SPIERINGS SK375-AT3 User manual

SK375-AT3
Introduction
Truck
SPIERINGS MOBILE CRANES USER MANUAL V 0.0
© 2014 Spierings Mobile Cranes –All rights reserved.
Nov 2014 Changes and typographical errors reserved.
Introduction
Dear user,
This manual provides the user of the Spierings folding crane SK375-AT3 with information concerning the truck’s
construction, function and operation. Also detailed, technical descriptions and maintenance instructions are given in
the maintenance section of this manual.
© 2014 Copyright Spierings Mobile Cranes. All rights reserved.
No part of this publication may be reproduced or published, in any form or in any way, by print, photo print, microfilm or any other
means without prior permission from the manufacturer.
SPIERINGS MOBILE CRANES
P.O. Box 24
5340 AA OSS
The Netherlands
Merwedestraat 15
5347 KZ OSS
The Netherlands
Fax [phone]
Phone number daytime: [phone]
Phone number evening time: [phone]
www.spieringscranes.com

SK375-AT3
Liability clause
Truck
II SPIERINGS MOBILE CRANES USER MANUAL V 0.0
Nov 2014 Changes and typographical errors reserved.
© 2014 Spierings Mobile Cranes –All rights reserved.
Liability clause
This liability clause was added to prevent possible miscommunication.
ARTICLE 1. USE
The Spierings truck may only be used for the designated purpose, and in the manner as laid down/described in the
manual and possible additions thereto.
Any other than the designated use and/or any other manner of operation than laid down/described in this manual and
possible additions thereto, and/or action inconsistent with the previous, will explicitly invalidate any guarantee claim
as well as any liability for damage, consequential damage and future damage, by any reason and for no matter what.
Operating the Spierings truck is only permitted by people, who have the relevant expertise and a valid driving license
for driving a heavy truck, and who are physically and mentally capable of properly carrying out the work involved.
In case of the additions to the manual, the user/operator/driver of the Spierings truck must be notified thereof
immediately, and the additions must be added to the manual.
ARTICLE 2. SAFETY
For safety reasons, the user/operator/driver must strictly comply with the instructions in the manual and possible
additions thereto.
The user/operator/driver must keep strictly to the lifting specifications as indicated on the Spierings truck/crane, in the
manuals and the additions thereto.
If at any work site of the Spierings truck/crane the safety rules and regulations are more strict than those laid down in
the manual, or possible additions thereto, these stricter rules are to be complied with under penalty of expiry of the
guarantee and with exclusion of every liability.
The Spierings truck manufacturer explicitly warns the user/operator/driver and/or bystanders, to stay out of the
Spierings truck/crane's danger zone.
If any unexpected situation, by whatever cause, occurs during use and/or operation of the Spierings truck, please
contact your technical department or Spierings Service immediately.
ARTICLE 3. WARRANTY
Without previous written permission of the Spierings truck manufacturer, it is forbidden to carry out modifications
and/or welding at or on the Spierings truck.
Systematic maintenance and periodic inspections must be carried out according to the manual and possible additions
thereto.
Deviating from these instructions without prior written consent of the Spierings truck manufacturer 's, turns every
guaranty claim invalid as well as every liability for damage, consequential damage and future damage, by any reason
and for no matter what.

SK375-AT3
Explanation of the used symbols
Truck
SPIERINGS MOBILE CRANES USER MANUAL V 0.0 III
Nov 2014 Changes and typographical errors reserved.
Explanation of the used symbols
Information!
Toxic substances!
Wear safety glasses!
Dangerous for hands!
Wear safety gloves!
Do not come in turning radius!
Wear safety shoes!
Corrosive substances!
Wear a helmet!
Electric voltage!
Wear a safety harness!
Environmental hazard!
Check / test!
Caution!
Incorrect!
Danger of slipping!
Good!
Threat to circulation!
Conditions
Fire hazard!

