Stanley SXEW145001 User manual

1
ELECTRIC PRESSURE WASHER
1200W 1450PSI
For service, spare parts or product information,
please contact Smart Marketing Group Pty. Ltd.
AUST. 1300 660 457 N.Z. 0800 474 876
03649 05/18
MODEL NO.
SXEW145001

2
3
These are some suggested articles which could be cleaned
by this pressure washer:
• Concrete driveway • Paved area
• Car • Motorbike
• Truck • Wall
• Garden feature
CONTENTS
Section Page
Suggested Applications 2
Technical Information 2
Introduction 3
Warranty 3 – 4
General Safety Instructions 5 – 6
Personal Safety Instructions 7
Specific Safety Instructions 8
Components and Controls 9
Unpacking & Assembly Instructions 10 – 11
Operating Instructions 12 – 13
Maintenance 14
Cleaning Tips 15
Trouble Shooting 16
Parts Diagram 16
Please take note of serial number and write here for ease of
reference:
Serial Number:
Date of Purchase:
Place of Purchase:
Receipt Number:
TECHNICAL INFORMATION
Specifications
Pressure washer SXEW145001
Maximum pressure 1450PSI
Rated pressure 1015PSI
Flow rate 5.5L/min
Water inlet pressure 1.0 MPa
Max. water temp 35oC
Power Input 1200 W
Noise 102db @ 7m
Mains voltage 240V AC
Mains frequency 50Hz
For any queries or assistance call
Customer Service
AUST. 1300 660 457
NZ 0800 474 876
Hours of operation:
Monday to Friday 8.00am - 5.00pm AEST
Do not return to place of purchase.
Keep your purchase receipt, this will be required
to make any claims under the 24 month warranty.
SUGGESTED APPLICATIONS

2
3
Dear Customer,
Thank you for purchasing this pressure washer which has
passed through our extensive quality assurance processes.
Every care has been taken to ensure that it reaches you in
perfect condition. However, in the unlikely event that you should
experience a problem, or if you require any assistance please
do not hesitate to contact us;
If you have a problem, call customer service do not
return this pressure washer to the place of purchase.
CUSTOMER SERVICE
Australia: 1300 660 457
New Zealand: 0800 474 876
Operating times: Monday – Friday
8.00am - 5.00 pm
Australian Eastern Standard Time (AEST)
EXPRESS WARRANTY STATEMENT
PRESSURE WASHER
You are not required to do anything to register your pressure
washer purchase. Please attach the purchase receipt to this
manual and ensure both are kept safe. We hope you enjoy
your new pressure washer, and if you have any problems call
customer service on the above phone numbers. Do not return to
place of purchase.
Smart Marketing Group Pty Ltd (SMG) warrants that this
pressure washer will be free from manufacturing faults or
defects for 24 months from the date of purchase, providing
original purchase receipt is kept and shown when needed and
is subject to the terms and conditions below.
If a warranty fault appears within the warranty period, SMG
reserves the right to replace or repair the product. In the event
that SMG chooses to replace the product, this original warranty
will expire at the original date. If the product includes various
accessories or components, only the defective accessory or
component will be replaced or repaired.
SMG reserves the right to replace defective parts of the
product with parts and components of similar quality, grade and
composition where an identical part or component is not available.
Products presented for repair may be replaced by refurbished
products of the same type rather than being repaired.
Refurbished parts may be used to repair the products.
WHAT IS COVERED
• Manufacturing fault or defect.
HOW TO CLAIM UNDER THIS WARRANTY
• Call customer service.
• Ensure you have the following: Original purchase receipt,
Model of pressure washer, Serial number of pressure
washer.
• Discuss the issue.
• Customer service will advise which authorised service agent
to take the pressure washer to provided the issue
is a warranty one.
• Take pressure washer to authorised service agent for
repair.
WHAT IS NOT COVERED
• Use of Pressure Washer for hire.
• Commercial use of pressure washer.
• Use of pressure washer in a commercial premises.
• Damage or deterioration due to transport.
• Damage caused by negligence, misuse, abuse or accident
or incorrect voltage and wattage.
• Any corrosion or rusting.
• Damage caused by incorrect set up and start up.
• Replacement parts due to general wear and tear.
• Pressure washers with serial number defacement,
modification or removal.
• Pressure washers which have been serviced by other than
an authorised SMG service agent.
• Pressure washers with no original purchase receipt.
• Pressure washers which have been on sold,
not original purchaser.
• Damage due non-servicing of pressure washer as is
required by this manual.
• Blockages / damage caused by dust, dirt, spiders webs
or insects.
• Damage caused by the incorrect fitting of accessories.
• Damage caused by overloading, overworking
the pressure washer.
• Damage to attached equipment or third party accessories.
• Damage caused by attached equipment or
third party accessories.
CONTACT DETAILS
Smart Marketing Group Pty Ltd
33-35 Lionel Road, Mt. Waverley
Victoria 3149, Australia.
Tel [phone]
Fax [phone]
[email protected]
INTRODUCTION

