Step 2 Spin & Go Extreme Cruiser 8572 User manual

1
Spin & Go
Extreme CruiserTM
8572
For assistance or replacement
parts please contact :
The Step2 Company, LLC.
10010 Aurora-Hudson Rd.
Streetsboro, OH 44241 USA
1-800-347-8372 USA & Canada Only
[phone]
www.step2.com
Step2 UK LTD
Great Bank Road
Wingates Industrial Estate
BOLTON
BL5 3XU
Uk freephone: 0800 393159
Step2 UK website: www.step2uk.com
Thank you for purchasing the Step2® Spin & Go Extreme Cruiser™.
We’d appreciate a few minutes of your time to complete a brief
survey so we can continue providing you with great products.
To participate, please visit our website at:
www.step2.com/survey/?partnumber=857200
Thank you for your time,
your friends at Step2.
REFER TO THE OWNERS MANUAL FOR WARNINGS,
CHARGING INSTRUCTIONS, OPERATING INSTRUCTIONS, AND
TROUBLESHOOTING.
CONSULTEZ LE MANUEL DU PROPRIÉTAIRE POUR LES MISES
EN GARDE, LES INSTRUCTIONS DE RECHARGEMENT, LES
INSTRUCTIONS DE FONCTIONNEMENT ET LE DÉPANNAGE.
CONSULTE EL MANUAL DEL PROPIETARIO PARA
ADVERTENCIAS, INSTRUCCIONES SOBRE LA CARGA,
INSTRUCCIONES DE USO Y SOLUCIÓN DE PROBLEMAS.
WARNING
Only for family domestic outdoor use by children from ages 4 to 8
years old. Maximum user weight: 81lbs (36.8 kg) per child
MISE EN GARDE
Ce produit est destiné uniquement à un usage familial en extérieur par
des enfants de 4 ans à 8 ans. Poids maximal : 36,8 kg (81 lbs) par enfant.
ADVERTENCIA
Sólo para uso familiar doméstico en exteriores para niños de 4 a 8
años de edad. Peso máximo del usuario: 36,8 kg (81 lbs) por niño
4x 1-1/2” (3,81 cm)
1 2
193731 7/9/15
AB x 3
C x 6
D x 2 x 6
x 20
x 12
x 6
Repeat steps 1-2 to all 6
wheels
Répétez les étapes 1 et 2
pour chacune des 6 roues.
Repita los pasos 1 y 2 en las 6
ruedas

2
3
4
Steps 4 - 8
Étapes 4 à 8
Pasos 4 a 8
Steps 9 - 13
Étapes 9 à 13
Pasos 9 a 13
C
B
x 4

3
5 6
78
A
C
E
x 2
x 2

4
9
C
x 2

5
10
11
12 13
C
x 1
x 1

6
14
15
16 17
D
2x 1-1/2” (3,81 cm)
Ensure the white marks on the wiring harness are lined up and both the arrow and the Step2 logo on each
handle are facing forward before securing the handles with the screws.
Avant de fixer les poignées à l’aide des vis, assurez-vous que les marques blanches sur le faisceau de fils
sont alignées, et que la flèche et le logo Step2 de chacune des poignées font face vers l’avant.
Asegúrese que las marcas blancas en el arnés del cable estén alineadas y que la flecha y el logotipo de
Step2 de ambas agarraderas queden hacia delante antes de fijarlas con los tornillos.
Repeat steps 14 and 15 for the other handle, ensuring both the arrow
and the Step2 logo on each handle are facing forward.
Répétez les étapes 14 et 15 pour l’autre poignée, en vous assurant
que la flèche et le logo Step2 font face vers l’avant.
Repita los pasos 14 y 15 en la otra agarradera. Asegúrese que la flecha
y el logotipo de Step2 de cada agarradera queden hacia delante.

