Stahl SLE22 Wiring diagram

SLE22
Translation of Original Operating Instructions

2 10.20133
BA_SLE22_EN.DO X
Contents
1 General information ................................................................................................................................................................................................ 3
1.1 General information on operating instructions ................................................................................................................................................. 3
1.2 Contents of operating instructions ...................................................................................................................................................................... 3
1.3 Approvals / test symbols ....................................................................................................................................................................................... 3
1.4 Liability e clusion / loss of warranty ................................................................................................................................................................... 3
1.5 Symbols ..................................................................................................................................................................................................................... 4
1.6 Target group ............................................................................................................................................................................................................. 5
1.7 Claims for liability for defects ............................................................................................................................................................................... 5
1.8 Misuse and malpractice ......................................................................................................................................................................................... 5
1.9 Commissioning / operation / documentation ..................................................................................................................................................... 6
1.10 Use for intended purpose ...................................................................................................................................................................................... 6
2 General safety instructions ................................................................................................................................................................................... 7
2.1 Requirements for installation ................................................................................................................................................................................ 7
2.2 Residual dangers ..................................................................................................................................................................................................... 7
3 General description, function ................................................................................................................................................................................ 9
3.1 Description ................................................................................................................................................................................................................ 9
3.2 Load sensor .............................................................................................................................................................................................................. 9
3.3 Frontal view .............................................................................................................................................................................................................. 9
3.4 Block circuit diagram of SLE22 .......................................................................................................................................................................... 10
3.5 Simplified circuit diagram .................................................................................................................................................................................... 10
3.6 Safety functions ..................................................................................................................................................................................................... 11
3.6.1 Overload cut-off ............................................................................................................. 11
3.6.2 Sensor errors ................................................................................................................. 11
3.7 General functions .................................................................................................................................................................................................. 12
3.7.1 Activation, relay outputs and motor management ...................................................... 12
3.7.2 Mechanical operating hours counter ............................................................................ 15
3.7.3 Temperature control for hoist and travel motors ......................................................... 15
3.7.4 Signal relays................................................................................................................... 16
4 Installation ............................................................................................................................................................................................................... 17
4.1 Dimensions ............................................................................................................................................................................................................. 17
4.2 Mounting ................................................................................................................................................................................................................. 17
4.3 Lead connection .................................................................................................................................................................................................... 17
4.4 Replacement of device or sensor ....................................................................................................................................................................... 17
4.5 Installation ............................................................................................................................................................................................................... 17
5 Commissioning and testing ................................................................................................................................................................................ 18
5.1 Commissioning and periodic tests .................................................................................................................................................................... 18
5.2 Crane test ................................................................................................................................................................................................................ 19
5.3 Documenting alterations of cut-off point .......................................................................................................................................................... 20
6 Operation................................................................................................................................................................................................................. 21
7 Wearing parts ......................................................................................................................................................................................................... 22
8 Error and warning signals, faults ....................................................................................................................................................................... 23
8.1 Operation................................................................................................................................................................................................................. 23
8.2 Error status signals ............................................................................................................................................................................................... 23
8.3 Warning signals ..................................................................................................................................................................................................... 24
9 Decommissioning ................................................................................................................................................................................................. 25
10 Technical data ........................................................................................................................................................................................................ 26
10.1 Electrical data ......................................................................................................................................................................................................... 26
10.2 Mechanical data ..................................................................................................................................................................................................... 27
10.3 Rating plates ........................................................................................................................................................................................................... 28

1 General information
10.2013 3
BA_SLE22_EN.DO X
1General information
1.1 General information on operating instructions
These operating instructions form an integral part of the SLE22 electronic control device
for the manufacturer's hoists. It is addressed to hoist manufacturers, users, operators,
commissioning engineers and service personnel.
It must be available to the machinery manufacturer's or operator's technical personnel
during the whole period of use for erection, electrical installation, configuration, commis-
sioning, maintenance and diagnosis, and be observed by them.
The safety instructions must be observed without fail.
Further safety instructions are to be found in chapter 2 of the original operating
instructions for wire rope hoists/chain hoists, and in chapter 4.8, "Electrical
equipment" further important information and e planations which must be ob-
served.
1.2 Contents of operating instructions
These operating instructions contain information on the subject of:
•Installation
•Electrical installation
•ommissioning
•Operation
•Service
•Diagnosis
•Troubleshooting
•Technical data
•Order numbers
•onformity and approvals
The specialist knowledge necessary for planning and using protective devices is not
given or explained in the operating instructions.
1.3 Approvals / test symbols
See Technical data (chapter 10).
1.4 Liability e clusion / loss of warranty
The precondition for safe operating and achieving the stated product characteristics and
performance features is:
•Observing the operating instructions.
•Non-observance will lead to the exclusion of liability and loss of warranty for the
device and the hoist.

