Sportline ThinQ XA 305 User manual

ThinQ XA
PEDOMETER
model 305
WV4748IS01SPT.indd 1WV4748IS01SPT.indd 1 3/20/14 12:24 PM3/20/14 12:24 PM

TABLE OF CONTENTS
INTRODUCTION 1
HOW TO USE THIS MANUAL 2
REMOVING THE BATTERY INSULATOR TAB 3
WARNINGS & CAUTIONS 4
PEDOMETER FUNCTIONS 5
HOW TO WEAR YOUR PEDOMETER 6
KEYS AND THEIR FUNCTIONS 7
MAIN OPERATING MODES 8
SETTING THE PEDOMETER FUNCTIONS
SETTING TIME 9
SETTING USER DATA 10
OPERATING THE PEDOMETER
VIEWING PEDOMETER DATA 11
RESETTING PEDOMETER DATA 12
TIPS FOR INCREASING YOUR DAILY STEPS 13
REPLACING THE BATTERY 14
CARE & MAINTENANCE 15
RANGES & SPECIFICATIONS 16
WARRANTY 17
WV4748IS01SPT.indd Sec1:1WV4748IS01SPT.indd Sec1:1 3/20/14 12:24 PM3/20/14 12:24 PM

1
ThinQ XA
INTRODUCTION
Congratulations on your purchase of a Sportline ThinQ XA Pedometer. The ThinQ XA
Pedometer features the Infinity Motion Sensor, a highly advanced pedometer technology
that accurately measures your body movements from multiple locations on the body and in
multiple orientations.
Please keep in mind your pedometer is a sensitive technical instrument. With proper care
and maintenance, it will last for many years. However, improper care and handling can cause
the various sensors to be damaged and to stop functioning.
WV4748IS01SPT.indd Sec2:1WV4748IS01SPT.indd Sec2:1 3/20/14 12:24 PM3/20/14 12:24 PM

2
Sportline ThinQ XA Pedometers have many unique features and functions. Please read all
sections of this manual carefully and become familiar with the operation of the pedometer
before using it in the field.
Proper setup and operation will greatly enhance the pedometer’s usefulness and your
enjoyment of the product.
The manual is divided into sections outlining each of the major functions of the pedometer.
A drawing of the screen that represents a starting point or other important point for each
operational process is shown adjacent to the instructions; important keys are shown
indicating PRESS & HOLD and PRESS.
The steps for the programming or operation are adjacent to the screen illustration. Key points
and important information are shown in highlighted blocks.
HOW TO USE THIS MANUAL
WV4748IS01SPT.indd Sec2:2WV4748IS01SPT.indd Sec2:2 3/20/14 12:24 PM3/20/14 12:24 PM

3
ThinQ XA
NOTE: In order to activate your pedometer after purchase, you must remove the battery
insulator tab inside the battery compartment.
1. Unscrew the battery compartment door with a
small Phillips screwdriver.
2. Remove the tab (be sure that the battery is in
the correct polarity position – positive (+) side
of the battery is visible).
3. Replace the battery compartment door and
tighten the fastening screw with a Phillips
screwdriver.
4. Remove the label that appears on the
pedometer display.
REMOVING THE BATTERY INSULATOR TAB
WV4748IS01SPT.indd Sec2:3WV4748IS01SPT.indd Sec2:3 3/20/14 12:24 PM3/20/14 12:24 PM

4
WARNINGS & CAUTIONS
WARNING: Before starting any exercise program or performing any vigorous physical activity,
we strongly suggest you visit your doctor for a complete physical and to discuss your plans.
CAUTION ThinQ XA Pedometers are not water resistant.
AVOID exposing the Pedometer to extreme conditions.
AVOID rough uses or severe impacts to the Pedometer.
CLEAN the Pedometer occasionally with a soft, dry cloth.
STORE the Pedometer in a dry place when it is not in use for a long time.
WV4748IS01SPT.indd Sec2:4WV4748IS01SPT.indd Sec2:4 3/20/14 12:24 PM3/20/14 12:24 PM

5
ThinQ XA
PEDOMETER FUNCTIONS
TIME
•Time displayed in 1-second resolution
•12 or 24 hour formats
PEDOMETER
•Measures Walking Steps
•Distance
•Exercise Time
•Calories Burned
TIMER
•1-Second Resolution
•10 Hour
WV4748IS01SPT.indd Sec2:5WV4748IS01SPT.indd Sec2:5 3/20/14 12:24 PM3/20/14 12:24 PM

6
HOW TO WEAR YOUR PEDOMETER
For most accurate measurements, Sportline recommends inserting the unit into a tight,
secure pocket.
FOR MOST ACCURATE PEDOMETER READINGS:
1. Position the unit in a vertical orientation (angle of 30° or less – see
illustration A. IMPORTANT: positioning the unit horizontally (display
flat to the ground) will compromise accuracy – see illustration B.
2. Secure the unit as close to the body as possible.
NOTE: This Pedometer will be most accurate when worn close to the body.
If the Pedometer is loosely contained in a pocket, the unit’s accuracy may be
compromised.
30°
60°
30°
60°
6
60°
60
6
A
WV4748IS01SPT.indd Sec2:6WV4748IS01SPT.indd Sec2:6 3/20/14 12:24 PM3/20/14 12:24 PM

7
ThinQ XA
MODE KEY
•Scroll through operating modes
•Advance to next setting in
Programming Sequence
RESET KEY
•PRESS & HOLD: Clears data
in Pedometer modes (Step,
Distance, Calories, and Timer)
•Increase values being set
during a Programming
Sequence
SET KEY
•PRESS & HOLD: Accesses
Programming Sequence in Time
of Day and Step modes
•Toggle between Metric and
Imperial measurement in
Distance mode
KEYS AND THEIR FUNCTIONS
RESET KEY
SET KEY
MODE KEY
ThinQ XA
WV4748IS01SPT.indd Sec2:7WV4748IS01SPT.indd Sec2:7 3/20/14 12:24 PM3/20/14 12:24 PM

8
MAIN OPERATING MODES
The Sportline ThinQ XA has 5 main operating modes: Time, Step, Distance, Calories, and
Exercise Timer.
• Scroll through main operating modes by PRESSING the MODE key.
• Toggle between Metric and Imperial measurements (in Distance and Speed modes) by
PRESSING the SET key.
TIME OF DAY
PRESS
MODE
STEP
PRESS
MODE
DISTANCE
PRESS
MODE
CALORIES
PRESS
MODE
EXERCISE TIMER
PRESS
MODE
WV4748IS01SPT.indd Sec2:8WV4748IS01SPT.indd Sec2:8 3/20/14 12:24 PM3/20/14 12:24 PM
