Bilanciai D410 User manual

ENGLISH
Code 81320347 - 1/1/2010 WEIGHING TERMINAL QUICK START
D410
2. Display and keyboard
1. Unpacking and Installation
Stable weight Center zero
Tare Tare entered
via keyboard
Gross weight Gross weight
in pounds
Minimum
weight Net weight
Weighing range
indication
Below-range
weight indica-
tion
Within-range
weight indica-
tion
Above-range
weight indica-
tion
Weight reset Tare entry and
cancellation
Tare entry and
display
Printing and/or
transmission
start
Customizable
keys Enter
Alphanumeri-
cal keys and
symbols
I on
O off
*Not included
Remove terminal
from pack along with
the CD containing
the instructions.
Connect in
sequence.
A. Weighing plat-
form.
B. Any peripheral
equipment used
(e.g.: print-
ers, additional
displays, etc.).
C. Optional outputs
(e.g.: Ethernet,
WI-FI, I/O, BCD,
R232/422/485).
D. Analog output.
E. I/O connection.
F. Mains power
socket. Check
voltage value on
data plate.
Press button Ito
turn the terminal
on.
Press button Oto
turn the terminal
off.
85-265 Vac
50/60 Hz
BAF
ON/OFF
A C F
B
D E
*
*
...

3. Weighing with tare entry 5. Setup
Società Cooperativa Bilanciai Campogalliano - 41011 Campogalliano (MO) Italy
Via S. Ferrari, 16 - Tel. [phone] - Fax [phone]
Web: http://www.coopbilanciai.it - E-mail:[email protected]
Customer Assistance Service Tel. [phone] - Fax [phone]
DECLARATION OF CONFORMITY
N° D410_100101
SOCIETÀ COOPERATIVA BILANCIAI A.R.L.
We: Via S. Ferrari, 16
41011 Campogalliano (MO)- Italy
hereby declare under our responsibility that
the product: Electronic weighing terminal D410
and its optional equipment
described in this declaration conforms to the following
Directive EMC 2004/108/EEC
directives: Electrical Safety Directive 2006/95/EC
Weighing Instrument Directive 2009/23/EEC
Conformity is guaranteed by compliance with the following
EN 61000-6-3, EN 61000-6-4
standards: EN 60950
EN 45501
The terminal is also suitable for the creation of non-automatic weigh-
ing instruments approved with the "CE Type Approval Certificate" in
conformance with the requirements of Directive 2009/23/EEC (for-
merly 90/384).
The product bears CE marking.
Campogalliano, this day ............................
Division Management
Franco Brighenti
WARNINGS
Do not install in places with potentially explosive gas or
dust;
• This electrical or electronic device cannot be disposed of
as solid urban waste.
• It must be disposed of separately.
Consult the Operation, Maintenance and Installation instruc-
tions in the CD for further information.
SOCIETÀ COOPERATIVA
BILANCIAI
Weighing Instruments and Technologies
1-1-2010
1
2
3
4
5
6
Reset the terminal.
Load the empty container
(tare)
Acquire the tare
Load the product
Read the net weight
Print or transmit the data to
the PC
Main menu items ...>MENU>...
>Data management>...
>Totals Management>...
Generic code, product and general or
partial totalizing archive management
>MPP mode Permanent weight Memory Mode
>Display (DISPL) Character height and display type setup
>Contrast (CONTR) Adjusts the contrast
>Memory status Use of the vacant data store
>Reprint Last tag
>Date Time (DATETIM) Adjusts the date and time
>Reprint Repeats the last printout
>Memory status Clears the data store
>Diagnostics (only for
digital scales)
Identifies the cause of errors in digital
scales
Main menu items ...>MENU>Data Management...
>Code Management Generic, Product, Product Code ist
>Range (RANGE) Settings
>Set Point (SETPNT) Settings
>MPP data item display With MPP memory
>Preset tare With tare archive enabled
>Consecutive Consecutive number of the weighing operations performed
>Coefficient management Value and operation
4. Menu browsing
Allowthe user to browse in the program-
ming menus
Accesses the menu. The next item
required is selected with the other keys.
Up to 6 functions are available on the
shortcut key bar.
Switches to other functions controlled by the terminal.
Up, down, right and left
Selects the required item or accesses a
submenu
Unabbreviated path, path given in numbers
Goes back to the previous menu level
Press twice to go back to the weight display
mode
2°F
OTHER
SELEC
# \\
ESC