1 General information
4 10.20133
BA_SLE22_EN.DO X
1.5 Symbols
In these instructions, the safety notices are classified according to the severity of
the danger and the probability of its occurrence.
The procedures described for avoiding danger must be followed without fail.
DANGER
This symbol gives warning of an imminent danger to health and life.
Ignoring these warning notices will lead to severe injuries, possibly resulting in death.
WARNING
This symbol gives warning of situations which are potentially dangerous to
health and life.
Ignoring these warning notices may lead to severe injuries, possibly resulting in death.
CAUTION
This symbol gives warning of
situations which are potentially dangerous
to health.
Ignoring these warning notices may lead to injuries.
NOTICE
warns
of damage to property or the environment.
Specific symbols:
Warning of electrical voltage
overs such as hoods and caps which are marked with this symbol may only be opened
by "skilled or qualified personnel".
ontact with live parts can cause death instantaneously.
Warning of suspended load
It is forbidden for persons to stand under suspended loads. This entails risks to life and
limb!
Warning of injuries to hands
Danger of crushing or cutting hands and fingers. The appropriate personal protective
equipment should be worn for this task to avoid injury.
Tips / recommendations
Tips for use and other particularly important information.

1 General information
10.2013 5
BA_SLE22_EN.DO X
1.6 Target group
NOTICE
All
installation work and elimination of faults must be carried out by a
skilled electr
i-
cian, commissioning and maintenance by a qualified person.
The following must be observed
• EN 60204-1 and 32
• DIN VDE 0100
• DIN VDE 0110 and national accident prevention regulations
Skilled electrician
A skilled electrician possesses knowledge and experience on electrical equipment
arising from specialist training and, with knowledge of the applicable standards and
regulations, is able to assess the work with which he is entrusted and detect and avoid
possible risks. The skilled electrician must be familiar with the commissioning and
operation of the product and have been trained on it.
Definition of a qualified person:
A qualified person is one who has gained the specialised knowledge required for
testing the equipment from his/her vocational training, professional experience and
contemporary professional activity.
This person must be in a position to assess the safety of the system in conjunction with
the application. Qualified persons with the competence to undertake certain mainte-
nance work on our products include the manufacturer’s service engineers and trained
fitters with the corresponding certification.
1.7 Claims for liability for defects
DANGER
The prior condition for trouble
-
free operation of the device and settlement of any l
iability
claims for defects is compliance with the operating instructions.
•Read the operating instructions before working with the device.
•Use the device only for its intended purpose. Observe the content of sections "Tech-
nical data," "Use for intended purpose" and "Misuse".
•Observe the requirements of EN 60068-2-6 for transport, storage and operation (see
"Technical data").
•These operating instructions describe only the basic functions of the device.
•Do not open the casing and do not carry out any unauthorised modifications.
•It is essential to disconnect the supply voltage during maintenance work (e.g. when
replacing contactors).
•In addition to the information given in the operating instructions, official and legal
regulations on operation must be strictly observed.
1.8 Misuse and malpractice
DANGER
The device
may be used
solely
in accordance with the instructions and information given
in these operating instructions.