4
5
As soon as you have purchased the pressure washer, we
recommend that you check to make sure it is intact and that you
read the operating instructions carefully before using it. The
purchase receipt for this product is to be retained and must
be presented if making a claim under the terms of the Smart
Marketing Group (SMG) warranty. Bank account statements are
not acceptable for proof of purchase.
This warranty does not cover pressure washers intended
for hire or use in commercial applications or in commercial
premises. The warranty will under no circumstances extend to
reimbursement or payment of damages, whether direct, indirect
or consequential. The warranty is void if there is evidence
the pressure washers has been modified or tampered with in
any way or used with unauthorised accessories without our
consent.
SMG declines any responsibility or liability whatsoever arising
from misuse or abuse, negligent handling of the pressure
washers or if the product has not been installed or failure
to comply with the relevant safety, operating, setting and
maintenance instructions (see further in this manual).
The warranty does not extend to installation or disconnection
costs.
Any item sent freight forward/collect for repair will be refused.
Warranty repairs are free of charge, provided the appliance is
delivered to our service department or authorised service agent.
The pressure washer will need to be returned, adequately
protected in a box. SMG will not be responsible for any
in-transit loss or damage. Assistance under the warranty will
only be made available if the request is made to our customer
service team on the contact numbers listed below and proof of
purchase is provided.
This is a repair only warranty you will need to take the pressure
washer to the authorised service agent after contacting our
customer service centre.
If the product includes various accessories or components,
only the defective accessory or component will be replaced or
repaired.
SMG reserves the right to replace defective parts of the
product with parts and components of similar quality, grade
and composition where an identical part or component is not
available.
Products presented for repair may be replaced by refurbished
products of the same type rather than being repaired.
Refurbished parts may be used to repair the products.
Damage caused by third party accessories is not covered under
this warranty.
Damage caused to attached equipment or third party
accessories will not be covered under this warranty.
Rust and corrosion are not covered under this warranty.
If a warranty fault is found the freight cost will be credited to the
owner. If no fault is found the product will be returned and any
costs associated with the service will be charged to the owner.
Blockages caused by spider webs, insects, dirt, accumulated
dust, incorrect voltage and wattage are not covered by
warranty. SMG reserves the right to replace or repair the
appliance within the warranty period. Parts found to be
defective due to a manufacturing default will be replaced free
of charge.
In the event of SMG choosing to replace the appliance, the
warranty will expire at the original date of purchase. If no
warranty fault is found the owner will be advised and the
product will be returned and any costs associated with the
service will be charged to the owner.
Our goods come with guarantees that cannot be excluded under
the Australian Consumer Law. You are entitled to a replacement
or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled
to have the goods repaired or replaced if the goods fail to be of
acceptable quality and the failure does not amount to a major
failure. The benefits of this warranty are in addition to any
rights and remedies imposed by Australian State and Federal
legislation that cannot be excluded.
In New Zealand, this SMG warranty is in addition to the
conditions and guarantees which are mandatory as implied by
the New Zealand Consumer Guarantee Act 1993.For service,
spare parts or product information please contact customer
service:
Australia: 1300 660 457
New Zealand: 0800 474 876
CONTACT DETAILS
Smart Marketing Group Pty Ltd
33-35 Lionel Road, Mt. Waverley
Victoria 3149, Australia.
Tel [phone]
Fax [phone]
[email protected]
COMPLETE WARRANTY STATEMENT – PRESSURE WASHER

