Status Instruments SEM1620 User manual

D2442_01_03 CN5219_SEM1620_User_Guide
IMPORTANT - CE & SAFETY REQUIREMENTS
Product must be DIN rail mounted, inside a suitable enclosure providing environmental protection to IP65 or greater.
To maintain CE EMC requirements , input and supply wires must be less than 30 metres.
Dc supply must be derived from a local supply and not a distribution system.
The product contains no serviceable parts , or internal adjustments. no attempt must be made to repair this product. Faulty units must be returned to supplier for repair.
This product must be installed by a qualified person. All electrical wiring must be carried out in accordance with the appropriate regulations for the place of installation.
Before attempting any electrical connection work, please ensure all supplies are switched off.
ABSOLUTE MAXIMUM CONDITIONS ( To exceed may cause damage to the unit):-
Supply Voltage ± 30 V dc (Protected for over voltage and reverse connection)
Current with over voltage ± 200 mA
Input Voltage ± 5 V between any terminals
Input Current ± 100 mA between terminals 7 & 10
Ambient Temperature (-30 to 75) °C Humidity (10 to 95) % RH (Non condensing)
Status Instruments Ltd, Status Business Park, Gannaway Lane, Tewkesbury, Gloucestershire, UK, GL20 FD
Web Page: www.status.co.uk Tel : [phone] Fax: [phone] email : [e-mail]
SEM1620 USER GUIDE
DIN RAIL MOUNTED CONDITIONER
UNIVERSAL INPUT
THREE WIRE VOLTAGE OUTPUT
Every effort has been ta en to ensure the accuracy of this document, however we do not accept responsibility for damage, injury, loss or expense resulting from errors and omissions, and we reserve the right of amendment without notice.
Important - Please read this document before any installing.
PRODUCT SPECIFICATION
RECEIVE AND UNPACKING
CONFIGURATION
Please refer to the product data sheet for full specification, available to down load at www.status.co.uk.
Please inspect the packaging and instrument thoroughly for any signs of transit damage. If the instrument has been damaged, please notify your supplier immediately.
SEM1620
USB LINK SOFTWARE
USB CABLE
Download @
www.status.co.uk
COMPUTER
The following parameter can be configured by simply entering as prompted by the software package.
· Input type (K,J,E,N,T,R,S,mV,PT100,mA)
· Low range
· High range
· Units (°C, °F, mV, mA)
· Burnout (direction of output current on sensor burnout)
· Output Range (0 to 10), (0 to 5), (0 to 1), (1 to 5), and (2 to 10) V
· User Trim (option to lock out front panel trim function)
Factory default:
Input type = P
Units = C
High Range = 100
Low Range = 0
Burnout = UPSCALE
Output range = (0 to 10) V
User Trim = ON
IMPORTANT The SEM1620 can be configured whilst connected and powered, but a portable battery powered computer must be used to avoid the effects of ground loops.
++
--
PT100
+
-
Vs
USB
+
-
+
-
10
9
8
7
mV
mA
SEM1620
5
Universal
Input
6
Vo
4
+
-
Three Wire Voltage Output

USER TRIM
MECHANICAL INSTALLATION
SEM1620 Enclosure
Style DIN 43880 (1 module width)
Material Polyamide 6.6 self extinguishing
Terminals Screw terminal
Cable 2.5 mm Max
Colour Grey
Ø 3 mm
90 mm
MOUNTING
Screw driver
EN50022 DIN RAI
56.4 mm17.5 mm
1
2
11 1210
987
4 5 6
1 2 3
1
2
+ 70 °C Max
- 20 °C Min
UNIVERSAL INPUT CONNECTION
For cable length < 3 Metres no screen or twist pair required.
Thermocouple inputs must use correct compensation cable.
PT100 inputs all three wire must be equal length (resistance).
Use recommended types for cable length (3 to 30) metres.
mV
++
-
-
PT100
m
A
+
-
OUTPUT
Three wire voltage
Max cable length 30 metres
Use twisted pair cable or screened > 3 metres
Ø 3 mm
ELECTRICAL INSTALLATION
Screw Driver
Screened Cable Twisted Pair Cable
10
7
7
9
7 7
TC Compensation Cable
Screened
Supply (Vs ) (15 to 28) V dc
Output (Vo) (0 to 10) V max
O/p drive Current 2 mA
TURN OFF SUPPLY BEFORE WORKING ON ANY
ELECTRICAL CONNECTION
Ø 3 mm
Screw Driver
10
1010
10.
..
.000
000 000
000
Digital Voltage meter
Power supply (24 V dc)
Input Simulator
User trim function allows manual adjustment of the output current, this
is useful for minor calibration adjustment or trimming out any sensor
error, ± 5% of range adjustment is available at both offset and span.
Raise and lower buttons are provided on the front panel, of the
conditioner, accessed using a 3 mm flat blade screw driver. Insert the
screw driver into the appropriate slot to operate the button. The button
has a click action.
METHOD
1.0 Connect input simulator or sensor. Connect supply to a 24 V dc,
connecting a digital volt current meter to output. Turn supply on, set
input to either offset or span calibration point.
+
-
10
1010
10.
..
.00
00 00
00
+
-
SEM1620
or
2.0 Enter trim menu by pressing "raise" button for > two seconds.
When the trim menu is open the range LED will flash :-
> 3 s
Range LED will indicate Trim action
Offset slow toggle
Span fast toggle
Out of trim range
Input out of range
3.0 Trim output voltage by
pressing either the raise or
lower button, single click to
step advance , or press
continuously to auto
advance.
Raise
Lower
4.0 Once trim is complete
allow 30 seconds with no
button press, the cobnditioner
will time out and return to
normal operation.
D2442_01_03 CN5219_SEM1620_User_Guide
Escape
> 30 s
Enter
The conditioner will
automatically detect the correct
trim point (offset or span) based
on the output current drive.
Offset will be trimmed when the
output voltage is within ± 0.1 V
of offset output, span when the
output voltage is within (50 to
105) % of output range.
offset
span
offset
± 0.1 V
50%
Span
105 %
Span
Three Wire Voltage Output
To fit or release module
Insert screw driver into
slot and lever latch
away from body
T/C
1
2
or sensor
Vs
USB
+
-
+
-
10
9
8
7
SEM1620
5
6
Vo
4
+
-
