Starkey Remote Microphone Plus Operator's manual

Pairing
The Remote Microphone Plus must be paired to interact with compatible 2.4 GHz hearing aids on the Thrive platform.
Pairing occurs once, then the hearing aids and Remote Microphone Plus will automatically recognize each other.
1Power off your smart device or other accessories that were previously paired with your hearing aids.
2Ensure the Remote Microphone Plus is powered on.
3Power off, then power on your hearing aids to place in pairing mode.
4Place your hearing aids within 6 inches of the Remote Microphone Plus.
5Press the Input Mode and Volume Up buttons simultaneously for 7 seconds
until the LED status indicator alternately blinks blue and red.
6A green LED will blink for each hearing aid to confirm a successful pairing.
Pairing Remote Microphone Plus to Bluetooth Devices
1Power off your smart device or other accessories that were previously paired with your hearing aids.
2Ensure the Remote Microphone Plus is powered on.
3Press the Input Mode and Volume Down buttons simultaneously
for 7 seconds until the LED status indicator rapidly blinks blue.
4Put the Bluetooth®device into pairing mode.
5When the Remote Microphone Plus appears, select it on the Bluetooth device.
6The Remote Microphone Plus LED will turn green for 2 seconds with successful pairing.
Remote
Microphone Plus
FM Receiver Jack
Microphones
Multi-Function Button
Input Mode Button
Input Mode LEDs
Clip
MicroUSB Jack
Stream
Volume
Up/Down
5
Volume +
Input
Mode
3
Volume −
Input
Mode

Use
• Press the Multi-function button for 2 seconds
to power the Remote Microphone Plus on or off.
• The Remote Microphone Plus can be clipped to
clothing or worn on a lanyard.
• Remote Microphone Plus operating range is up to
30 feet (10m).
• The Remote Microphone Plus can stream for up to
10 hours on a full charge.
• The Remote Microphone Plus reaches a full charge
in 3 hours.
• The LED status indicator will blink red and an
audible indicator tone will play in your hearing aids
every 5 minutes when the Remote Microphone
Plus battery is low.
• The Remote Microphone Plus will momentarily
mute if it is dropped and will resume streaming
once the device is stabilized.
• To adjust the stream volume, press the +or -
buttons on the Remote Microphone Plus. Volume
can also be adjusted via the hearing aid user
controls, the Remote Control accessory (if
applicable) or in the Thrive Hearing Control app.
• When the audio source is set to Remote Mic
or to Bluetooth for phone streaming, the Remote
Microphone Plus should be within 8 inches (20cm)
of the speaker’s mouth. Wearing the Remote
Microphone Plus in a vertical position provides
the best performance (see image below.)
Input Mode
1Press the Input Mode button to advance to the
next available audio source. When cycling
through input modes, the FM System and Line-
In options will only be available when physically
attached to the Remote Microphone Plus.
2If the Input Mode LED is off, press the Input
Mode button to temporarily illuminate the LED.
3When the Remote Microphone Plus is powered
off, it will remember the input mode that was
last used and will return to that position when
powered back on.
Audio Source Options
Remote Microphone:
• Ensure the Remote Microphone Plus is powered on
and the input mode is set to Mic.
• Streaming starts automatically in your hearing aids.
• The Remote Microphone Plus can be worn by the
speaker or can be set on a tabletop.

Input Mode (Continued)
Incoming/Outgoing
Phone Call Streaming:
• Ensure the Remote Microphone Plus is powered
on and the status indicator LED is blue.
• Press the Multi-function button
to accept an incoming call.
• For an outgoing call, dial the number
on the mobile phone. Streaming
starts automatically in your
hearing aids.
• Press the Multi-function button
to end a phone call.
• Once the phone call has ended,
the Remote Microphone Plus
will automatically return to the
previous input mode.
• To reject a phone call, press the Multi-function
button for more than 2 seconds.
Other Audio Streaming
• Ensure the Remote Microphone Plus
is powered on.
• Set the input mode to Bluetooth.
The LED indicator will be blue
when connected to a
Bluetooth device.
• Start music or other
audio on your Bluetooth
device. Streaming starts
automatically in your hearing aids.
Loop System
Remote Microphone Plus can receive
audio via a built-in telecoil when using
a Loop System. Wearing the Remote
Microphone Plus in a vertical orientation
provides the best performance.
To stream Loop audio:
• Ensure the Remote Microphone Plus is
powered on and the input mode is set to Loop.
• Streaming starts automatically in your hearing aids.
FM System
• Insert the FM system transmitter into Europin Jack.
• Ensure the Remote Microphone
Plus is powered on and the
input mode is set to FM system.
• Streaming starts automatically
in your hearing aids.
Line-In
When a Line-In cable is attached via the microUSB
Jack, the Remote Microphone Plus can receive audio
from a mobile phone that’s not using a Bluetooth
technology, MP3 player, tablet or computer.
To stream Line-In audio:
• Insert the Line-In cable into
the microUSB Jack.
• Ensure the Remote
Microphone Plus is powered
on and
the input mode
is set to Line-In.
• Start music or other audio
on your
electronic audio source. Streaming
starts automatically in your hearing aids.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Starkey is under license.
The Starkey logo, Starkey Hearing Technologies and Thrive are trademarks of Starkey Inc.
©2021 Starkey. All Rights Reserved. 3/21 FLYR3405-04-EE-GS