7
18
19 20
Ensure both batteries are securely seated in the module before
moving on to step 19
Avant de passer à l’étape 19, assurez-vous que les deux batteries
sont posées dans le module de façon sécuritaire.
Asegúrese que ambas baterías estén bien asentadas en el módulo
antes de proseguir con el paso 19

8
B2
B1
C
D
E2
E1
A
F1,2,3 F4,5,6
H1 H2
G
I
K1
K2
J4,5,6 J1,2,3

spin & go
Xtreme Cruiser
Owners Manual
English- page 1
Manuel du propriétaire
Françias- page 11
Manual del propietario
Español- page 21
Years
Ans/Años
4-8
193735 7/13/15

1
Warnings & Cautions . . . . . . . . . . . . . . . . . . 2
Vehicle Care & Maintenance Instructions . . . . . 3
Battery
Installation & Charging . . . . . . . . . . . . . . 4
Care, Storage, & Disposal . . . . . . . . . . . . . 4
Vehicle Operations . . . . . . . . . . . . . . . . . . . 5
Rules For Safe driving . . . . . . . . . . . . . . . 5
Operating the Xtreme Cruiser . . . . . . . . . . 5
Control Stick Motions . . . . . . . . . . . . . . . 6
Troubleshooting . . . . . . . . . . . . . . . . . . . . . 7
Limited Warranty. . . . . . . . . . . . . . . . . . . . .10
Table of Contents
• This vehicle requires adult assembly.
• You must charge vehicle batteries (no more than 24
hours) before you use in the vehicle the first time.
• Read this manual carefully for important safety
information and operating instructions before
using your vehicle.
• Keep this owners manual and sales receipt in a
safe place for future reference. Sales receipt is
required for warranty.
Important Consumer
Information
For service assistance or replacement
parts please contact:
The Step2 Company, LLC.
10010 Aurora-Hudson Rd.
Streetsboro, OH 44241 USA
1-800-347-8372 USA & Canada
[phone]
www.step2.com
Inspect this product before each use. Tightly secure connections and replace damaged
or worn components. Contact The Step2 Company, LLC. for replacement parts.
Thank you for purchasing the Step2® Spin & Go Xtreme Cruiser™. We’d appreciate a few minutes of your
time to complete a brief survey so we can continue providing you with great products.
To participate, please visit our website at:
www.step2.com/survey/?partnumber=842300
Thank you for your time,
your friends at Step2.

2
Only for family domestic outdoor use by children from ages 4 to 8 years
old. Maximum user weight: 81lbs (36.8 kg) per child.
CHOKING HAZARD
SMALL PARTS. SHARP POINTS. ADULT ASSEMBLY REQUIRED.
Do not allow children to handle parts including battery or assist with the
assembly or charging of the product.
TO AVOID SERIOUS INJURY
RISK OF FIRE
OBSERVE THE FOLLOWING STATEMENTS AND
WARNINGS TO REDUCE THE LIKELIHOOD OF
SERIOUS OR FATAL INJURY.
SAVE THIS OWNERS MANUAL FOR FUTURE REFERENCE
WARNING
WARNING
WARNING
WARNING
• To reduce the risk of injury, adult supervision is required. Never use in roadways,
near motor vehicles, on or near steep inclines or steps, swimming pools or other
bodies of water; always wear shoes, and never allow more than 1 rider.
• Use vehicle on grass, asphalt or other similar surfaces on level ground.
• Do not use vehicle on wet soil, mud or snow.
• Do not use vehicle in the dark.
• Do not use in areas unsafe for pedestrians.
• Teach child on proper use of this vehicle.
• Teach child to always sit in the seat.
• Do not tow or tie items to the handles in the front of or rear of vehicle.
• Do not pick vehicle up by the handles with child in seat.
• Do not exceed the maximum weight capacity of 81 lbs. (36.8 kg).
Do not bypass fuse. Replace only with 35A fuse.

