StarTech.com 116E-USBC-DOCK User manual

Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: April 28, 2023 3:19 PM
Product Diagram (Side A)
USB-C Triple Monitor Dock 2x DP/3x HDMI - 2x USB-C/3x USB-A - GbE - 100W PD
6
1
4 5
9
8
Component Function
1Power Button • Press and release to toggle power for the Dock
2USB-A Data/Charge Port
• Connect and/or charge a USB-A Peripheral
• USB 3.2 Gen 2 (10 Gbps)
• Supports BC 1.2 5 V/1.5 A (7.5 W) charging
3USB-C Data/Charge Port
• Connect and/or charge a USB-C Peripheral
• USB 3.2 Gen 2 (10 Gbps)
• Supports BC 1.2 5V/1.5A (7.5 W) charging
4USB-C Data Port
• Connect and/or charge a USB-C Peripheral
• USB 3.2 Gen 1 (5 Gbps)
• Supports up to 5 V/0.9 A (4.5 W) of power
53.5mm Audio Port
• Connect an Audio Device
• 4 Position Audio Jack for Headset use
• CTIA/OMTP
710 11 12 13
2
(Side B)
3
Product ID
116N-USBC-DOCK / 116E-USBC-DOCK / 116U-USBC-DOCK
(Side C)
14
6DC 24V Port • Connect the Dock to a Power Source, using the Universal
Power Adapter
7Gigabit Ethernet Port
• Connect the Dock to a Network Device, using a Network
Cable
• 10/100/1000 Mbps
82x USB-A Data Ports
• Connect USB-A Peripherals
• USB 3.2 Gen 1 (5 Gbps)
• Supports up to 5 V/0.9 A (4.5 W) of power
9Video 1 DisplayPort Port • Connect a DisplayPort Display as Video Output #1
• Up to 4K (4096x2160) 60Hz
10 Video 1 HDMI Port • Connect an HDMI Display as Video Output #1
• Up to 4K (4096x2160) 60Hz
11 Video 2 DisplayPort Port • Connect a DisplayPort Display as Video Output #2
• Up to 4K (4096x2160) 60Hz
12 Video 2 HDMI Port • Connect an HDMI Display as Video Output #2
• Up to 4K (4096x2160) 30Hz
13 Video 3 HDMI Port
• Connect an HDMI Display as Video Output #3
• Up to 4K (4096x2160) 60Hz
• Via DP Alt Mode
14 USB-C Host Port
• Connect to a USB-C Port on a Host Computer
• USB 3.2 Gen 2 (10 Gbps)
• Power Delivery 3.0 Specication
• Capability of charging the Host Computer up to 100W
15 Lock Slot
(K-Slot)
• Connect a K-Slot Style Locking Device to deter the theft of
the Docking Station
Requirements
• Computer
• DP Alt Mode enabled USB-C Port
• Video support and performance on Video Output #3, such as
resolution, and refresh rate depend upon your host computer’s video
controller. Please verify the specications of your computer.
For the latest drivers, manuals, product information, technical specications, and declarations of
conformance, please visit: www.StarTech.com/116N-USBC-DOCK,
www.StarTech.com/116E-USBC-DOCK or www.StarTech.com/116U-USBC-DOCK
(Side D)
15

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-
party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only
and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which
this manual applies by the third-party company in question. StarTech.com hereby acknowledges that all trademarks, registered
trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the
property of their respective holders.
Warranty Information
This product is backed by a 3-year warranty.
For further information on product warranty terms and conditions, please refer to www.startech.com/warranty.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents)
for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of prots, loss of
business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.
Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations
or exclusions contained in this statement may not apply to you.
FR: startech.com/fr
DE: startech.com/de
ES: startech.com/es
NL: startech.com/nl
IT: startech.com/it
JP: startech.com/jp
StarTech.com
Ltd.
45 Artisans Cres
London, Ontario
N5V 5E9
Canada
StarTech.com Ltd.
Unit B, Pinnacle 15
Gowerton Rd,
Brackmills,
Northampton
NN4 7BW
United Kingdom
StarTech.com LLP
4490 South Hamilton
Road
Groveport, Ohio
43125
U.S.A.
StarTech.com Ltd.
Siriusdreef 17-27
2132 WT Hoofddorp,
The Netherlands
Regulatory Compliance
FCC -- Part 15
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation. Changes or modications not expressly approved by StarTech.com could void
the user’s authority to operate the equipment.
Industry Canada Statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.
CAN ICES-3 (B)/NMB-3(B)
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:
(1) This device may not cause interference, and (2) This device must accept any interference, including interference that may
cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation
est autorisée aux deux conditions suivantes:
(1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d’en compromettre le fonctionnement.
IC Radiation Exposure Statement:
This equipment complies with IC RSS-102 radiation exposure limit set forth for an uncontrolled environment. This equipment
should be installed and operated with minimum distance 20cm between the radiator and your body.
Installation
1. Connect the Power Adapter from an AC outlet, to the DC 24V Port on the dock.
2. Connect a USB Peripheral Device to the USB-C (USB 3.2 Gen 2) Data/Charge Port on
the dock.
3. Connect a USB Peripheral Device to the USB-A (USB 3.2 Gen 2) Data/Charge Port on
the dock.
4. Connect USB Peripheral Devices to the USB-A (USB 3.2 Gen 1) Data Ports on the
dock.
5. Connect an RJ-45 terminated network cable (CAT 5e or better) from your local area
network (e.g. Router, Switch, Modem, etc.) to the Gigabit Ethernet Port on the Dock,
to access your network via a wired LAN connection.
6. Video 1
To connect a display using the DisplayPort or HDMI Video Port, connect the
respective cable from the respective port to the display device.
Note: Only a single display can be connected to either of the Video Output #1
output options.
7. Video 2
To connect a display using the DisplayPort or HDMI Video Port, connect the
respective cable from the respective port to the display device.
Note: Only a single display can be connected to either of the Video Output #2
output options.
8. Video 3
Connect an HDMI cable from the HDMI enabled display device, to the HDMI Video
Port on the dock.
9. If you have a Windows computer with Internet access, connect the USB-C Cable to
the USB-C Host Port located on the dock, and to a USB-C port on your host laptop.
Your computer will automatically detect the device and install all the required
drivers.
If you’re running a non-Windows operating system or the drivers do not
automatically install, disconnect the dock from your computer, then:
a. Navigate to www.StarTech.com/116N-USBC-DOCK,
www.StarTech.com/116E-USBC-DOCK or www.StarTech.com/116U-USBC-DOCK,
and click the Drivers/Downloads tab.
b. Under Driver(s), download the Driver Package for your operating system, and
follow the steps outlined in the Installation guide, that’s included in the Driver
Package.
Over Current Protection
To protect your connected devices from power surges, this dock features
Over Current Protection (OCP).
If a high-powered USB Peripheral, such as a USB-powered external drive, is connected
to a USB port on the dock, and the USB Peripheral Device attempts to draw more than
1.8 A of power, the dock will prevent this device from consistently connecting to the
Computer. This may result in the Computer re-recognizing the device continuously,
until the device is disconnected.
For more information on OCP, including details on how to resolve issues with device
detection, please visit www.StarTech.com/116N-USBC-DOCK,
www.StarTech.com/116E-USBC-DOCK or www.StarTech.com/116U-USBC-DOCK, and
select the Product Support tab.
Package Contents
• USB-C Docking Station x 1
• 3 ft (1m) USB-C Host Cable x 1
• Universal Power Adapter x 1
• Quick-Start Guide x 1