SK375-AT3
Table of contents
Truck
IV SPIERINGS MOBILE CRANES USER MANUAL V 0.0
Nov 2014 Changes and typographical errors reserved.
© 2014 Spierings Mobile Cranes –All rights reserved.
Table of contents
Introduction
Liability clause ………………………………………………………………………………………………………………..… II
Explanation of the used symbols ..…………………………………………………………………………………………. III
Table of contents………………………………………………………………………………………………………………. IV
1. General data............................................................................................................................................... 1-1
1.1. Dimensions and weight ....................................................................................................................... 1-1
1.2. Drive line ............................................................................................................................................ 1-1
1.3. Steering.............................................................................................................................................. 1-2
1.3.1. Road steering........................................................................................................................... 1-2
1.3.2. Off-the-road steering ................................................................................................................ 1-2
1.4. Suspension......................................................................................................................................... 1-2
1.5. Braking system ................................................................................................................................... 1-2
1.6. 4-Point outrigger system...................................................................................................................... 1-2
2. Introduction to the truck............................................................................................................................... 2-1
2.1. Get to know the truck .......................................................................................................................... 2-1
2.2. Keys................................................................................................................................................... 2-2
2.3. Truck cab............................................................................................................................................ 2-3
2.3.1. Fuse box.................................................................................................................................. 2-4
2.3.2. Central console........................................................................................................................ 2-5
2.4. Engine cowling.................................................................................................................................... 2-7
2.4.1. Left-hand engine cowling.......................................................................................................... 2-9
2.4.2. Right-hand engine cowling........................................................................................................ 2-9
2.5. Outriggers..........................................................................................................................................2-10
2.6. Work lamps........................................................................................................................................2-11
2.7. Storage box.......................................................................................................................................2-11
2.8. Storage box fibre glass pads ..............................................................................................................2-11
2.9. Truck ladder.......................................................................................................................................2-11
2.10.Side view camera (optional)................................................................................................................2-11
3. Operating the truck...................................................................................................................................... 3-1
3.1. Doors.................................................................................................................................................. 3-1
3.2. Seats.................................................................................................................................................. 3-2
3.3. Wing mirrors ....................................................................................................................................... 3-5
3.4. Sun blinds........................................................................................................................................... 3-5
3.5. Storage room...................................................................................................................................... 3-5
3.6. Battery chargers remote control batteries............................................................................................. 3-6
3.7. Windscreen washer reservoir .............................................................................................................. 3-7
3.8. Fire extinguisher ................................................................................................................................. 3-7
3.9. Control panel ...................................................................................................................................... 3-8
3.9.1. Indicators................................................................................................................................3-21
3.9.2. Main screen ............................................................................................................................3-23
3.9.2.1. Main screen: General screen...................................................................................3-23
3.9.2.2. Main screen: Differential indication screen................................................................3-27
3.9.2.3. Main screen: Information screen..............................................................................3-28
3.9.3. Display gearbox ......................................................................................................................3-29
3.9.4. Malfunctions in the gearbox.....................................................................................................3-30
3.9.5. Keys control panel steering system..........................................................................................3-33
3.9.6. Malfunctions in het steering system..........................................................................................3-37
3.10.Signalling direction indicators .............................................................................................................3-40
3.11.Climate control...................................................................................................................................3-42