3
To minimize risks posed by drill shavings, screws are designed to pierce the plastic and form their own
threads. Use caution not to over-tighten screws or they will not hold parts together appropriately.
ELECTRICAL HAZARD
WARNING
• This unit contains two 6 volt batteries.
• Batteries can fall out and injure a child if the vehicle tips over. Always make sure seat
covering battery compartment is securely fastened.
• Prevent Fire or Explosion:
- Never modify the electrical system.
- Do not short circuit the batteries.
- Use the proper type of battery and charger. Contact Step2 consumer service at
1-800-347-8372 for proper replacement parts.
- The charger is not a toy.
- Never use components from this vehicle on another vehicle.
• Only adults should handle and charge the batteries. Battery is heavy. If dropped, the
battery could result in serious injury. The battery contains lead acid (electrolyte).
• Never allow child to charge battery. Adults must be the only ones to charge battery.
Never charge vehicle in a wet area.
• Never lift or carry a battery by the wires or connectors. This can damage the battery and
possibly cause a fire resulting in serious injury. Lift and carry the battery by the case only.
Read safety instructions on the battery.
• Examine the battery, charger and all connections for excessive wear or damage before
and after each use and when charging the battery.
• Check all connections and tighten as required.
• Check all plastic parts before and after use for
cracks or broken pieces.
• Do not use during rain or snowy conditions.
• Charge the battery at least once a month while
vehicle is not in use.
• Do not spray with a hose or wash the vehicle
with soap and water.
• Wipe down with a damp cloth.
• Store vehicle indoors or cover with a tarp to
protect from wet weather.
• Do not leave vehicle in the sun for long periods
of time. Store in shade or cover with tarp.
• Check the tightness of all screws and fasteners
before each use.
• Check the tightness of the wheels.
• Ensure seat is secured with screws.
Vehicle Care &
Maintenance Instructions

4
• Do not dispose of battery in household trash.
• The battery is a sealed lead-acid battery. It must
be recycled or disposed of in compliance with all
government regulations.
• The incineration, landfilling, or mixing of sealed
lead-acid with household trash is prohibited by
law in most states.
• Best to leave battery in battery compartment
when vehicle is being stored.
• Disconnect the battery when the vehicle is
not going to be used for long period of time.
• Only wipe battery clean with a dry cloth.
• If removed, store battery only on a wood surface.
Do not place on cement. This will result in battery
discharge.
• Store battery where temperatures are between
-10 degrees F (-23 degrees C) and 75 degrees F
(24 degrees C).
Battery Care, Storage &
Disposal Instructions
• Connect batteries and wiring as per assembly
instructions/drawings.
• The batteries have to be charged before using
vehicle.
• Only use Step2 batteries and charger.
• Unplug charger before cleaning.
• Use charger in dry locations only.
• Periodically examine batteries and battery
charger for damage to the wires, cord, housing
or other parts that may result in the risk of fire,
electric shock or injury. If batteries or battery
charger are damaged, do not use.
• Do not make direct contact between battery
terminals, as this can cause an explosion or fire.
• The batteries contain chemicals known to
the state of California to cause cancer and
reproductive harm. Wash hands after handling.
DO NOT CHARGE BATTERIES BEYOND 24 HOURS
Battery Installation &
Charging
Use the indicator light on the charger to determine if
the vehicle is charged
• Indicator light RED - Charging
• Indicator light GREEN - Charged
Charging portIndicator Light

