Stahls Hotronix MAXX CAP User manual

OPERATOR’S MANUAL
MAXX®CAP

2
HOTRONIX®
MAXX®CAP Safety Instructions Safety Instructions
When using your heat press, basic precautions should always be
followed, including the following:
1. Read all instructions.
2. Use heat press only for its intended use.
3. To reduce the risk of electric shock, do not immerse the heat press in water or other liquids.
4. Never pull cord to disconnect from outlet, instead grasp plug and pull to disconnect.
5. Do not allow cord to touch hot surfaces and allow heat press to cool completely before storing.
6. Do not operate heat press with a damaged cord or if the equipment has been dropped or damaged. To
reduce the risk of electric shock, do not disassemble or attempt to repair the heat press. Take it to a
qualified service person for examination and repair. Incorrect assembly or repair could increase the
risk of fire, electric shock, or injury to persons when the equipment is used. Power supply cord must be
disconnected before cleaning or servicing press.
7. This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
8. Close supervision is necessary for any heat press being used by or near children. Do not leave equipment
unattended while connected.
9. To avoid burns, do not touch hot metal parts or the heated platen during use.
10. To reduce the likelihood of circuit overload, do not operate other high voltage equipment on the same circuit.
11. If an extension cord is necessary, then a 20-amperage rated cord should be used. Cords rated for less
amperage may overheat. Care should be taken to arrange the cord so that it cannot be pulled or tripped
over.
12. Keep hands clear of the upper heat press platen during lock down as the pressure may cause injury.
13. Heat press should be placed on a sturdy, suitable stand at least 91,5 cm L x 60 cm W x 75 cm H.
14. Work area must be kept clean, tidy and free of obstructions.

3
WWW.STAHLSASIA.COM
Safety Instructions
Safety Instructions 2
Machine View 4
Control Panel Guide 5
Operating Instructions 6-8
Connecting the System 6
Start Up/Shut Down 6
Adjusting Temperature 7
Adjusting Time 7
Adjusting Pressure 8
Printing/Pressing 8
Electrical Schematic 9
Parts Location Guide 10
Replacement Parts List 11
Contact us 12

4
HOTRONIX®
MAXX®CAP Machine View
Circuit
Breaker
Power
Supply
Located on the back of the press
LED Display
Lower Platen
Lift Handle
ON/OFF
Switch
Upper Platen
Cap Hold
Down Lever
Pressure
Adjustment Knob
(not shown in
picture)

5
WWW.STAHLSASIA.COM
Control Panel Guide
Digital Display
Temperature
Indicator
Set Indicator
Time Indicator
Mode Select
Decrease Increase

6
HOTRONIX®
MAXX®CAP
Connecting the System
Connect the power cord into a properly grounded electrical
outlet with a sufficient amperage rating.
Voltage
120 volt requires a full 20-amp grounded circuit.
220 volt requires a full 10-amp grounded circuit.
Extension Cords should be as short as possible and not
less than 12 gauge. Heavy duty cords are recommended.
Circuits with less than 10 amps or have other high demand
equipment or heat presses plugged in should not
be used.
Note: If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or a similarly qualified person in
order to avoid hazard. Use SJT type rated 300 V cord for replacement.
CAUTION
Failure to follow these instructions will cause:
1. Erratic controller functions.
2. Inaccurate displays and slow heat up.
3. The circuit breaker to disengage.
Operating Instructions
Start Up/Shut Down
Locate the lift handle and position the heat platen in the
UP position.
Locate the Power ON/OFF Switch on the side of the press,
then turn the Power Switch ON.

7
WWW.STAHLSASIA.COM
Operating Instructions
Adjusting Temperature
Press the Mode Select button in the center of the Control
Panel.
The (SET) and (TEMP) lights located next to the display
will illuminate.
Press the (+) or (-) button to raise or lower the
temperature setting.
The temperature can be set from 205°F (96°C) to 430°F
(220°C).
The LED Display will show changes as you make them.
Note: The temperature indicator will only display temperatures
200°F (93°C) and up.
Adjusting Time
Once you have adjusted the temperature, press the Mode
Select button again to advance to Time Mode.
The (SET) and (TIME) lights will illuminate.
Adjust the time in the same manner you adjusted
the temperature.
Select the desired time and push the Mode Select button
again to exit.
All lights will be off and the press will return to PRINT mode.

8
HOTRONIX®
MAXX®CAP
Adjusting Pressure
Pressure
Adjustment Knob
The Pressure Adjustment Knob is located directly under the
lower platen.
Turn the knob clockwise to increase pressure and
counterclockwise to decrease pressure.
Remember to allow for the thickness of your cap when
adjusting the pressure.
WARNING: Structural damage caused by excessive
pressure is not covered under the limited warranty!
Operating Instructions
Printing/Pressing
Once your equipment has reached the designated
temperature:
• Pull the Cap Hold Down Lever up and towards the
operator and load the cap onto the lower platen.
• Pull out the sweatband and position the cap so it clears
the upper platen when the machine is closed.
• Push the Cap Hold Down Lever down and away from the
operator to stretch the cap and keep it from shifting.
• Position your design and lower and lock the heat platen
into the PRESS position to begin the automatic timing
process.
• The timer will automatically count down and audibly
signal you to lift the heat platen into the UP position
when the print cycle is complete.
Pressure
Adjustment Knob

