock when, while driving with longitudinal lock, you still have insufficient grip.
The differentials in the axles will be locked.
3. Transfer case high/low
While driving on the road this switch must be on "high" (hare). The transfer case is in road travel
mode.
If you drive off the road you can put the switch on "low" (turtle). The transfer case in in all-terrain
mode.
4. Switch hazard warning light
In case of emergency you can switch the hazard warning lights on and off with this switch.
5. Aeronautical warning light
If you are working on or near an airport, you have to switch on this warning light.
7. Switch dim light
8. Dimmer dashboard lighting
9. Switch work lamps
This switch controls the work lamps left and right at the back of the truck cab.
10. Switch mirror heating
11. Switch rotating beacon
12. Switch Fog Tail Light

MANUAL SPIERINGS TRUCK AT6
AT6-EN-061031.doc 2-9
13. Switch all axles up/down
With this switch the cylinders of every axle are simultaneously extended or retracted (e.g. when
operating the outrigger system).
14. Switch axles 1 and 2 up/down
With this switch the cylinders of axles 1 and 2 can be extended or retracted simultaneously.
15. Switch axles 3, 4, 5 and 6 left up/down
With this switch the cylinders at the left-hand side of the 3rd, 4th, 5th and 6th axle can be extended or
retracted.
16. Switch axles 3, 4, 5 and 6 right up/down
With this switch the cylinders at the right-hand side of the 3rd, 4th, 5th and 6th axle can be extended
or retracted.
17. Switch levelling
E.g. to get all the axles at the same height for transport after outrigger operation, the axle cylinders
must be levelled.
18. Switch driving/blocking
19. Switch outrigger beam front left-hand side retract/extend

MANUAL SPIERINGS TRUCK AT6
AT6-EN-061031.doc 2-10
20. Switch outrigger front left-hand side retract/extend
21. Switch outrigger beam rear left-hand side retract/extend
22. Switch outrigger rear left-hand side retract/extend
23. Switch outrigger front right-hand side retract/extend
24. Switch outrigger beam front right-hand side retract/extend
25. Switch outrigger rear right-hand side retract/extend

MANUAL SPIERINGS TRUCK AT6
AT6-EN-061031.doc 2-11
26. Switch outrigger beam rear right-hand side retract/extend
27. Switch outrigger controls on/off
Switch off the outrigger control when the outriggers are not being operated. Also switch it off while
rigging up, rigging down or operating the crane. The remote control is also de-activated. Failing to
switch off the controls means the crane can not be operated over the full operating range (full support
base).
28. Indicator lamp head light
29. Indicator lamp dim light
30. Indicator lamp blinker left
31. Display automatic transmission
Indicates the automatic transmission mode.
32. Indicator lamp blinker right
33. Indicator lamp oil pressure diesel engine
34. Indicator lamp coolant level
35. Revolution counter
The revolution counter is fitted with an hour counter. On this counter you can read the the number of
operating hours of the diesel engine.
36. Mileage counter
The truck has a standard speed limiter (max. speed 85 km/h).
The total number of kilometres driven is shown on the counter at the bottom of the mileage counter
display.