SK375-AT3
Table of contents
Truck
SPIERINGS MOBILE CRANES USER MANUAL V 0.0 V
Nov 2014 Changes and typographical errors reserved.
© 2014 Spierings Mobile Cranes –All rights reserved.
4. Driving........................................................................................................................................................ 4-1
4.1. General............................................................................................................................................... 4-1
4.2. Running-in the vehicle......................................................................................................................... 4-2
4.3. Before driving...................................................................................................................................... 4-4
4.3.1. CHECKLIST: Before driving on public roads.............................................................................. 4-4
4.3.2. CHECKLIST: Check vehicle lights............................................................................................. 4-6
4.4. Start diesel engine truck...................................................................................................................... 4-7
4.4.1. CHECKLIST: Start diesel engine............................................................................................... 4-7
4.4.2. CHECKLIST: Start diesel engine in cold environment ................................................................ 4-9
4.4.3. Instruments: Turn the truck on ignition....................................................................................... 4-9
4.4.4. Instruments: After starting the diesel engine.............................................................................4-10
4.4.5. Instrumentd: During driving......................................................................................................4-11
4.5. Switching gears..................................................................................................................................4-12
4.5.1. Gear lever...............................................................................................................................4-13
4.5.2. Rotary switch ..........................................................................................................................4-14
4.5.3. Automatic mode......................................................................................................................4-15
4.5.4. Manual mode..........................................................................................................................4-16
4.6. Driving off..........................................................................................................................................4-17
4.7. Driving backwards..............................................................................................................................4-18
4.8. Brakes...............................................................................................................................................4-19
4.8.1. Service brake..........................................................................................................................4-19
4.8.1.1. Anti blocking system................................................................................................4-19
4.8.2. Parking brake..........................................................................................................................4-20
4.8.2.1. Parking brake as an emergency brake.....................................................................4-21
4.8.3. Engine brake...........................................................................................................................4-21
4.8.4. Retarder..................................................................................................................................4-22
4.8.5. Bremsomat .............................................................................................................................4-23
4.9. Stop...................................................................................................................................................4-24
4.9.1. Turn off diesel engine..............................................................................................................4-24
4.9.2. Parking...................................................................................................................................4-24
4.9.3. Long-term parking / garaging...................................................................................................4-25
4.10.Speed regulators................................................................................................................................4-26
4.10.1.Cruise control..........................................................................................................................4-26
4.10.2.Variable speed limitation device...............................................................................................4-27
4.10.3.Engine speed control (ESC).....................................................................................................4-29
4.11.Uphill and downhill driving..................................................................................................................4-30
4.12.Refuelling ..........................................................................................................................................4-31
4.12.1.Refuelling diesel......................................................................................................................4-31
4.12.2.Refuelling Adblue....................................................................................................................4-32
4.13.Off-the-road driving............................................................................................................................4-34
4.13.1.Axle load.................................................................................................................................4-34
4.13.2.Axle height adjustment ............................................................................................................4-35
4.13.2.1. Axle blocking...........................................................................................................4-36
4.13.2.2. Off-the-road mode...................................................................................................4-37
4.13.2.3. Levelling .................................................................................................................4-38
4.13.3.Off-the-road gear.....................................................................................................................4-38
4.13.4.Differentials.............................................................................................................................4-39
4.13.4.1. Longitudinal differential lock.....................................................................................4-40
4.13.4.2. Transversal differential lock.....................................................................................4-40
4.13.5.Steering system ......................................................................................................................4-42
4.13.6.Manoeuvrering: gearbox..........................................................................................................4-43
4.14.Buffer beam.......................................................................................................................................4-44
4.15.Driving with an erected tower..............................................................................................................4-46
4.15.1.Conditions for driving with an erected tower..............................................................................4-47
4.15.2.Instructions for driving with erected tower.................................................................................4-49

SK375-AT3
Table of contents
Truck
VI SPIERINGS MOBILE CRANES USER MANUAL V 0.0
Nov 2014 Changes and typographical errors reserved.
© 2014 Spierings Mobile Cranes –All rights reserved.
4.16.Towing...............................................................................................................................................4-51
4.16.1.Towing with functioning diesel engine, service brake and steering system.................................4-52
4.16.2.Towing with a malfunctioning diesel engine..............................................................................4-53
4.16.2.1. Service brake when towing with malfunctioning diesel engine...................................4-54
4.16.2.2. Releasing the parking brake when towing with malfunctioning diesel engine..............4-55
4.16.3.Enabling transfer case to neutral position.................................................................................4-56
4.16.3.1. Remove drive shafts on output shafts of the transfer case ........................................4-56
4.16.3.2. Power-assisted steering ..........................................................................................4-56
4.16.4.Towing with damage to the transfer case..................................................................................4-57
4.16.5.Towing with damage to the driven axles...................................................................................4-57
5. Maintenance truck....................................................................................................................................... 5-1
5.1. When is the right time to thoroughly inspect your Spierings crane?....................................................... 5-1
5.1.1. Electronic component............................................................................................................... 5-1
5.1.2. Drive component of the crane................................................................................................... 5-1
5.1.3. Jib sections and towers ............................................................................................................ 5-2
5.1.4. Ty bars, A-frames, erecting cylinder and luffing cylinders........................................................... 5-2
5.1.5. Outrigger system...................................................................................................................... 5-2
5.2. Maintenance truck after commissioning................................................................................................ 5-3
5.2.1. First service truck..................................................................................................................... 5-3
5.3. Maintenance schedule truck................................................................................................................ 5-4
5.3.1. Maintenance schedule diesel engine truck ................................................................................ 5-5
5.3.2. Maintenance schedule drive line............................................................................................... 5-6
5.3.3. Maintenance schedule steering system..................................................................................... 5-6
5.3.4. Maintenance schedule electrical system truck ........................................................................... 5-6
5.3.5. Maintenance schedule lighting truck.......................................................................................... 5-7
5.3.6. Maintenance schedule hydraulic system truck........................................................................... 5-7
5.3.7. Maintenance schedule pneumatic system ................................................................................. 5-7
5.3.8. Maintenance schedule lubrication truck..................................................................................... 5-8
5.3.9. Maintenance schedule others truck........................................................................................... 5-8
6. Electrical system......................................................................................................................................... 6-1
6.1. Alternator............................................................................................................................................ 6-1
6.2. Batteries............................................................................................................................................. 6-2
6.2.1. Checking batteries.................................................................................................................... 6-2
6.2.2. Charging batteries.................................................................................................................... 6-3
6.2.3. Replacing batteries................................................................................................................... 6-3
6.3. Main switch......................................................................................................................................... 6-4
6.4. Fuses ................................................................................................................................................. 6-4
6.4.1. Fuses in the fuse box................................................................................................................ 6-4
6.4.2. Main fuses ............................................................................................................................... 6-5
6.4.3. Fuses in the control cabinet of the truck .................................................................................... 6-5
7. Lighting....................................................................................................................................................... 7-1
7.1. Low beam........................................................................................................................................... 7-2
7.2. DRL lighting (Daylight Running Lamps)................................................................................................ 7-3
7.3. Main beam.......................................................................................................................................... 7-4
7.4. Parking light........................................................................................................................................ 7-4
7.5. Direction indicator ............................................................................................................................... 7-5
7.5.1. Front direction indicator ............................................................................................................ 7-5
7.5.2. Side direction indicator ............................................................................................................. 7-6
7.5.3. Rear direction indicator............................................................................................................. 7-6
7.5.4. Direction indicators buffer beam................................................................................................ 7-7
7.6. Tail light.............................................................................................................................................. 7-7
7.6.1. Tail light truck........................................................................................................................... 7-7
7.6.2. Extra tail light on the tower........................................................................................................ 7-8
7.6.3. Tail light buffer beam................................................................................................................ 7-8