4
5
ASSEMBLY
This pressure washer MUST be fully assembled by you prior
to use. Failure to do so will result in the warranty being VOID.
Failure to fully assemble this pressure washer may also result in
personal injury.
SAFETY
Before attempting to operate this pressure washer the following
basic safety precautions should be taken to reduce the risk
of fire, electric shock and personal injury. It is important to
read the instruction manual and to understand applications,
limitations and potential hazards associated with this pressure
washer. It is important that you read, understand and follow
these instructions very carefully. This pressure washer is not
intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or
instruction concerning the use of the appliance by a person
responsible for their safety.
BEWARE OF CHILDREN & PETS
Children and pets should be kept out of the operating area.
Children should not be allowed to touch or operate pressure
washers. All pressure washers should be kept out of reach
of children. When NOT in use keep the pressure washer
preferably stored or locked in a secure well ventilated cabinet
or room.
WORK AREA
Work areas and benches should be kept tidy. Cluttered benches
and work areas can cause accidents. Floors should be kept
clean and free from rubbish. Special care should be taken
when the floor is slippery due to sawdust or wax. Always leave
sufficient distance, at least 5 metres between the pressure
washer and the work area.
OPERATING ENVIRONMENT
ALWAYS use your pressure washer in an open well ventilated
area. Do not expose your pressure washer to rain. Do not
expose your pressure washer to direct sunlight. Keep the work
area well lit. Do not use your pressure washer in areas where
there is a risk of explosion or fire from combustible materials,
flammable liquids, paint, varnish, petrol, etc flammable
gases and dust of an explosive nature. As a precaution it is
recommended that you consult an expert on selecting and using
a suitable fire extinguisher and have it available for use in an
emergency when operating the pressure washer.
SELECT A PRESSURE WASHER WITH A
SUFFICIENT RATING
Select the right pressure washer for the job. Do not use a
pressure washer to do a job for which it was not designed. Do
not force a small pressure washer to do the job of a heavy duty
pressure washer. Any damage caused by overloading will void
the warranty. Do not use pressure washers for purposes not
intended.
HOT COMPONENTS
Beware many of the components will get hot during use. Never
touch any of the metal pipes, pump or motor as these may burn.
GUARD AGAINST ELECTRIC SHOCK
Avoid body contact with earthed or grounded surfaces (e.g.
pipes and refrigerators).
DO NOT ABUSE THE POWER CORD
Never yank or pull on the power cord to disconnect it from the
mains supply socket. Never carry or pull your pressure washer
by its power cord. Keep the power cord away from heat, oil,
solvents and sharp edges. Regularly check the plug and cord
and if damaged stop using the pressure washer immediately
and have it replaced by an authorised service facility.
EXTENSION CORDS AND REELS
Use of an extension cord with this product is NOT
RECOMMENDED. If you must use an extension cord, use only
extension cords that are intended for outdoor use. These cords
are identified by a marking “ACCEPTABLE FOR USE WITH
OUTDOOR APPLIANCES, STORE INDOORS WHILE NOT IN USE.”
Use only extension cords having an electrical rating not less
than the rating of the product. Examine extension cord before
use. DO NOT USE DAMAGED EXTENSION CORDS! If damaged
never use always replace.
Always disconnect the extension cord from the power point
before disconnecting the product from the extension cord.
WARNING – To reduce the risk of electrocution, keep all
connections dry and off the ground. Do not touch the plug with
wet hands.
• Do not use the appliance if a supply cord or important parts
of the appliance are damaged, e.g. safety devices, high
pressure hoses, trigger gun.
• If an extension cord is used, the plug and socket must be of
watertight construction.
• WARNING: Inadequate extension cords can be dangerous
• Remove the plug from the socket-outlet during cleaning
or maintenance and when replacing parts or converting the
machine to another function.
GENERAL SAFETY INSTRUCTIONS

