Spon NAS-8505L User manual

Basic functions
With a compact and a wall-mounted design to save space.
Adopt high-speed industrial dual core (ARM+DSP) chip, start time ≤1s
Built in digital amplifier with 2X10W or 2X30W power (8Ω) output
Status indicator light real -time displays status of all terminals ( online, offline, or task status)
With 1 alarm input/ output interfaces
Support configuration remotely and upgrading online.
With a standard RJ45 interface, access is available where there is an Ethernet port.
Audio functions
With 1 analog audio input with local volume adjustment knob, and 1 line output to connect amplifier
Additional functions
Optional: wireless transceiver module and 2.4G wireless vod microphone (NCS-3073) :
The wireless transceiver module and 2.4g wireless VOD microphone can automatically pair on and
operate at ISM channel 2400-2483mhz.
Realize local sound system via built-in MIC of wireless VOD microphone or headset
Use 3.5-inch stereo interface of wireless vod microphone to amplify the audio played by mobile phone;
Through the wireless microphonecan broadcast announcement to other terminals and call the main
control room for two-way intercom;
Wireless vod microphone comes with 2-inch OLED display screen, Chinese and English vod cata-
logue and current task information, through the control button, vod server program library any content,
can control play/pause, fast forward/fast back, a-b repeat reading, flexible and simple operation.
The volumn can be adjusted on the wireless microphone.
Standard microUSB port charging (compatible with mobile phone charger), standby time is about 36
hours, and sound amplification is about 8 hours.
NAS-8505L
IP AUDIO INTERCOM TERMINAL
MAIN FUNCTIONS
IP Audio Intercom Terminal

NAS-8505L
Audio
Speaker
Amplifier
Network
System
integration
General
SPECIFICATIONS
IP Audio Intercom Terminal
one-way/two-way, mono
PCM、ADPCM
Line input
20Hz-16KHz
/
/
/
/
2*10W\2*30W
Password protection
IPv4/v6, TCP, UDP, IGMP, ARP,ICMP
Support for SIP protocol to realize network transmission of audio
and PBX
/
/
2×10W or 2×30W
≤24W\≤70W
It can be realized the broadcast , alarm, and other functions with
XC-9000 software.
Black
Steel
/
/
/
DC24V 1A（20W）\DC 24V 2.7A（60W）
1 X RJ45, 1 X line input, 1 X power output, 1 X alarm input, 1 X
alarm output.
Designed for 24/7 operation
–10 °C ~ 50 °C
– 40 °C ~60 °C
3C
132*36*156.5mm
0.5Kg（20W）\ 0.6Kg（60W）
Wiring terminal （3.81-4P）2PCS, half round head self tapping
screw 4 PCS，plastic expansion sleeve 4 PCS (F7), installation
manual 1 PCS, certificate and warranty card 1 PCS, power adaptor
1 PCS （DC24V 1A\DC24V 2.7A), antenna 1PCS (only equipped
with 2.4G wireless module terminal)
/
/
Simplified Chinese, English
1 Years
Audio streaming
Audio compression
Audio input
Frequency response
Speaker component
Max SPL
Frequency response
Sensibility
Built-in amplifier
Security
Supported protocols
Voice announcement
VoIP
Intelligent detection
DC
Power consumption
Event actions
Shell color
Shell material
Grille material
Grille surface treatment
Memory
Power
Interface
Reliability
Operating conditions
Storage conditions
Approvals
Dimensions
Weight
Included accessories
Optional accessories
Software
Languages
Warranty

INSTALLATION
①Amplifier output interface: Internal power amplifier output port, it offer two way
power amplifier output, it can output from amplifier when the terminal is receiving
broadcasting or playing the background music. When the terminal power is 20W,
amplifier output 2*10W; when the power is 60W, amplifier output 2*30W.
②Alarm input/output interface:
G-A: alarm input interface, it can trigger the NandFlash card built-in ShortIN folder
audio playing when it`s closed. when the two pins are short circuited, the audio
terminal will automatically make some special operation (eg: generate an alarm
signal and sent to the server or send the alarm from local terminal etc) . Alarm
button, short circuit signal generator all these devices all can access to this port;
O-1: alarm output interface, alarm output is triggered by server software, it also
triggered by alarm input or shutoff signal to play the alarm function (eg: open the
electronic lock door). Alarm output port the maximum loaded current is 1A, the
highest
voltage is AC100V(or DC24V).
③The volume adjustment knob: used for line input volume adjustment, clockwise
for up, anticlockwise for down.
④Forced upgrade or play device IP button When the terminal without power on,
press button by tweezers or pin, then power on till 5 seconds, so that it will enter
into upgrade status ( press this button can voice play the terminal IP and subnet
mask information in free status).
⑤Line input interface: it can connect the external analog sound source (eg:
dynamic microphone, computer...etc) to this port.
⑥Line output interface: this port output the restored audio signal; It can used as a
sound source access to the active speakers, audio pre-amplifier, sound console,
audio amplifier device...etc.
⑦Network interface: this port connect with Ethernet by cables.
⑧STATE: status light
If the terminal is upgrading firmware, the status light is flashing in red and green; If
the terminal is not login or required to login, the status light is flashing in red. If the
terminal logined server and in free status, the status light is normal green on; If
the terminal logined server and is executing the task, the status light is flashing in
green.
⑨The power interface: connect 24V power DC power supply.
⑩ANT: antenna interface
IP Audio Intercom Terminal

WIRING
APPLICATION
Application 1
Application 2
IP audio terminal NAS-8505L built-in 2*10W/2*30W class D digital constant resis-
tance (8Ω output)amplifier , can receive broadcast task initated by server software
NAS-8500/XC-9000、IP paging microphone(NAS-8502)、SIP phone(Requires
XC-9000), at the same time output to speaker and line out interface,the line out inter-
face can connect with amplifier ,which is used in large-scale sound amplification
occasions.
Application 3
The IP audio terminal NAS-8505L has an alarm input and output interface, which can
be linked with peripheral equipment, such as alarm input connected with alarm
button, alarm output connected with electronic door lock. When the alarm button is
pressed, it will trigger the IP network audio terminal NAS-8505L to play the preset
audio file, and control the door lock to close.
IP audio terminal NAS-8505L with line in interface , can connect with PC 、DVD for
local sound amplification.
IP Audio Intercom Terminal

Application 4
The IP network audio terminal NAS-8505L can be optionally equipped with a wireless
transceiver module. With the wireless microphone (NCS-3073), it can be used for
teaching sound reinforcement and intercom between the teacher and the control
room.
IP Audio Intercom Terminal

IP audio terminal NAS-8505L is suitable for wall-mounted installation , use 4 plastic
expansion sleeves (F7) and 4 semi-round head tapping screws (M4 * 25) provided
with the equipment , refer to the installation dimensions below to fix the device on the
wall.