SK375-AT3
Table of contents
Truck
SPIERINGS MOBILE CRANES USER MANUAL V 0.0 VII
Nov 2014 Changes and typographical errors reserved.
© 2014 Spierings Mobile Cranes –All rights reserved.
7.7. Brake light........................................................................................................................................... 7-8
7.7.1. Brake light truck ....................................................................................................................... 7-8
7.7.2. Brake light buffer beam............................................................................................................. 7-8
7.8. Reverse drive light .............................................................................................................................. 7-9
7.8.1. Reverse drive light truck........................................................................................................... 7-9
7.8.2. Reverse drive light buffer beam................................................................................................. 7-9
7.9. Fog tail light........................................................................................................................................ 7-9
7.9.1. Fog tail light truck..................................................................................................................... 7-9
7.9.2. Fog tail light buffer beam .......................................................................................................... 7-9
7.10.Side marking lights.............................................................................................................................7-10
7.10.1.Side marking light truck ...........................................................................................................7-10
7.10.2.Side marking light buffer beam.................................................................................................7-11
7.11.Contour lights.....................................................................................................................................7-11
7.11.1.Front contour lights..................................................................................................................7-11
7.11.2.Rear contour light....................................................................................................................7-12
7.12.License plate lights.............................................................................................................................7-13
7.13.Rotaflares..........................................................................................................................................7-14
7.14.Work lamps........................................................................................................................................7-15
8. Hydraulic system......................................................................................................................................... 8-1
8.1. Hydraulic tank..................................................................................................................................... 8-1
8.1.1. Checking oil level ..................................................................................................................... 8-2
8.1.2. Topping up oil .......................................................................................................................... 8-2
8.1.3. Analysing oil............................................................................................................................. 8-2
8.1.4. Refreshing oil........................................................................................................................... 8-3
8.2. Hydraulic pumps................................................................................................................................. 8-3
8.3. Filters ................................................................................................................................................. 8-3
8.3.1. Replacing hydraulic fine filter .................................................................................................... 8-4
8.3.2. Replacing the hydraulic coarse filter.......................................................................................... 8-5
8.3.3. Replacing the hydraulic fine filter at rear axle steering................................................................ 8-6
9. Pneumatic system....................................................................................................................................... 9-1
9.1. Primary system: the brakes ................................................................................................................. 9-1
9.2. Secundary system............................................................................................................................... 9-2
9.3. Air dryer.............................................................................................................................................. 9-3
9.3.1. Replacing filter air dryer............................................................................................................ 9-3
9.4. Compressed air reservoirs................................................................................................................... 9-4
9.5. Oil atomizer / water separator.............................................................................................................. 9-4
9.5.1. Topping up oil atomizer ............................................................................................................ 9-5
9.5.2. Performance water separator.................................................................................................... 9-5
9.5.3. Replacing element water separator........................................................................................... 9-5
9.5.4. Adjusting air pressure secondary air circuit................................................................................ 9-5
9.6. Checking brake pressure..................................................................................................................... 9-6
9.6.1. Pressure brake boosters........................................................................................................... 9-6
9.7. Hoses and connections pneumatic system........................................................................................... 9-6