6
7
FOR YOUR SAFETY
This pressure washer is to be connected directly to an
outdoor power point.
The electrical system of this pressure washer must be
connected with an automatic 30mA circuit breaker and/
or residual current device (RCD). If uncertain have a
qualified electrician check your electrical system before
use.
All electrical connections are made in a dry area.
Outdoor power points must be weatherproof and installed
by a qualified electrician.
MAINTAIN YOUR PRESSURE WASHER WITH CARE
When not using your pressure washer ensure the ON/OFF
switch is ‘OFF’. Never leave the ON/OFF switch ‘ON’ as this can
damage the pressure washer, and is also a danger if it is started
with the switch ‘ON’ and the power cord is plugged in. Follow
the instructions for lubricating and changing accessories. Keep
handles clean, dry and free from oil and grease. Ensure that
ventilation slots are kept clean and free from dust at all times.
Blocked ventilation slots can cause overheating and damage to
the motor.
STOP PRESSURE WASHER
Ensure that the pressure washer has stopped and is turned
off when not in use, before servicing, lubricating, making
adjustments or when changing any accessories.
DISCONNECT PRESSURE WASHER
Ensure that the pressure washer is disconnected from the
mains supply when not in use, before servicing, making
adjustments or when changing any accessories.
AVOID UNINTENTIONAL STARTING
Ensure that the switch is in the ‘OFF’ position before plugging
the pressure washer into the mains supply.
REMOVE ADJUSTING KEYS AND WRENCHES
Form the habit of always checking to see that any adjusting keys
or wrenches have been removed from the pressure washer
before operating.
FIRE PRECAUTIONS
Always contact your fire authority before using the pressure
washer on fire restricted days. It is not recommended to use
your pressure washer when a total fire ban is in force. As a
precaution it is recommended that an expert is consulted on
obtaining and using a suitable fire extinguisher.
CLEANING YOUR PRESSURE WASHER
Always stop your pressure washer before you commence
cleaning. Always ensure that your pressure washer has cooled,
about one (1) hour, before cleaning and storing. When cleaning
your pressure washer use only a damp soft cloth. NEVER use
liquid or solvents of any type.
RISK OF DAMAGE
Damage may occur if nozzle is used too close to appliance
being cleaned. Always trial test the pressure washer on an
inconspicuous part of the appliance. Beware poor paint and
rust as the water will lift poor paint and cause rust spots to
grow. Damage caused by pressure washer is not covered by
warranty.
CHECK DAMAGED PARTS
Before using the pressure washer it should be carefully
checked to determine that it will operate properly and perform
its intended function.
Check for broken or missing parts and have them replaced
or repaired at an authorised service facility. Check any
other condition that may affect the operation of the pressure
washer. A guard or any other part of the pressure washer
that is damaged should be properly repaired or replaced by an
authorised service facility unless otherwise indicated in this
instruction manual.
Any switch that does not operate correctly must be replaced by
an authorised service facility.
DO NOT use the pressure washer if the ‘ON / OFF’ motor switch
does not turn the pressure washer ‘ON’ and ‘OFF’.
GENERAL SAFETY INSTRUCTIONS

6
7
WARNING
Only use pressure washer when fully assembled
Do not attempt to modify the pressure washer in any way; this will VOID your warranty.
The use of any attachment or accessory other than those recommended in this instruction manual could result in damage to the
pressure washer and could cause injuries to the operator.
This pressure washer complies with Australian / New Zealand and International standards and safety requirements. Repairs
should only be carried out by qualified persons using original spare parts. Failure to do so may result in considerable danger to
the operator.
CLOTHING
Do not wear loose clothing, jewellery or anything that could get
caught in moving machinery.
HAIR
Long hair should be tied back or contained in a protective
covering.
EYE PROTECTION
The use of safety goggles is highly recommended (normal
glasses are not sufficient for eye protection) when using
pressure washers. Prescription glasses do not have safety
lenses.
FOOTWEAR
Where there is the risk of heavy objects or if there is a risk
of slipping on wet or slippery floors, suitable non–slip safety
footwear should be worn. Protect your feet from dropping
accidents.
EAR PROTECTION
The use of ear protection is highly recommended when using
pressure washers. The continual noise may damage your ears.
RESPIRATORY PROTECTION
When cleaning dirt, concrete, man-made fibres, especially MDF
(Medium Density Fibre board), the resin used in these materials
can be hazardous to your health. Use an approved face mask
with replaceable filter.
DO NOT OVER REACH
Do not over reach. Keep a proper footing and maintain your
balance at all times. Avoid using abnormal stances and
awkward body positions.
STAY ALERT
Watch what you are doing, use common sense, and never
operate a pressure washer when you are tired, drinking alcohol,
taking drugs or if taking medication that causes drowsiness.
PERSONAL SAFETY INSTRUCTIONS

