Introduction of Connected system
The connected system consists of a wireless system with external Passive Infra-Red sensors and SubstiTUBE
Connected tubes. The system can be configured directly on the sensor or by a remote control.
The system provides illumination when vehicles or pedestrians enter a detection zone and goes back to
stand-by mode when no motion is detected.
With the connected system people will experience adequate light and feel safe at reduced energy costs
Application
System overview
Communication between tubes and sensors are Zigbee 3.0 based. It is based on a 2.4 GHz mesh communication
model using low-power devices to transmit data over long distances
Principle of Connected system
All the tubes in the network will lighten up automatically when pedestrians or vehicles (engine heat) are detected.
Duration and delay time (hold time) can be configured by installers. When pedestrians or vehicles are detected
every lamp lights up to 100% or up to the configured setting.
As they move out the detection zone, every lamp dims to a level of 20% or configured set up
The installer can also configure to switch off the lamp
Motion sensing and ambient light measurement functions
For each sensor it is possible to configure the threshold of ambient daylight level.
The primary trigger to react is given by the motion trigger.
If motion is sensed, based on the measured ambient light level, each sensor decides to switch the tubes light on
or not.
Master and Slave sensor
The factory setting of sensor is the slave mode. Once the sensor is electrified
feedback red LED shows up.The assignment to be a master sensor is configured during installation of the network.
First sensor you open the network will be assigned as a master sensor. In a network only one master sensor is
allowed. After installation master and slave sensors can be identified as feedback LED color in sensors
Connected Sensor
Ambient temperature Indoor use, operation –20°C ... +50°C
Storage temperature Storage –25°...+70°C
IP ratings IP 54 (Indoor use)
Master sensor feedback LED color
Slave sensor feedback LED color
SubstiTUBE ® Connected System UI extend version

LEDVANCE GmbH, Parkring 29 – 33, 85748 Garching
LEDVANCE ST8 Connected sensor
at a glance
3
Can connect up to 200 devices in a network
1 master sensor+ m slave sensors + n LED tubes
examples: 1 master sensor , m=20 slave sensors, n=179 tubes
or
1 master sensor, m=30 slave sensors, n=169 tubes
! only 1 master sensor is allowed in a network.
Two different sensors available
Low bay sensor (LB) : up to 4.0m
High bay sensor (HB): 4.0- 14.0m
Remote control
easy installation, flexible adjustment of product.
•Important
In case of several networks in the same placeplease wait for 3min to start next network installation :
not to interfere signal between different networks.
Connected system needs up to 5min to reactivate all the network
after power off and on. Please wait and do not touch sensor or remote control during this period.
SubstiTUBE ® Connected System UI extend version

LEDVANCE GmbH, Parkring 29 – 33, 85748 Garching
Creating a network
4
One network in one area
Master sensor
Slave sensor
LED tube
What is a network
the network is a group of tubes and sensors that form a connected system. It is controlled by
one master sensor
All the tubes in a network will react in the same way.
If you want to have different behaviors of the tubes in one area you have to create different
networks.
• In one network, tubes are behaving the same.
• If one of the sensor in the network is detecting the
motion and ambient light is below threshold all the tubes
react
• If you want to have muti networks in one area
each network has to be powered on separately
during installation.
• If unpaired tubes and sensors of another intended
network are powered on during the installation of the
first network they may join the wrong network
• Close the pairing of network1 and wait for 3min
before start pairing network 2.
otherwise network 2 may join network1
Multi networks in one area
SubstiTUBE ® Connected System UI extend version

LEDVANCE GmbH, Parkring 29 – 33, 85748 Garching 5
Sensor and tube installation
Creating a newtwork
Functions Actions Results
Open pairing
(assign a master sensor)
Assign a master sensor. First
sensor you open the network
will be assigned as a master
sensor.
Press and hold the operation
button for 4 seconds
• Pairing (network) is open
(LED indicator color will turn from red to green
and starts blinking)
• All other powered-on unpaired slave sensors
will automatically paired to the new network
and remain slave sensors (LED Status red
blinking)
• Tubes blink and dim down to 20% as a sign of
connection
Close pairing
Press and hold the operation
button of master sensor for 4
seconds
• Green LED blinking of master sensor stops
• Lamps dim up to 100% light
• Pairing window is closed
SubstiTUBE ® Connected System UI extend
version
Slave sensors