1 General information
6 10.20133
BA_SLE22_EN.DO X
1.9 Commissioning / operation / documentation
NOTICE
The SLE22 does not
fulfil
its
safety function until it has been programmed accordingly.
ommissioning a hoist must be documented. This documentation must also include the
overload cut-off point. It must be signed by the qualified person and the user after
commissioning ( hapter 5: ommissioning and testing).
1.10 Use for intended purpose
NOTICE
The
SLE22
•may only be used for controlling a manually operated single hoist from the manufac-
turer
•is intended for industrial systems and may only be used in accordance with the
information given in the technical documentation and on the rating plate
•comprises a safety-oriented overload cut-off which in conjunction with a dual channel
load sensor (specification see hapter 3.2), while observing the corresponding stan-
dards relating specifically to machines and systems, can be used for the above-
mentioned machines or systems up to category 2, PL d, in compliance with
EN13849-1:2006.
•is a configurable system that performs its safety functions only after the safety-
relevant parameter "overload cut-off point" has been set, which may be altered by a
qualified person only.
•is used as a central safety device for overload cut-off in the control
•is used in the hoist control for activating the motor
•monitors motor temperature by means of PT thermistors
NOTICE
•
The circuit diagrams and block diagrams supplied with the hoist must be followed
and implemented in controls built by customers
•If control elements supplied by the manufacturer are integrated into an overall control
or superordinated SP the product standards for hoists and technical specifications
regarding functionality, signal sequence and device timing must be observed.
•The system manufacturer is responsible for the overall system.
Errors and warnings displayed must be remedied immediately. If this is not possible the
device and thus also the hoist controlled by it must be decommissioned until the fault has
been remedied.
CAUTION
Any other use or alterations to the device, including during erection and install
a-
tion, lead to the loss of warranty claims against the manufacturer.

2 General safety instructions
10.2013 7
BA_SLE22_EN.DO X
2General safety instructions
DANGER
Observe the safety information without fail:
•National and international directives and regulations must be observed for erection,
commissioning, operation and periodic tests, in particular the Machinery Directive
2006/42/E , the directive for the use of work equipment 89/655/EE , safety regula-
tions and relevant national safety regulations.
•The manufacturer and user of the machine or system must agree and observe all
valid safety regulations with the appropriate office on his own responsibility.
•Detailed regulations for commissioning and testing are described in chapter 5.
2.1 Requirements for installation
WARNING
For applications with the device please observe the following
information on electrical
installation:
•If it is to be installed in a control cabinet, the type of protection must be min. IP 54.
•arry out wiring in compliance with EN 60204-32.
•The load sensor cable must be shielded. The shield is connected to the ground close
to the device (ideally, directly next to the device).
•If there is an intermediate terminal on the load sensor lead, connect the shield
isolated from the ground (e.g. with a standard terminal).
Analog leads (load sensor, Temp1 and Temp2) must be routed separate from high-
voltage cables (e.g. routed separately in different channels or bundles).
2.2 Residual dangers
DANGER
U
ne pected start
-
up
:
•is prevented when energy supply is reconnected
•The control must also ensure this feature.
Bodily injury from crushing, tearing off or even death.
The safety instructions must be observed and applied!
WARNING
Dire
ct contact with supply voltage:
Fatal contact voltages can occur:
•due to incorrect wiring
•by not disconnecting the supply voltage when working on the control
Physical damage may be lasting, e.g. ventricular fibrillation, burns
•This must be taken into account by the skilled electrician and corresponding action
must be taken.
CAUTION
Operating errors
•Never bridge the device
•Operating personnel must be trained by the system user in order to prevent operating
errors. (See original operating instructions of hoist).

2 General safety instructions
8 10.20133
BA_SLE22_EN.DO X
DANGER
Failure of one of the downstream power devices:
•Downstream power devices are not monitored by the SLE22.
•Failure must be prevented by
the designer of the control selecting appropriate devices
•If a device fails the user must have it replaced immediately by a qualified person.

3 General description, function
10.2013 9
BA_SLE22_EN.DO X
3General description, function
3.1 Description
The SLE22 is an electronic control device for hoists. The device can be used to control
pole-changing or frequency-controlled drives. It comprises a safety-oriented overload cut-
off for hoists in conjunction with a load sensor (see point 3.2.) It is a configurable system
that performs the safety function only after parameterizing and saving the safety-relevant
parameter overload cut-off point, reliably disconnecting the hoist motion.
In addition the device performs other control functions which are not safety-relevant
•Mechanical operating hours counter
•Temperature control for hoist and travel motors
•Display of system status via signal relay
•ontrol of hoist motions by motor management
3.2 Load sensor
NOTICE
The SLE22 processes loa
d sensor currents from 0
-
25.5
mA. Two independent load
sensors or a dual-channel sensor are to be connected.
The load sensor is an integral part of the prototype test of the device and is thus a safety-
relevant component. For this reason only load sensors approved by the manufacturer
must be used. If a load sensor is defective, the same type must always be ordered and
installed. The load sensors are specified by the manufacturer corresponding to the
individual hoist and load and assigned in-house. During replacement, note hapter 4.4,
Replacement of devices and sensors.
Warranty and approval of the device e pire if an unapproved sensor is installed!
WARNING
If a load sensor with two internally independent channels is used, it must be
of
two
-
channel design. A single fault must not cause both sensor cells to fail. See T
echnical data
for further requirements.
3.3 Frontal view
He switch
: L
EDs
S1:
Motor management selector switch
S4: Rough adjustment of cut-off point
S2: Fine adjustment of cut-off point
S3: DIP switch for activating test rig, operating
relays and motor management functions
S5: Enter switch: e.g. crane test
View without lid
DANGER
Alterations to the setting of the stored cut
-
off point may only be performed by a
qualified person!
Unauthorised alterations cause the warranty to e pire!
DIP switch