8
9
Warning! Do not use the pressure washer in areas where
there is a risk of explosion or fire from combustible materials.
The sparks possibly caused when using this pressure washer
may ignite combustible materials as well as flammable liquids,
paint, varnish, petrol, flammable gases and dust of an explosive
nature. As a precaution it is recommended that you consult an
expert on a suitable fire extinguisher and its use. Ensure that the
work area is kept clear of combustible materials.
Warning! Do not use the pressure washer indoors or in
confined spaces.
• Fully assemble pressure washer before use.
• Ensure the pressure cleaner is ‘OFF’ before plugging into the
mains power supply.
• Always use the pressure washer in an open well
ventilated area.
• Unit will become hot during use. Please keep pressure
washer at least one metre (1m) away from buildings, other
equipment, pedestrian areas or flammable materials.
• Ensure the pressure washer has stopped before servicing,
or changing accessories.
• Do not attempt to modify the pressure washer, guards or the
supplied accessories in any way.
• Never operate or store the pressure washer on its side,
ALWAYS operate or store in an upright manner on firm,
solid ground.
• Ensure that the pressure washer has stopped and turned
off when not in use, before servicing, lubricating, making
changes and when changing accessories.
• Your pressure washer is factory set, NEVER attempt to
speed it up as this could endanger the user and damage the
pressure washer and/or attached accessories.
• If the pressure washer makes an unfamiliar sound or
vibrates excessively, switch the pressure washer ‘OFF’
immediately. Investigate the possible cause or consult your
authorised service agent.
• Never use coolant in the pressure washer as damage may
occur.
• Do not tamper or alter any parts as this may cause personal
injury or damage the pressure washer.
• Never point gun/lance at people or animals.
• Never hose or wet people or animals.
• Never spray the pressure cleaner.
• Never spray electrical connections, electrical outlets or
electrical appliances/fixtures.
• Never operate the pressure cleaner without water, any
damage caused will not be covered by warranty.
• Never use hot water.
• Maximum water temperature is 35ºC.
• Only use cold water with this pressure cleaner.
• Bystanders or people watching must be at least 10m away
from operating the pressure cleaner.
• Only use clean water with this pressure cleaner.
• Never pump acids, alkaline, solvents or flammable liquids
through this pressure cleaner, any damage caused will not
be covered under warranty.
• Inlet water hose size must be at least 12mm diameter.
• Inlet flow rate must be at least 18 L/min and mains pressure.
• Damage may occur if pressure washer nozzle is held too
close to the cleaning surface. Damage caused will not be
covered under warranty.
• Always trial the pressure washer cleaner and selected
nozzle on an inconspicuous part of the product to be
cleaned.
• Ensure that the pressure cleaner is disconnected from the
mains supply when not in use, before making changes or
cleaning.
• Always carry your pressure cleaner by its handle.
• Only use Bio-Degradable detergent, with a PH level 6 – 8.
• NEVER use hot, dirty or chemically infested water as it will
damage your pressure cleaner. Only use cold clean water
• Do not start the pressure cleaner with the water trigger ‘ON’.
• Never use a pressure cleaner when standing on a ladder. If
additional height is required a stable platform or approved
scaffold must be used.
• Never clamp your pressure cleaner to a bench or other
device, IT IS A HAND HELD TOOL.
ELECTRICAL DATA
IMPORTANT
This pressure washer is fitted with a sealed electrical connection plug that is compatible with the mains power supply for
Australia / New Zealand and meets the requirements of Australian Standards. This air compressor must be connected to a
supply voltage that is equal to that stated on the rating label. If the mains power connection plug or power cord becomes
damaged you must stop using the pressure washer immediately and it must be replaced with a complete assembly that is
identical to the original, and this must be replaced by an authorised service centre. Always follow the Australian / New Zealand
requirements for connection to the mains supply. If in doubt always consult a qualified electrician.
SPECIFIC SAFETY INSTRUCTIONS

8
9
1. Power cord and plug (not shown)
2. On / Off Switch
3. Hose and power cord hook
4. Handle
5. Gun with trigger
6. Nozzle
7. Gun and accessories hook
8. Lance
9. Wheel
10. High pressure hose connection
PIC. 1
9
5
8
6
7
2
10
3
4

10
11
UNPACKING
Note: Carefully unpack your pressure washer. Dispose of all
packing material in an environmentally responsible manner.
Open carton, gently lift the pressure washer clear of the carton
and packaging, Remove from plastic bag.
Note: Plastic bags can be a danger to young children, dispose
of immediately. Always dispose of packaging in a responsible
manner.
Your Pressure Washer needs minor assembly before use.
CONNECTING LANCE TO GUN (PIC. 2)
• Push the lance into the gun firmly.
• Then twist the lance clockwise while still pushing in.
• This will lock the lance in to position.
CONNECTING NOZZLE TO LANCE (PIC. 3)
• Push the red button on the lance in firmly.
• Then push in the selected nozzle.
• Release the red nozzle and ensure the nozzle is
firmly fitted.
• This will lock the lance in to position.
SELECTING NOZZLE
This pressure washer is supplied with 2 different nozzles, see
page 13 for details;
• An adjustable nozzle.
• A turbo nozzle.
HANDLE (PIC. 4)
Fit handle by;
1. Push handle onto pressure washer frame.
2. Secure with 2 screws and tighten fully by hand.
HOLDERS (PIC. 4)
1. Hose holder in on the “power cord” side.
2. To fit slide down onto the lug and push down till it locks
in place.
3. Nozzle holder is on the other side.
4. To fit slide down onto the long lug.
PIC. 2
PUSH IN LANCE AND TWIST TO LOCK
PIC. 3
HANDLE
HOSE
HOLDER NOZZLE
HOLDER
PIC. 4
UNPACKING & ASSEMBLY