LEDVANCE GmbH, Parkring 29 – 33, 85748 Garching 6
Functions Actions Results
Test mode on
Press operation button 2
times (short press) on any
sensor
Paired tubes and sensors will start
blinking continuously to identify which
tubes and sensors are paired within the
network
Test mode off Press again operation button
2 times (short press)
Paired tubes and sensors stop blinking,
end of test mode
Test mode ( test paired tubes in a network)
Potentiometer functions
Functions Actions Results
17a : time delay
potentiometer Functional at master sensor only
• The chosen light on: delay time can be varied
continuously from approx. 1min to a maximum
of 10 min. Any movement detected before time
elapses will re-start the timer
18 daylight potentiometer Functional at master and slave
sensor
• desired response threshold of the light can be
infinitely adjusted from approx.2 – 1000 lux.
• Turn control fully anticlockwise to select night-
time operation at about 2 lux (Moon)
• Turn control fully clockwise to the Sun position
means daylight operation at about
• 1000 lux (Sun)
SubstiTUBE ® Connected System UI extend
version

LEDVANCE GmbH, Parkring 29 – 33, 85748 Garching 7
Stand by mode and lamp off mode
Functions Actions
Motion detected The sensor detects motion and tubes go up at the maximum light
100%
Stand by mode
The sensor doesn’t detect movement and after the delay time
elapses (1-10min) tubes dim down to 20% dim level. Tubes always
stay at 20% dim level when motion is not detected.
Lamp off mode
The sensor doesn’t detect movement and after the delay time
elapses (1-10min) tubes dim down to 20% dim level. The system
will start stand by timer and after elapsing (15min) tubes switch off
Reset
Functions Actions Results
Reset 1 Press operation button on
master sensor 10times
All devices will be set to factory settings and the
whole network will be unpaired.
• Feedback of sensors will have permanent red
LED
• After blinking all the tubes in the network will
turn to 100% light level.
• This process will take minimum 30 seconds
Reset 2
Only needed if master
sensor is broken
Press any slave sensor in a
network and press operation
button for 15 seconds
SubstiTUBE ® Connected System UI extend version

LEDVANCE GmbH, Parkring 29 – 33, 85748 Garching
Adding a new lamp into the network
Adding a sensor into the network
Removing a sensor from the network
Wait for 30 seconds and
remove slave sensor
Master sensor Master sensor
Slave sensor installation Master sensor Slave sensor
Green
Green
Master sensor
10X
Slave sensor
Removing a tube from the network
SubstiTUBE ® Connected System UI extend version

LEDVANCE GmbH, Parkring 29 – 33, 85748 Garching
9
FAQ
functions Actions Results
Sensor mounting location
at least 50 cm away from other lights because
heat radiated from these may activate
system.
What is max. allowed
distance between sensor
and tube
15m fee air
Close luminiare, cornerstone,
airconditioner, heater within this
distance may shorten the distance
What is max. allowed
distance between sensor
and tube 15m free air
Close luminiare, cornerstone,
airconditioner, heater within this
distance may shorten the distance
Master sensor is broken
Please go to any slave sensor and press and
hold for 15 seconds.
This destroys the pairing of the
group (delete network) and all
devices go back to factory settings
Stop overruling the
potentiometers by the
remote control
Press operation button of master or slave
sensor 6 times (short)
The read values from the Daylight
and Delay potentiometers are used
again
Power off -> on
Please wait for 5min to reactivate system.
Network will be reconnected automatically.
Please do not touch operation button or
paring button on the remote controller
Connected system needs up to
5min to reactivate all the network
after power off and on. It is very
similar to WIFI router
Compatibility between
Gen1 and Gen2 system
Gen2 tube with Gen1 sensor will still
have same function like Gen1
system. Master and slave functions
are not possible.
How i recognize master
sensor and slave sensor
after installation
If you go to detection zone :
• Master sensor: green LED feedback
• Slave sensor: red LED feedback
