Bedienungsanleitung
AIREX Lager-/Transportwagen
Stand-Alone

AIREX –Mat rack / Assembling manual
Step 2
Tighten the reinforcing frame and both precasted
rods and connecting pieces +on the base plate.
(bolts M6 x 25mm with shim M6)
Please take care that you hold the bolts strictly
horizontal. They could easily deform. We advise you
to do this assembling with another person.
It is important to bolt the precasted rods on the
longer sides of the base plate. Otherwise, the
whole construction becomes awry.
Step 3
Now connect the holder with the rods on both sides.
We use the matholder-poles and twist them into the
thread. Afterwards we put on the struts with the
16mm-bolts and the rosettes.
Necessary tools
Allen key size 4 and 5
Material

4 pcs. M6x25 cheese head

rods (4 pcs.)

4 pcs. Shim M6

connecting piece (2 pcs.)

4 pcs. M6x16 counter sunk

matholder-poles (4 Stk.)
4 pcs. rosette M6 strut (2 pcs.)

reinforcing frame (1 pc.)

holder with

base plate with 4 wheels (1 pc.)
AIREX –Logo (2 pcs.)











Step 1
According to the pictures below unpack
the material and bolt the rods +
together as strong as possible