SK375-AT3
Table of contents
Truck
VIII SPIERINGS MOBILE CRANES USER MANUAL V 0.0
Nov 2014 Changes and typographical errors reserved.
© 2014 Spierings Mobile Cranes –All rights reserved.
10. Diesel engine truck.....................................................................................................................................10-1
10.1.Specifications diesel engine truck .......................................................................................................10-1
10.2.Engine oil diesel engine truck.............................................................................................................10-2
10.2.1.Checking oil level diesel engine truck.......................................................................................10-2
10.2.1.1. Checking oil level on the main screen ......................................................................10-3
10.2.1.2. Checking oil level by means of a dipstick..................................................................10-3
10.2.2.Topping up oil diesel engine truck............................................................................................10-4
10.2.3.Refreshing oil diesel engine truck.............................................................................................10-5
10.2.3.1. Draining oil..............................................................................................................10-5
10.2.3.2. Replacing oil filter element.......................................................................................10-6
10.2.3.3. Topping up oil .........................................................................................................10-6
10.3.Cooling system diesel engine truck.....................................................................................................10-7
10.3.1.Checking coolant level diesel engine truck ...............................................................................10-7
10.3.2.Topping up coolant diesel engine truck.....................................................................................10-8
10.3.3.Refreshing coolant diesel engine truck.....................................................................................10-9
10.3.4.Anti-freeze concentration.......................................................................................................10-10
10.3.5.Cleaning radiator diesel engine truck......................................................................................10-11
10.3.6.Air intake system diesel engine truck......................................................................................10-11
10.3.7.Cleaning air filter diesel engine truck......................................................................................10-12
10.3.8.Replacing air filter element diesel engine truck.......................................................................10-13
10.4.Fuel system diesel engine truck........................................................................................................10-13
10.4.1.Checking fuel system.............................................................................................................10-14
10.4.2.Fuel tanks.............................................................................................................................10-14
10.4.3.Fuel pre-filter / water-separator..............................................................................................10-15
10.4.3.1. Draining water separator .......................................................................................10-15
10.4.3.2. Replacing fuel pre-filter / water separator...............................................................10-16
10.4.4.Fuel filter diesel engine truck..................................................................................................10-17
10.4.5.Venting fuel system diesel engine truck..................................................................................10-19
10.5.EAS system.....................................................................................................................................10-20
10.5.1.AdBlue filter...........................................................................................................................10-21
10.5.2.Air filter / oil separator EAS system .......................................................................................10-22
10.6.Drive belts diesel engine truck..........................................................................................................10-23
10.6.1.Poly-V-belt steering shaft.......................................................................................................10-23
10.6.2.Poly-V-belt............................................................................................................................10-25
11. Drive line ...................................................................................................................................................11-1
11.1.Gearbox.............................................................................................................................................11-1
11.1.1.Specifications gearbox.............................................................................................................11-1
11.2.General maintenance gearbox............................................................................................................11-1
11.2.1.Checking oil level gearbox.......................................................................................................11-2
11.2.2.Refreshing oil gearbox.............................................................................................................11-3
11.2.3.Replacing oil filter retarder.......................................................................................................11-4
11.3.Transfer case.....................................................................................................................................11-6
11.3.1.General maintenance transfer case..........................................................................................11-6
11.3.2.Checking oil level transfer case................................................................................................11-7
11.3.3.Refreshing oil transfer case .....................................................................................................11-8
11.4.Axles .................................................................................................................................................11-8
11.4.1.Axle configuration....................................................................................................................11-9
11.4.2.Checking oil level differentials..................................................................................................11-9
11.4.3.Refresh oil differential............................................................................................................11-10
11.4.4.Checking oil level axle hubs...................................................................................................11-11
11.4.5.Refreshing oil axle hubs.........................................................................................................11-12
11.5.Tyres...............................................................................................................................................11-13
11.5.1.General maintenance ............................................................................................................11-13
11.5.2.Tyre pressure........................................................................................................................11-13
11.6.Brake linings....................................................................................................................................11-14
11.6.1.Checking brake linings...........................................................................................................11-14

