Stairville DMX Foot 2 User manual

DMX Foot 2
DMX controller
user manual

Musikhaus Thomann
Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Germany
Telephone: [phone]
E-mail: [email protected]
Internet: www.thomann.de
03.11.2020, ID: 492512

Table of contents
1 General information................................................................................................................................. 5
1.1 Further information........................................................................................................................... 6
1.2 Notational conventions.................................................................................................................... 7
1.3 Symbols and signal words............................................................................................................... 8
2 Safety instructions.................................................................................................................................. 10
3 Features....................................................................................................................................................... 13
4 Installation.................................................................................................................................................. 14
5 Starting up.................................................................................................................................................. 16
6 Connections and operating elements........................................................................................... 19
7 Operating.................................................................................................................................................... 23
7.1 Assigning DMX channels and addresses................................................................................. 24
7.2 Deleting DMX channels and values........................................................................................... 26
7.3 Pedal settings.................................................................................................................................... 27
7.4 System settings................................................................................................................................. 32
7.5 Menu overview................................................................................................................................. 36
Table of contents
DMX Foot 2
3

8 Technical specications....................................................................................................................... 37
9 Plug and connection assignment.................................................................................................... 39
10 Protecting the environment.............................................................................................................. 40
Table of contents
DMX controller
4

1 General information
This user manual contains important information on the safe operation of the device. Read and
follow all safety notes and all instructions. Save this manual for future reference. Make sure
that it is available to all persons using this device. If you sell the device to another user, be sure
that they also receive this manual.
Our products and user manuals are subject to a process of continuous development. We there‐
fore reserve the right to make changes without notice. Please refer to the latest version of the
user manual which is ready for download under www.thomann.de.
General information
DMX Foot 2
5

1.1 Further information
On our website (www.thomann.de) you will nd lots of further information and details on the
following points:
Download This manual is also available as PDF le for you to download.
Keyword search Use the search function in the electronic version to nd the topics of
interest for you quickly.
Online guides Our online guides provide detailed information on technical basics
and terms.
Personal consultation For personal consultation please contact our technical hotline.
Service If you have any problems with the device the customer service will
gladly assist you.
General information
DMX controller
6

1.2 Notational conventions
This manual uses the following notational conventions:
The letterings for connectors and controls are marked by square brackets and italics.
Examples: [VOLUME] control, [Mono] button.
Texts and values displayed on the device are marked by quotation marks and italics.
Examples: ‘24ch’ , ‘OFF’ .
Letterings
Displays
General information
DMX Foot 2
7

The individual steps of an instruction are numbered consecutively. The result of a step is
indented and highlighted by an arrow.
Example:
1. Switch on the device.
2. Press [Auto].
ðAutomatic operation is started.
3. Switch o the device.
1.3 Symbols and signal words
In this section you will nd an overview of the meaning of symbols and signal words that are
used in this manual.
Instructions
General information
DMX controller
8

Signal word Meaning
DANGER! This combination of symbol and signal word indicates an
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
NOTICE! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
Warning signs Type of danger
Warning – danger zone.
General information
DMX Foot 2
9

2 Safety instructions
This device is used to control DMX-controlled LED spotlights. Use the device only as described
in this user manual. Any other use or use under other operating conditions is considered to be
improper and may result in personal injury or property damage. No liability will be assumed for
damages resulting from improper use.
This device may be used only by persons with sucient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from
the unit. They could swallow the pieces and choke!
Never let children unattended use electrical devices.
Intended use
Safety
Safety instructions
DMX controller
10

NOTICE!
External power supply
The device is powered by an external power supply. Before connecting the
external power supply, ensure that the input voltage (AC outlet) matches the
voltage rating of the device and that the AC outlet is protected by a residual cur‐
rent circuit breaker. Failure to do so could result in damage to the device and pos‐
sibly the user.
Unplug the external power supply before electrical storms occur and when the
device is unused for long periods of time to reduce the risk of electric shock or
re.
NOTICE!
Risk of re
Do not block areas of ventilation. Do not install the device near any direct heat
source. Keep the device away from naked ames.
Safety instructions
DMX Foot 2
11

NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never
expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and
strong vibrations.
Only operate the device within the ambient conditions specied in the chapter
‘Technical specications’ of this user manual. Avoid heavy temperature uctua‐
tions and do not switch the device on immediately after it was exposed to tem‐
perature uctuations (for example after transport at low outside temperatures).
Dust and dirt inside can damage the unit. When operated in harmful ambient
conditions (dust, smoke, nicotine, fog, etc.), the unit should be maintained by
qualied service personnel at regular intervals to prevent overheating and other
malfunction.
Safety instructions
DMX controller
12

3 Features
Special features of the device:
nSimple foot control for 512 DMX channels
n2 adjustable pedals (ash or toggle)
n40 storable presets
nLTP, HTP
nConguration via buttons and display on the unit
nAdjustable hold, fade-in and fade-out times per pedal
nFloor device, all functions foot-controllable
nRugged design, ideal for stage use
Features
DMX Foot 2
13

4 Installation
Unpack and check carefully there is no transportation damage before using the unit. Keep the
equipment packaging. To fully protect the product against vibration, dust and moisture during
transportation or storage use the original packaging or your own packaging material suitable
for transport or storage, respectively.
NOTICE!
Possible data transmission errors
For error-free operation make use of dedicated DMX cables and do not use ordi‐
nary microphone cables.
Never connect the DMX input or output to audio devices such as mixers or ampli‐
ers.
Installation
DMX controller
14

NOTICE!
Possible staining
The plasticiser contained in the rubber feet of this product may possibly react
with the coating of your parquet, linoleum, laminate or PVC oor and after some
time cause permanent dark stains.
In case of doubt, do not put the rubber feet directly on the oor, but use felt-pad
oor protectors or a carpet.
The device is designed for oor use. Position the unit on a at, non-slip surface, use a non-slip
pad if necessary.
Connect the included 9V power supply unit to the power supply input of the unit and then
plug the power cord plug into the wall outlet. The device is immediately operational.
Installing the device
Connecting the power adapter
Installation
DMX Foot 2
15

5 Starting up
Create all connections while the device is o. Use the shortest possible high-quality cables for
all connections. Take care when running the cables to prevent tripping hazards.
Starting up
DMX controller
16

Connect the DMX input of the device to the DMX output of a DMX controller or another DMX
device. Connect the output of the rst DMX device to the input of the second one, and so on
to form a daisy chain. Always ensure that the output of the last DMX device in the daisy chain
is terminated with a resistor (110 Ω, ¼W).
Connections in DMX mode
Starting up
DMX Foot 2
17

Every DMX device operates with a certain vendor specic number of channels through which
the incoming control signals are converted into movements, brightness or colour changes,
etc.. Since all receivers in a DMX chain always receive all signals, a starting address must be
assigned to each DMX device. Starting from this address (a value between 1 and 512), the
incoming signals are then interpreted by the receiver and implemented in accordance with
the function mode set on the receiver (device-internal channel assignment).
Within a DMX chain, one start address can easily be assigned multiply. The corresponding
receivers then operate synchronously (same movements, same brightness, same colour, etc.).
Signal conversion
Starting up
DMX controller
18

6 Connections and operating elements
Top view
Connections and operating elements
DMX Foot 2
19

1[Pedal 1]
Foot switch for controlling the assigned presets in the device memory
2[Pedal 2]
Foot switch for controlling the assigned presets in the device memory
Rear panel
Connections and operating elements
DMX controller
20
