HOW TO USE THE ORAL IRRIGATOR ? (Figure 1)
1 - Remove the water tank (3). When removing water tank use
one hand to firmly hold the base of the unit (1) in place, and with
the other hand, lift the water tank straight up. Fill with lukewarm
water and add mouthwash solution if you want. Reinstall the
water tank onto the unit.
Note : Prior to initial use, rinse the unit by letting a full water tank
of water pass through it. If the unit is used with a mouthwash
solution, it should be rinsed with clean water after each use to
remove any traces of mouthwash. If the unit has not been used
for an extended period of time, to maintain hygiene it is
recommended that you follow the directions for initial use,
letting a full water tank of water pass through.
2 - Select an irrigator tip for your personal use (6). Lift the
irrigator handle out of the base and attach the irrigator tip to the
irrigator handle. (Figure 2).
3 - Adjust the pressure control (2) on the base unit to minimum
pressure (position 1) for first-time use. Increase the pressure over
time using position 2 or 3.
4 - Before turning the unit on, check that the ‘water stop’ (4)
switch on tthe irrigator handle is in the ‘off’ position (away from
the tip). After turning the unit on by pressing the ‘on/off’ (7) but-
ton on the base unit, lean over the sink and position the tip in your
mouth. Move the water stop switch to on (towards the tip) to
begin the cleaning process.
Note : Keep your mouth slightly open and hold your elbow at
mouth level so that the water can run back into the sink
.
5 - Direct the flow along the gumline (Figure 3) and also between
your teeth. Do not point the irrigator tip directly at your gums. For
best results, begin with your back teeth and work forward. Consult
your dental professional for further recommendations on use.
6 - When finished, move the ‘water stop’ switch to the off position
and turn off the unit. Remove the irrigator tip and replace in the stor-
age. Empty any liquid remaining in the unit. Unplug the unit.
Note : NEVER leave the unit on when not in use. Water pressure
will continue to build and may cause damage to the unit. ou must
turn the water stop switch and the power switch to the “O”
position when not in use.
CLEANING AND AINTENANCE
1 - After use, empty any liquid remaining in the unit.
Note : If the unit is used with a mouthwash solution, a full water
tank of water should be run through after each use to rinse it and
remove any traces of mouthwash.
2 - Rinse the irrigator tip and the irrigator handle separately for
several seconds under running water.
Note : Be sure to point the irrigator handle downward
(upside down) when rinsing.
Do not allow water to drain into the irrigator handle.
3 - After cleaning, place the irrigator tip back in the
storage and the irrigator handle on the base. Unplug the unit.
4 - Clean the base periodically with a soft cloth or paper towel.
The base must be dry before plugging it into an electrical outlet.
EDICAL SAFEGUARDS
Please note the following safeguards for your continued safety.
Similar to starting any new oral hygiene product, contact your
dentist before using Oral Irrigator if you had oral or
periodontal surgery.
Contact your dentist if excessive bleeding occurs or if bleeding
continues after 2 weeks.
CONNECTING THE UNIT TO A POWER SOURCE
Plug the cord into any standard electrical outlet. If a wall switch
controls the outlet, be sure it is turned on.
Caution
The supply cord cannot be replaced. If the cord is damaged the
appliance should be scrapped.
Check the cord occasionally for any damage. Should this be the
case, unplug the charging unit immediately and take it to a
service centre. our service centre will replace the complete
charging unit. The charging unit cannot be repaired for safety
reasons.
A damaged or non-functioning unit may no longer be used.
CE - (EMC:2004/108/CE)
- (LVD:2006/95/CE)
RoHs (2002 /95 /EC) : This product is manufactured without
materials which could have a harmful effect on ecology.
DESCRIPTION
1 - base
2 - pressure control
3 - tank
4 - “water stop” button
5 - storage
6 - 4 irrigating heads
7 - on/off button
INSTRUCTION ANUAL
PRECAUTIONS OF USE IN ELECTRICAL APPLIANCE
CONTEXT :
During the use of electrical appliance, it is necessary to respect some
security instructions in order to avoid any accident. Please read
carefully the instruction manual before using the apparatus, and store
it somewhere safe for any future need.
It is recommended to use the appliance on a electrical
installation using a differential with nominal current loss which
doesn’t exceeds 20m A.
- Before starting your dental jet, please read carefully the
following instructions. They contain important information
concerning the use, the safety and the maintenance of your
apparatus.
- Please store this instruction manual somewhere safe for any
future need.
- Please refer to the explanatory figures while reading this manual.
- Only use this with AC current 230 V, check before
connecting your device that the tension of your electrical network
corresponds to the one mentioned on your product. The device
should be connected only on one electrical supply network whose
installation is in conformity with the standards of safety.
- Always disconnect and switch off your device in the following
cases : in the event of anomaly during use, before any cleaning
or maintenance, and after use.
- Do not let hang the cord on the edge of a table, on sharp surfaces
or to come into contact with hot surfaces.
- Keep the apparatus away of heat sources.
- Use a extension for your cord only if it is suitable and in perfect
state.
- Never disconnect while pulling on the cord.
- Children do not recognize the dangers emanating from an
electrical appliance.Do not leave the apparatus under operation
within the range of children.
- Never immerse the apparatus in water or in others liquidate.
- Do not use the apparatus outside.
- Do not pose the apparatus when it is under operation.
- Do not use accessories other than those provided with your
apparatus, a danger could result from it. Disconnect the socket
when you do not use your apparatus, before mounting or to
dismounting the accessories or before any cleaning.
- Simply clean the apparatus using a dry or slightly wet rag. Do
not use metal sponges or abasiv products for cleaning.
- Do not make function the apparatus in presence of explosives
or of fumes.
- CAUTION : o avoid any risk of fire or electrocution, not
to dismount the apparatus.
Any intervention or repair must be carried out by an
approved repairer.
- Do not use your apparatus, disconnect it or do not connect it
immediately if :
- it is damaged
- the electrical cord or the socket is damaged
- you noticed an abnormal fonctionning after incident
- Non-professional fix-ups can be at the origin of dangers to the user.
- If the electric cable is damaged, it must be replaced by the
Manufacturer, his After-sales service or a person with similar
qualification, in order to avoid any danger.
- our apparatus is planned for domestic use. A non-adequate
use and non-conform to the instructions cancels the guarantee
and cannot engage the responsibility of the manufacturer.
- Avoid using the apparatus in a damp room.
- TOANY DETERIORATION RESULTING FRO THE
NON-APPLIANCE OF THESE PRECAUTIONS OF USE
AUTO ATICALLY SUPPRESSES THE GUARANTEE
SAVE THESE INSTRUCTIONS
USA
TECHNICAL FEATURES :
Power sector : 230 V - 50 Hz
Power : 46 W
Protection index : IPX7
CE
6
1
2
3
4
5
6
7
Fig 1 Fig 2
Fig 3