SK375-AT3
Table of contents
Truck
SPIERINGS MOBILE CRANES USER MANUAL V 0.0 IX
Nov 2014 Changes and typographical errors reserved.
© 2014 Spierings Mobile Cranes –All rights reserved.
12. Steering system.........................................................................................................................................12-1
12.1.Steering modes..................................................................................................................................12-1
12.1.1.On-the-road mode...................................................................................................................12-2
12.1.2.Off-the-road mode...................................................................................................................12-2
12.2.Steering mechanisms.........................................................................................................................12-2
12.3.Performance steering system .............................................................................................................12-2
12.3.1.Steering circuits.......................................................................................................................12-3
12.3.1.1. Steering circuit 1 .....................................................................................................12-3
12.3.1.2. Steering circuit 2 .....................................................................................................12-3
12.3.1.3. Rear axle steering...................................................................................................12-3
12.4.Maintenance steering system .............................................................................................................12-4
12.4.1.Checking steering system........................................................................................................12-4
12.4.2.Aligning...................................................................................................................................12-4
13. Lubrication.................................................................................................................................................13-1
13.1.Automatic lubrication system truck......................................................................................................13-1
13.1.1.Grease pump..........................................................................................................................13-1
13.1.2.Timer......................................................................................................................................13-2
13.1.3.Lubrication points central lubrication system.............................................................................13-3
13.2.Manual lubrication truck......................................................................................................................13-4
13.2.1.Retractable cylinders outrigger beams......................................................................................13-4
13.2.2.Drive shafts.............................................................................................................................13-4
13.2.3.Steering system ......................................................................................................................13-5
13.2.4.Tower support.........................................................................................................................13-5
14. Specifications truck....................................................................................................................................14-1
14.1.Specifications diesel engine truck .......................................................................................................14-1
14.2.Maintenance specifications diesel engine truck ...................................................................................14-2
14.3.Specifications drive line......................................................................................................................14-2
14.3.1.Specifications gearbox.............................................................................................................14-2
14.3.2.Specifications transfer case.....................................................................................................14-3
14.3.3.Specifications axles / brakes / tyres..........................................................................................14-3
14.4.Specifications electric system truck.....................................................................................................14-3
14.5.Specifications hydraulic system truck..................................................................................................14-4
14.6.Specifications pneumatic system truck................................................................................................14-4
14.7.Specifications lubricants truck.............................................................................................................14-4
15. Annexes ....................................................................................................................................................15-1

SK375-AT3
Table of contents
Truck
X SPIERINGS MOBILE CRANES USER MANUAL V 0.0
Nov 2014 Changes and typographical errors reserved.
© 2014 Spierings Mobile Cranes –All rights reserved.

SK597-AT4
General data
Truck
SPIERINGS MOBILE CRANES USER MANUAL V 0.3 1-1
Jun 2016 Changes and typographical errors reserved.
© 2016 Spierings Mobile Cranes –All rights reserved.
1. General data
De AT3-truck carriage is especially designed for the Spierings SK375 folding crane. Extra attention is
paid to a safe and comfortable transport to the work site. Thanks to the rear steering, the AT3 is
extremely manoeuvrable. The crane is suited for driving on public roads, fully equipped with
counterweight and tools. The chassis is a specially rigid structure to create a good crane support.
Picture 1-1 shows the measurements of the SK375-AT3 with the AT4-carriage.
The measurements given are the overall dimensions, axle bases and turning circle (see also picture in
the Annexes).
1.1. Dimensions and weight
Length: 12.80 m;
Width: 2.60 m;
Height: 4 m;
Mass: approx. 36,000 kg (complete vehicle);
Axle load: approx. 12,000 kg.
1.2. Drive line
9.2 litre DAF diesel engine with turbo compressor and intercooler (PR265);
ZF AS-Tronic automatic transmission with retarder, 12 forward gears and 2 reverse gears;
STEYR transfer case (VG1600/300) with high speed (road) and low speed (off the road)
transmission;
Electronic accelerator;
3x GINAF axles, of which axles 1 and 3 are driven;
Maximum speed limited at 83 kph (52 mph);
Minimum speed at 1,000 rpm diesel engine 1.8 kph (1.12 mph) (30 m/min).
Picture 1-1