10
11
PRESSURE HOSE TO PUMP CONNECTION (PIC. 5)
To connect hose;
1. Push lever in towards the left and push the hose fitting in,
release the lever. Hose fitting should be locked in place.
PRESSURE HOSE TO GUN CONNECTION (PIC. 6)
To connect hose;
1. Push hose lever in towards the gun and push the hose fitting
in, release the hose lever. Hose fitting should be locked in
place.
GARDEN CONNECTION (PIC. 7)
1. Screw clear garden hose/filter connection to pump. PUSH LEVER
TO LEFT
PIC. 5
HOSE LEVER
PUSH IN
PIC. 6
PIC. 7

12
13
WARNING: THIS UNIT IS INTENDED TO BE USED WITH COLD
WATER ONLY! DO NOT USE HOT WATER IN THIS PRESSURE
CLEANER!
STARTING AND STOPPING YOUR PRESSURE CLEANER
Never switch your pressure cleaner ON unless the water has
been turned on and connected to the pressure cleaner first.
Your pressure cleaner is equipped with an automatic on/off
switch. The pressure cleaner will only run when the power
switch is in the ON position and the trigger on the gun is
squeezed, with water flowing through. When you release the
trigger to stop spraying water through the gun, the motor will
automatically shut off. Simply squeeze the trigger again to
resume using the cleaner. Always ensure that you plug your
pressure cleaner into a standard 240V AC power point.
OPERATING SWITCH
To turn your pressure cleaner ON, rotate the switch to ‘ON/l’.
To turn your pressure cleaner OFF, push the switch to’OFF/0’.
GUN SAFETY LOCK (PIC. 8)
This pressure cleaner is equipped with a gun trigger safety lock.
When not using the pressure cleaner, use the safety lock to
keep from accidentally engaging the high pressure spray.
BLEEDING THE PRESSURE WASHER SYSTEM
It is very important to bleed the gun before using the pressure
cleaner.
To bleed the gun, simply connect the garden hose to the
pressure cleaner and squeeze the trigger BEFORE turning the
electrical supply on. This allows any air trapped inside the
pressure cleaner and gun to be removed before using the unit.
Continue holding trigger for approximately one minute to allow
any excess air out of the unit. Water will flow through the gun at
low pressure during this procedure.
TO START USING
1. Ensure your pressure washer is fully assembled, including
the lance and nozzle.
2. Ensure the high pressure hose is firmly connected to the
units outlet.
3. Connect your water hose to the pressure cleaner inlet.
4. Connect your water hose to the mains tap and turn on.
5. Un-lock the safety gun lock.
6. Bleed the pressure washer system.
7. Connect your pressure cleaner to a 240V AC power outlet
and turn on.
8. Switch pressure cleaner ON.
9. Pick up gun, point at object to be cleaned and squeeze
trigger.
NOTE: The unit should be turned completely OFF while not in
use or while unattended.
PIC. 8
OPERATING INSTRUCTIONS

12
13
PIC. 9
TO STOP USING
1. Release the trigger and switch the unit to the OFF position.
2. Turn the main water tap OFF.
3. Squeeze the trigger to release the water pressure.
4. Engage the safety gun lock.
5. Disconnect the water hose and pack up your pressure
washer.
6. Once cool, about 1hr, wipe your pressure washer down and
store in a secure location.
NOZZLES
Your pressure washer is supplied with these nozzles;
ADJUSTABLE NOZZLE (PIC. 9)
This nozzle can be adjusted while in use there is no need to stop
the water flow.
Being an adjustable nozzle, there are many different positions
which will give a variety of different spray widths and water
pressure.
WARNING: Never point or spray water at people or animals,
injury will occur.
WARNING: When adjusting the nozzle be careful of your hand
as the injury may occur if the water spray touches your hand.
LOW PRESSURE AND WIDE SPRAY
• While holding the gun twist the nozzle to the left.
HIGH PRESSURE AND NARROW SPRAY
• While holding the gun twist the nozzle to the right.
TURBO NOZZLE
This nozzle has a circular spray pattern which also oscillates
slightly. This is ideally used for pavers or concrete.
TO CHANGE NOZZLES
1. Ensure the pressure cleaner is turned OFF.
2. Push the red button on the lance in.
3. Remove the nozzle.
4. Select the next nozzle.
5. Push the red button on the lance in.
6. Push the nozzle in and release the red button.
7. Turn pressure washer back on and continue cleaning.