5
Rules for Safe Driving
Teach children safety rules. Before using this vehicle the child should understand the vehicle controls
and safety rules. They must demonstrate the capability to handle the vehicle and operate its controls.
It is the responsibility of the adult to educate the child and supervise the vehicles use. Review all rules
with other children that come over to play. Unsupervised driving by children can lead to serious injury.
Adults must always supervise child when operating this vehicle. Adults should evaluate the area to be
driven in for any obstacle or obstructions that would prevent the child from driving the vehicle safely.
• Always sit on the seat.
• Always wear shoes.
• Only 1 rider.
• Do not allow any child to drive the vehicle in the
street, roadways or near moving vehicles.
• Do not allow any child to drive near bodies of water,
obstructions, or drop offs such as stairs or decks.
• Do not tow or tie items to the handles in the front
of or rear of vehicle.
• Do not allow any child to drive the vehicle in the
dark. Operate the vehicle only in the daytime or
in a well-lit area.
• Do not allow child to drive on sloped or
inclined surface.
• Do not allow child to place anything on or near any
moving parts such as motors, gear boxes, wheels.
• Instruct child to keep hands, feet, loose clothing
and long hair away from the wheels during use.
• Do not operate vehicle when it is on its side or
upside-down.
• Do not operate vehicle near flammable vapors
such as gasoline, paint thinner, acetone, etc.
• Keep all flammable product in tightly sealed
containers and away from the vehicle.
• Do not allow a child to operate the vehicle
without direct adult supervision.
• To help prevent the unauthorized use of the
vehicle, disconnect the motor harness from
the battery when not in use.
• Battery life is dependent on the terrain and usage.
• Use vehicle on generally level ground only.
• Use vehicle on grass, asphalt or other similar
surfaces on level ground.
• Do not use vehicle on wet soil, mud or snow.
• Do not allow child to drive up, across or down a
steep slope:
• The vehicle may tilt and tip over.
• The wheels could lose traction.
• The vehicle may gain unsafe speed and not
be able to stop even if the pedal is released
to stop.
Operating Instructions
Operating the Xtreme Cruiser
• Help your child practice steering to learn how all
movements work.
• Ensure children have an understanding of when to
stop the vehicle:
• Both letting off the foot switch and releasing the
control sticks will cause the vehicle to stop.
• Both motors operate independently from one
another and each control stick controls a motor.
• Hi/Low switch cover is designed to lock the speed
in low when the cover is on.
• Set the Hi/Low switch to a speed appropriate for
the riders skill level.
• To adjust the Hi/Low switch:
• Remove cover by removing the screw highlighted.
• Select desired speed. Hi/Low Switch
This vehicle has two
speeds, high (up) and
low (down).

6
Foot Switch
The foot switch must be
depressed for control
sticks to operate vehicle
Control Stick Motions

7
Troubleshooting Guide
Problem Possible Cause Solution
Charge the battery. A new battery should be
charged before using the vehicle. Recharge the
battery after each use. Never charge the battery
longer than 24 hours.
Check all connectors. Make sure the charger
connector is plugged into the battery, and the
charger is plugged into the wall.
Make sure there is power flow to the wall outlet
charger is plugged into.
If you suspect that there is a problem with your
charger, Contact Step2 consumer service at
1-800-347-8372.
A thermal fuse may ‘trip” and shut down operation of
the vehicle if the vehicle is overloaded or the driving
conditions are too severe. The fuse will automatically
reset itself after approximately 25 seconds allowing
the vehicle to resume normal operation. To prevent
tripping of the fuse, do not overload the vehicle by
exceeding the weight capacity or by towing anything
with the vehicle. Do not drive up hills or run into fixed
objects which can cause the wheels to stop spinning
while the power is still being supplied to the motors.
If the thermal fuse continually trips, contact Step2
consumer service.
Check fuse and replace with 35A fuse.
Check all wires and connections. Make sure the
harness connector is plugged into the battery, and
there are no loose wires around the motor.
If the battery is old or if you have not followed the
battery care instructions, contact Step2 consumer
service.
Contact Step2 consumer service at 1-800-347-8372.
Contact Step2 consumer service at 1-800-347-8372.
Vehicle does not run Undercharged battery
Charger is not working
Blown Fuse
Loose wires or wire
connections
Dead Battery
Electrical switch damage
Motor Damage