SK597-AT4
General data
Truck
1-2 SPIERINGS MOBILE CRANES USER MANUAL V 0.0
Nov 2014 Changes and typographical errors reserved.
© 2016 Spierings Mobile Cranes –All rights reserved.
1.3. Steering
Axle 1 is mechanically steered with the steering wheel; axle 2 remains rigid, axle 3 is hydraulically
steered;
The steering system is hydraulically powered by means of a steering gear housing and auxiliary
cylinders;
The steering system is fitted with an emergency steering pump, so in case of main control pump
malfunction or diesel break-down, the truck remains steerable until it stands still.
For more information, see § 3.9.5. Keys control panel steering system and
Chapter 12. Steering system.
1.3.1. Road steering
Axle 1 is mechanically steered with the steering wheel; axle 2 remains rigid, axle 3 is hydraulically
steered and steers speed-dependent in opposite direction till 50 kph (31 mph).
1.3.2. Off-the-road steering
Provisions for driving off the road:
Adjustable axle height;
Transfer case with off-the-road gear;
Longitudinal and transverse differentials can be locked.
1.4. Suspension
Hydro-pneumatic suspension;
Possibility to block the suspension (e.g. when driving with erected tower).
1.5. Braking system
Pneumatically operated brakes with anti-blocking system (ABS);
Parking brake;
Retarder.
1.6. 4-Point outrigger system
Full outrigger support base (wide): 6.90 m x 5.80 m;
Reduced outrigger support base (narrow): 6.90 m x 4.20 m.

SK597-AT4
General data
Truck
SPIERINGS MOBILE CRANES USER MANUAL V 0.3 1-3
Jun 2016 Changes and typographical errors reserved.
© 2016 Spierings Mobile Cranes –All rights reserved.
Identification
Vehicle identification number (VIN):
On the identification plate at the passenger side (on the left side of the door pillar)
(Picture 1-2,left);
Stamped in the right-hand frame girder in front of the first axle (Picture 1-2,right).
In case there is help needed from ITS (International Truck Service of DAF Trucks N.V.), the chassis
number will be asked.
However, for Spierings cranes it is not the chassis number that is needed. ITS needs the engine
number, which is listed on the UPEC chart and can be found underneath the cover plate of the central
console in the truck cabin.
International Truck Service
Phone number in Europe [phone]
Picture 1-2

SK597-AT4
General data
Truck
1-4 SPIERINGS MOBILE CRANES USER MANUAL V 0.0
Nov 2014 Changes and typographical errors reserved.
© 2016 Spierings Mobile Cranes –All rights reserved.

SK375-AT3
Introduction to the truck
Truck
SPIERINGS MOBILE CRANES USER MANUAL V 0.3 2-1
© 2014 Spierings Mobile Cranes –All rights reserved.
Jun 2016 Changes and typographical errors reserved.
2. Introduction to the truck
2.1. Get to know the truck
A. Truck cab (see § 2.3. Truck cab);
B. Work lamps (see § 2.6. Work lamps);
C. Outriggers (see § 2.5. Outriggers);
D. Left-hand engine cowling (see § 2.4.1. Left-hand engine cowling);
E. Crane platform;
F. Truck ladder (see § 2.9. Truck ladder);
G. Storage box fibre glass pads (see § 2.8. Storage box fibre glass pads);
H. Storage boxes (see § 2.7. Storage box);
I. Battery cabinet;
J. Superstructure slewing rim;
K. Filler neck fuel tank (see § 2.5. Outriggers);
L. Auxiliary rod jib turning;
M. Buffer beam;
N. Rear toolbox (optional);
O. Filler neck AdBlue tank;
P. Right-hand engine cowling (see § 2.4.2. Right-hand engine cowling);
Q. Side view camera (optional) (see § 2.10. Side view camera (optional)).
Picture 2-1
A
B
C
D
E
F
G
H
I
J
K
C
L
M
B
C
K
H
G
F
C
N
O
P
Q

