Star Trac E Series Operation manual

Service Menu
STAR TRAC FITNESS 1 635-4116 Rev: A
Diagnostic Mode
E Series: All Embedded Units
The following procedure will show you how to enter the Diagnostic Mode of the all E Series Embedded Products
Step 1
Start on the default screen (Fig. 1)
Fig. 1
Step 2
Press and hold the VOL ‘+’ key and the CH ‘+’ key and the number ‘3’
key on the keyboard at the same time to enter the Service Menu (Fig.
2).
VOL
CH
Step 3
Press the number ‘3’ key on the keyboard or touch “Diagnostic Mode”.
Fig. 2

Service Menu
STAR TRAC FITNESS 2 635-4116 Rev: A
Step 4
Enter the Password “2 1 8” and press ‘OK’. (Fig.3)
Fig. 3
Step 5
When in Diagnostic Mode press all keys on the keypad to verify they
are working properly. The name of the selected key will be displayed
for apprx. 6 seconds (it will not remain displayed) in the “Key Press
Monitor” box at the lower left hand side of the screen.
Then, “No Key” will be displayed (Fig. 4).
Fig. 4
Step 6
Example 1
‘Quick Start’ key was pressed (Fig. 5)
Fig. 5

Service Menu
STAR TRAC FITNESS 3 635-4116 Rev: A
Step 7
Example 2
‘Volume Up’ key was pressed (Fig. 6)
Fig. 6
Step 8
Example 3
Number ‘5’ was pressed (Fig. 7)
Fig. 7
Step 9
To test the Contact Heart Rate system, grab the heart rate grips. The
current measured heart rate will be displayed in the HR Monitor
window with the word “Contact” (Fig. 8).
Fig. 8

Service Menu
STAR TRAC FITNESS 4 635-4116 Rev: A
Step 10
To test the Telemetry Heart Rate system, either a heart rate strap or
heart rate simulator is required. The current telemetry heart rate will be
displayed in the HR Monitor window with the word “Telemetry” (Fig. 9).
Fig. 9
To exit the Diagnostic Mode, use one of your fingertips and gently touch ‘Exit’ on the touch screen or press the ‘OK’ key
on the keypad.
Step 11
Test unit for proper function.