3 General description, function
10 10.20133
BA_SLE22_EN.DO X
3.4 Block circuit diagram of SLE22
Key
Supply
1: Supply voltage L
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
UBS
GD
I1+
I1-
I2+
UB
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
K↓↓
K↓
K↑↑
K↑
L↓↑
S↕↕
S↓
S↑
N
L
Connection terminal
Relay outputs Activation
Signal relay
µP1 µP2
Safety analog inputs
load 1 load 2
ϑ2
ϑ2ϑ2
ϑ2
left
right
Supply
Temp relay
Connection terminal
ϑ1
ϑ1ϑ1
ϑ1
ϑ1
ϑ1ϑ1
ϑ1
ϑ2
ϑ2ϑ2
ϑ2
err
option
Analog safety inputs
Load1
19: 15V supply for load sensor 1 UBS
20: Ground for 15V and 24V supply GD
21, 22: Load sensor input 1 I1+/I1-
Load2
23: Load sensor input 2 I2+
24: 24V supply for load sensor 2 UB
2
:
Supply voltage ground
N
Activation
3
:
Safety input up
S
↑
4
:
Safety input down
S
↓
5
:
Input fast
S
↕↕
Relay outputs
6: Switching voltage of relays L↑↓
7
:
Safety output slow up
K
↑
8
:
Safety output fast up
K
↑↑
9
:
Safety output slow down
K
↓
10
:
Safety output fast down
K
↓↓
Temp relays
12
-
15
:
Relay outputs for cutting
off
travel
motors at overtemperature right/left
ϑ
ϑϑ
ϑ1
16, 17: PT thermistor input hoist motor
ϑ
ϑϑ
ϑ1
ϑ
ϑϑ
ϑ2
25, 26: PT thermistor input travel motor
ϑ
ϑϑ
ϑ2
Signal relays
27, 28: Signal relay err
29, 30: Signal relay option
3.5 Simplified circuit diagram
Up
Down
Fast
S211
S212
3 4 5 16 17 19 20 21 22 23 24 25 26
S↑S↓S↕↕
ϑ1
ϑ1ϑ1
ϑ1
UBS GD I1+ I1- I2+ UB
ϑ2
ϑ2ϑ2
ϑ2
1 L
err option
2 N L↓↑ K↑K
↑↑
K↓K
↓↓
6 7 8 9 10 27 28 29 30 12 13 14 15
Activation
Load1
Power section signal
lamp, horn
Power section travel
drive
ϑ1
ϑ1ϑ1
ϑ1 ϑ2
ϑ2ϑ2
ϑ2
left
Relay outputs
Fast downFast up
Up
Supply
Power section downPower section up
W
E
Load2
Temp relay
W
E
Down right
Signal relay
ϑ
ϑϑ
ϑϑ
ϑϑ
ϑ