SK375-AT3
Introduction to the truck
Truck
2-2 SPIERINGS MOBILE CRANES USER MANUAL V 0.0
Nov 2014 Changes and typographical errors reserved.
© 2014 Spierings Mobile Cranes –All rights reserved.
2.2. Keys
A. Door key;
B. Ignition key truck;
C. Ignition key crane;
D. Key hatch crane cab;
E. General key:
- Electrical cabinet;
- Control panel control cabinet;
F. Key fuel tank;
G. Key operated selector switch:
- Key operated selector switch full / reduced outrigger base;
I. Cross key:
- Left-hand and right-hand cover of engine cowling truck;
- (Sliding) doors rear toolbox and side boxes;
- Removable cover plates engine cowling;
L. Cross key control cabinet truck:
- Control cabinet truck (for the benefit of suspension system and outrigger base).
Picture 2-2

SK375-AT3
Introduction to the truck
Truck
SPIERINGS MOBILE CRANES USER MANUAL V 0.3 2-3
© 2014 Spierings Mobile Cranes –All rights reserved.
Jun 2016 Changes and typographical errors reserved.
2.3. Truck cab
A. Door handle with lock;
B. Door;
C. Driver’s seat (see § 3.2. Seats);
D. Wing mirrors (see § 3.3. Wing mirrors);
E. Spirit level;
F. Battery charger remote control batteries (see § 3.6. Battery chargers remote control
batteries);
G. Steering wheel;
H. Control panel (see § 3.9. Control panel);
I. Windscreen wipers (see § 3.9. Control panel, 42. Control lever left);
J. Fuse box (see § 2.3.1. Fuse box);
K. Windscreen washer reservoir (see § 3.7. Windscreen washer reservoir);
L. Co-driver’s seat (see § 3.2. Seats);
M. Fire extinguisher (see § 3.8. Fire extinguisher);
N. Central console (see § 2.3.2. Central console);
O. Cup holder;
P. Main switch truck (see § 3.9. Control panel, 54. Main switch truck).
Picture 2-3

SK375-AT3
Introduction to the truck
Truck
2-4 SPIERINGS MOBILE CRANES USER MANUAL V 0.0
Nov 2014 Changes and typographical errors reserved.
© 2014 Spierings Mobile Cranes –All rights reserved.
2.3.1. Fuse box
The fuse box is located at the co-driver’s side of the truck cab under the cover of the dashboard.
Open fuse box
1. Remove the two turning knobs at the front of the cover;
2. Open the cover; the cover can befixed by means of support A (Picture 2-4).
Under the cover, the following components can be found:
A. Support;
B. Circuit board with fuses and relays;
C. Overview fuses;
D. Control module steering system.
Picture 2-4
A
B
C
D

SK375-AT3
Introduction to the truck
Truck
SPIERINGS MOBILE CRANES USER MANUAL V 0.3 2-5
© 2014 Spierings Mobile Cranes –All rights reserved.
Jun 2016 Changes and typographical errors reserved.
2.3.2. Central console
The central console (Picture 2-5 and Picture 2-6) situated between the driver's seat and the co- driver's
seat.
Central console at driver’s side
A. Pressure gauge oil pump;
B. Cigarette lighter;
C. Diagnostic connector OBD (On Board Diagnostics) for diagnosis of the full drive line
consists of (Picture 2-5):
- Diesel engine truck;
- Gearbox;
- Retarder;
- Anti-blocking system (ABS);
- Dashboard.
Picture 2-5
A
B
C

SK375-AT3
Introduction to the truck
Truck
2-6 SPIERINGS MOBILE CRANES USER MANUAL V 0.0
Nov 2014 Changes and typographical errors reserved.
© 2014 Spierings Mobile Cranes –All rights reserved.
Central console at co-driver’s side
The central console at the co-driver’s side consists of (Picture 2-6):
D. Diagnostic connector steering system;
E. Buckle clusure;
F. Power socket 230 V (voltage only at running crane generator);
G. 12 V connector;
H. Switch electrically operated window at co-driver’s side.
Remove cover central console
1. Open buckle closure C at the co-driver’s side (see Picture 2-6);
2. Take the cover at the window side and tilt it upwards;
3. Slide the cover horizontally from the hinge pins towards the passenger side.
D
E
F
G
H
Picture 2-6
