Stairville Infinite Pixel 250 User manual

Innite Pixel 250
Moving Head
User Manual

Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Germany
Telephone: [phone]
Internet: www.thomann.de
20.04.2023, ID: 524843

Table of contents
1 General information.............................................................................................................. 5
1.1 Further information........................................................................................................ 5
1.2 Notational conventions................................................................................................. 5
1.3 Symbols and signal words........................................................................................... 6
2 Safety instructions................................................................................................................. 7
3 Features....................................................................................................................................... 9
4 Installation.............................................................................................................................. 10
5 Starting up............................................................................................................................... 12
6 Connections and controls................................................................................................ 13
7 Operating................................................................................................................................. 15
7.1 Starting the device....................................................................................................... 15
7.2 Main menu...................................................................................................................... 15
7.2.1 DMX address............................................................................................................... 16
7.2.2 Network settings (ArtNet)...................................................................................... 16
7.2.3 DMX mode................................................................................................................... 17
7.2.4 Preprogrammed automatic show....................................................................... 17
7.2.5 Manual control........................................................................................................... 17
7.2.6 Operating mode ‘Slave’........................................................................................... 18
7.2.7 Sound control............................................................................................................. 18
7.3 Settings............................................................................................................................. 19
7.4 System information...................................................................................................... 20
7.5 Menu overview.............................................................................................................. 21
7.6 Functions in 10-channel DMX mode..................................................................... 21
7.7 Functions in 18-channel DMX mode..................................................................... 22
7.8 Functions in 108-channel DMX mode................................................................... 24
8 Technical specications.................................................................................................... 26
9 Plug and connection assignment................................................................................. 27
10 Troubleshooting................................................................................................................... 28
11 Cleaning.................................................................................................................................... 29
12 Protecting the environment........................................................................................... 30
Table of contents
Innite Pixel 250 3
Moving Head

4Innite Pixel 250
Moving Head

1 General information
This user manual contains important information on the safe operation of the device.
Read and follow all safety notes and all instructions. Save this manual for future refer‐
ence. Make sure that it is available to all persons using this device. If you sell the
device to another user, be sure that they also receive this manual.
Our products and user manuals are subject to a process of continuous development.
We therefore reserve the right to make changes without notice. Please refer to the
latest version of the user manual which is ready for download under
www.thomann.de.
1.1 Further information
On our website (www.thomann.de) you will nd lots of further information and
details on the following points:
Download This manual is also available as PDF le for you to download.
Keyword search Use the search function in the electronic version to nd the
topics of interest for you quickly.
Online guides Our online guides provide detailed information on technical
basics and terms.
Personal
consultation
For personal consultation please contact our
technical hotline.
Service If you have any problems with the device the
customer service will gladly assist you.
1.2 Notational conventions
This manual uses the following notational conventions:
The letterings for connectors and controls are marked by square brackets and italics.
Examples: [VOLUME] control, [Mono] button.
Texts and values displayed on the device are marked by quotation marks and italics.
Examples: ‘24ch’ , ‘OFF’ .
The individual steps of an instruction are numbered consecutively. The result of a
step is indented and highlighted by an arrow.
Example:
1. Switch on the device.
2. Press [Auto].
ðAutomatic operation is started.
3. Switch o the device.
Letterings
Displays
Instructions
General information
Innite Pixel 250 5
Moving Head