3 General description, function
10.2013 11
BA_SLE22_EN.DO X
3.6 Safety functions
3.6.1 Overload cut-off
The overload cut
-
off is designed in accordance with performance level d, category 2, to
EN 13849-1:2006. As shown in the simplified circuit diagram, UBS supplies the first load
sensor Load1. The load sensor current is fed into l1+ and the bridge from I1- to GD
closes the circuit.
The second load sensor Load2 is supplied by UB. The load sensor current is fed into l2+
and the circuit is closed internally.
The overload cut-off disconnects in the following cases:
•If the load sensor current exceeds the set cut-off threshold while S↑ is active, the
SLE22 recognises "Overload" and disconnects K↑ and K↑↑. The outputs are dis-
abled until the overload is no longer detected.
•If the load sensor current exceeds the set cut-off threshold while outputs K↓, K↓↓ are
active or at standstill, the SLE22 recognises "Overload" after 800 ms and disables
outputs K↑ and K↑↑, until the overload is no longer detected.
Due to an internal filter function the maximum reaction time for cut-off when lifting a load
from the ground is 500 ms. The elasticity of the crane system must be taken into account
to obtain the total reaction time.
"Overload" is acknowledged when the load on the hook is less than 82,5% of maximum
working load and safety input S↑ is active for 2 seconds or the load (minimum load)
corresponds to a current value of 6 mA for 2 seconds.
Outputs K↓ and K↓↓ can be switched after an overload has been detected!
3.6.2 Sensor errors
The S
LE
22 constantly monitors and compares the values of sensor channels 1 and 2.
The following three types of sensor error are detected:
Differential error
if the difference between the sensor currents is > 6,7%, related to the set overload
cut-off point (see page 16 for definition)
•Broken cable:
If the sensor current in one or both sensor channels is < 3.3mA
•Short circuit:
if the load sensor current in one or both sensor channels is >2 .5 mA
In all three cases of sensor error output relays K↑ and K↑↑ are disabled dependent on
activation of safety inputs S↑ and S↕↕ and the incident is displayed by the device LEDs.
The maximum reaction time for disabling the outputs is:
if input S↑ is active = 950 ms
if input S↑ is not active = 1950 ms
A sensor error is acknowledged if:
•The difference between the sensor currents is <6.6%, related to the overload cut-off
point1, and
•the load sensor current is within the function limits and
•up S↑ is not activated.
Definition:
The basis for calculation is the hoist sensor current, i.e. the cut-off sensor current (at
110% load) minus the zero point current (at 0%) load.
Example: cut-off current = 13 mA; zero point current = 4.0 mA; permissible current
difference between the sensor channels <= 0.6 mA

3 General description, function
12 10.20133
BA_SLE22_EN.DO X
→ max. difference =

.




∗


%




.


–


.




=

6
.
66

%
WARNING
The down motion (outputs K
↓ and K↓↓ activated) is still possible at overload and
sensor error to permit a suspended load to be set down if necessary!
3.7 General functions
3.7.1 Activation, relay outputs and motor management
Activation
Safety inputs S↑, S↓ and input S↕↕ are read in relation to N.
S↑ and S↓ are transmitted on two channels to both controllers in the device and evalu-
ated in accordance with category 2 performance level d.
The activation of S↕↕ is only detected if the related direction S↑ or S↓ is also active at
the same time.
If S↑ or S↓ are activated from idle state, the SLE22 switches the related safety output
K↑ or K↓ after a maximum delay time of 300 ms.
Relay outputs
The relay outputs switch the voltage connected to L↑↓ which must coincide with the
supply voltage at L.
In accordance with category 2 performance level d, the safety outputs K↑ and K↑↑ are
supplied by an internal safe circuit. In the case of a fault or at overload this circuit discon-
nects safety outputs K↑ and K↑↑ .
Safety outputs K↓ and K↓↓ are also supplied by an internal safe circuit in accordance
with category 2 performance level d.
In the case of a fault this circuit disconnects safety outputs K↓ and K↓↓ .
Safety output K↑↑ or K↓↓ is only active in conjunction with safety output K↑ or K↓ .
Motor management
ut
-
off times for hoisting and lowering motions are combined in the term motor manag
e-
ment.
The cut-off times are explained below on the e ample of hoisting:
Starting via slow speed ta:
If S↑ and S↕↕ are activated together, K↑ is switched first. After cut-off time ta has
expired, K↑↑ is activated.
Braking via slow speed tb:
If K↑ and K↑↑ are active, K↑↑ is switched off after activation of S↑ and S↕↕ K↑↑ is
switched off. After the expiry of braking time tb, K↑ is also no longer activated.
ut-off time for slow speed tl and fast speed ts:
If S↑ or S↕↕ are not active, K↑ or K↑↑ are no longer activated. If S↑ or S↕↕ are switched
again directly afterwards, K↑ or K↑ and K↑↑ are activated after expiry of the cut-off time
for slow speed tl or fast speed ts.
ut-off time for change of direction tr:

3 General description, function
10.2013 13
BA_SLE22_EN.DO X
If the direction of activation is reversed, the hoist is stopped and the relevant safety
output is activated after cut-off time tr has expired.

