StarTech.com USBthere USB120EXT User manual

USBthere - 2 Port Bus Powered 165 Foot (50 meter) Multi-Speed USB Extender
StarTech ID: USB120EXT
Boost the distance of your USB connection with the USBthere, a two-port multi-speed USB extender from
StarTech.com. You’ll be able to place your full-speed or low-speed USB device up to 165 feet (50m)
away from your computer, an incredible 10 times greater than normal USB length restrictions.
The Local and Remote units connect using standard Cat 5e Ethernet Cable and there’s no need to
buy additional hubs, repeaters, power adapters or software, you just plug in and go.
Applications and Solutions
> Ideal for connecting USB keyboards, mice, printers, scanners and other USB devices to your system from a distance
Features
> Allows users to make use of existing Ethernet infrastructure for extending USB devices
> Comes complete with a 6 foot USB cable
> Compliant with USB 1.1 specifications
> Data transfer rates of up to 12 Mbits/sec
> Easy installation and set up with no software required
> Extends the connection distance of two USB devices to up to 165 feet (50 meters)

> Requires no external power adapter
Specifications
> Color Black
> Enclosure Type Plastic
> Product Height 1.18 in [30 mm]
> Product Length 3.94 in [100 mm]
> Maximum Cable Length 164 ft [50 m]
> Number of Ports 2
> Operating Temperature 4 to 40
> Carton Quantity 30
> Industry Standards USB 1.1
> Shipping (Package) Weight 0.82 lb [0.37 kg]
> Product Weight 3.53 oz [100 g]
> Product Width 2.76 in [70 mm]
> Extension Distance 165 ft (50 m)
> Dimensions 2.7 x 3.9 x 1.2 Inches (70 x 100 x 30 mm)
> Weight 0.2 lb (0.1 kg)
> Total Shipping Weight 0.8 lb (400 grams)
> Maximum power available to USB at the Remote Unit 300 mA when the Local Unit is supplied with 500
mA<br>600 mA when the Local Unit is supplied with 1000 mA
> Data Transfer Rate Up to 12 Mbits/sec
> Local Unit Connectors Upstream: 1 x 4 pin USB (Type B)<br>Downstream: 1 x RJ-45
> Remote Unit Connectors Upstream: 1 x RJ-45<br>Downstream: 2 x 6 pin USB (Type A)
> USB Hub Support Up to 5 hubs connected to the local unit