14
15
It is recommended after every use or when required that
following items are cleaned.
NOZZLE
When the nozzle is clogged, it will cause the pump to build
pressure and may cause unit to surge, you can clean the nozzle
inserting needle into the tip to rid of the deposits.
For the adjustable nozzle, you can also lubricate the nozzle
collar (high pressure to low pressure ) by using non-water
soluble grease regularly.
INLET FILTER
The inlet filter may become blocked.
To check and clean:
1. Turn unit OFF and disconnect from mains power.
2. Turn water OFF.
3. Bleed off excess water and disconnect from mains water.
4. Unscrew and remove hose connector.
5. Remove white filter and check and clean.
6. Once clean replace white filter and re-fit the hose
connector.
7. Turn Water on and bleed pressure washer.
8. Turn pressure washer on and resume cleaning.
CLEANING
NEVER use this pressure cleaner to clean itself. Damage caused
by cleaning the pressure washer with its own gun will not be
covered under warranty. Ensure pressure washer is cool before
cleaning, about 1 hour after use.
• Wipe down all surfaces with a soft clean cloth.
• Rinse all nozzles, detergent bottle in a bucket of clean water.
• Allow to dry before storing.
STORAGE
NOTE: When storing the pressure washer, parts, and
accessories always store in a secure area with a temperature
above 0° C.
LONG-TERM STORAGE
FOLLOW ALL OF THE NORMAL SHUT-DOWN PROCEDURES
HOWEVER ADD THESE FOLLOWING STEPS….
• After disconnecting the water supply, and before
disconnecting the high-pressure hose, turn the pressure
cleaner on for 2-3 seconds, until any remaining water in the
pump exits. TURN UNIT OFF IMMEDIATELY.
CONTINUED USE OF THE PRESSURE CLEANER WITHOUT
WATER SUPPLY ATTACHED WILL CAUSE SEVERE DAMAGE TO
THE UNIT!
MAINTENANCE INFORMATION