3 General description, function
14 10.20133
BA_SLE22_EN.DO X
The duration of these follow
-
up and cut
-
off times is set via switch S1 and DIP switch
S3_1.
DANGER
Alterations to the settings of S1 and S3_1 may only be
performed by a qualified
person!
Motor
management table
This table shows the correlation between settings and times:
F =
setting for
frequency converter operatior
A = motors, type "A"

3 General description, function
10.2013 15
BA_SLE22_EN.DO X
3.7.2 Mechanical operating hours counter
The device counts the total operating hours.
They are shown on the operating hours
counter mounted on the front.
•If motor management for frequency inverter operation is selected, the operating
hours counter starts to count as soon as the hoist motor is activated.
•If motor management for a pole-changing motor is selected, the operating hours
counter starts to count as soon as the hoist motor is activated.
3.7.3 Temperature control for hoist and travel motors
DANGER
ϑ
ϑϑ
ϑ1
The hoist motor temperature is constantly monitored. If the motor ptc thermistor (input
ϑ
ϑϑ
ϑ1) is activated a message is given via the device LEDs and all hoist motions (outputs
K↓, K↓↓ and K↑ , K↑↑) are disabled..
The load cannot be moved until the hoist motor has cooled off.
NOTICE
The ptc thermistor input ϑ
ϑϑ
ϑ1 is monitored for short-circuiting. If the resistance measured
at the ptc thermistor input drops to <80 Ohm, a ptc thermistor error is displayed for ϑ
ϑϑ
ϑ1
and the hoist motions disabled as for overtemperature (see chapter 9.2.1).
WARNING
ϑ
ϑϑ
ϑ2
The travel motor PT thermistor(s) are connected to temperature input ϑ
ϑϑ
ϑ2. If the
PT
thermistor reaches cut-off temperature, the SLE22 detects the status
overtemperature2
and disconnects left/right. The travel motors can no longer be activated.
After the motor has cooled down the error is automatically acknowledged by the SLE22.
NOTICE
•
All PT thermistors must meet the requirements of DIN 44080.
•All PT thermistors can be replaced by resistances with ~300 Ohm if the motors
used have no PT thermistors.
CAUTION: The hoist or cross travel motors are then no longer protected against
overtemperature.
•Note technical data!
The ptc thermistor inputs are monitored for short-circuiting. If the resistance
measured at the input drops to <80 Ohm, a ptc thermistor error is displayed.
If no temperature sensor is connected to ϑ
ϑϑ
ϑ2 the warning signal can be disabled by
switching sliding switch S3_2.
left/right is switched independently of this.

3 General description, function
16 10.20133
BA_SLE22_EN.DO X
3.7.4 Signal relays
CAUTION
e
rr
a
nd
"
option
" are used for transmitting error signals and must not be used for safety
-
relevant functions.
The signal relays may only be parameterized by a skilled electrician using suitable tools.
Both relays can be parameterized as normally open or normally closed:
Rela
y
Normally open
Normally closed
option
S3_7 off
S3_7 on
err
S3_6 off
S3_6 on
Err switches at every error condition which interrupts a hoist motion.
Option can be parameterized as required. Parameterizing is dependent on the position
of switch S3.
DIP
switch
:
S
witch
S3_3
S
witch
S3_4
S
witch
S3_5
option relay
0
0
0
does not switch
1
0
0
switches at overload
0
1
0
at overtemperature
1
1
0
at sensor error
0
0
1
at all errors which
disable
lifting and lowering
1
0
1
wiping contact at overload: relay changes to
switching state for 500 ms
0
1
1
not used
1
1
1
not used
The settings are made during initial commissioning in
the factory.

4 Installation
10.2013 17
BA_SLE22_EN.DO X
4Installation
4.1 Dimensions
•
100 x 110 x 75 mm (B x H x T)
4.2 Mounting
•
lipped onto 35 mm top hat rail 3 (EN 50022-35)
•Screwed onto base of casing (M4) with pull-out slide
4.3 Lead connection
•
30 box terminals with captive plus-minus screws
•Per box terminal: 1 x 4 mm2 solid or 1 x 2.5 mm2 stranded wire with sleeve
DIN 46 228 or 2 x 1.5 mm2 stranded wire with sleeve DIN 46228
Installation must be performed by a skilled electrician. The maximum values for tighten-
ing torques given in EN ISO 898-1 must be observed for all screws.
All screws must be checked for firmness and tightened if necessary at every mainten-
ance, at least once a year.
4.4 Replacement of device or sensor
DANGER
After a device or load sensor has been replaced by a
qualified person
a complete
commissioning test (see chapter 5: ommissioning and testing) must be repeated and the
reading of the operating hours counter of the device which has been replaced recorded in
the crane logbook.
4.5 Installation
Installation in a panel box, IP 54 minimum
.