9
WWW.STAHLSASIA.COM
Electrical Schematic
US 120V/240V VERSION
CE 230V VERSION
240V
120V
Electrical Schematic: MAXX Cap

10
HOTRONIX®
MAXX®CAP Parts Location Guide Replacement Parts List

ITEM # PART # DESCRIPTION QTY
1 4-1172-B Control Housing, MAXX 1
3 1-2018 Controller Overlay, MAXX 1
4 1-2105 Grommet, 9/32" ID 3/8" OD 2
5 3-1011-235 Screw, Sheet Metal #6 x 1/2" 6
6 2-1006-50 Nut, #6-32 Hex with Lockwasher 9
7 3-1011-130 Screw, Pan Phillips #4-40 x 1" 2
8 1-1759 Power Inlet 1
9 1-2087 Power Switch 1
10 3-1011-19 Screw, Machine #6-32 x 1/2" 7
11 3-1011-25 Screw, Machine #6-32 x 1/4" 5
12 1-1353 Conduit Fitting, 1/2" Topaz Straight Twist-On 2
13 Kit 3-6946 Controller Kit, MAXX 1
14 2-1006-51 Nut, #4-40 with Tooth Washer 8
15 2-1661 Controller Bracket, STX MAXX 1
16 1-1059 TRIAC 1
17 3-1011-22 Screw, Machine #4-40 x 3/8" 6
18 1-1290 Terminal Block, 5 Contact High Voltage 1
20 1-1211 Proximity Switch 1
21 1-2317 Circuit Breaker 5A (CAP 6x6) 1
24 KIT 3-6910-1 Handle Assembly, MAXX Cap 1
26 1-2440 Shaft Collar, STX6LR Medium 2
27 1-2085-4 Magnet Bracket, MAXX Cap 1
28 1-1219 Proximity Magnet 1
29 2-1055-26 Steel Pin, 1/2" x 6.45" 2
30 1-1048-3 Washer, 1/2" Nylon 4
31 1-1107-1 Hub Cap 1/2" 8
32 2-1055-9 Steel Pin, 1/2" x 5-7/8" 1
33 1-1049-1 PVC Spacer, 1/2" x 3.30" 2
34 1-1049-14 PVC Spacer, 1/2" x 0.70" 2
35 2-1006-2 JCN - NUT 2
36 1-1042-1 All Thread Pin 1
37 1-1049-11 PVC Spacer, 1/2" x 5" 1
38 1-1540 Foam Grip, Black 1
39 KIT 3-6957 Lift Link, MAXX 6x6 & Cap 2
ITEM # PART # DESCRIPTION QTY
40 1-1023 Adjustment Spindle, STX 6x6 1
41 1-1095 Knob, Black Plastic 3/8"-16 1
42 1-1051 Bronze Washer 1
44 2-1050-C Cap Platen, Standard 3.5" x 6" 1
45 1-1050 Silicone Pad, Cap 3.5" x 6" Gray 1
46 2-1042 Cap Hold Down 1
47 1-1089 Cap Hold Down Vinyl Cover 1
48 1-1073 Spring 1
51 1-2246 Gas Spring 11x15 & 6x6 & Cap 1
52 KIT 3-6907-1 Base, MAXX Cap 1
59 3-1011-252 Screw, Pan Phillips #6-32 x 3/4" 1
60 1-1939 Ball Stud 10mm 2
61 2-1006-20 Nut, Hex Nylok 5/16"-18 3
62 3-1011-182 Acorn Nut 10-32 5
63 1-1256 Rubber Foot 6
64 3-1011-164 Screw, Button Socket Head #10-32 x 1/2" 5
65 1-1085 Eyebolt 1
66 2-1006-56 Nut, Nylok #8-32 1
67 KIT 3-6908-1 Heater Arm Assembly, MAXX Cap 1
70 1-1049-5 PVC Spacer, 1/2" x 3.80" 1
71 2-1055-29 Steel Pin, 1/2" x 4.69" 1
72 1-1049-3 PVC Spacer, 1/2" x 5/8" 2
73 3-1011-55 Screw, Shoulder 3/8" x 1-1/4" w/ 5/16"-18 Thread 1
74 1-2253 Heat Platen, Cap 120V/220V 1
76 1-1017-2 Pin, Clevis 3/8" x 1-5/8" 2
77 1-1043-2 Retaining Clip, Rue Ring 2
79 3-1011-87 Screw, SS Phillips #8-32 X 1/4" 5
80 1-1272-1 Temperature Probe 1
81 1-2076 Thermostat Disc 1
82 3-1011-98 Screw, SS Sheet Metal #4 X 1/4" 2
83 2-1663 Heat Platen Cover, Cap 1
84 1-1048-2 Conduit, STX MAXX Cap, 13" 1
85 1-1063 Washer, Plastic Finishing 2
86 3-1011-217 Screw, Flat Head Phillips #10-24 x 7/16" 2
11
WWW.STAHLSASIA.COM
Replacement Parts List

12
HOTRONIX®
MAXX®CAP CONTACT US
This document includes multiple trademarks and describes equipment covered by many
patents that are owned by GroupeSTAHL and/or its subsidiaries. GroupeSTAHL enforces
its rights to protect these intellectual properties.
©
2021
STAHLS’ Asia
8-79, Samseong 3-gil
Dongnam-gu
Cheonan-si
Chungcheongnam-do
Rep. of Korea
Technical Support & Customer Service
[phone]
Email
[email protected]
Web
stahlsasia.com
