StarTech.com ECUSB3S2 User manual

Manual Revision: 11/28/2012
For the most up-to-date information, please visit: www.startech.com
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
ECUSB3S2
2 Port ExpressCard SuperSpeed USB 3.0 Adapter
*actual product may vary from photos

Instruction Manual
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by
turning the equipment o and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only and do not
represent an endorsement of a product or service by StarTech.com, or an endorsement of the
product(s) to which this manual applies by the third-party company in question. Regardless
of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby
acknowledges that all trademarks, registered trademarks, service marks, and other protected
names and/or symbols contained in this manual and related documents are the property of
their respective holders.

Instruction Manual
i
Table of Contents
Introduction ............................................................................................1
Packaging Contents ................................................................................................................................. 1
System Requirements .............................................................................................................................. 1
Installation ..............................................................................................2
Hardware Installation .............................................................................................................................. 2
Driver Installation ...................................................................................................................................... 2
Verifying Installation ................................................................................................................................ 3
Specications ..........................................................................................4
Technical Support ..................................................................................5
Warranty Information ............................................................................5

Instruction Manual
1
Introduction
10x faster than that of USB 2.0, this SuperSpeed USB 3.0 adapter card enables you to
access your data and transfer les much faster than USB 2.0! The new USB 3.0 standard
supports transfer rates of up to 5Gbps, while still providing connectivity and support
for the older USB 2.0 (480Mbps) and 1.1 (12Mbps) devices.
Packaging Contents
• 1 x USB 3.0 ExpressCard Adapter
• 1 x Driver CD
• 1 x Instruction Manual
System Requirements
• ExpressCard/34 or /54 enabled computer system
• Microsoft® Windows® 2000/ XP/ Server 2003/ Vista/ 7 (32/64-bit) / 8 (32/64-bit)
USB 3.0 type
A ports
DC power connector
(on opposite side)

Instruction Manual
2
Installation
Hardware Installation
1. ExpressCard adapters can be hot-plugged into a computer system, while running.
Turning the computer o to insert/remove ExpressCard adapters is not necessary.
2. Locate your computer’s ExpressCard slot. This card can t into an ExpressCard/34 or
ExpressCard/54 slot.
3. Slide the adapter card into the ExpressCard slot fully and you should hear the card
engage with a clicking noise.
NOTE: Some ExpressCard/54 slots hold an ExpressCard/34 adapter loosely, so
movement of the computer or the adapter card can result in accidental disconnection.
An ExpressCard/34 to /54 bracket is recommended for those types of computers
(i.e. StarTech.com ID: ECBRACKET).
4. The card should now be detected by the computer systems operating system.
5. To remove the card, press the card into the ExpressCard slot all the way and
you should hear it disengage with a clicking sound. The card should now be
automatically ejected from the slot.
OPTIONAL: If the ExpressCard slot on the computer does not provide enough power
to the USB ports, an external power adapter would be required and plugged into the
DC power connector.
Driver Installation
Windows XP/Server 2003/Vista/7
1. Once the computer has started and the operating system is fully loaded, insert the
provided Driver CD into the computer’s CD/DVD drive.
2. AutoPlay should give you the option to browse the les on the CD or automatically
open the CD.

Instruction Manual
3
If Autorun does not start, Go into “My Computer” and access the CD/DVD drive that
the CD is in.
3. Run the “setup.exe” le located in “ExpressCard USB 3.0 2Port Card (ECUSB3S2)”.
Follow the onscreen instructions to complete the driver installation.
Verifying Installation
Windows 2000/XP/Server 2003/Vista/7
From the main desktop, right-click on “My Computer” (“Computer” in Vista/7), then
select Manage. In the new Computer Management window, select Device Manager
from the left window panel.
In the Device Manager, under the Universal Serial Bus Controllers category, you should
see the new entries for the USB 3.0 controller card.

Instruction Manual
4
Specications
Bus Interface
ExpressCard (34mm form factor)
USB 3.0 rev1.0
Intel xHCI rev0.95
External Connectors 2 x USB 3.0 type A Female
1 x DC power connector
Chipset ID NEC uPD720200
Maximum Data Transfer Rate USB 3.0: 5Gbps
Operating Temperature 0°C ~ 50°C (32°F ~ 122°F)
Storage Temperature -20°C ~ 60°C (-4°F ~ 140°F)
Humidity 0% ~ 85% RH
Power Adapter (optional) 5VDC, 2A, type H plug,
center positive
Compatible Operating Systems Windows 2000/XP/Server 2003/Vista/
7 (32/64-bit) /8 (32/64-bit)

Instruction Manual
5
Technical Support
StarTech.com’s lifetime technical support is an integral part of our commitment to
provide industry-leading solutions. If you ever need help with your product, visit
www.startech.com/support and access our comprehensive selection of online tools,
documentation, and downloads.
For the latest drivers/software, please visit www.startech.com/downloads
Warranty Information
This product is backed by a lifetime warranty.
In addition, StarTech.com warrants its products against defects in materials
and workmanship for the periods noted, following the initial date of purchase.
During this period, the products may be returned for repair, or replacement with
equivalent products at our discretion. The warranty covers parts and labor costs only.
StarTech.com does not warrant its products from defects or damages arising from
misuse, abuse, alteration, or normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their
ocers, directors, employees or agents) for any damages (whether direct or indirect,
special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,
or any pecuniary loss, arising out of or related to the use of the product exceed the
actual price paid for the product. Some states do not allow the exclusion or limitation
of incidental or consequential damages. If such laws apply, the limitations or exclusions
contained in this statement may not apply to you.