5 Commissioning and testing
18 10.20133
BA_SLE22_EN.DO X
5Commissioning and testing
DANGER
Commissioning and testing may only be performed by a qualified person
following
the "Servicing instructions of the original operating instructions".
5.1 Commissioning and periodic tests
NOTICE
The person commissioning must have all necessary information on system and device.
Testing must comprise the correct interaction of the device with the hoist control, the
safe status and position in relation to statutory standard operating procedures and safety
regulations relating specifically to the equipment (directives, product standards, regula-
tions / information from the Employers' Liability Insurance Associations.)
The test results must be recorded in writing in a report signed by the person performing
the tests. The report must be filed where the machine or system is situated.
The following types of test are distinguished:
a) Tests before first commissioning and after alterations (acceptance tests)
A test must be performed before the first commissioning of the SLE22 and after
alterations to the SLE or to components or units affecting the safety function.
Regarded as alterations are all alterations to wiring, control, configuration, para-
meterization of the SLE and related components or units affecting the safety
function. The test must determine that the requirements for hoists are met when
using the SLE22 and that correct functioning of the components or units affecting
the safety function in interaction with the SLE22 is ensured. In addition, the type
of use / mounting of the SLE22 and the braking path of the system are to be
tested.
Acceptance test: overload cut-off:
Lifting a test load of 110% maximum working load. The device must detect the
overload at the latest when the load has been lifted completely off the ground,
and disconnect the hoist motion. In accordance with DIN EN 14492-2: 2010-05
an overload must not be lifted over a distance of more than the maximum rated
hoisting speed multiplied by 1s.
b) Periodic tests
Periodic tests serve to detect systematically and eliminate safety-related faults
(e.g. due to alterations or manipulations) on the system's protective equipment
occurring after commissioning. To comply with §3 clause 3 of the Ordinance on
Safety in Operation, type, extent and time limits must be ascertained and laid
down by the user in relation to the specific equipment. An inspection interval of at
least once a year has proved appropriate. Shorter test intervals may be neces-
sary for multi-shift operation, heavy duty, adverse ambient conditions or to comp-
ly with national regulations.
This test comprises inter alia testing the overload cut-off point with a test load of
110% maximum working load, a safety check of the correct functioning of the
SLE22 and the interaction of the SLE22 with components or units relating to the
safety function. In addition it includes checking that the limit value given for over-
run is not exceeded.

5 Commissioning and testing
10.2013 19
BA_SLE22_EN.DO X
5.2 Crane test
DANGER
When commissioning a hoist a so
-
called crane test must be performed in accordance with
its original operating instructions. To enable this, the " rane test" function can be acti-
vated, raising the overload cut-off point.
The "Crane test" function may only be activated for the purpose of this test by a
qualified person in the presence of an authorized crane e pert.
The crane runway and the crane bridge are tested with a load of 125%.
The " rane test"
function can be activated to permit this test. After this function has been activated, the
cut-off point is raised to 137.5% maximum working load for 30 minutes (125% + 10%).
Activating "Crane test" function
:
Preparations before
activating crane test:
•remove lid with a screwdriver
(hexagon socket, width across flats 2.5)
The " rane test" function can only be activated when the hoist is at a standstill and has
no overload on the hook. The DIP switches S3 must correspond to the settings shown on
the lid of the casing. The " rane test" function must be activated within 12 seconds,
following these steps:
1. Press button S5 for more than 3 seconds
2. After an interval of 1 second, press button S5 for more than 3
seconds again until the red LED flashes.
If an error should occur while the crane test is being activated, the LED flashes 3
times. After this error signal the crane test function can be activated once again.
Deactivating the crane test function
:
The crane test function is deactivated as follows:
•Reboot the device
•Press button S5 until the red LED stops flashing.

5 Commissioning and testing
20 10.20133
BA_SLE22_EN.DO X
5.3 Documenting alterations of cut-off point
DANGER
After
testing the new cut
-
off point, it must be documented, confirmed and signed in the lid
of the case, in the following table and in the crane logbook.
Any undocumented alteration of the cut-off point leads to an immediate loss of warranty
and is grossly negligent.
Cut
-
off point
Reason for alteration
Signature of
user
Signature of
service engi-
neer