14
15
RECOMMENDATIONS
If painted surfaces are peeling or chipping, use extreme
caution as pressure washer may remove the loose paint
from the surface. Note: Always pre-test any paint work in an
inconspicuous area in case of paint damage.
DECK CLEANING - WITH OR WITHOUT DETERGENT
Pre-rinse deck and surrounding area with fresh water. If using
deck wash, place deck wash into a bucket of cold water and
apply with a brush and thoroughly clean area.
For best results, limit your work area to smaller sections of
approximately 2m square, allow deck wash to remain on surface
1-3 minutes.
Do not allow deck wash to dry on surface, if surface appears to
be drying, simply wet down surface with fresh water.
Rinse at high pressure in a long sweeping motion keeping the
spray nozzle approximately 75mm to 150mm from the cleaning
surface. Always clean from top to bottom and from left to right.
For stubborn dirt/stains you can use the turbo nozzle. Be careful
as the turbo nozzle may damage timber or some surfaces if held
too close or too long on the area.
When moving on to a new section of the cleaning surface, be
sure to overlap the previous section to eliminate stop marks and
ensure a more even cleaning result.
HOUSE SIDING - WITH OR WITHOUT DETERGENT
Pre-rinse cleaning surface with fresh water. If using house
wash, place house wash into a bucket of cold water and apply
with a brush and thoroughly clean area. For best results apply
house wash from bottom to top and limit your work area to
smaller sections of approximately 2m square, allow house wash
to remain on surface 1-3 minutes.
Do not allow house wash to dry on surface, if surface appears
to be drying, simply wet down surface with fresh water.
Rinse at high pressure from top to bottom in an even sweeping
motion keeping the spray nozzle approximately 150mm from the
cleaning surface.
CEMENT PATIOS, BRICK & STONE - WITH OR
WITHOUT DETERGENT
Pre-rinse cleaning surface with fresh water. If using all
purpose cleaner, place all purpose cleaner into a bucket of
cold water and apply with a brush and thoroughly clean area.
For best results, limit your work area to smaller sections of
approximately 2m2. Allow all purpose cleaner to remain on
surface 1-3 minutes.
Do not allow all purpose cleaner to dry on surface, if surface
appears to be drying, simply wet down surface with fresh water.
Rinse at high pressure in a sweeping motion keeping the spray
nozzle approximately 75mm to 150mm from the cleaning surface.
CLEANING TIPS
Always clean from top to bottom and from left to right. For
stubborn dirt/stains you can use the turbo nozzle. Be careful as
the turbo nozzle may damage timber or some surfaces if held
too close or too long on the area.
CARS, BOATS & MOTORCYCLES - WITH OR WITHOUT
DETERGENT
Pre-rinse vehicle with fresh water. If using vehicle wash, place
vehicle wash into a bucket of cold water and apply with a soft
sponge or cloth and thoroughly clean area. For best results,
limit your work area to smaller sections of approximately 2m2.
Allow vehicle wash to remain on surface 1-3 minutes. For best
results, clean one side of vehicle at a time and always apply
vehicle wash from bottom to top, do not allow vehicle wash to
dry on surface. Rinse at high pressure in a sweeping motion
keeping the spray nozzle approximately 150mm to 200mm from
the cleaning surface (distance should increase with pin-striping,
decals or other sensitive surfaces).
Always clean from top to bottom and from left to right. For best
results, wipe surface dry with a chamois or soft dry cloth.
BBQ GRILLS, OUTDOOR POWER EQUIPMENT &
GARDENING TOOLS - WITH OR WITHOUT DETERGENT
Pre-rinse surface with fresh water. If using all purpose cleaner,
place all purpose cleaner into a bucket of cold water and apply
with a brush and thoroughly clean area. For best results, limit
your work area to smaller sections of approximately 2m2. Allow
all purpose cleaner to remain on surface 1-3 minutes.
Do not allow all purpose cleaner to dry on surface, if surface
appears to be drying, simply wet down surface with fresh water.
Rinse at high pressure keeping the spray nozzle approximately
75mm to 150mm from the cleaning surface. For removing
extremely stubborn dirt, it may be necessary to move the spray
nozzle even closer to the surface for greater dirt cutting action
or you can use the turbo nozzle. Be careful as the turbo nozzle
may damage timber or some surfaces, including chipped paint if
held too close or too long on the area. To remove caked-on mud
from garbage cans, lawn mower blades, wheelbarrows or other
non-sensitive metal surfaces.
PATIO & LAWN FURNITURE - WITH OR WITHOUT
DETERGENT
Pre-rinse surface with fresh water. If using all purpose cleaner,
place all purpose cleaner into a bucket of cold water and apply
with a brush and thoroughly clean area. For best results, limit
your work area to smaller sections of approximately 2m2. Allow
all purpose cleaner to remain on surface 1-3 minutes.
Do not allow all purpose cleaner to dry on surface, if surface
appears to be drying, simply wet down surface with fresh water.
Rinse at high pressure keeping the spray nozzle approximately
75mm to 150mm from the cleaning surface. For stubborn dirt/
stains you can use the turbo nozzle. Be careful as the turbo
nozzle may damage timber or some surfaces, including chipped
paint if held too close or too long on the area.

16
TROUBLE SHOOTING
WHEN THE SWITCH IS IN THE “I” POSITION THE MACHINE WILL NOT START
Possible Cause Suggested Fix
Electrical socket is faulty Check plug, socket, fuses
Power cord is not plugged in Plug in power cord
THE PUMP DOES NOT REACH ADEQUATE PRESSURE OR FLUCTUATES
Water inlet filter is clogged Remove and clean filter
Pump is drawing air Tighten connections/bleed system
Suction valves are clogged/worn Clean or replace valves
Black detergent nozzle is attached Remove detergent nozzle and attach a high pressure nozzle
Diameter of garden hose too small Replace with 12mm or bigger garden hose
Water supply is restricted Check hose for kinks or leaks
Insufficient water supply Fully open water source
THE PRESSURE CLEANER HAS OR WILL NOT MAINTAIN PRESSURE
Excessive air in waterline and pump Turn unit off / bleed system
THE PRESSURE CLEANER MAKES EXCESSIVE NOISE
Filter is dirty Check, clean, or replace filter
1
2
3
4
5
PARTS DIAGRAM
Part Description Part No.
1 Handle 84 EW1450H
2 Gun 84 EW1450GT
3 Nozzle Holder 84 EW1450NH
4 Lance 84 EW1450L
5 Hose Holder 84 EW1450HH
User replaceable parts listed below. All other parts must be
serviced/replaced by an authorised service agent.
STANLEY®, The STANLEY Logo, The Notched Rectangle and the Yellow and
Black Diagonal Package Design are all trademarks of the Stanley Black & Decker,
Inc or an affiliate thereof and are used under license. Product manufactured
and distributed by Smart Marketing Group Pty Ltd. Manufactured in China.