8
Problem Possible Cause Solution
Check all wires and connections. Make sure the
harness connector is plugged into the battery, and
there are no loose wires around the motor.
A thermal fuse may ‘trip” and shut down operation of
the vehicle if the vehicle is overloaded or the driving
conditions are too severe. The fuse will automatically
reset itself after approximately 25 seconds allowing
the vehicle to resume normal operation. To prevent
tripping of the fuse, do not overload the vehicle by
exceeding the weight capacity or by towing anything
with the vehicle. Do not drive up hills or run into fixed
objects which can cause the wheels to stop spinning
while the power is still being supplied to the motors.
If the thermal fuse continually trips, contact Step2
consumer service at 1-800-347-8372.
Charge the battery. A new battery should be
charged before using the vehicle. Recharge the
battery after each use. Never charge the battery
longer than 24 hours.
Do not charge the battery longer than 24 hrs. If you
suspect that your battery is damaged as a result of
over changing contact Contact Step2 consumer
service at 1-800-347-8372.
Contact Step2 consumer service at 1-800-347-8372.
A thermal fuse may ‘trip” and shut down operation of
the vehicle if the vehicle is overloaded or the driving
conditions are too severe. The fuse will automatically
reset itself after approximately 25 seconds allowing
the vehicle to resume normal operation. To prevent
tripping of the fuse, do not overload the vehicle by
exceeding the weight capacity or by towing anything
with the vehicle. Do not drive up hills or run into fixed
objects which can cause the wheels to stop spinning
while the power is still being supplied to the motors.
If the thermal fuse continually trips, contact Step2
consumer service at 1-800-347-8372.
Vehicle runs but
suddenly stops
Vehicle does only runs
for a short time
Loose wire or loose
connections
Tripped thermal fuse
Tripped thermal fuse
Undercharged Battery
Overcharged battery
Battery will not accept
charge
Troubleshooting Guide

9
Problem Possible Cause Solution
Charge the battery. A new battery should be
charged before using the vehicle. Recharge the
battery after each use. Never charge the battery
longer than 24 hours.
Charge battery after each use.
Contact Step2 consumer service at 1-800-347-8372.
Make sure you don’t exceed weight capacity of 81lbs.
(36.8 kg) or tow objects.
Use vehicle only on level ground.
Check all wires and connections that they are tight.
Contact Step2 consumer service at 1-800-347-8372.
Vehicle has two speeds, low and high, both
controlled by an adult. Change to high speed.
Make sure vehicle is in the upright position.
Make sure middle wheels, one on each side in the
middle of vehicle are properly assembled and
engaging the motor. To further check, lift vehicle
up and depress pedal, both wheels should spin. If
you are still experiencing problems, contact Step2
consumer service at 1-800-347-8372.
Check all wires and connections that they are tight.
Contact Step2 consumer service at 1-800-347-8372.
Contact Step2 consumer service at 1-800-347-8372.
Vehicle runs slowly Undercharged battery
Charger is not working
Improper usage
Motor or electrical
switch damage
Loose wires or wire
connections
Loose wires or wire
connections
Dead spot on motor
Sometimes vehicle runs
and sometimes vehicle
does not run
Vehicle runs in low
speed, but does not
run in high speed
High speed not engaged
When the foot pedal is
pressed only one wheel
spins
Vehicle at an angle
Troubleshooting Guide
Loud grinding noise
coming from gearbox,
motor
Broken gears

10
Problem Possible Cause Solution
Charger gets warm
during use It is normal for some chargers to get warm
during use and is not
reason for concern.
If your charger does not get warm during use, it does
not mean that it is not working properly. No action
required.
If your battery does not make noise or swell slightly
during charging, it does not mean that it is not
accepting a charge. No action required.
Make sure batteries have the proper fuse installed.
Charge the battery. A new battery should be charged
for at least 18 hours before using the vehicle. After
use, recharge the battery for 14 hours after each use.
Never charge the battery longer than 24 hours.
Battery makes noises
when charging Some batteries make noises and swell slightly
while charging and is not
reason for concern
Vehicle constantly blows
fuse Wrong type of fuse used
Vehicle jumping (like
a start and then stop)
when trying to operate
the unit.
Battery voltage or charge
is low
Warranty Information
Each Spin & Go Xtreme Cruiser (8423) 12-Volt battery operated vehicle is covered by a One (1) Year bumper-to-
bumper Limited Warranty, excluding the battery, motor, and gearboxes, which are covered under the Six (6)
Month Limited Warranty, against product defects in materials and workmanship during normal use.
For the complete limited warranty details and service or replacement parts, please see our website,
www.step2.com or call 1-800-347-8372 (US only).
Troubleshooting Guide
